Coalesse Bix Table User manual

Page 1 of 5
939503318 Rev B
Bix™Table Installation Instructions
If you have a problem, question, or request, call
your local dealer, or Coalesse at 1.800.627.6770
Or visit our website: www.coalesse.com
©2013 Coalesse
San Francisco, California U.S.A.
Printed in U.S.A.
bix table 20" round
x 18" high or 27" high
bix table
24 x 24 x 18 high
bix table 28" round x 18" high
or 27" high boring layout
bix table
24 x 48 x 18 high
bix table
24 x 72 x 18 high
bix table
36 x 48 x 27 high
bix table
36 x 72 x 27 high
bix table 20" round x 18" high
or 27" high boring layout
bix table 28" round x 18" high
or 27" high boring layout
bix table 24 x 24
boring layout
bix table 24 x 48
boring layout
bix table 24 x 72 x 18 high
boring layout
bix table 36 x 48 x 27 high
boring layout
bix table 36 x 72 x 27 high
boring layout

Page 2 of 5
939503318 Rev B
1. The bix table base has 4 styles:
-18" high with wire management.
-18" high without wire management
-27" high with wire management
-27" high without wire management
Drawing to the right shows a Bix table base
without wire managment, a Bix table base with
wire management and a Bix tabletop.
2. Flip the tabletop over with the bottom up.
Base without
wire management
Base with
wire management
Tabletop
(bottom view)
1
MOUNTING HOLES
FOR BASE
5mm HOLES
FOR WIRE CLIP
MOUNTING HOLES
FOR BASE

Page 3 of 5
939503318 Rev B
3. Flip the base over the bottom of the tabletop
and align the bolt holes on the mounting plate of
the base to the insert installed on the bottom of
the tabletop.
4. Normally, for tops with wire management
bases, the mouse holes on the base should be
facing each other. However, it could be rotated
at the discretion of the end user.
5. Install (4) screws (P/N 673035) with supplied
hex key (P/N 804022).
6. Install supplied wire clips (P/N 631071) on
the pre-drilled 5mm holes for tabletop with
optional utility grommet.
3 4
5
6WIRE CLIP

Page 4 of 5
939503318 Rev B
7. Flip the tabletop over (7a) with the top up (7b).
8. For tabletop with optional utility grommet, press the
dummy grommet or PVD into the 3.5" hole (8a).
Route wires down through the base column (8b) and out
through the mouse hole at the bottom of the base plate
(8c).
Note: It is necessary to unscrew the four screws on
the mounting plate with hex key in order to remove
the dummy grommet or PVD after it is installed.
7a
8a
7b
8b
8c

Page 5 of 5
939503318 Rev B
Configuration Guidelines
1. The space relationship between the seating
and the table should be 96 to 99 inches.
2. The space relationship for leg clearance
(with the table base centered) should be
24 to 27 inches.
96"-99"
72"
24"-27"
