Wall Mount Quick Installation Guide
for SIP-T4X/T5X IP Phones
(V1.3)
This quick installation guide provides step-by-step instructions for
mounting your IP phone to a wall.
www.yealink.com
The wall mount bracket is required for wall mount installation,
which is not included with your IP phone, contact your reseller to
purchase it separately.
Wall mount is avaliable for the following IP phones:
Packaging Contents
The following items are included in your package. If you find
anything missing, contact your system administrator.
SIP-T41S/T41P IP Phone
SIP-T42S/T42G IP Phone
Quick Installation Guide
Wall Mount Quick Installation Guide
Wall Mount Bracket
100mm 2
Following the drilling template above, you can mount the IP phone
to the wall, as shown below:
You can also download the wall mount drilling template online:
http://www.yealink.com/Support.aspx.
SIP-T40P/T40G IP Phone
SIP-T58V/T58A IP Phone
For a SIP-T40P/T40G IP phone:
For a SIP-T58V/T58A/T56A IP phone:
For a SIP-T42G/T42S/T41P/T41G/T40P/T40G IP phone:
93 .79 mm
Max:4.5mm
(0.177”)
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
Screw position
x 2
94.72mm
SIP-T56A IP Phone
1. Pull the hookswitch tab in the handset cradle.
2. Rotate the hookswitch tab 180 degrees.
3. Reinsert the hookswitch tab.
To adjust the hookswitch tab:
Wall anchors and appliable tools not included in your package are
also required for wall mount installation.
Adjusting the Hookswitch Tab
The IP phone is packaged with the hookswitch tab in desk mount
position. Before mounting the IP phone to a wall, you must set the
hookswitch tab to wall mount position.
Adjust the hookswitch tab as shown below:
T41P
Insert the tabs on the wall mount bracket into the slots on the back
of IP phone. And then slide the wall mount bracket to right.
The hookswitch tab has a lip which allows the handset to stay
on-hook when the IP phone is mounted vertically.
Attaching the Wall Mount Bracket
To attach the wall mount bracket:
www.yealink.com
Mounting the Wall Mount Bracket
Yealink provides the wall mount drilling templates, which locate
and mark the position for mounting the screws (not provided) on
the wall, as shown below:
Wall Mount Quick Installation Guide
83mm 2
For a SIP-T42G/T42S/T41P/T41G IP phone:
Quick Installation Guide
Wall Mount Bracket
For a SIP-T58V/T58A/T56A IP phone:
