ACS WR3 User manual


© Alcohol Countermeasure Systems Corp.
The information disclosed in this document is the valuable property of Alcohol Countermeasure
Systems Corp. and all copyright and other proprietary rights to this document are reserved. No
reproduction of this document is permitted without the prior written consent of Alcohol
Countermeasure Systems Corp.

Safety and Precautions
WR3 has been designed for easy and safe operation. The alcohol interlock is to be used only for
the purposes specified herein. To help ensure your safety, you must follow these precautions:
• In response to a retest request, carefully stop your vehicle at the side of the road. Complete a
successful breath test before you resume driving.
• Do not open the handset case. Doing so will void the warranty and potentially damage the
components within.
• Avoid exposing the handset to direct sunlight for extended periods of time.
• If liquid spills onto the handset, remove the excess with a cloth and allow the handset to dry
thoroughly. If there is substantial moisture damage, do not turn the handset on. Contact your
local service centre.
• Keep all radio frequency (RF) transmitting devices (such as cell phones) away from WR3 to
minimize interference.
• Do not attempt to tamper with or circumvent WR3. This is considered a program violation.
Maintenance
During field use, WR3 is susceptible to dirt and debris. Clean the handset with a damp cloth and
mild soap. Do not use abrasive cleaners or solvents.
Periodic service appointments are required. Consult your compliance guide for more
information.
Information and Support
For information and support, please contact your local service centre.

v
WR3 User Guide
Table of Contents
Safety and Precautions .............................................................iii
Maintenance ..........................................................................iii
Information and Support ...........................................................iii
Getting Started 1
What is an alcohol interlock? ................................................... 1
How does it work? .................................................................. 1
User Fees ............................................................................... 2
Installation .............................................................................. 2
Maintenance .......................................................................... 2
Handset Cable ........................................................................ 3
To Disconnect ...................................................................... 3
To Connect .......................................................................... 3
More information .................................................................... 4
Alcohol Influence on Testing .................................................. 4
Operating Temperature ......................................................... 4
Battery Voltage .................................................................... 4
Using the Interlock 5
Starting the motor .................................................................... 5
Warm-up and Standby (where applicable) ................................. 7
Restarting the motor ................................................................. 8
Running retests ........................................................................ 9
TABLE OF CONTENTS

vi WR3 User Guide
Menu Options 11
Wake-Up Mode .................................................................... 11
Sleep Mode .......................................................................... 12
Time Mode ........................................................................... 13
Date Mode ........................................................................... 13
Language Mode .................................................................... 14
Volume Mode ....................................................................... 14
Maintenance & Troubleshooting 15
Troubleshooting Table ............................................................ 15
Service Dates ........................................................................ 15
Error Messages ..................................................................... 16
Reset Codes .......................................................................... 18
Emergency Override (where applicable) ............................... 18
Third-Party Maintenance (TPM) ............................................. 18
Other ................................................................................ 18
Disposal of Unit at End of Service Life ...................................... 18
Replacement Parts ................................................................. 19
Index 21
Service Record 23

1
WR3 User Guide
Getting Started
What is an alcohol interlock?
An alcohol interlock is an in-car breath alcohol
screening instrument. It prevents a vehicle from
starting if it detects that a driver’s breath alcohol
concentration (BrAC) is over a preset limit. It is
designed to fit inside the vehicle, near the driver’s
seat, and connects directly to the vehicle’s ignition
system.
The interlock consists of a handset and relay
module. The relay module enables or disables the
ignition of the motor and stores the handset settings.
To help prevent other people from providing the
required breath samples, the interlock requests
additional breath samples at random intervals
during the trip.
How does it work?
WR3 uses the same alcohol sensing technology used by police in
roadside screening. A special alcohol-sensitive cell detects the amount
of alcohol in the breath. Breath alcohol is directly proportional to the
blood alcohol concentration (BAC).
GETTING STARTED

2WR3 User Guide
User Fees
Drivers who are subject to an alcohol interlock program are
responsible for all installation and maintenance costs. Refer to your
compliance guide for a complete list of costs.
Installation
Installation centres are conveniently located, and the interlock is
installed while you wait. You receive full training on site, and
technicians help to ensure that everything operates properly.
The interlock is installed by a qualified installer in accordance with
national regulations. An unqualified installation may invalidate the
type approval of the vehicle.
Maintenance
You must visit the installation centre a short time after installation. You
must also visit at certain intervals for maintenance and data
download. Maintenance appointments typically take less than 20
minutes.
Refer to your compliance guide for the interval dates.

3
WR3 User Guide
Getting Started
Handset Cable
The handset cable connects the handset to the interface module,
which is connected to the vehicle’s ignition. The handset should
remain connected at all times, but for instances in which the handset
needs to be removed, follow these steps:
To Disconnect
1. Make sure that the vehicle motor is off.
The handset cable consists of a connector, a
sleeve and a cord.
2. Release the connector from the interface mod-
ule plug by pulling back on the sleeve. This
disconnects the handset cable.
Warning! Do not pull on the handset cord or turn the connector. This could
damage the cable.
To Connect
1. With the vehicle motor off, locate the green
arrows on the handset cable connector and plug.
Note! If the vehicle’s motor is running, the interface
module plug flashes green and beeps every 15
seconds.
2. Line up the green arrows and gently push the
connector into the interface module plug. A
light click sounds when they properly connect.
3. A Wait message displays. WR3 may require
another breath test. Observe the message on
the display.

4WR3 User Guide
More information
Alcohol Influence on Testing
Drinking alcohol and eating foods containing alcohol will cause a
failed alcohol test.
Some other factors that may affect a test (because they may contain or
produce residual alcohol in the mouth) are medicines, drops,
smoking, using mouthwash or mouth spray.
Rinsing the mouth with water after using mouthwash or mouth spray
will remove the alcohol content in the mouth.
According to the previous information, do not eat, smoke or drink for
at least 10 minutes before taking a test.
Additionally do not spray any air fresheners, disinfectants, cologne or
perfume in the vehicle prior to a test, as these can also contain
alcohol.
Note! The above mentioned list of factors that may affect a test is not
exhaustive. There are additional items that may affect the results of a breath
test. Follow this guide carefully to avoid incorrect results.
Operating Temperature
The maximum ambient operational temperature is between -40°C and
+85°C.
Note! Depending on the ambient temperature, the handset takes a few
seconds to warm up (approximately 15 seconds at 20°C, approximately
1 minute at 0°C).
Battery Voltage
The voltage supplied to the relay module, which in turn powers the
handset, is supplied by the vehicle battery.
For the 12V Interlock system, the vehicle battery voltage can range
from 9V - 18V.

5
WR3 User Guide
Using the Interlock
Starting the motor
1. The interlock turns on automatically
when you plug it in, and Wait dis-
plays as the unit warms up.
If the interlock is plugged in, but has
gone into sleep mode, turn the power on
again by pressing the right button.
Alternatively, you can move the key
between the On and Off positions.
Note: The ignition must be OFF before you can
continue.
2. The handset displays Ready for test
when it has finished warming up.
The warm-up time is longer in cold
temperatures.
Note: Do not store the mouthpiece to be used
in a cold area. This causes condensation in the
mouthpiece and increases the opportunity for
water to enter the handset.
3. Insert a clean mouthpiece. Using a
clean mouthpiece is good hygiene,
and it helps to ensure a usable
breath sample.
Note: Do not eat, drink or smoke for at least 15 minutes before the test. This
could contaminate the breath sample.
USING THE INTERLOCK

6WR3 User Guide
4. Blow moderately and continuously as you simultaneously hum into
the mouthpiece. The handset makes a tone to indicate proper air-
flow and hum. If you are not blowing correctly, a message dis-
plays to give you instructions for correcting it.
5. Stop blowing when the handset clicks and stops the tone. Wait
displays as the breath sample is analyzed.
6. The handset beeps and displays the result:
Start Motor
You have passed the breath test, and no
alcohol has been detected. You can start
the motor.
Note! You must start the motor within five
minutes.
Caution (i.e., BAC limit warning)
You have passed the breath test, but
alcohol below the allowable limit has
been detected. You have two options:
•Wait five minutes and try the test again
if you are certain there is no alcohol in
your system.
•Press the Start button to acknowledge
that you intend to drive with alcohol in
your system. The motor must be started
within five minutes.
Note! You can continue driving, but WR3 will
have warned you about the alcohol detected.

7
WR3 User Guide
Using the Interlock
Lockout
You have failed the breath test. The alcohol level
detected is over the preset limit. You may NOT
start the motor.
Lockout and a countdown timer display. Wait for
the countdown to finish before attempting another
breath test.
WARNING! Do not attempt another breath test until you are sure that your
alcohol level is under the limit. A second failed test may result in a longer
lockout time. Please refer to your compliance guide for actual program
requirements and details specifying program violations.
All breath tests are logged by WR3 and downloaded during routine
service appointments. Any instance of alcohol detected in the breath
samples may be considered as a program violation. Refer to your
compliance guide for specific limit amounts.
Warm-up and Standby (where applicable)
Once you have started your vehicle, Drive Safely displays.
You can place WR3 in Warm-up mode by holding the left button.
Warm-up displays, and your vehicle can remain idle without requiring
another breath test for up to 30 minutes.
To exit this mode, hold the right button. This mode also terminates if
the RPMs of your engine increase.
Note! For commercial vehicles, the corresponding mode is Standby. Standby
displays, but the idle time is not limited to 30 minutes. The idle time for Standby
mode is unlimited.

8WR3 User Guide
Restarting the motor
If the motor is turned off for a short period of time, you can restart it
without another breath test. This safety feature is helpful if the motor
stalls, or if you need to make frequent, short stops. Refer to your
compliance guide for the restarting time limit.
Observe the message on the handset:
Restart Available
You can restart the motor without providing
another breath test.
To cancel the restart, press and hold the right
button.
Blow for 5 seconds
The restart period has expired. You need to
pass a breath test to start the motor.
Refer to the section about starting the motor.

9
WR3 User Guide
Using the Interlock
Running retests
Additional breath tests are required at random times to ensure that the
driver has not consumed alcohol since the motor has been started.
This occurs at random intervals during the trip. Refer to your
compliance guide for more information.
1. The handset beeps and displays Retest.
2. Do not provide a breath test while the
vehicle is in motion. The interlock pro-
vides sufficient time for you to stop in a
safe location.
3. Provide a breath sample and observe the display messages as
they apply:
Drive safely
You have passed the breath test. You can
continue driving.
Beep
Drive safely

10 WR3 User Guide
Pull over, Turn off Motor
The alcohol level is over the preset limit.
Lockout and a countdown timer display until
you attempt another breath test. You cannot
start the motor until a passed breath test is
provided.
WARNING! Do not attempt another breath test until you are sure that your
alcohol level is under the limit. A second failed breath test may result in a longer
lockout time.
In response to a retest request, carefully stop your vehicle at the side of the road.
Complete a successful breath test before you resume driving.
Pull over, Turn
off Motor

11
WR3 User Guide
Menu Options
WR3 has a number of customizable options, such as volume control,
language selection, and wake-up/sleep times. These options are
found in the main menu, which can be accessed by pressing and
holding the left button.
Wake-Up Mode
The handset can “wake up” up to three times per day. This helps to
ensure that the handset is warmed up and ready before you enter the
vehicle.
Note! Before using this option, make sure that the vehicle battery has sufficient
charge. The Wake-Up option is automatically disabled if the handset has not
been used for three consecutive days.
1. Press and hold the left button to access
the main menu. Press the left button to
scroll to Wake-Up. Select with the right
button.
2. Select a time slot by placing the cur-
sor underneath an on/off entry. Set
the wake-up time for that slot. The left
button moves the cursor, and the
right button changes the value.
3. Press and hold the right button to
save your selection and exit this
mode.
MENU OPTIONS

12 WR3 User Guide
Sleep Mode
The handset can be put into sleep mode manually or automatically
when the ignition is off. This conserves the battery.
To put the handset into sleep mode manually, press and hold both
buttons.
1. Press and hold the left button to access
the main menu. Press the left button to
scroll to Sleep. Select with the right
button.
2. The Sleep menu offers four pre-pro-
grammed times: 5, 30, 60 and 90
minutes. Press the left button to scroll
through the times, and press the right
button to make your selection.
3. Press and hold the right button to
save your time selection and exit this
mode.

13
WR3 User Guide
Menu Options
Time Mode
You can adjust the handset time for different time
zones, daylight savings, etc.
This adjustment is primarily for the Wake-Up
feature. It does not change the times in the Service
Date list.
1. Press and hold the left button to access the main menu. Press the
left button to scroll to Time. Select with the right button.
2. The current time displays with the option to increment the time up
or down by 0.5 to 3.0 hours. Press the right button to increase the
time [+] and the left button to decrease it [–].
3. Press and hold the right button to save your time setting and exit
this mode.
Date Mode
To view service dates and other important dates and times, press and
hold the left button to access the main menu. Select the first item,
Service Date, with the right button. The current date and time display.
You can press the left button to scroll through all of the dates in the list:
To exit at any time, press and hold the right button.
Current Date
Service Date
Lockout Date
Calibration Date
Calibration Expiry Date

14 WR3 User Guide
Language Mode
WR3 is available in multiple languages. The
selections are programmed at the factory.
1. Press and hold the left button to access the
main menu. Press the left button to scroll to
Language. Select with the right button.
2. Use the left button to scroll through the
languages. Stop at your selection.
3. Press and hold the right button to save
your selection and exit this mode.
Volume Mode
The handset produces audio tones. You can set their volume from the
main menu.
Note! This applies to the handset only. The volume of the Relay
Module cannot be set.
1. Press and hold the left button to access the
main menu. Press the left button to scroll to
Volume. Select with the right button.
2. Use the left and right buttons to adjust
the volume up and down.
3. Press and hold the right button to save
the setting and exit the menu.

15
WR3 User Guide
Troubleshooting
Troubleshooting Table
The following table lists basic problems that can occur, along with
their solutions. For other problems, contact your service provider.
Service Dates
After WR3 installation, you need to return for a follow-up
appointment. Service appointments are then scheduled at regular
intervals. See your compliance guide for the interval dates.
The service appointments are for verifying interlock accuracy and
downloading the log of breath tests.
If WR3... You should...
Will not turn on Check the vehicle battery
Displays an error code Refer to the table of errors
Displays an early or immediate recall Contact your service provider
Aborts a breath test Retry the test, or investigate the Abort
code
Is in permanent lockout Contact your service provider
Requires service Contact your service provider
MAINTENANCE & TROUBLESHOOTING
Other manuals for WR3
3
Table of contents
Other ACS Test Equipment manuals

ACS
ACS Alcoscan User manual

ACS
ACS Alcolock L OEM User manual

ACS
ACS ALCOLOCK V3 B-2 WI-FI Series Use and care manual

ACS
ACS ALCOCHECK Use and care manual

ACS
ACS ALCOLOCK LR Programming manual

ACS
ACS Alcolock WR2 Installation and operating manual

ACS
ACS Alcoscan User manual

ACS
ACS ALCOLOCK LR User manual

ACS
ACS SAF'IR EVOLUTION User manual

ACS
ACS ALCOHOL INTERLOCK V3 User manual
