Coalesse Bix Bridge Table User manual

Page 1 of 5
939503317 Rev B
If you have a problem, question, or request, call
your local dealer, or Coalesse at 1.800.627.6770
Or visit our website: www.coalesse.com
©2013 Coalesse
San Francisco, California U.S.A.
Printed in U.S.A.
Combo Wrench
Part No. 804025
Hex Key-M4
Part No. 804022
Bix™ Bridge Table Installation Instructions
Table of Contents
Page Topic
2 Bridge Table - Corner Top
3 Bridge Table - Rectangular Top
4 Straight Screen
5 Corner Screen

Page 2 of 5
939503317 Rev B
BOTTOM VIEW
Bridge Table - Corner Top:
2. Snap-on wire clips, (p/n 631069), are furnished for tops with utility.
Locate the wire clips at your discretion as shown in Steps 1 & 2.
1. Assemble the metal frame as shown in Steps 1 & 2 using 1/4"-20 x 2.25"
FH-PL-BO screws, (p/n 673085).
3. Temporarily remove the three JCB machine screws, (p/n 673058), on
the bottom of the seat.
4. Align the metal frame to the bottom of the seat and reinstall the machine screws as
shown in Step 3. Repeat to attach the other side of the metal frame to another seat.
5. Align and attach the top to the frame as shown in Steps 4 & 5 with 1/4-20 x .75"
machine screws, (p/n 673008).
3
12
Screw (1/4-20 x 2.25")
p/n 673085
Bix Straight
Section, Bottom
BACK
FRONT
4 5
JCB Machine Screw
p/n 673058
Wire Clip
p/n 631069
SIDE VIEW

Page 3 of 5
939503317 Rev B
Bridge Table - Rectangular Top:
2. Snap-on wire clips, (p/n 631069), are furnished for tops with
utility. Locate the wire clips at your discretion as shown in Steps 1 & 2.
1. Assemble the metal frame as shown in Steps 1 & 2 using
1/4"-20 x 2.25" FH-PL-BO screws, (p/n 673085).
3. Temporarily remove the three JCB machine screws, (p/n 673058), on
the bottom of the seat. Align the metal frame to the bottom of the seat and
reinstall the machine screws. Repeat procedure to attach the other side of
the metal frame to another seat.
4. Install double-sided tape to SA-BRKT00301 as shown, then align and attach
SA-BRKT00301 to the top using No. 8 x .75" PH-PL-BO wood screws,
(p/n 672024).
5. Align and attach the top to the frame as shown using 1/4"-20 x .75"
machine screws, (p/n 673008).
6. Remove backing from double-sided tape on SA-BRKT00301. Hang SA-DISP00301
onto SA-BRKT00301 tabs and press down to attach.
Screw (1/4-20 x 2.25")
p/n 673085
1
Wire Clip
p/n 631069
2
456
Wood Screw
p/n 672024
Wood Screw
p/n 672024
Machine Screw
p/n 673008
SA-BRKT00301
SA-DISP00301
SA-BRKT00301
Tape
SA-DISP00301
FRONT
GRAIN DIRECTION
FRONT
BACK
FRONT
BACK BACK
3
Machine Screw
p/n 673058
Bottom Shown Face-up
BACK
FRONT
TOP VIEW
SIDE VIEW
ASSEMBLED

Page 4 of 5
939503317 Rev B
Straight Screen:
1. Align and attach the straight screen mounting bracket, (p/n 679403), to the
underside of the rectangular top (pilot holes provided) as shown using No.-10 x .625"
PH-PL-BO wood screws, (p/n 672028).
2. Align and attach the straight screen and screen support wire frame, (p/n
712301 & 679133), to the screen mounting bracket as shown.
3. Insert retention pad, (p/n 643300), between the screen and the screen support
and attach push nuts, (p/n 674025), to secure the support wire frame.
Pilot Holes
(underside)
Top
1
2 3
Straight Screen Mounting
Bracket p/n 679403
Wood Screw
p/n 672028
Retention Pad
p/n 643300
Wire Frame
p/n 679133
Straight Screen
p/n 712301
Push Nuts
p/n 674025
FRONT
FRONT

Page 5 of 5
939503317 Rev B
1
3
Corner Screen:
1. Align and attach the corner screen mounting brackets, (p/n 679400, 679401,
& 679402), to the underside of the corner top (pilot holes are provided) as shown in
Step 1 using No. 10 x .625" PH-PL-BO wood screws, (p/n 672028).
2. Align and attach the corner screen and screen support wire frames, (p/n 712300
& 679130, 679131 & 679132), to the screen mounting brackets as shown in
Step 2. Next, Insert retention pad, (p/n 643300), between the screen and the
left and right hand screen supports (2 places).
3. Attach push nuts, (p/n 674025), to secure the support wire frame.
Top
Mounting Bracket
p/n 679402
Mounting Bracket
p/n 679400
Wire Frame
p/n 679130 Wire Frame
p/n 679131
Wire Frame
p/n 679132
Wire Frame
p/n 679132
Retention Pad
p/n 643300
Retention Pad
p/n 643300
Corner Screen
p/n 712300
Mounting Bracket
p/n 679401
TOP NOT SHOWN TOP NOT SHOWN
GRAIN DIRECTION
Push Nut
p/n 674025
2
BACK VIEW
FRONT VIEW
