PaloSanto Solutions
Atcom AT530P Server Setup Guide
2
1.0 Setup Diagram
Figure 1-1 is a setup diagram for a single IP Phone AT530P configuration. The phone is
setup as a SIP telephony device.
Figure 1-1. Setup Diagram
2.0 Host PC Environment
Table 2-1. Host Server Environment Details
Description
Hardware Type
Elastix Appliance ELX-Series
Hardware Version
ELX-3000
Software Type
Elastix
Software Version
2.3
3.0 Test Setup Equipment
Table 3-1. Test Setup Equipment
Equipment
Model
Version
IP (SIP) Phone
N/A
N/A
Atcom
AT530P
1.7.493.353
Switch
N/A
N/A
PaloSanto Solutions
Atcom AT530P Server Setup Guide
2
1.0 Setup Diagram
Figure 1-1 is a setup diagram for a single IP Phone AT530P configuration. The phone is
setup as a SIP telephony device.
Figure 1-1. Setup Diagram
2.0 Host PC Environment
Table 2-1. Host Server Environment Details
Description
Hardware Type
Elastix Appliance ELX-Series
Hardware Version
ELX-3000
Software Type
Elastix
Software Version
2.3
3.0 Test Setup Equipment
Table 3-1. Test Setup Equipment
Equipment
Model
Version
IP (SIP) Phone
N/A
N/A
Atcom
AT530P
1.7.493.353
Switch
N/A
N/A
PaloSanto Solutions
Atcom AT530P Server Setup Guide
2
1.0 Setup Diagram
Figure 1-1 is a setup diagram for a single IP Phone AT530P configuration. The phone is
setup as a SIP telephony device.
Figure 1-1. Setup Diagram
2.0 Host PC Environment
Table 2-1. Host Server Environment Details
Description
Hardware Type
Elastix Appliance ELX-Series
Hardware Version
ELX-3000
Software Type
Elastix
Software Version
2.3
3.0 Test Setup Equipment
Table 3-1. Test Setup Equipment
Equipment
Model
Version
IP (SIP) Phone
N/A
N/A
Atcom
AT530P
1.7.493.353
Switch
N/A
N/A

PaloSanto Solutions
Atcom AT530P Server Setup Guide
3
4.0 Setup Procedure
To set up the Elastix Server for the Atcom AT530P,
1. Go to the web address of the Elastix Server Login page. The web address is
determined by the customer, for this guide we have used the IP address 192.168.1.65
2. On the Login page, type the username and password for an administrative user into
the Username and Password fields, see Figure 4-1. The username and password are
determined by the customer.
Figure 4-1. Login
3. Press Enter or click on the Submit button to go to Elastix’s Dashboard
4. Once inside, click on the PBX tab on the menu at the top of the screen
Figure 4-2. Dashboard
5. Click on the Submit button to add an extension, see Figure 4-3. This will take you to
the Add SIP Extension page.

PaloSanto Solutions
Atcom AT530P Server Setup Guide
4
Figure 4-3. Add an Extension
6. On the Add SIP Extension page (Figure 4-4), fill in the following information:
•User Extension (301 in this example)
•Display Name (‘AtcomAT530P’in this example)
•secret (‘h7Dka3Rf9si0t’in this example)
Figure 4-4. Add SIP Extension
7. Click on the ‘Submit’ button at the end of the page. The extension will be created and
you will see the page on Figure 4-5 displaying the “Apply Configuration Changes Here”
pink ribbon on top of the screen.
8. Click in the “Apply Configuration Changes Here” link
PaloSanto Solutions
Atcom AT530P Server Setup Guide
4
Figure 4-3. Add an Extension
6. On the Add SIP Extension page (Figure 4-4), fill in the following information:
•User Extension (301 in this example)
•Display Name (‘AtcomAT530P’in this example)
•secret (‘h7Dka3Rf9si0t’in this example)
Figure 4-4. Add SIP Extension
7. Click on the ‘Submit’ button at the end of the page. The extension will be created and
you will see the page on Figure 4-5 displaying the “Apply Configuration Changes Here”
pink ribbon on top of the screen.
8. Click in the “Apply Configuration Changes Here” link
PaloSanto Solutions
Atcom AT530P Server Setup Guide
4
Figure 4-3. Add an Extension
6. On the Add SIP Extension page (Figure 4-4), fill in the following information:
•User Extension (301 in this example)
•Display Name (‘AtcomAT530P’in this example)
•secret (‘h7Dka3Rf9si0t’in this example)
Figure 4-4. Add SIP Extension
7. Click on the ‘Submit’ button at the end of the page. The extension will be created and
you will see the page on Figure 4-5 displaying the “Apply Configuration Changes Here”
pink ribbon on top of the screen.
8. Click in the “Apply Configuration Changes Here” link

PaloSanto Solutions
Atcom AT530P Server Setup Guide
5
Figure 4-5. Apply Configuration Changes Here
9. With this you have just finished creating a SIP extension that will be used by the
Atcom AT530P to register with the Elastix Server. Repeat Steps 5 through 8 to similarly
create another extension (different values on Step 6) to be used by the IP (SIP) Phone to
register as well (extension 302 in this example). Once finished you will see something
similar to Figure 4-6
Figure 4-6. Atcom and IP Phone extensions successfully created
10. You will need to enter the information from the extension created on the Elastix
Server into the Atcom Phone.
For the initial configuration, refer to the Atcom AT530P User Manual which can be
found at: http://www.atcom.cn/products_ipphone.html
Factory default settings
IP Addressing
DHCP
Web Access User Name
admin
Web Access Password
admin
11.Log in to the Atcom AT530P WebUI by pointing your browser to the Atcom
Phone’s IP address.
12. When prompted, enter the Web Access Username and Web Access Password to
access the Atcom WebUI (Figure 4-7).
PaloSanto Solutions
Atcom AT530P Server Setup Guide
5
Figure 4-5. Apply Configuration Changes Here
9. With this you have just finished creating a SIP extension that will be used by the
Atcom AT530P to register with the Elastix Server. Repeat Steps 5 through 8 to similarly
create another extension (different values on Step 6) to be used by the IP (SIP) Phone to
register as well (extension 302 in this example). Once finished you will see something
similar to Figure 4-6
Figure 4-6. Atcom and IP Phone extensions successfully created
10. You will need to enter the information from the extension created on the Elastix
Server into the Atcom Phone.
For the initial configuration, refer to the Atcom AT530P User Manual which can be
found at: http://www.atcom.cn/products_ipphone.html
Factory default settings
IP Addressing
DHCP
Web Access User Name
admin
Web Access Password
admin
11.Log in to the Atcom AT530P WebUI by pointing your browser to the Atcom
Phone’s IP address.
12. When prompted, enter the Web Access Username and Web Access Password to
access the Atcom WebUI (Figure 4-7).
PaloSanto Solutions
Atcom AT530P Server Setup Guide
5
Figure 4-5. Apply Configuration Changes Here
9. With this you have just finished creating a SIP extension that will be used by the
Atcom AT530P to register with the Elastix Server. Repeat Steps 5 through 8 to similarly
create another extension (different values on Step 6) to be used by the IP (SIP) Phone to
register as well (extension 302 in this example). Once finished you will see something
similar to Figure 4-6
Figure 4-6. Atcom and IP Phone extensions successfully created
10. You will need to enter the information from the extension created on the Elastix
Server into the Atcom Phone.
For the initial configuration, refer to the Atcom AT530P User Manual which can be
found at: http://www.atcom.cn/products_ipphone.html
Factory default settings
IP Addressing
DHCP
Web Access User Name
admin
Web Access Password
admin
11.Log in to the Atcom AT530P WebUI by pointing your browser to the Atcom
Phone’s IP address.
12. When prompted, enter the Web Access Username and Web Access Password to
access the Atcom WebUI (Figure 4-7).

PaloSanto Solutions
Atcom AT530P Server Setup Guide
6
Figure 4-7. Atcom AT530P WebUI
To register the Atcom Phone we have two methods: Manual Configuration and
AutoProvisioning using Elastix’s Endpoint Configurator.

PaloSanto Solutions
Atcom AT530P Server Setup Guide
7
MANUAL CONFIGURATION
1. Use the information from the Add SIP Extension page (Figure 4-4) to enter the
following necessary information on “VoIP => SIP Config” section of the Atcom Phone
WebUI:
Register Server Addr: Elastix Server’s IP Address (192.168.1.65 in this
example)
Register Username: 301 in this example
Register Password: ‘h7Dka3Rf9si0t’ in this example
Phone number: 301 in this example
Enable Register: Checked
Figure 4-8. Account Configuration
2. Once you have entered the required information, click on ‘Apply’ button located at
the end of the page. The phone should be registered now. To check this, go to “Current
State” section and see the state of the phone. If the phone is not registered, make sure
you’ve entered the correct information (Figure 4.9).
Figure 4.9. State
3. Configure the other IP (SIP) Phone with the correct parameters.

PaloSanto Solutions
Atcom AT530P Server Setup Guide
8
4. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and
call the AT530P’s extension number (301 in this example). When the call is established,
speak into the phone and verify that the other IP (SIP) Phone can hear your voice.
Check this by calling from both ends. This step completes the manual procedure.

PaloSanto Solutions
Atcom AT530P Server Setup Guide
9
AUTOPROVISIONING USING ELASTIX’S ENDPOINT
CONFIGURATOR
1. In the Elastix WebUI go to “PBX => Endpoint Configurator” (Figure 4-10).
Figure 4.10 Endpoint Configurator
2. Next to the “Discover Endpoints in this Network” button, type the address where
the phone is located and hit Enter (or click the button). This will generate a list with
all the phones available in that network (Figure 4-11).
Figure 4.11 Endpoint Configurator
3. In the row where the phone you want to autoprovision is located (find it according
to either its MAC or IP Address):
Mark the checkbox
From the drop-down list, select the correct “Phone Type” (phone model) of the
phone
From the drop-down list, select the “User Extension” you want to assign to the
phone
PaloSanto Solutions
Atcom AT530P Server Setup Guide
9
AUTOPROVISIONING USING ELASTIX’S ENDPOINT
CONFIGURATOR
1. In the Elastix WebUI go to “PBX => Endpoint Configurator” (Figure 4-10).
Figure 4.10 Endpoint Configurator
2. Next to the “Discover Endpoints in this Network” button, type the address where
the phone is located and hit Enter (or click the button). This will generate a list with
all the phones available in that network (Figure 4-11).
Figure 4.11 Endpoint Configurator
3. In the row where the phone you want to autoprovision is located (find it according
to either its MAC or IP Address):
Mark the checkbox
From the drop-down list, select the correct “Phone Type” (phone model) of the
phone
From the drop-down list, select the “User Extension” you want to assign to the
phone
PaloSanto Solutions
Atcom AT530P Server Setup Guide
9
AUTOPROVISIONING USING ELASTIX’S ENDPOINT
CONFIGURATOR
1. In the Elastix WebUI go to “PBX => Endpoint Configurator” (Figure 4-10).
Figure 4.10 Endpoint Configurator
2. Next to the “Discover Endpoints in this Network” button, type the address where
the phone is located and hit Enter (or click the button). This will generate a list with
all the phones available in that network (Figure 4-11).
Figure 4.11 Endpoint Configurator
3. In the row where the phone you want to autoprovision is located (find it according
to either its MAC or IP Address):
Mark the checkbox
From the drop-down list, select the correct “Phone Type” (phone model) of the
phone
From the drop-down list, select the “User Extension” you want to assign to the
phone

PaloSanto Solutions
Atcom AT530P Server Setup Guide
10
Figure 4.12 Endpoint Configurator
4. Click the “Set” button. This will reboot the phone. After the phone has finished
rebooting, it will be automatically configured with the selected User Extension.
5. Configure the other IP (SIP) Phone with the correct parameters.
6. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and
call the AT530P’s extension number (301 in this example). When the call is
established, speak into the phone and verify that the other IP (SIP) Phone can hear
your voice. Check this by calling from both ends.
PaloSanto Solutions
Atcom AT530P Server Setup Guide
10
Figure 4.12 Endpoint Configurator
4. Click the “Set” button. This will reboot the phone. After the phone has finished
rebooting, it will be automatically configured with the selected User Extension.
5. Configure the other IP (SIP) Phone with the correct parameters.
6. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and
call the AT530P’s extension number (301 in this example). When the call is
established, speak into the phone and verify that the other IP (SIP) Phone can hear
your voice. Check this by calling from both ends.
PaloSanto Solutions
Atcom AT530P Server Setup Guide
10
Figure 4.12 Endpoint Configurator
4. Click the “Set” button. This will reboot the phone. After the phone has finished
rebooting, it will be automatically configured with the selected User Extension.
5. Configure the other IP (SIP) Phone with the correct parameters.
6. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and
call the AT530P’s extension number (301 in this example). When the call is
established, speak into the phone and verify that the other IP (SIP) Phone can hear
your voice. Check this by calling from both ends.
