3M 6000 User manual

Half and Full Facepiece Respirators
6000 Series, Reusable
Unmatched performance
and comfort.
3M™ Half and Full Facepiece
Respirators 6000 Series, Reusable
offer the user comfort and
convenience coupled with the cost
savings of a reusable respirator.
Features/Benefits
• Used with 3M™Filters and
Cartridges, these respirators are
among the lightest available
• The swept back design of the
cartridges improves balance
and visibility
• Remarkably comfortable,
soft, lightweight facepiece
and easy-to-adjust head straps
• Reusable — just dispose of
the cartridges/filters when
used to capacity
• The half facepiece design is
available with a standard and
drop down head harness
• Can be disassembled, cleaned
and reused
• NIOSH approved for negative
pressure air purifying and
positive pressure dual airline
applications
• Supplied with reclosable
storage bag
• The half and full facepieces are
each available in 3 sizes (small,
medium, large) to comfortably
fit many faces
The 6000 Series respirators
can be used in dual airline mode:
• Available with both back-
mounted and front-mounted
breathing tubes
•
Systems can be used in
combination
with NIOSH
approved 3M™2000 Series
Filters or 6000 Series Cartridges
and P100 Filter/Cartridges
• Cartridge/filter connections
provide negative and positive
pressure capability in one
respirator assembly
• Can be used on both high and
low pressure systems*
• Wearer can disconnect the airline
at the air regulating valve and the
system is changed to a filters/
cartridges air purifying mode —
then back to supplied air system
with a simple reconnection of
the airline
• Small diameter breathing tubes
are simple to work with and easy
to clean and decontaminate
4017
page 1 of 4
3
The 3M™ Half and Full Facepiece Respirators 6000 Series,
Reusable with replaceable cartridges/filters
3
3
3
3
3
These respirators help reduce
exposure to certain airborne
contaminants. Misuse may
result in sickness or death.
Before use, the wearer must
read and understand User
Instructions provided as a part
of product packaging. Time use
limitations may apply. For proper
use, see supervisor, packaging
or call 3M OH&ESD Technical
Service, call 1-800-243-4630.
In Canada, call 1-800-267-4414
or 1-800-265-1840, ext. 6137.
WARNING
!
Issue Date 03/24/03
* Employer must provide a minimum of Grade D breathing air in accordance with OSHA requirements.

3M™Half and Full Facepiece Respirators
6000 Series, Reusable
4017
page 2 of 4
Half Facepieces
6100/07024 Small
6200/07025 Medium
6300/07026 Large
Half Facepieces
Drop Down
6100DD Small
6200DD Medium
6300DD Large
3MTM Filters and Accessories 2000 Series, 7093, 5N11, 5P71
2071
P95
particulate
filter
2076HF
P95 filter with
hydrogen fluoride,
nuisance level
acid gas relief*
2078
P95 filter with
nuisance level
organic vapor and
acid gas relief*
2091/07000
P100
particulate
filter
2096
P100 filter
with nuisance
level acid
gas relief*
2097/07184
P100 filter
with nuisance
level organic
vapor relief*
3
2
0
7
1
3
2
0
7
1
11J6200
NIOSH
P95
3
2
0
9
1
3
2
0
9
1
P100
11J6200
NIOSH
3
PART NO.
DO NOTREMOVE
502
FROMCARTRIDGE
7093
P100
particulate
filter
5N11
N95 filter
(use with the 501
filter retainer)
5P71/07194
P95 filter
(use with the 501
filter retainer)
501
filter retainer
(use with the 5N11
and 5P71 filters)
502
filter adapter
(use with the 2000
Series and 7093 filters)
3
PART NO.
501
3
2
0
9
6
3
2
0
9
6
P100
11J6200
NIOSH
P95
11J6200
NIOSH
3
2
0
7
8
3
2
0
7
8
3
2
0
7
6
H
F
3
2
0
7
6
H
F
P95
HYDROGEN FLUORIDE
00J0000
NIOSH
P100
11J6200
NIOSH
3
2
0
9
7
3
2
0
9
7
*Nuisance levels refer to concentrations below the OSHA PEL.
Full Facepieces
6700 Small
6800 Medium
6900 Large
Full Facepieces DIN
6700DIN Small
6800DIN Medium
6900DIN Large

3M™Half and Full Facepiece Respirators
6000 Series, Reusable
4017
page 3 of 4
Accessories
6878 Spectacle Kit
6885 Face Shield Cover
6886 Tinted Lens Cover
Replacement Parts
7883 Neck Strap Assembly
6889 Exhalation Valve
6892 Center Adapter Assembly
6893 Inhalation Valve
6894 Nose Cup Assembly
6895 Inhalation Gasket
6896 Center Adapter Gasket
6897 Head Harness Assembly
6898 Lens Assembly
6899 Lens Frame Kit
Full Facepiece Replacement Parts and Accessories 6000 Series
Product
Number NIOSH Approval*
6001 Certain organic vapors (a)(b)
6002 Chlorine, hydrogen chloride, and
sulfur dioxide or chlorine dioxide or
hydrogen sulfide (escape only) (a)(b)
6003 Certain organic vapors, chlorine,
hydrogen chloride, and sulfur
dioxide or hydrogen sulfide
(escape only) or hydrogen
fluoride (a)(b)
6004 Ammonia and methylamine (a)(b)
6005 Formaldehyde and certain organic
vapors (a)(b)(c)
6006 Certain organic vapors, chlorine,
hydrogen chloride, chlorine dioxide,
sulfur dioxide, hydrogen sulfide
(escape only) ammonia/methylamine,
formaldehyde or hydrogen fluoride
(a)(b)(c)
6009 Mercury vapor or chlorine gas (a)(b)
*For respiratory protection against the following contaminants up to 10X PEL with half facepiece respirators or 50X PEL
with full facepiece respirators when quantitatively fit tested.
(a) All respirators and respirator/filter assemblies can be used up to the NIOSH approval limits, 10X PEL for half facepiece
respirators or 50X PEL for full facepiece respirators or the maximum use concentration allowable in applicable OSHA
standards, whichever is lower.
(b) For specific usage, limitations and warning information, see respirator and/or filter packaging, or call 3M OH&ESD
Technical Service 1-800-243-4630. In Canada, call 1-800-267-4414.
(c) OSHA regulations require that gas-proof goggles be worn with half facepiece respirators when used against formaldehyde.
(d) As recommended by the California Department of Pesticide Regulation no. 01-099 Methyl Bromide Field Fumigation.
Product
Number NIOSH Approval*
60921 P100/Certain organic vapors (a)(b)
60922 P100/Chlorine, hydrogen chloride,
and sulfur dioxide or chlorine
dioxide or hydrogen sulfide
(escape only) (a)(b)
60923
P100/Certain organic vapors, chlorine,
hydrogen chloride, and sulfur dioxide
or hydrogen sulfide (escape only) or
hydrogen fluoride (a)(b)
60924 P100/Ammonia and methylamine (a)(b)
60925 P100/Formaldehyde and certain
organic vapors (a)(b)(c)
60926 P100/Certain organic vapors,
chlorine, hydrogen chloride,
chlorine dioxide, sulfur dioxide,
hydrogen sulfide (escape only)
ammonia/methylamine, formaldehyde
or hydrogen
fluoride (a)(b)(c)
60928 P100/Organic Vapor/Acid Gas (d)
60929 P100/Mercury vapor or chlorine
gas (a)(b)
Replacement Parts
6281 Respirator Strap Assembly
6889 Exhalation Valve
Half Facepiece Replacement Parts 6000 Series Half Facepiece 6000 Series
Facepieces Facepieces
per bag per case
124
Full Facepiece 6000 Series
Facepieces Facepieces
per box per case
14
6893 Inhalation Valve
6895 Inhalation Gasket

Note: For more information on 3M™ Dual Airline Supplied Air Systems, please call 3M’s Fax On Demand line at
1-800-646-1655 and order document number 4024.
High Low
Accessories and replacement parts Pressure Pressure
Standard Back-Mounted Adapter Kit. Includes SA-2500 Breathing Tube, GVP-127 SA-2000 SA-2000LP
Belt and SA-1009 Air Regulator or SA-1029 Connector (low pressure).
Combination Back-Mounted Adapter Kit. Includes 2600 Breathing Tube, GVP-127 Belt SA-2100 SA-2100LP
and SA-1009 Regulator or SA-1029 Connector (low pressure). Cartridges/Filters not included.
Standard Front-Mounted Adapter Kit. Includes SA-1500 Breathing Tube, GVP-127 Belt, SA-1000 SA-1000LP
and SA-1009 Regulator or SA-1029 Connector (low pressure).
Combination Front-Mounted Adapter Kit. Includes SA-1600 Breathing Tube, GVP-127 Belt, SA-1100 SA-1100LP
and SA-1009 Regulator or SA-1029 Connector (low pressure). Cartridges/Filters not included.
To complete a 3M™Dual Airline Respirator System, select a facepiece, an adapter kit and an air supply hose.
For example: 6800 + SA-2000 + W-9435-100 = complete system.
3M™Half and Full Facepiece Respirators
6000 Series, Reusable
4017
page 4 of 4
3M Occupational Health and Environmental Safety Division
3M Center, Building 235-2W-70
St. Paul, MN 55144-1000
For more Information:
In the U.S., contact:
Technical Assistance
1-800-243-4630
Sales Assistance/Local Distributor
1-800-328-1667
Fax On Demand
1-800-646-1655
Internet
www.3M.com/occsafety
E-mail
occsaf[email protected]
For other 3M products
1-800-3M HELPS
In Canada, contact:
3M Canada Company, OH&ESD
P.O. Box 5757
London, Ontario N6A 4T1
Technical Assistance (Canada only)
1-800-267-4414
Sales Assistance
1-800-265-1840, ext. 6137
Fax On Demand
1-800-646-1655
Internet
www.3M.com/CA/occsafety
3M Canada E-mail
[email protected]
Technical Assistance In Mexico
01-800-712-0646
5270-2255, 5270-2119 (Mexico City only)
Technical Assistance In Brazil
0800-132333
Fax On Demand OUS Locations
1-651-732-6530
3M™Fit Test Respirator
3M developed this product
specifically for quantitative fit
testing. Available in small (6100Q),
medium (6200Q) and large (6300Q).
A probe has been added for fit
testing purposes. Do not use for
respiratory protection.
3
W
A
R
NIN
G
:
Q
U
A
N
TI
T
AT
I
V
E
FI
T
T
E
S
T
RE
S
PI
RA
T
O
R.
3M™Quantitative Fit Test
Adapter 601
For use with all 3M bayonet
attachment facepieces.
3M™Fit Test Kits
• FT-10 Qualitative Fit Test
Apparatus (sweet solution)
• FT-20 Training and Fit Testing
Case (sweet solution)
• FT-30 Qualitative Fit Test
Apparatus (bitter solution)
