Alcatel-Lucent IP Touch 4088 EE User manual

All Rights Reserved © Alcatel-Lucent 2009
Alcatel-Lucent
IP Touch 4088 EE/4018
EE SIP Phone installation
manual
8AL90824AAAAed01
October, 2009

All Rights Reserved © Alcatel-Lucent 2009 Page 2
1. Overview ........................................................................................... 3
2. SIP Stand-Alone Mode ............................................................................ 3
2.1. Initializing a Set in SIP Mode............................................................... 3
2.1.1. SIP Configuration Files ................................................................ 3
2.1.2. SIP Set Binaries......................................................................... 4
2.1.3. Selecting the Downloading Mode.................................................... 5
2.2. Updating SIP Binaries ....................................................................... 5
2.3. Phone Features .............................................................................. 5
2.3.1. Direct Key Management............................................................... 6
2.3.2. Multilines................................................................................ 6
2.3.3. Three-Party Conference .............................................................. 6
2.3.4. Speed Dialing Keys..................................................................... 6
2.3.5. Voice Mail ............................................................................... 7
2.4. SIP Configuration Files Description ....................................................... 7
3. Maintenance ......................................................................................13
3.1. Overview.....................................................................................13
3.2. Error and Information Messages..........................................................13
3.3. Ethernet Link................................................................................15

All Rights Reserved © Alcatel-Lucent 2009 Page 3
1. Overview
Alcatel-Lucent IP Touch 4008 EE/4018 EE sets are IP sets of the Alcatel-Lucent 8 series range.
The Alcatel-Lucent IP Touch 4018 EE Phone set is available as of R6.1.1. The Alcatel-Lucent IP
Touch 4008 EE Phone set is available as of R7.1.
Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition sets are IP sets of the
Alcatel-Lucent IP Touch 8 series phone Extended Edition range. They are available as of
R8.0.1.
Alcatel-Lucent IP Touch 4008 EE/4018 EE and Alcatel-Lucent IP Touch 4008 EE/4018 EE
phone Extended Edition sets present minor differences, expressly indicated where applicable.
When their features and capabilities are identical, only Alcatel-Lucent IP Touch 4008 EE/4018
EE sets are mentioned.
Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition sets provide extended
memory capacity (8 Mbytes FLASH and 16 Mbytes SDRAM).
As of R9.1, Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition sets can boot in SIP
mode (SIP standalone feature). In this case, Alcatel-Lucent IP Touch 4008 EE/4018 EE phone
Extended Edition sets are linked to a proxy acting as a PCX and operate as SIP sets.
The following chapters in this document describe the SIP mode initialization, the SIP Binaries
updating, the phone features, the SIP configuration files description and the maintenance.
2. SIP Stand-Alone Mode
2.1. Initializing a Set in SIP Mode
2.1.1. SIP Configuration Files
In SIP mode, the set downloads configuration files from the server defined in the TFTP server
address in MMI.
The TFTP address is received from DHCP or statically defined from the set.
Configuration files are:
– sipconfig.txt: this file is optional and contains all parameters required for operation. This
file configures all SIP sets of the system with the same parameters.
– sipconfig-MacAddress.txt : this file is mandatory and allows to configure specific
parameters for a set defined with its MAC address. For example, the sipconfig-
00809F5607AE.txt file contains specific parameters for a set with the 00:80:9F:56:07:AE
physical address.
If this file does not exist, only the parameters contained in the sipconfig.txt file are
used.

All Rights Reserved © Alcatel-Lucent 2009 Page 4
The two files have the same list of parameters.
Parameter values from the sipconfig-MacAddress.txt file override parameters of the
sipconfig.txt file. This applies only when the concerned parameter has been assigned a value
in the sipconfig-MacAddress.txt file.
Examples 1:
user name parameter
In the file sipconfig.txt the parameter user name is set to Alcatel-Lucent. As a result, all sets of
the system have the same name: Alcatel-Lucent.
For the set with MAC address 00:80:9F:56:07:AE, the file sipconfig-00809F5607AE.txt exists and
contains the parameter user name = Smith. As a result, this set is called: Smith and not: Alcatel-
Lucent.
Examples 2:
proxy_addr parameter
In the file sipconfig.txt the parameter proxy_addr is set to 192.168.110.80. As a result,
all sets share the same proxy.
For the set with MAC address 00:80:9F:56:07:AE, the file sipconfig-00809F5607AE.txt
contains the parameter proxy_addr. This parameter has no assigned value. As a result, this set
uses the proxy defined in the sipconfig.txt file.
sipconfig.txt and sipconfig-MacAddress.txt files are built with the SIP Device
Management application (SDM).
For more information on the structure of the sip configuration files, see: § SIP Configuration Files
Description.
When the set is registered with success, all parameters are saved in the non volatile memory
(flash memory) of the set. Saved parameters are used in case of TFTP server failure.
2.1.2. SIP Set Binaries
The SIP binary files must be set in the server in the same location as the sipconfig.txt and
sipconfig-MacAddress.txt configuration files.
The available binary files for Alcatel-Lucent IP Touch 4018 EE phone Extended Edition sets are:
– noesip4018 (application)
– datesip4018 (resources including the ringing melodies)
Except for their name, Alcatel-Lucent IP Touch 4008 EE phone Extended Edition set binary files
are identical.

All Rights Reserved © Alcatel-Lucent 2009 Page 5
These binary files are downloaded from the server whose IP address is either retrieved from a
DHCP server (dynamic configuration) or defined in the set itself (static configuration). The binary
files can be downloaded via TFTP, HTTP or HTTPS.
2.1.3. Selecting the Downloading Mode
Configuration files (sipconfig.txt and sipconfig-MacAddress.txt) are downloaded from
the server defined via DHCP or the set itself.
They can be downloaded via:
– TFTP
– HTTP
– HTTPS: to guaranty the authentication and the confidentiality of the files. This download
requires certificates.
When downloading fails, the parameters stored in flash memory of the set are used.
2.2. Updating SIP Binaries
To update SIP binaries on a set, SIP binaries must be made available on the server as indicated in
§ SIP Set Binaries,and the set must reset. This can be done in the following ways:
– Manually by disconnecting the set and plugging it in again
–Automatically after a polling timer defined in the configuration file (field Binary polling
timer) registered in the set at first initialization. The set monitors the server to check if new
binary files are available. When there are new binary files, the set automatically restarts and
proceeds with a binary update.
–After user changes the parameters in admin settings and exits, phone will reset automatically.
2.3. Phone Features
Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition sets in SIP stand-alone mode
benefit from the same PCX features as SIP extensions (SEPLOS mode).
PCX features can be activated by dialing PCX prefixes.
For some features, the user need not to know the prefix and can use a direct key. In this case,
corresponding prefixes are defined in the configuration file and sent to the terminal at
initialization.

All Rights Reserved © Alcatel-Lucent 2009 Page 6
2.3.1. Direct Key Management
In SIP mode, Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition keys have a
specific meaning.
table 1.1: Keys Meaning in SIP Standalone Mode
0Line 1
1Line 2
2Speed dialing
3Speed dialing
4Speed dialing
5Speed dialing
2.3.2. Multilines
The Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition sets allows to set two calls
simultaneously.The Line 1 key and the Line 2 key are used to speak with two parties
alternatively.
2.3.3. Three-Party Conference
A three-party conference can be performed locally on an Alcatel-Lucent IP Touch 4008 EE/4018
EE phone Extended Edition set in SIP mode.When two lines are set, the conference is available.
The word Conference is displayed on the set. Press the OK key to start the conference. Press the
OK key (or hang up) to end the conference.
2.3.4. Speed Dialing Keys
The user can make a call by pressing one of the speed dialing key. The set automatically dials the
content of the key.
A speed dialing key is configured with:
– The first name and the last name of remote party
– The URI or the call number of the remote party
Speed dialing keys can be programmed:
– Locally on the set
– Via the set configuration file
If a speed dialing key is configured via the configuration file, it cannot be modified from the set.

All Rights Reserved © Alcatel-Lucent 2009 Page 7
2.3.5. Voice Mail
In SIP mode, the set can access voice mail via the voice mail key.
The voice mail key is configured with the voice mail URI or voice mail call number in the SIP
configuration file.
To access voice mail press the voice mail key. When connected, voice guides are played to help
you select options from the set keypad. Digits are transmitted via DTMF coding.
When a new message has been received, the voice mail LED is on. LCD will indicate one more
new message after pressing voice mail key.
Note:
In conversation, a SIP set switches automatically to DTMF mode.
2.4. SIP Configuration Files Description
The sipconfig.txt and sipconfig-MacAddress.txt files are built by the SIP Device
Manager. These files are text files and can be modified with a text editor.
The sipconfig.txt and sipconfig-MacAddress.txt files have the same structure and
contain the following items:
Parameter Comment
###########################
# Configuration of SIP R7.1 Terminal
###########################
[basic]
[dns]
dns_addr= Enter the address of the DNS server
dns2_addr= Enter the address of the DNS backup server
hostname=noe_sip
[sip]
domain_name= Enter the IP address, FQDN or domain name
proxy_addr= Enter the address of the proxy server or PCX
address

All Rights Reserved © Alcatel-Lucent 2009 Page 8
proxy_port= Enter the proxy port number
registrar_addr= Enter the address of the registrar server and
PCX adresse
registrar_port= Enter the registrar port number
outbound_proxy_addr= Enter the outbound proxy server address
outbound_proxy_port= Enter the port used by the outbound proxy
server
proxy2_addr= Enter the backup proxy server address
proxy2_port= Enter the port number used by the backup proxy
server
registrar2_addr= Enter the backup registrar server address
registrar2_port= Enter the port number used by the backup
registrar server
outbound_proxy2_addr= Enter the outbound proxy server address
outbound_proxy2_port= Enter the port used by the outbound proxy
server
pcs_addr= Enter the PCS server address
pcs_port= Enter the port used by the PCS server
sip_transport_mode_survi Enter the Transport mode in PCS mode :
- 0 = UDP or TCP
- 1 = UDP
- 2 = TCP
option_timer=120
register_expire=3600 Enter the lifetime (in seconds) of a registration
register_retry=30 Enter the number of retry to connect the
registration server
local_sip_port= Enter the port number used by the SIP set

All Rights Reserved © Alcatel-Lucent 2009 Page 9
local_sips_port= Enter the port number used by the SIP set used
in secured mode
sip_transport_mode=0 Enter level transport mode:
– 0for UDP or TCP
– 1for UDP only
– 2for TCP only
local_rtp_port=42000 Leave the default value
local_rtcp_port=42001 Leave the default value
prack_type=0 Enter PRACK type :
- 0 = PRACK supported
- 1 = PRACK required
- 2 = PRACK disabled
preferred_vocoder=0,4,8,18 Enter the preferred voice coder:
– 0for PCMU
– 8for PCMA
– 4for G723.1
– 18 for G729A
authentication_realm= If no authentication, leave empty
authentication_name= If no authentication, PUT A VALUE LIKE none
authentication_password= If no authentication, leave empty
user_name= Enter the name of the user
display_name= Enter the name to be displayed on the set
voice_mail_uri= Enter the URI or the call number of the voice
mail
message_waiting_indication_uri= Complete SIP URI of the voice mail
[qos]
sip_diffserv=0
rtp_diffserv=0

All Rights Reserved © Alcatel-Lucent 2009 Page 10
sip_qos_tickets_enable=0 – 0 : disable
–1 : enable
sip_qos_tickets_target= Enter Domaine name
[sntp]
sntp_addr= Enter IP adresse of the SNTP server
timezone= Enter the delta time between UTC and local
time
Local time = UTC – timezone
Ex : UT::60:032902:102503
telnet_password=111111 Password to access the telnet session
[arp]
arp_spoofing_enable=1 -0 : ARP spoofing disabled
-1 : ARP spoofing enabled
arp_spoofing_timer=30
[init]
application_mode=1 Enter the operating mode of the set:
– 0for NOE mode
– 1for SIP mode
[audio]
Tone_country=0 Enter the country language of the user:
– 0for English
– 1for French
– 2for German
– 3for Italian
– 4for Spanish
– 5for Dutch
– 6for Portuguese

All Rights Reserved © Alcatel-Lucent 2009 Page 11
Dtmf_type=2 Enter the DTMF type:
– 0for DTMF according to RFC2833
– 1for DTMF in band
– 2for SIP INFO
Dtmf_level=0 Enter the audio level for DTMF:
– 0for 0db
– 1or +3db
– 2for +6db
– 3for -3db
– 4for -6db
Dtmf_avt_payload_type=96
vad=1 Voice Activity Detection:
– 0VAD out of service
– 1VAD in service
dtmf_feedback_enable=1 0 = VAD not used
1 = VAD used
rlr_handset=10
slr_handset=10
sidetone_handset=2
hearing_aid_enable=1 0 = VAD not used
1 = VAD used
[appl]
admin_password=111111 Enter the set password in SIP mode
Bluetooth_parameters=
remote_forward_code= Enter the forwarding activation code.
remote_forward_deactive_code= Enter the forwarding deactivation code.

All Rights Reserved © Alcatel-Lucent 2009 Page 12
power_priority=0 – 1for critical
– 2for hight
– 3for low
asset_id=
time_format=0 Enter the time format for set display:
– 0for 24 hours format
– 1for AM and PM format
speed_dial_1_first_name= Enter the first name to display when key 3 is
activated
speed_dial_1_last_name= Enter the last name to display when key 3 is
activated
speed_dial_1_uri= Enter the URI or the call number locally dialed
by the set when key 3 is activated
speed_dial_2_first_name= Enter the first name to display when key 4 is
activated
speed_dial_2_last_name= Enter the last name to display when key 4 is
activated
speed_dial_2_uri= Enter the URI or the call number locally dialed
by the set when key 4 is activated
speed_dial_3_first_name= Enter the first name to display when key 5 is
activated
speed_dial_3_last_name= Enter the last name to display when key 5 is
activated
speed_dial_3_uri= Enter the URI or the call number locally dialed
by the set when key 5 is activated
speed_dial_4_first_name= Enter the first name to display when key 5 is
activated
speed_dial_4_last_name= Enter the last name to display when key 5 is
activated
speed_dial_4_uri= Enter the URI or the call number locally dialed
by the set when key 5 is activated

All Rights Reserved © Alcatel-Lucent 2009 Page 13
remote_forward_deactive_code= Enter the forwarding deactivation code. This
code must be identical with the forward
cancellation prefix defined in the PCX.
[admin]
binary_polling_timer=10
config_polling_timer=10
disable_pc_port=
activate_vlan_filter=
3. Maintenance
3.1. Overview
This module describes:
– The error and information messages that appear during the starting phase.
– The Ethernet link table.
3.2. Error and Information Messages
The table below lists the error and information messages. It has the following format:
Short text = text displayed on the screen, in case of real error or for information.
Description = status/error description
table 2.1: Starting Phase Information and Error Messages
Short text Description
END Starting phase is terminated (successful or
unsuccessful)
STARTED Step started
SUCCESS Step successful
FAIL Step failed
RETRYING Retrying step
NO MAC ADDRESS No Ethernet MAC address stored in flash
DHCP NOT RESPONDING Server is not responding

All Rights Reserved © Alcatel-Lucent 2009 Page 14
BAD IP ADDRESS IP address is incorrect
BAD ROUTER ADDRESS Router address is incorrect
ROUTER PING FAILED Router not responding to ping
BAD TFTP ADDRESS TFTP server address is incorrect
ADDRESSES MISMATCH Address, mask and router do not match
TFTP NOT RESPONDING TFTP server is not responding
TFTP SERVER ERROR TFTP server error
BAD FILE CONTENT Error found in downloaded file
FILE TOO LARGE File is too large (cannot be downloaded)
SAME VERSION FOUND The version retrieved is the same as the version
running
NEW VERSION FOUND New IP Touch software version found
(download)
FLASHING SUCCESS Flashing successful
FLASHING FAILED Failed to flash downloaded binary
TRYING ANOTHER CPU Trying next address from configuration file
NO ETHERNET LINK Ethernet link not connected (LAN port only)
RESOURCES NOT FOUND Resources file not found in flash
DOWNLOAD FORCED Download was forced because resources are
missing
NOT COMPATIBLE Downloaded version not compatible with the
terminal hardware
initializing First text message after hardware reset and
copyright information
1/5 network start phase 1 is running: the set is starting its
network interface

All Rights Reserved © Alcatel-Lucent 2009 Page 15
2/5 network setup Phase 2 is running: the set is looking for IP
addresses
3/5 config download Phase 3 is running: the set is trying to get a
lanpbx file
4/5 binary download Phase 4 is running: the set is downloading a new
binary
5/5 connecting Phase 5 is running: the set is trying to set up the
signaling link with the system
802.1x Auth Failed 802.1x authentication has failed: RADIUS server
is unreachable, access is refused to the terminal
on the RADIUS server or the terminal has an
incorrect identity (bad login and/or password).
802.1x Auth Success 802.1x authentication process is complete. The
RADIUS server grants access to the terminal, the
authenticator opens its port.
3.3. Ethernet Link
By default, IP Touch sets are configured to perform auto-negotiation on both ports (LAN and PC).
Provided that the PC and the LAN switch are also configured to perform auto-negotiation, this is
the best configuration for QoS improvement.
However, depending on the network configuration, it may not always be possible to leave the
terminal in auto-negotiation: link speed and duplex of both ports can be forced to determined
values using the supervisor menu:
– Plug in the set, as described: module IP Touch 4008 EE/4018 EE Phone - Commissioning §
Commissioning the 4008 EE or 4018 EE IP Touch Set.
– Once the set displays initialization, press i, then #or enter the admin settings during phone
idle status.
– Use the navigation key to select Ethernet Links
– Modify data as requested
A configuration mismatch between the terminal and PC/LAN switch can lead to nasty effects on
the voice quality:
– No link (or speed mismatch): 8, 9, 11 and 12
– Packet loss (or duplex mismatch): 2, 4, 7 and 14

All Rights Reserved © Alcatel-Lucent 2009 Page 16
Note 1:
Collisions are not detected by the device operating in full-duplex mode: packets from this device are
never re-transmitted if a collision occurs on them.
The following table lists all possible Ethernet port configuration combinations when connecting
an IP Touch set to an external device (switch on LAN side, PC on PC side). For each combination,
the table shows the link status: valid or invalid (duplex or speed mismatch), as described above.
table 2.2: Ethernet Link Combinations
Terminal Port External Device Port Link Status
1auto-negotiation auto-negotiation Valid
2auto-negotiation 100-FULL Invalid (packet loss)
3auto-negotiation 100-HALF Valid
4auto-negotiation 10-FULL Invalid (packet loss)
5auto-negotiation 10-HALF Valid
6100-FULL 100-FULL Valid
7100-FULL 100-HALF Invalid (packet loss)
8100-FULL 10-FULL Invalid (no link)
9100-FULL 10-HALF Invalid (no link)
10 100-HALF 100-HALF Valid
11 100-HALF 10-FULL Invalid (no link)
12 100-HALF 10-HALF Invalid (no link)
13 10-FULL 10-FULL Valid
14 10-FULL 10-HALF Invalid (packet loss)
15 10-HALF 10-HALF Valid
Note 2:
To prevent slowness problem on PC when the two ports of an Alcatel-Lucent IP Touch 4008 EE/4018 EE or
Alcatel-Lucent IP Touch 4008 EE/4018 EE phone Extended Edition set are configured in auto-negotiation
mode, if the negotiation has led to a 10 Mbps rate on the PC port and a 100 Mbps rate on the LAN port,
the IP Touch set automatically tries to renegotiate a 10 Mbps rate on the LAN port.

All Rights Reserved © Alcatel-Lucent 2009 Page 17
www.alcatel-lucent.com
