BROSA Bristol Sideboard User manual

ASSEMBLY GUIDE
v1.0
Bristol Sideboard

Components
Upon unpacking your sideboard from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new sideboard.
A x 8
(Ø8x30)
J x 4
E x 4
(Ø15xH15)
D x 4
(Ø7xL48)
K x 4
B x 4
(Ø7xL30)
H x 8
(M6x55)
I x 8
(Ø7xL30)
C x 4
(Ø15xH12)
G x 1
(10g)
F x 10
(Ø3.8xL38)
Hardware
What you need
Body
Leg
Leg
Side Beam
Side Beam
Connecting
Beam
Connecting
Beam
1
2
2
3

Step 1
1.1 Insert cam locks (E) into the corresponding holes
on the side beams making sure the mouth is facing
the screw hole.
1.2 Insert dowels (A) into the outer holes of the legs.
It is optional to use the glue over the wooden dowels.
1.3 Insert cam screws (D) into the inner holes of the
legs.
1.4 Align the the legs (2) with the side beams (3) using
the dowels and cam screws. Firmly press them
together.
1.5 Screw the cam locks using a screw driver.
1.6 Insert plastic caps (J) to cover the cam lock holes
on the sides of the leg structure.
A x 4
D x 4
E x 4
A
E
D
J
J x 4
Step 1.2
Step 1.1
Step 1.6
Step 1.5
Step 1.3
Step 1.4
Step 1.4
2
23
3

2.1 Insert dowels (A) into the corresponding holes of
the storage body.
2.2 Insert cam screws (B) into the corresponding
holes of the storage body.
2.3 Align the the body with the leg structure and
rmly press them together.
2.4 Insert cam locks (C) into the corresponding holes
on the leg structure making sure the mouth is facing
the cam screw. Screw the cam locks using a screw
driver.
2.5 Insert plastic caps (F) into the corresponding
holes on the sides of the leg structure.
A x 4
B x 4
C x 4
K x 4
Step 2
B
A
K
Step 2.1
Step 2.2
Step 2.3
Step 2.5
C
Step 2.4

Step 3
7.1 Allign the leg structure to the storage body. Fit the
connecting beams To the formed corners. Fit a
washer (I) to a bolt (H) and screw into the
corresponding holes to secure the beams to the legs.
7.2 Secure the foot construction to the storage body
using long screws (F).
F x 10
I x 8
H x 8
F
Step 7.4
H
I
Step 7.1

Step 3
Gently lift the storage and place upright on a level
surface. Enjoy your new storage!
