Lagunitas® Booth Screen Installation Instructions
If you have a problem, question, or request, call
your local dealer, or Coalesse at 1.800.627.6770
Or visit our website: www.coalesse.com
©2016 Coalesse
San Francisco, California U.S.A.
Printed in U.S.A.
T-30 Torx Bit with
Extension
SCREEN
GANGING
CLIP
BOTTOM
GANGING
BRACKET
Hot Knife

Page 2 of 4
69925 Rev B
FABRIC SCREEN GANGING CLIP INSTALLATION
(The instructions on this page only apply if your unit has
upholstered screens. If your unit has mesh screens, please
continue to page 3)
Locate the end of the unit you wish to gang.
Measure down from the top of the screen and place a mark on
the welt cord at 4 inches.
Using pliers, carefully grab the welt cord and pull it slightly out of
the channel.
Using , the welt cord at the line you’ve
marked in step 2. BE CAREFUL NOT TO CUT THE FABRIC ON
THE SCREEN! After cutting the welt cord, you should see a hole in
the screen. Trim a 1/2 inch from the welt cord, making sure the hole
will be accessible when the welt cord is tucked back into the
channel. NOTE: If the hole in the screen is covered by fabric, trim
the fabric away with scissors, so it doesn’t prevent the ganging clip
from functioning properly.
Install the screen ganging clip (with the overlapping joint on top)
until a ‘click’ is heard and ensure the clip can’t be pulled out from the
screen.
2
3
4”
4
5
SCREEN
GANGING CLIP
OVERLAPPING
JOINT
WELT
CORD
WARNING: Ganging units using the screen ganging clip will
require creating a hole in the upholstery. This hole is only visible
if the units are separated.
NOTE: The screen ganging clip can only be used if the adjoining
screens are the same height.

Page 3 of 4
69925 Rev B
MESH SCREEN GANGING CLIP INSTALLATION:
WARNING: Ganging units using the screen ganging clip will
require creating a hole in the upholstery. This hole is only visible
if the units are separated.
NOTE: The screen ganging clip can only be used if the adjoining
screens are the same height.
1. Determine assembled configuration of your screens to confirm
where screen ganging clips must be applied. Locate the hole in the
frame on the side of the screen (approximately 4 inches down from
the top) by pressing your finger along the seam (you will feel the
indentation). Place a mark on the fabric mesh at the hole location.
Repeat at all points where ganging clips must be used.
2. Using a hot knife, carefully melt the mesh approximately1/2” long.
A small hole will now be visible in the knit /mesh material. Repeat at
all points where ganging clips will be used.
3. Install screen ganging clips (with the overlapping joint on top)
until a ‘click’ is heard. Pull on the clip to ensure the clip is engaged in
the screen frame and can’t be pulled out from the screen.
1
2
OVERLAPPING
JOINT
SCREEN
GANGING CLIP
3
4”
CLICK
1/2”

Page 4 of 4
69925 Rev B
MESH AND FABRIC SCREEN BOTTOM GANGING BRACKET
INSTALLATION AND GANGING:
WARNING: To avoid damage to product it is recommended that two
(2) persons, minimum, are present to safely complete this installation.
NOTE: This procedure outlines connecting two lounge units using the
booth screen COLAGLBS, resulting in an enclosed booth screen
application. Complete lounge units are not shown to allow for a
detailed view.
Mark a line on bottom 4 inches from side of screen. Pull out the welt
cord and
On the center screen, remove both panel glides. Place a bottom
ganging bracket over one of the glide mounting holes, as shown. Install
one (1) supplied screw and reinstall one (1) glide to attach the bottom
ganging bracket to the bottom of the screen. Repeat for the opposite
side of the screen.
Place center screen, with all ganging hardware installed, upright
onto a pallet or suitable spporting object. Remove glide from adjoining
screen. Engage one (1) adjoining screen onto screen ganging clip in
center screen, until an audible click is heard (3a). Reinstall glide to
secure adjoining screen to bottom ganging bracket on center screen (3b).
NOTE: Ensure that all screen ganging clips are engaged and all screens
are aligned and supported until all ganging connections are complete.
4. Repeat step 1 to install remaining adjoining screen.
5. Remove assembled screens from supports and adjust all glides.
2
SCREEN
GANGING CLIP
CLICK
PROVIDED
SCREW
BOTTOM GANGING BRACKET
GLIDE
CENTER SCREEN
3a
COLAGLBS
3b
GLIDE
ADJOINING
SCREEN
CENTER SCREEN
1a 1b
1c
4” WELT
CORD
