Yealink VC110 Quick reference guide

Deployment Guide for Your Video Conference Room
Applies to: VC110

Requirements of Video Conference Room
3. Conference Room Illumination
Lighting is an important factor in the conference room, because the natural light shade in the conference room is different through the day. Conference room
should avoid using natural light and prefer to use artificial light. When using artificial light, preferentially choose cold light source, such as "three primary
colours " (R, G, B) which works best, and avoid using the heat source at the same time, such as high intensity of iodine-tungsten lamp.
2. Conference Room Setup
The scenery around the conference room, the color of the table and chairs may also affect the quality of image pickup, so complete white or black should be
These two colors can produce reflections and less brightness for the pickup of people and objects.
The wall around the conference room, table and chairs should use uniform light color, such as beige or grey. The wall of the conference room should not use
complex pattern or hanging complex portrayals, so as to avoid getting fuzzy for the image when the camera is moving or zooming.
To make the video conferencing endpoint achieve a good effect, the rational design of the conference room is very important, suggestions are as follows:
Temperature: 20C
Humidity: 70%
Acoustic panels
Light
1. Conference Room Environment
Keep the indoor temperature and humidity appropriate is the basic elements for making the video conferencing endpoint steady and work reliable. And the
recommended temperature is 15-25 degree centigrade, humidity is 60-80 percent.
The recommended environmental noise in the conference room is within 40 dB (A). The big indoor noise, such as the noise of the air conditioner, can affect
the performance of the audio system, causing people in the other conference room cannot capture the speaker ’s voice..
LCD TV
avoided.
The conference room can accommodate 4 people.
The length of the conference room should be less than 3 meters.
Conference Room Requirements
The area of the conference room should be less than 10 square meters.
Because the VC110 camera lens uses the digital zoom technology, you'd better deploy your conference room as follows:
3m
3m

Recommendations of Camera Installation
Others
Install the LCD TV and video camera relative to the center of the participants. To ensure that the participants are directly facing the camera and LCD TV
during calls.
The camera should be mounted on the wall, about 1.5 meters to 1.8 meters above the ground. Install the LCD TV below the camera.
The camera should not directly face light source, to prevent image spot causing glaring bad experience.
Place the whiteboard in the opposite of camera.
Distance between participants and LCD TV is about 4-6 times the height of screen.
An infrared receiver is located in the camera. Make sure no obstruction is in front of the camera.
The camera should not directly face the door, to prevent the movement of personnel influencing the camera focus.
4. Conference Room Acoustic Requirements
The ceiling in the hall and walls around conference room are suggested to install acoustic panels, and use double deck glass or curtain, in order to heighten
an effect of sound insulation and sound-absorbing.
Recommended height 1.5m-1.8m
The LED TV should be less than 40 inch.
LCD TV LCD TV
The VC110 can be powered from a PoE-compliant switch or hub.
The recommended light intensity is 400 to 500 lux on faces, overall lighting layout is reasonable, ensure the light distribution is uniform on faces (eye, nose,
and jaws shadow), light intensity around LCD TV and video camera should be less than 80 lux, otherwise it will affect the image pickup and viewing. All the
windows should use brunet curtains to prevent from direct sunlight.

Deployment Solutions of Yealink Audio Devices
r=2m
VCM60 supports 360-degree audio pickup at a radius of up
to 2 meters.
The VCM60 video conferencing wireless microphone should
be less than 30 meters distant from the dongle, and isn’t
disturbed by obstacles.
Place the VCM60 on a stable surface and keep it away from
obstacles so that it can effectively pick up sounds.
When using the VCM60, the area of the conference room
should be less than 15 square meters.
VCM60
Video conferencing endpoint supports different audio input devices according to the conference requirements. Such as VCM60 video conferencing wireless microphone,
VCM30 video conferencing microphone array or video conferencing phone. Deployment solutions for different audio input devices are as follows:
r=3m
VCM30
VCM30 supports 360-degree audio pickup at a radius of up
to 3 meters.
Place the VCM30 on a stable surface and keep it away from
obstacles so that it can pick up sounds effectively .
When using the VCM30, the area of the conference room
should be less than 20 square meters.

r=3m
CPE80 expansion microphone is a directional microphone,
which suppo 120-degree audio pickup and should be rts
faced to the speaker.
Video conferencing phone provides two MIC ports.
Please choose any one to connect as required.
When audio pickup range is more than 3 meters, two
CPE80 expansion microphones can be connected to
the MIC ports on the video conferencing phone to pick
up sound effectively.
The scope indicated by the dotted line has the best effect.
If you cannot achieve good effect at your seat, you can
move the microphone to a suitable place.
CPE80 CPE80
120
120
r=3m
L=1.8m L=1.8m
Video Conferencing Phone
Far away from the noise source when installing video
conferencing phone (such as air conditioner or computer
host).
Video conferencing phone should be placed in the center
of all participants, make sure that all participants are within
If you need to connect an expansion microphone, the
arrangement of microphones should make the sound field
to be evenly distributed, then it will avoid echo from
microphone.
Video conferencing phone supports 360-degree audio
pickup at a radius of up to 3 meters.
the scope of pickup.
Video Conferencing Phone
