About This Guide
v
About This Guide
Thank you for choosing the Yealink VC110 full HD video conferencing endpoint. It is an
all-in-one unit that supports 1080P-full HD video conferencing and includes outstanding
features such as good compatibility, easy deployment and intelligent network adaptability.
These make it the best choice for SME.
The Yealink VC110 full-HD video conferencing endpoint is designed to help enterprises
organize video conferences easily and efficiently. Users can expect to enjoy the high-quality
video conferencing experience very cost-effectively.
The guide is intended for administrators who need to configure, customize, manage, and
troubleshoot the video conferencing endpoint properly, rather than for end-users. It provides
details on the functionality and configuration of the Yealink VC110 video conferencing
endpoint.
Many of the features described in this guide involve network and account settings, which could
affect the endpoint’s performance in the network. Therefore, an understanding of IP networking
and a prior knowledge of VoIP telephony concepts are necessary.
See the Yealink Products Regulatory Notices Guide for all regulatory and safety guidance.
Documentations
This guide covers the VC110 video conferencing endpoint. In addition to the administrator
guide, the following related documents are available:
Quick Start Guide, which describes how to assemble the endpoint and configure basic
network features on the endpoint.
User Guide, which describes how to configure and use basic features available on the
endpoints.
Video Conference Room Deployment Solution, which describes the conference room
layout requirements and how to deploy the endpoints.
Network Deployment Solution, which describes how to deploy network for your systems.
You can download the above documentations online:
http://support.yealink.com/documentFront/forwardToDocumentFrontDisplayPage
For support or service, please contact your Yealink reseller or go to Yealink Technical Support
online: http://www.yealink.com/Support.aspx .
Firmware
Common reasons for updating firmware include fixing bugs or adding features to the device.

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
vi
You can download the latest firmware for your product online:
http://support.yealink.com/documentFront/forwardToDocumentFrontDisplayPage
For more information on how to upgrade the endpoint firmware, refer to Upgrading Firmware
on page 271.
In This Guide
This administrator guide includes the following chapters:
Chapter 1, “VC110 Video Conferencing Endpoint Introduction”describes endpoint
components, icons and Indicator LEDs.
Chapter 2, “Getting Started” describes how to install and start up the endpoint and config
uration methods.
Chapter 3, “Configuring Network”describes how to configure network features on the
endpoint.
Chapter 4, “Configuring Call Preferences” describes how to configure call preferences on
the endpoint.
Chapter 5, “Configuring Endpoint Settings” describes how to configure basic, audio and
video features on the endpoint.
Chapter 6, “Endpoint Management” describes how to manage endpoint contacts and call
history.
Chapter 7, “Configuring Security Features” describes how to configure security features on
the endpoint.
Chapter 8, “Endpoint Maintenance” describes how to upgrade endpoint firmware and reset
the endpoint.
Chapter 9, “Troubleshooting” describes how to troubleshoot the endpoint and provides
some common troubleshooting solutions.
Typographic Conventions
Yealink documentations contain a few typographic conventions.
You need to know the following basic typographic conventions to distinguish types of in-text
information:
Convention
Description
Bold
Highlights the web/phone user interface items such as menus, menu
selections, soft keys, or directory names when they are involved in a
procedure or user action (e.g., Click on Setting ->General).
Also used to emphasize text

About This Guide
vii
Convention
Description
Blue Text
Used for cross references to other sections within this documentation
(e.g., refer to Troubleshooting).
Blue Text in
Italics
Used for hyperlinks to Yealink resources outside of this documentation
such as the Yealink documentations (e.g.,
For more information, refer to VC110 Video Conferencing Endpoint User
Guide .
You also need to know the following writing conventions to distinguish conditional information:
Convention
Description
->
Indicates that you need to select an item from a menu. For example,
Settings->Basic Settings indicates that you need to select Basic
Settings from the Settings menu.
Terms
As you read this guide, you’ll notice that the same terms are used repeatedly. Make sure you
familiarize yourself with these terms.
Cloud platform: This term refers to Yealink VC Cloud Management Service (Yealink Cloud),
Yealink Meeting Server, Zoom, BlueJeans, Pexip, Mind and Custom platform.
Cloud account: This term refers to Yealink Cloud, YMS, BlueJeans, Pexip, Mind and Custom
account.
Cloud systems: This term refers to the systems that support Cloud feature, including SIP
VP-T49G IP phone, VC desktop and VC110/VC120/VC400/VC500/VC800 video conferencing
system.
Cloud contacts: This term refers to Yealink Cloud contacts and YMS contacts.
Summary of Changes
This section describes the changes to this guide for each release and guide version.
Changes for Release 23, Guide Version 23.20
The following section is new for this version:
Virtual Remote Control on page 171
Public Mode on page 169
Hiding Menu Logo on page 184

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
viii
Multiple Preset on page 210
Major updates have occurred to the following sections:
Configuring Video Conference Platform on page 107
Appendix B: Trusted Certificates on page 300
Changes for Release 23, Guide Version 23.6
The following section is new for this version:
Registering a YMS Account on page 112
Logging out of the Cloud Platform on page 130
Sharing Content on page 164
Endpoint Integrated with Control Systems on page 244
Major updates have occurred to the following sections:
Intelligent Firewall Traversal on page 99
Default Layout on page 168
Changes for Release 22, Guide Version 22.15
The following section is new for this version:
Logging into the StarLeaf Cloud Platform on page 114
Major updates have occurred to the following sections:
H.323 Tunneling on page 82
Enabling H.460 Support for H.323 Calls on page 142
Methods of Transmitting DTMF Digit on page 145
Dual-Stream Protocol on page 200
Camera Control Protocol on page 215
H.235 on page 264
Changes for Release 22, Guide Version 22.5
The following sections are new for this version:
Virtual Remote Control on page 171
Auto Dialout Mute on page 159
Meeting Blacklist on page 191
USB Configuration on page 222

About This Guide
ix
Major updates have occurred to the following sections:
Icon Instructions on page 33
Configuring Video Conference Platform on page 107
DTMF on page 144
Dual-Stream Protocol on page 200
Camera Control Protocol on page 215
Secure Real-Time Transport Protocol on page 261
Changes for Release 21, Guide Version 21.20
The following sections are new for this version:
Keyboard Input Method on page 192
Configuring Video Conference Platform on page 107
Major updates have occurred to the following sections:
Icon Instructions on page 33
Setup Wizard on page 49
Directory on page 231
Changes for Release 21, Guide Version 21.15
The following section is new for this edition:
IPv6 Support on page 64
Video Codecs on page 152
Hiding Icons in a Call on page 185
Output Resolution on page 221
Video Recording on page 223
Screenshot on page 225
Major updates have occurred to the following sections:
Icon Instructions on page 33
Setup Wizard on page 49
Configuring LAN Properties on page 56
Call Protocol on page 153
Dual-Stream Protocol on page 200
Far-end Camera Control on page 214
Search Source List in Dialing on page 242

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
x
Changes for Release 10, Guide Version 10.11
Major updates have occurred to the following sections:
Codecs on page 150
Configuring Camera Settings on page 206
Camera Control Protocol on page 215

Table of Contents
xi
Table of Contents
About This Guide ........................................................................... v
Documentations ......................................................................................................................................................................... v
Firmware ........................................................................................................................................................................................ v
In This Guide ............................................................................................................................................................................... vi
Typographic Conventions......................................................................................................................................................vi
Terms.............................................................................................................................................................................................vii
Summary of Changes .............................................................................................................................................................vii
Changes for Release 23, Guide Version 23.15....................................................................................................vii
Changes for Release 23, Guide Version 23.6 .....................................................................................................viii
Changes for Release 22, Guide Version 22.15...................................................................................................viii
Changes for Release 22, Guide Version 22.5 .....................................................................................................viii
Changes for Release 21, Guide Version 21.20..................................................................................................... ix
Changes for Release 21, Guide Version 21.15..................................................................................................... ix
Changes for Release 10, Guide Version 10.11...................................................................................................... x
Table of Contents..........................................................................xi
VC110 Video Conferencing Endpoint Introduction ....................1
VoIP Principles.............................................................................................................................................................................1
Physical Features of Endpoint...............................................................................................................................................2
Packaging Contents ..................................................................................................................................................................3
VC110 All-in-one Package ............................................................................................................................................4
VCM60 Package ................................................................................................................................................................5
VCP40 Package..................................................................................................................................................................6
VCP41 Package..................................................................................................................................................................7
VCM30 Package ................................................................................................................................................................8
Endpoint Component Instructions .....................................................................................................................................8
VC110 All-in-one Unit.....................................................................................................................................................9
Cable Hub ......................................................................................................................................................................... 12
VCM60 Video Conferencing Wireless Microphone......................................................................................... 12
Video Conferencing Phone........................................................................................................................................ 22
CPE80 Expansion Microphone ................................................................................................................................. 27
VCM30 Video Conferencing Microphone Array............................................................................................... 28
VCR10 Remote Control ............................................................................................................................................... 31
Icon Instructions ...................................................................................................................................................................... 33
Icons on Display Device .............................................................................................................................................. 33
Icons on Video Conferencing Phone..................................................................................................................... 35
LED Instructions ....................................................................................................................................................................... 36

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
xii
User Interfaces.......................................................................................................................................................................... 38
Web User Interface ....................................................................................................................................................... 38
Remote Control .............................................................................................................................................................. 39
Getting Started.............................................................................41
Endpoint Connection and Installation............................................................................................................................ 41
Connecting the VC110 Video Conferencing Endpoint .................................................................................. 42
Installing the VC110 Video Conferencing Endpoint ....................................................................................... 43
Installing Batteries in the Remote Control.......................................................................................................... 45
Powering the Endpoint On or Off.................................................................................................................................... 46
Endpoint Initialization ........................................................................................................................................................... 48
Endpoint Startup ..................................................................................................................................................................... 48
Setup Wizard............................................................................................................................................................................. 49
Enabling Communication with Other Endpoints ....................................................................................................... 53
Placing a Test Call from the Yealink VC110 endpoint ............................................................................................. 54
Configuring Network...................................................................55
Preparing the Network ......................................................................................................................................................... 55
Configuring LAN Properties ............................................................................................................................................... 56
DHCP................................................................................................................................................................................... 56
Configuring Network Settings Manually ............................................................................................................. 61
IPv6 Support .................................................................................................................................................................... 64
Configuring Network Speed and Duplex Mode ........................................................................................................ 68
VLAN............................................................................................................................................................................................. 70
LLDP..................................................................................................................................................................................... 71
Manual Configuration for VLAN.............................................................................................................................. 74
DHCP VLAN...................................................................................................................................................................... 75
802.1X Authentication........................................................................................................................................................... 77
H.323 Tunneling....................................................................................................................................................................... 82
Configuring the Endpoint for Use with a Firewall or NAT ..................................................................................... 86
Call Setup and Media Ports....................................................................................................................................... 86
Restricting Reserved Ports......................................................................................................................................... 87
Network Address Translation ................................................................................................................................... 89
Intelligent Firewall Traversal ............................................................................................................................................... 99
Quality of Service ..................................................................................................................................................................100
VPN .............................................................................................................................................................................................103
Configuring Call Preferences ....................................................107
Configuring Video Conference Platform.....................................................................................................................107
Logging into the Yealink VC Cloud Management Service Platform ......................................................108
Registering a YMS Account.....................................................................................................................................112
Logging into the StarLeaf Cloud Platform ........................................................................................................114

Table of Contents
xiii
Logging into the Zoom Cloud Platform.............................................................................................................116
Registering a Pexip Account ...................................................................................................................................119
Logging into the BlueJeans Cloud Platform.....................................................................................................122
Logging into the Mind Platform............................................................................................................................124
Registering a Custom Account ..............................................................................................................................127
Logging out of the Cloud Platform......................................................................................................................130
Configuring the Third-party Virtual Meeting Room .....................................................................................130
Configuring SIP Settings ....................................................................................................................................................134
SIP Account ....................................................................................................................................................................134
SIP IP Call.........................................................................................................................................................................136
Configuring H.323 Settings...............................................................................................................................................138
Enabling H.460 Support for H.323 Calls.............................................................................................................142
DTMF..........................................................................................................................................................................................144
Methods of Transmitting DTMF Digit.................................................................................................................145
Codecs .......................................................................................................................................................................................150
Audio Codecs ................................................................................................................................................................150
Video Codecs.................................................................................................................................................................152
Call Protocol............................................................................................................................................................................153
Account Polling......................................................................................................................................................................155
Do Not Disturb.......................................................................................................................................................................157
Auto Answer............................................................................................................................................................................158
Auto Dialout Mute................................................................................................................................................................159
Call Match ................................................................................................................................................................................160
History Record........................................................................................................................................................................161
Bandwidth ................................................................................................................................................................................162
Sharing Content.....................................................................................................................................................................164
Ringback Timeout.................................................................................................................................................................165
Auto Refuse Timeout...........................................................................................................................................................166
SIP IP Call by Proxy...............................................................................................................................................................166
Default Layout ........................................................................................................................................................................168
Public Mode ............................................................................................................................................................................169
Configuring Endpoint Settings .................................................171
General Settings ....................................................................................................................................................................171
Virtual Remote Control .............................................................................................................................................171
Configuring Remote Control ..................................................................................................................................172
Site Name........................................................................................................................................................................173
Backlight of the Video Conferencing Phone....................................................................................................174
Language.........................................................................................................................................................................175
Date & Time...................................................................................................................................................................176
Automatic Sleep Time................................................................................................................................................182
Hiding IP Address ........................................................................................................................................................183
Hiding Menu Logo ......................................................................................................................................................184
Hiding Icons in a Call .................................................................................................................................................185

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
xiv
Relog Offtime................................................................................................................................................................189
Key Tone..........................................................................................................................................................................190
Meeting Blacklist..........................................................................................................................................................191
Keyboard Input Method ...........................................................................................................................................192
Audio Settings........................................................................................................................................................................193
Audio Output Device..................................................................................................................................................193
Audio Input Device .....................................................................................................................................................195
Adjusting MTU of Video Packets....................................................................................................................................198
Dual-Stream Protocol..........................................................................................................................................................200
Mix Sending.............................................................................................................................................................................205
Configuring Camera Settings...........................................................................................................................................206
Multiple Preset..............................................................................................................................................................210
Far-end Camera Control ....................................................................................................................................................214
Camera Control Protocol ...................................................................................................................................................215
Output Resolution ................................................................................................................................................................221
USB Configuration ................................................................................................................................................................222
Video Recording....................................................................................................................................................................223
Screenshot ...............................................................................................................................................................................225
Tones..........................................................................................................................................................................................226
Endpoint Management..............................................................231
Directory ...................................................................................................................................................................................231
LDAP ...........................................................................................................................................................................................235
Call History...............................................................................................................................................................................240
Search Source List in Dialing ............................................................................................................................................242
Dual Display Screen Layouts ............................................................................................................................................243
Two-way Video Calls ..................................................................................................................................................243
Two-way Video Call with Presentation...............................................................................................................244
Endpoint Integrated with Control Systems................................................................................................................244
Using the API with a LAN Connection ................................................................................................................244
Using the API with a Serial Connection..............................................................................................................245
Configuring Security Features ..................................................249
User Mode................................................................................................................................................................................249
Administrator Password .....................................................................................................................................................250
Web Server Type ...................................................................................................................................................................251
Transport Layer Security.....................................................................................................................................................253
Secure Real-Time Transport Protocol...........................................................................................................................261
H.235 ..........................................................................................................................................................................................264
Defending against Attacks ................................................................................................................................................267
Abnormal Call Answering.........................................................................................................................................267
Configuring Safe Mode Call....................................................................................................................................268

Table of Contents
xv
Endpoint Maintenance ..............................................................271
Upgrading Firmware............................................................................................................................................................271
Importing/Exporting Configuration ..............................................................................................................................272
Resetting to Factory.............................................................................................................................................................273
SNMP .........................................................................................................................................................................................274
Troubleshooting.........................................................................279
Troubleshooting Methods ................................................................................................................................................279
Viewing Log Files .........................................................................................................................................................279
Capturing Packets........................................................................................................................................................282
Getting Information from Status Indicators .....................................................................................................285
Analyzing Configuration Files.................................................................................................................................285
Viewing Call Statistics ................................................................................................................................................286
Using Diagnostic Methods ......................................................................................................................................286
Troubleshooting Solutions................................................................................................................................................288
General Issues ...............................................................................................................................................................289
Camera Issues................................................................................................................................................................290
Video & Audio Issues.................................................................................................................................................291
Why does the far-site display black screen when local starts a presentation? .................................293
Endpoint Maintenance ..............................................................................................................................................294
Appendix.....................................................................................297
Appendix A: Time Zones ....................................................................................................................................................297
Appendix B: Trusted Certificates.....................................................................................................................................300
Index ...........................................................................................303

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
xvi

VC110 Video Conferencing Endpoint Introduction
1
VC110 Video Conferencing Endpoint
Introduction
This chapter contains the following information about VC110 video conferencing endpoint:
VoIP Principles
Physical Features of Endpoint
Packaging Contents
Endpoint Component Instructions
Icon Instructions
LED Instructions
User Interfaces
VoIP Principles
VoIP
VoIP (Voice over Internet Protocol) is a technology that uses the Internet Protocol instead of
traditional Public Switch Telephone Network (PSTN) technology for voice communications.
It is a family of technologies, methodologies, communication protocols, and transmission
techniques for the delivery of voice communications and multimedia sessions over IP networks.
The H.323 and Session Initiation Protocol (SIP) are two popular VoIP protocols that are found in
widespread implementation.
H.323
H.323 is a recommendation from the ITU Telecommunication Standardization Sector (ITU-T)
that defines the protocols to provide audio-visual communication sessions on any packet
network. The H.323 standard addresses call signaling and control, multimedia transport and
control, and bandwidth control for point-to-point and multi-point conferences.
It is widely implemented by voice and video conference equipment manufacturers, is used
within various Internet real-time applications, such as GnuGK and NetMeeting, and is widely
deployed by service providers and enterprises for both voice and video services over IP
networks.

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
2
SIP
SIP (Session Initiation Protocol) is the Internet Engineering Task Force’s (IETF’s) standard for
multimedia conferencing over IP. It is an ASCII-based, application-layer control protocol
(defined in RFC 3261) that can be used to establish, maintain, and terminate calls between two
or more endpoints. Like other VoIP protocols, SIP is designed to address the functions of
signaling and session management within a packet telephony network. Signaling allows call
information to be carried across network boundaries. Session management provides the ability
to control the attributes of an end-to-end call.
Physical Features of Endpoint
Video conferencing endpoints are in the overall network topology, which are designed to
interoperate with other compatible equipment, including application servers, media servers,
Internet-working gateways, and other endpoints.
In order to operate endpoints in your network successfully, the endpoints must meet the
following requirements:
A working IP network is established.
VoIP gateway is configured for SIP or H.323, and H.323 gatekeeper is configured for H.323.
You can also deploy Cloud server for Cloud platform.
The latest (or compatible) firmware of endpoint is available.
A call server is active and configured to receive and send SIP/H.323 messages.
VC110 All-in-one Unit User Interface
-2 x HDMI
-1x DVI-I
-1 x Line-in (3.5mm)

VC110 Video Conferencing Endpoint Introduction
3
-1 x Line-out (3.5mm)
-2 x USB2.0 port
-Others: 1 x security lock slot, 1 x reset slot
Cable Hub User Interface
-1x DVI-I
-1x 10/100Mb (RJ-45)
-1x VGA
-1xRJ-45
-Input：AC 100-240V；Output：12V/2A
Full-HD Camera
-1920x1080 video resolution
-Pan range: ±100°
-Tilt range: ±30°
-Beauty shot feature
Video Resolution
-Full-HD 1080P at 30fps (1920x1080), from 1Mbps
-720P (1280x720), from 512Kbps
-W448P (768 x 448), WQVGA (400 x 240)
-4CIF (704×576), CIF (352 x 288)
Packaging Contents
We provide the following packaging contents. You can purchase any combination according to
your needs:
VC110 Package
VC110 Package+VCM60 Package
VC110 Package+VCP40 Package
VC110 Package+VCP41 Package
VC110 Package+VCM30 Package
Note
We recommend that you use the accessories provided or approved by Yealink. The use of
unapproved third-party accessories may result in reduced performance

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
4
VC110 All-in-one Package
VC110 All-in-one Unit
Cable Hub
L-Bracket (for installing the VC110 one-in-one unit)
Mounting Accessories (for installing the VC110 one-in-one unit)
VCR10 Remote Control
AAA Batteries×2
