Abus SHSG10000 Manual

1
SHSG10000
ABUS Z-Wave Siren
Important information and FAQs about this product and other
products can be found on the website
www.abus.com
Version 1.0 Original operating instructions in English.
Keep for future use!

2
English
Summary
1. Introduction....................................................................................................................................... 3
1.1. Declaration of Conformity........................................................................................................ 3
1.2. Disclaimer of Liability............................................................................................................... 3
2. Important Safety Informations.......................................................................................................... 4
2.1. Intended Use ........................................................................................................................... 4
2.2. Unboxing.................................................................................................................................. 4
2.3. Installation location / operating environment........................................................................... 4
2.4. Children ................................................................................................................................... 4
2.5. Information on handling batteries ............................................................................................ 4
2.6. Important information on battery disposal ............................................................................... 5
2.7. Cleaning................................................................................................................................... 5
2.8. Information on device disposal................................................................................................ 5
2.9 Power Supply........................................................................................................................... 6
3. Product introduction ......................................................................................................................... 6
3.1. Scope of delivery..................................................................................................................... 6
3.2. Device features........................................................................................................................ 6
3.3 Operating Principle.................................................................................................................. 7
3.4 Performance features.............................................................................................................. 7
4. Overview of functions....................................................................................................................... 7
4.1. Inclusion / Add Device............................................................................................................. 7
4.2. Exclusion / Remove Device..................................................................................................... 8
4.3. Reset (Factory-Reset) ............................................................................................................. 9
4.4 Important Note......................................................................................................................... 9
5. Advanced Z-Wave Parameters...................................................................................................... 10
5.1. Association Group Information .............................................................................................. 10
5.2. Supported Command Classes............................................................................................... 10
6. Technical Specifications................................................................................................................. 11

3
English
1. Introduction
Dear customer,
We are pleased that you have chosen our product and thank you for your trust! You
made a good choice.
This siren (hereinafter referred to as the "device") has been developed and
manufactured with the utmost care. Please read these operating instructions
completely and observe all operating and safety instructions, as this ensures the best
possible handling of the device. This document is an installation and maintenance
manual.
All contained company names and product designations are trademarks of the
respective owners. All rights reserved.
If you have any questions, please contact your specialist installer or specialist trade
partner!
1.1. Declaration of Conformity
ABUS Security-Center hereby declares that the enclosed product comply with
the requirements of the following directives
RED Directive (2014/53/EU), EMC Directive (2014/30/EU), Low Voltage Directive
(2014/35/EU) and RoHS Directive (2011/65/EU). The full EU Declaration of
Conformity text can be found at:
www.abus.com/product/SHSG10000
It can also be obtained at the following adress:
ABUS Security-Center GmbH & Co. KG,
Linker Kreuthweg 5, 86444 Affing, GERMANY
1.2. Disclaimer of Liability
These operating instructions have been prepared with the greatest care. Should you
nevertheless notice omissions or inaccuracies, please inform us in writing at the above
address.
Your rights are limited to the repair or replacement of this product as delivered. ABUS
Security Center assumes no liability for any special, incidental or consequential
damages, including but not limited to loss of revenue, loss of profit, restrictions in the
use of the software, loss or recovery of data, costs for replacement equipment,
downtime, property damage and claims of third parties, as a result of and in connection
with the use of the software.a. warranty, contractual, legal or claims for damages
notwithstanding other limited or implied warranty provisions or in the event that the
limited warranty does not apply, the scopeof liabilityof ABUS SecurityCenter is limited
to the purchase price of the product.
The contents of this manual are subject to change without notice.© ABUS Security-
Center GmbH & Co. KG, 09/2018

4
English
2. Important Safety Informations
2.1. Intended Use
Only use the device for the purpose for which it was built and designed. Any other use
is considered unintended.
All guarantee claims are invalid in the event of damage caused by non-
compliance with this safety information. We cannot be held liable for resulting
damage.
2.2. Unboxing
Handle the device with extreme care when unpacking it.
Packaging and packaging aids can be reused and, as far as possible, should be sent
for recycling.
If the original packaging has been damaged, inspect the device first. If the
device shows signs of damage, return it in the original packaging and inform
the delivery service.
2.3. Installation location / operating environment
Do not place any heavy objects on the device.The device is only designed for
operation in spaces with appropriate temperatures or humidity (e.g. bathrooms), or
excessive accumulation of dust. Please refer to the individual devices' technical data
for more detailed information. Ensure that: adequate ventilation is always guaranteed;
no direct sources of heat can affect the device; interior devices are not exposed to
direct sunlight or strong artificial light; the device is not in the immediate vicinity of
magnetic fields (e.g. loudspeakers); no naked flames (e.g. lit candles) are placed on
or next to the device; sprayed or dripping water is prevented from coming into contact
with interior devices and caustic fluids are avoided; the device is not operated in the
vicinity of water, in particular, the device should never be submerged (do not place
objects containing fluids, e.g. vases or drinks, on or near the device); no foreign bodies
penetrate the device; the device is not exposed to wide temperature variations, as
otherwise there may be condensation from humidity causing electrical short circuits;
the device is not exposed to excessive shock or vibration.
2.4. Children
Keep electrical devices out of reach of children. Never allow children to use electrical
devices unsupervised. Children may not always properly identify possible hazards.
Small parts may be fatal if swallowed. Keep packaging film away from children. There
is a risk of suffocation. This device is not intended for children. If usedincorrectly, parts
under spring tension may fly out and cause injury to children (e.g. to eyes).
2.5. Information on handling batteries
- Make sure that batteries are kept away from small children. Children may put
batteries in their mouths and swallow them. This can cause serious harm to their
health. If this happens, consult a doctor immediately.
- Do not charge normal batteries, heat them up or throw them into naked flames
(they may explode).

5
English
- The battery must not be directly exposed to heat or sunlight, and must not be
stored in a place with a very high temperature.
- The battery must not come into contact with water.
- The battery must not be dismantled, pierced or otherwise damaged.
- The battery contacts must not be short-circuited.
- Change low batteries in good time.
- Always change all the batteries at the same time and use batteries of the same
type.
- Leaky or damaged batteries can cause chemical burns on contact with the skin.
In this case, wear protective gloves. Clean the battery compartment with a dry
cloth.
2.6. Important information on battery disposal
Batteries with this label do not contain harmful substances such as
cadmium, lead and mercury. However, used batteries must not be
disposed of along with household waste in accordance with the battery
directive. To protect natural resources and promote the recycling of
materials, separate the batteries from other waste and deposit them at a
local recycling center. An additional label with the chemical symbols for
Hg, Cd or Pb means that the batteries contain quantities of mercury, cadmium or lead
which exceed the restrictions set by the EU Directive 2006/66/EG. If batteries are not
disposed of properly, these substances can cause harm to human health or the
environment
2.7. Cleaning
- Dusty devices must be cleaned. You can clean dust from the air vents using a
vacuum cleaner or compressed air. If necessary, you can remove the dust with
a brush.
- You can clean the surface using a cloth slightly dampened in soapy water. Only
use suitable microfiber cloths for high-gloss surfaces.
- Do not allow water to penetrate the device.
- Do not clean the device in a dishwasher.
- Do not use sharp, pointed, abrasive or corrosive cleaning materials or hard
brushes.
- Do not use chemicals.
- Do not use flammable liquids for cleaning the device.
2.8. Information on device disposal
Important: The EU Directive 2012/19/EU regulates the proper return,
treatment and recycling of used electronic devices. This symbol means
that in the interest of environmental protection the device must be
disposed of separately from household or industrial waste at the end of
its service life in accordance with applicable local legal guidelines.
Disposing of used devices can be done at official recycling centers in your
country. Obey local regulations when disposing of material. Further details on returns
(also for non-European countries) can be obtained at your local authority. Separate

6
English
collection and recycling saves natural resources and ensures that all the provisions
for protecting health and environment are observed when recycling the product.
2.9 Power Supply
Only operate this device through a power source which supplies the mains power
specified on the type plate. If you are unsure which voltage is supplied at the
installation location, contact your energy provider. Disconnect the device from the
power supply before carrying out maintenance or installation work. The device is only
fully disconnected from the mains network when the device is removed. In order to
eliminate the risk of fire, the device's mains plug should always be disconnected from
the mains socket, if the device is not being used for an extended period of time. Prior
to unstable weather and/or when there is a risk of lightning strike, disconnect the
device from the mains network or connect the device to a UPS. Avoid overloading
electrical sockets, extension cables and adapters, as this can result in fire or electric
shock.
3. Product introduction
3.1. Scope of delivery
- ABUS Z-Wave Siren
- Quickguide & Safety instructions
3.2. Device features
2
4
1
3

7
English
Nr
Label
Comment
1
Networking-Button
For inclusion / exclusion of the siren in a Z-Wave Gateway,
factory reset
2
Loudspeaker
In case of an alarm, a 95dB loud signal tone sounds here
3
Power Plug
For connection in the socket
4
Flashing Light
In case of alarm the ring lights up red
3.3 Operating Principle
The SHSG10000 was developed for use in home automation systems that use the Z-
Wave wireless standard. The siren serves as an alarm device and is equipped with a
loud siren (up to 95 dB) and a red LED flash. Thanks to the integrated backup battery,
the siren can still alert for up to 5 minutes or operate in standby mode for approx. 4
hours, even when removed from the power supply.
3.4 Performance features
The ABUS Z-Wave SHSG10000...:
- …is an radio siren with integrated backup battery
- …is Z-Wave PLUS compatible & certified
- …supports the Z-Wave S2 Standard (Security 2)
- …alarms loudly by the integrated 95dB siren
- …has a red LED flash which lights up in case of alarm
- …was developed for indoor use
3.5 Use in systems of different manufacturers
Communication is via the Z-Wave EU frequency (868.42 Mhz). You can integrate the
device into any Z-Wave network with a certified Z-Wave gateway, regardless of
manufacturer. All non-battery powered nodes in the network act as repeater to increase
the durability of the network.
4. Overview of functions
4.1. Inclusion / Add Device
A
Plug the device into a socket

8
English
B
Click the + (Add) button in your Z-Wave App
and follow the further instructions
C
Press the Network-button 3 times within 1.5
seconds and the Status-LED will flash 3 times
If the Add device process is successful, the
Status-LED will turn off.
Repeat the inclusion process from step B if it
was not successful.
4.2. Exclusion / Remove Device
A
Click the - (Remove) button in your Z-Wave
App and follow the further instructions

9
English
B
Press the Network-button 3 times within 1.5
seconds and the Status-LED will flash 3 times
If the Remove device process is successful,
the Status-LED flash 6 times.
Repeat the inclusion process from step B if it
was not successful.
4.3. Reset (Factory-Reset)
Press the Network-button for 10 seconds to
factory reset the device
Note:
1, This procedure should only be used if the
primary gateway is not capable of acting.
2, If the multi-sensor is set to the factory
setting, the status is set to "not included", the
association settings and possible
configurations are reset to default.
4.4 Important Note
Once the device is added to a Z-Wave gateway, the alarm can be released and
terminated In Event of an Alarm the high-volume siren (95dB) will sound and LED
strobe lights up.
In Event of main power loss, the Siren can even operate up to 5 minutes in Alarm-
case by the integrated backup-battery. (or 4 hours standby operation)

10
English
5. Advanced Z-Wave Parameters
5.1. Association Group Information
Z-Wave devices can control other devices directly. This direct control is called in Z-
Wave association. For this purpose, the device ID of the device to be controlled must
be stored in the controlling devices. This is done in so-called association groups. An
association group is always linked to an event in the controlling device (pressing a key
or triggering a sensor). When this event occurs, a control command - usually a BASIC
SET - is sent to all devices stored in an association group.
The siren supports the following association group:
Group
Number
Maximum
Devices
Transmitted Content
Group 1
0x05
Association group 1: Lifeline association group Include
command classes: Switch Binary report ,Battery and Device
Reset Locally notification.
5.2. Supported Command Classes
1 Z-Wave plus InfoVersion 2
2 Switch Binary Version 1
3 Association Version 2
4 Association Group Info Version 1
5 Transport Service Version 2
6 Version Version 3
7 Manufacturer Specific Version 2
8 Device Reset Locally Version 1
9 Powerlevel Version 1
10 Security 2 Version 1
11 Supervision Version 1
12 Basic Version2
