Abus Smartvest User manual

1
Smartvest
User manual
You can find important information and FAQs about this and other
products online at:
www.abus.com
Version 1.2 English translation of the original German user manual.
Retain for future reference.

2
English
Introduction
Dear Customer,
Thank you for purchasing this product.
This device complies with the requirements of the applicable EU directives. The declaration of
conformity can be obtained from:
ABUS Security-Center GmbH & Co. KG
Linker Kreuthweg 5
86444 Affing
GERMANY
To ensure this condition is maintained and that safe operation is guaranteed, it is your obligation to
observe this user manual.
Please read the entire user manual carefully before putting the product into operation, and pay attention
to all operating instructions and safety information.
All company names and product descriptions are trademarks of the corresponding owner. All
rights reserved.
If you have any questions, please contact your specialist installation contractor or specialist
dealer.
Disclaimer
This user manual has been produced with the greatest of care. Should you discover any omissions
or inaccuracies, please contact us in writing at the address provided above.
ABUS Security-Center GmbH does not accept any liability for technical and typographical errors, and
reserves the right to make changes to the product and user manuals at any time and without prior
warning.
ABUS Security-Center GmbH is not liable or responsible for direct or indirect damage resulting from
the equipment, performance and use of this product. No guarantee is made for the contents of this
document.

3
English
Explanation of symbols
The triangular high voltage symbol is used to warn of the risk of injury or health
hazards (e.g. caused by electric shock).
The triangular warning symbol indicates important notes in this user manual which
must be observed.
This symbol indicates special tips and notes on the operation of the device.
Lists
1. …
2. …
Lists with a set order, given either in the text or warning notice
…
…
Lists without a set order, given either in the text or warning notice
Intended use
Only use the device for the purpose for which it was built and designed. Any other use is considered
unintended!
This device may only be used for the following purpose(s):
The Smartvest wireless alarm system enables easy access to modern homes with its
combination of reliable all-round security and attractive home-automation functions. Up to 32
wireless components and four IP cameras can be connected to the Smartvest alarm panel via
the free app, enabling you to access the alarm panel from anywhere in the world. If an alarm is
triggered, the alarm panel activates its built-in, high-volume 90 dB siren; it can also raise the
alarm simultaneously via push notifications in the app and email.
Important safety information
General
Before using this device for the first time, please read the following instructions carefully and observe
all warning information, even if you are familiar with the use of electronic devices.
All guarantee claims are invalid in the event of damage caused by non-compliance
with this user manual. We cannot be held liable for resulting damage.
We cannot be held liable for material or personal damage caused by improper
operation or non-compliance with the safety information. All guarantee claims are
void in such cases.
Retain this handbook for future reference.
If you sell or pass on the device to third parties, you must include these instructions with the device.
The following safety information and hazard notes are not only intended to protect your health, but also
to protect the device from damage. Please read the following points carefully:

4
English
Power supply
Only operate this device using a power source which supplies the grid voltage specified on the
type plate. If you are unsure which power supply is available, contact your utility company.
Disconnect the device from the power supply before carrying out maintenance or installation work.
To fully disconnect the device completely from the mains, the mains plug must be withdrawn from
the mains socket.
In order to eliminate the risk of fire, the device's mains plug should always be disconnected from
the mains socket, if the device is not being used for an extended period of time.
Overload/overvoltage
Prior to unstable weather and/or when there is a risk of lightning strike, disconnect the device from
the mains network or connect the device to a UPS.
Avoid overloading electrical sockets, extension cables and adapters, as this can result in fire or
electric shock.
Cable
Always grasp all cables by the plug connector and do not pull the cable itself.
Never grasp the power cable with wet hands, as this can cause a short circuit or electric shock.
Do not place the device itself, items of furniture or other heavy objects on the cable and ensure
that it does not become kinked, especially at the connector plug and at the connection sockets.
Never tie a knot in the cable and do not bundle it together with other cables.
All cables should be laid so that they cannot be trodden on, or cause a hazard.
Damaged power cables can cause fire or electric shock. Check the power cable from time to time.
Do not modify or manipulate the power cable or plug.
Only use adapter plugs or extension cables that conform to applicable safety standards, and do
not interfere with the mains or power cables.
Children
Do not allow electrical devices to be handled by children. Do not allow children to use electrical
devices unsupervised. Children may not properly identify possible hazards. Small parts may be
fatal if swallowed.
Keep packaging film away from children. Risk of suffocation.
This device is not intended for children. If used incorrectly, parts under spring tension may fly out
and cause injury to children (e.g to eyes).

5
English
Installation location/operating environment
Place or mount the device on a steady, level surface and do not place any heavy objects on the device.
Make sure that there is adequate ventilation (do not place the Smartvest on a shelf, thick carpet, bed
or wherever the ventilation slits may be covered. Always leave a gap of at least 10 cm on all sides).
The Smartvest is not designed for operation in rooms prone to high temperatures or humidity (e.g.
bathrooms) or excessive dust accumulation.
For all components only suitable for indoor use, please ensure that
no direct heat sources (e.g. radiators) have an effect on the components
the components are not exposed to direct sunlight or strong artificial light
no naked flames (e.g. lit candles) are placed on or next to the components
contact with sprayed or dripping water is avoided
the components are not operated in the vicinity of water and, in particular, never submerged (do
not place objects containing fluids, e.g. vases or drinks on or near the device)
the components are not exposed to large temperature fluctuations, as otherwise there may be
condensation from humidity which may lead to electrical short circuits
For all components that are suitable for indoor and outdoor use, please ensure that
the components are not exposed to excessive shock or vibration
the components are not placed in the immediate vicinity of magnetic fields (e.g. loudspeakers)
contact with aggressive liquids is avoided
no foreign objects are able to penetrate the components
the operating temperature and operating humidity of the components are observed.
Please refer to the relevant quick guide, technical information and installation instructions in chapter 3
for information on proper installation and compliance with the operating environment for components.
Battery
All Smartvest components, with the exception of power switches, are or can be supplied with a battery.
In order to guarantee a long lifespan and avoid fire and injury, please follow the instructions below:
Do not dispose of the battery with household waste.
The battery must not be directly exposed to heat or sunlight, and must not be stored in hot places.
The battery must not be burned.
The battery must not come into contact with water.
The battery must not be dismantled, pierced or otherwise damaged.
The battery contacts must not be short-circuited.
The battery must be kept away from small children.
The battery cannot be recharged.

6
English
Unpacking the device
Handle the device with extreme care when unpacking it.
Packaging and packaging aids can be reused and, as far as possible, should be sent for recycling.
We recommend the following:
Paper, cardboard and corrugated cardboard as well as plastic packaging items should be placed in the
appropriate containers provided.
If no such facility exists in the area, these materials should be put into the general household waste.
Warning
If the original packaging has been damaged, start by inspecting the device. If the device
shows signs of damage, return it in the original packaging and inform the delivery service.
Start-up
Observe all safety and operating instructions before operating the device for the first time.
Warning
Improper or unprofessional work on the power supply system or domestic installations
puts both you and others at risk.
Connect the installations so that the mains power circuit and low-voltage circuit always run
separately from each other. They should not be connected at any point or become
connected as a result of a malfunction.
Care and maintenance
Maintenance is necessary if the device has been damaged (e.g. damage to the power cable and plug,
or the housing), or if liquids or foreign bodies have got into the interior of the device, or if it has been
exposed to rain or damp, or if it does not work properly or has been dropped.
Maintenance
If smoke, unusual noises or smells develop, switch the device off immediately and unplug from
the socket. In such cases, the device should not be used until it has been inspected by a qualified
technician.
Have all maintenance tasks carried out by qualified technicians only.
Never open the housing on the device or accessories. If the housing is open, there is the risk of
fatal electric shock.
Cleaning
Only clean the device housing with a damp cloth.
Do not use solvents, white spirit, thinners etc. or any of the following substances:
Brine, insect spray, solvents containing chlorine or acids (ammonium chloride), or scouring
powder.
Rub the surface gently with the cotton cloth until it is completely dry.
The device operates with a dangerous voltage level. When conducting maintenance
work (e.g. cleaning), disconnect the device from the mains.
Contents
1. Device description ........................................................................................................................... 8
FUAA35000 Smartvest............................................................................................................ 8
FUHA35000 power switch..................................................................................................... 11

7
English
FUMK35000 magnetic contact .............................................................................................. 12
FUBW35000 PIR Motion Detector......................................................................................... 13
FURM35000 smoke alarm/heat detector .............................................................................. 13
FUSG35000 siren.................................................................................................................. 14
FUBE35000 Remote Key...................................................................................................... 15
2. Start-up.......................................................................................................................................... 16
Installing the Smartvest App.................................................................................................. 16
Setting up the Smartvest ....................................................................................................... 16
Pairing components............................................................................................................... 19
General settings..................................................................................................................... 21
3. Installation...................................................................................................................................... 23
FUAA35000 Smartvest.......................................................................................................... 23
FUHA35000 power switch..................................................................................................... 24
FUMK35000 magnetic contact .............................................................................................. 24
FUBW35000 PIR Motion Detector......................................................................................... 26
FURM35000 smoke alarm/heat detector .............................................................................. 27
FUSG35000 siren.................................................................................................................. 28
FUBE35000 Remote Key...................................................................................................... 29
4. Operation....................................................................................................................................... 30
Navigation bar and footer ...................................................................................................... 31
Overview................................................................................................................................ 32
Hotkeys.................................................................................................................................. 34
Rooms ................................................................................................................................... 35
Cameras................................................................................................................................ 37
Contacts................................................................................................................................. 39
Basic event............................................................................................................................ 40
Alarm view............................................................................................................................. 41
5. Configuration ................................................................................................................................. 42
Configuration overview.......................................................................................................... 43
Components .......................................................................................................................... 44
Hotkeys.................................................................................................................................. 52
Scenarios............................................................................................................................... 53
Schedules.............................................................................................................................. 54
Advanced settings ................................................................................................................. 55
6. Technical data ............................................................................................................................... 60

8
English
1. Device description
This chapter contains descriptions of the Smartvest and all associated components.
FUAA35000 Smartvest
Front

Power LED
Green
On
System is supplied with power
Off
No power supply

Status LED
Off
System is "disarmed"
Yellow
On
The system is "disarmed" and there is a fault
(e.g. battery dead or magnetic contact is "open")
Blue
On
System is "armed"
Red
On
System is "armed" and in the alarm state
(normal alarm, tamper alarm or panic alarm)

Network LED
Green
On
Connection to network and internet
Off
Connection to network without internet
Red
Flashing
No network connection

Optional stand. Removable for wall installation.





9
English
Under side

Reset button
To reset passwords to the default settings (123456) and network settings
to DHCP:
While the system is in operation, press and hold the reset button for
>10 seconds using a paper clip. The power LED will go out and a
continuous tone will sound. The system then restarts.
Resetting the system to the default settings means that all settings are reset
and component pairings are deleted.
Press the reset button with the alarm control panel turned off, and
hold it for >10 seconds while turning on the alarm control panel. The
power LED will go out and a continuous tone will sound. The system
then restarts.

RJ45 connector
Integrated network access 10/100 Mbit

Voltage supply
5 V DC/1.5 A. Device starts automatically when powered by line voltage.

Hygrometer
Integrated hygrometer for measuring temperature and humidity





10
English
Rear

Battery
operation
6 x AA (1.5 V) batteries for backup power supply (approx. 5h battery life)
Changing the battery
Push the clips to open the battery compartment cover.
Remove the dead 6 AA (1.5 V) batteries from the compartment and replace
with the new 6 AA (1.5 V) batteries. Make sure they are facing in the direction
shown on the compartment floor, then close the battery compartment by
replacing the cover.

Mounting
bracket
Mounting bracket for wall installation
Drill hole spacing: 10 cm (drilling template provided)

Loudspeaker
Smartvest loudspeaker with a maximum volume of 90db.

Background
LEDs
Off
Off
System is "disarmed"
Yellow
On
The system is "disarmed" and there is a fault
(e.g. battery dead or magnetic contact is "open")
Blue
On
System is "armed"
Red
On
System is "armed" and in the alarm state
(e.g. magnetic contact open).

Cabling
Cabling for power supply and network cable.





