BROSA Josie Sideboard Large User manual

ASSEMBLY GUIDE
Josie Sideboard Large
v1.0

Components
Upon unpacking your sideboard from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new sideboard.
Outer body of sideboard
Draws
Base x 1
Top Panel x 1
Leg frame x 2
Shelving x 2
Draw side walls x 6
Draw back walls x 3
Draw support panel x 3
Draw base x 3
Door x 2
Draw front panel x 3
Back walls x 3
Side/inner
wall x 4

Hardware
You will need

Step 1
Step 2
Starting with the body of the sideboard, take each
side/inner wall and insert a dowel (A) into the two
inner holes along the bottom and a cam screw (B) into
the outer holes. Align the each wall to their
corresponding place along the base and rmly press
together. Insert a cam lock (C) on the inside of the
sideboard as shown in the diagram. Place a plastic cap
(W) to cover the cam locks (C).
Grab the back walls and slide them into place.
A
B
C
W
A x 8
B x 8
C x 8
W x 8

Step 3 Insert a dowel (A) into each of the inner holes along
the top of each side/inner wall and a cam screw (B) in
the outer holes. Align the top panel so that all the parts
align to the corresponding holes and rmly press into
place. Insert a cam lock (C) into the holes on the inside
of the sideboard as shown. Cover each of the cam locks
(C) with a plastic cap (W).
A x 8
B x 8
C x 8
W x 8
Step 4 Align one leg frame to the corresponding holes then t
a washer (T) to a bolt (S) and screw into place. Repeat
for the remaining screws for that leg frame, then repeat
for the other leg frame.
T
S
S x12
T x12
A
B
C
W

Step 5
Step 6
Lift the sideboard and rmly place on a level surface.
Insert a laminates nail (H) in each of the holes inside
the sideboard and screw tightly into place.
H x 8
H

Step 7
Step 8
I x 8
Insert a xed laminates nail (I) in each of the holes in
the shelving and then insert each shelf into the
separate compartments of the sideboard.
Align the track (O) to the corresponding holes and x
into place with the screws (L & J). Repeat for the other
tracks (O).
I
O
L
J
J x 6
L x 18
O x 3

Step 9
Step 10
M x 12
N x 12
J x 18
P x 3
Place a stopper (N) along the side of the back of the
sideboard as shown in the diagram and follow it with a
screw (M) to secure it in place.
On the inner side of the draw walls, align track (P) and
t into place with screws (J). Repeat for all draw walls.
N
M
P
J

K x12
Step 11 Align the side walls of the draw to the back wall and t
together tightly with screws (K). Repeat for the
remaining draws.
D x 3
E x 3
F x 6
W x 3
K
Slide the base of the draw into place by tting it into the
grooves in the walls of the draw. Insert a dowel (F) into
the outer two holes of the support panel and a cam
screw (D) in the middle hole. Firmly press it into place
along the bottom of the draw. Insert a cam lock (E) in
the corresponding hole followed by a plastic cap (W).
Repeat for the other two draws.
Step 12
DF
W
E

Insert cam screw (D) into the holes on the sides of the
front panel of the draw and one in the bottom center.
Place dowels (F) in the remaining two holes along the
bottom of the panel. Align to the draw and rmly press
together. Insert a cam lock (E) in the hole in the
support panel underneath as well as two in the in each
side of the draw followed by a plastic cap (W).
Repeat for the other two draws.
Step 13
Align the handle (U) to the corresponding holes and
use screws (V) to x into place. Insert the draws to
their corresponding slots.
Step 14
D
W
E
F
D x 15
E x 15
F x 6
W x 15
V
U
U x 3
V x 6

R x 2
Step 15 Separate the hinge (R) by sliding the two halves out
from one another and with the smaller part, attach to
the inner wall of the sideboard as shown in the
diagram (by screwing it into place).
With the other half of the hinge (R) align it to the
corresponding holes on the door and screw into place.

With another person holding the door, slide the hinges
(R) back together. Insert the screws and tighten. Align
the handle (U) to the corresponding holes and use
screws (V) to x into place.
Step 16
U
V
R
U x 1
V x 2
R x 2

Q x 2
Step 17 Repeat the last step to t the door on the other side.
U
V
Q
Step 18 Place the sideboard in your beautiful home and enjoy!

Step 19 e followig steps are to instruct how to adjust the
hinges if needed.
19.1 Lateral adjustment by screw adjustment.
19.2 Front-to-Back adjustment by slackening and
retightening the hinge-arm mounting screw.
19.3 Vertical adjustment via slots on mounting plate by
slackening and retightening the screws on the
mounting plate.
Step 19.1
Step 19.2
Step 19.3

Step 20 e following steps are to instruct how to remove the
door if needed. Have a second person supporting the
door during the removal process. Using a phillips head
screwdriver remove the screws from the hinge holding
the two halves together. Slide the half attached to the
door out to remove from the body of the unit.
