Coalesse SW 1 Operating instructions

If you have a problem, question, or request, call
your local dealer, or Coalesse at 1.800.627.6770
Or visit our website: www.coalesse.com
©2016 Coalesse
San Francisco, California U.S.A.
Printed in U.S.A.
MAGNETIC BITS
BIT HOLDER
R2
Customer Service Instruction for Replacement of
Knit and Fabric Components on SW_1™Seating
Page 1 of 7
1070628001 Rev A

3
2
1. Invert the chair and place on a clean soft surface.
2. Using an Allen wrench or driver bit, remove and save
the four (4) screws securing the seat cushion assembly
to the seat plate.
3. By hand, deflect and push the retaining tab through the
slot near the center rear of the seat plate and remove the
seat cushion assembly from the chair.
SEAT CUSHION SCREWS
SEAT PLATE
1
RETAINING
TAB
Seat Cushion Removal
Page 2 of 7
1070628001 Rev A

2
1. Return the chair to upright.
2. Locate one (1) screw at each point where the chair shell
fabric ends, approximately 6”-7” from the center of the frame.
Work the fabric back to expose the screws. A utility blade maybe
needed to access these screws. Use care and minimal cutting
of fabric to minimize the impact on the final look of the chair
once it is reassembled.
NOTE: Do not remove the screws with the wires attached.
3. Using a number 2 Phillips screwdriver, remove the two (2)
screws securing the shell assembly to the tube frame.
NOTE: On older lounge seating it will be necessary to cut two
(2) retaining cables between the chair shell and the tube frame
near the support yoke.
NOTE: On older chair seating it will be necessary to cut
two (2) plastic zip ties and two (2) retaining cables
between the chair shell and the tube frame.
4. If necessary, insert wire cutters between the
chair shell and the mesh fabric on the tube frame.
Cut the retaining cables and/or zip ties to
disconnect the chair shell from the tube frame.
NOTE: CUT RETAINING CABLES AND/OR
ZIP TIES ON OLDER SEATING .
3
4
Shell Removal
Chair seating shown. Lounge
seating procedure similar.
3
APPROXIMATELY 6”-7”
DO NOT REMOVE
THE (2) SCREWS
WITH WIRES
Page 3 of 7
1070628001 Rev A

6
NOTE: On older seating product the shell and the
tube frame have different mounting features. Neither
will retrofit to newer product, requiring replacement
of shell and frame together. If you have older seating
product, complete removal of shell is not required.
Proceed to tube frame removal.
5. Begin removal of the shell by lifting up on the
front of the shell.
6. Work around the perimeter of the shell to
disengage the mounting slots in the shell
from the mounting lugs in the tube frame.
5
Shell Removal (Cont’d)
Chair seating shown. Lounge
seating procedure similar.
Older product shell attachment detail.
Replace shell and frame together.
See page 5 for tube frame removal.
MOUNTING
SLOT
MOUNTING
LUG
Page 4 of 7
1070628001 Rev A

2
1.Using an Allen wrench or driver bit, remove four (4)
screws securing the tube frame assembly to the support
yoke.
2.Remove the two (2) screws securing the product
branding badge to the front of the seat plate. Set the
screws and branding badge aside.
3. Remove the two (2) screws securing the front of
the tube frame to the seat plate. Find the screws on the
inside of the seat plate, as shown.
Tube Frame Removal
Chair seating shown. Lounge
seating procedure similar.
1
1
SUPPORT YOKE
SCREWS
BRANDING BADGE
SEAT PLATE
SCREWS
3
Page 5 of 7
1070628001 Rev A

2
NOTE: When servicing seating with swivel return cylinders, check
to ensure that the arm yoke is aligned properly with the base. The
arm yoke should be aligned evenly between the “X” angle of the
base legs, as noted below.
1.If the yoke is not in alignment with the base and removal is
necessary, stand at the back of the chair and place both feet on
the outer ends of the nearest base legs.
2.Grasp both ends of the arm yoke and pull up while rocking the
yoke side to side, to dislodge it and the cylinder from the base.
3. Disengage the yoke and cylinder from the base and then allow
this assembly to rest loosely in the base.
4.Tilt the base and yoke together, backwards, until it is resting
on two (2) of the base legs and the arm yoke ends, on the floor.
This will align the yoke properly with the base.
5.Hold the yoke and cylinder and strike the base with a soft blow
mallet to reseat the cylinder into the the base.
Yoke to Base Alignment (Swivel Return Cylinders)
1
4
5
CORRECT ALIGNMENT! INCORRECT ALIGNMENT!
TOP VIEW
(Seat plate not shown for clarity)
3
Page 6 of 7
1070628001 Rev A

NOTE: To ease reassembly and avoid damaging any components,
it is recommended that two persons be present when reassembling
this product.
1.To install tube frame assembly, align the two (2) holes on each
mounting plate in the frame with the mounting holes in the arm yoke.
Use an awl type tool to align holes and loosly install the screws. Prior
to tightening screws, adjust fabric evenly on the tube, then tighten all
four (4) screws. Make sure to secure the tube frame to the seat plate
with two (2) screws and branding badge and screws.
2 .To install the shell, begin by engaging the the upper most mounting
slots in the shell onto the upper most mounting lugs in the tube frame.
Work the shell, side to side, and force it down to engage the lower
mounting lugs and slots. Check to ensure the shell is completely and
evenly seated onto the tube frame. Make any required adjustments to
ensure the fabric on the tube frame is evenly dispersed. Install two (2)
screws to secure the front of the shell to the tube frame.
3. To install the seat cushion, begin by aligning the locating tabs at the
front of the cushion with the front of the seat plate. Rotate the cushion
back and engage the retaining tab with the slot near the back of the seat
plate. One installer must sit on the cushion to fully contact it with the seat
plate,
while the second installer secures the cushion with four screws.
Ensure that the fabric on the tube frame is evenly dispersed.
Reassembly
1
Chair seating shown. Lounge
seating procedure similar.
MOUNTING
SLOT
MOUNTING
LUG
2
NOTE: Sit in chair to fully contact
cushion to seat plate and disperse
frame fabric. Then install screws.
3
LOCATING
TAB
RETAINING TAB
SEAT PLATE
BRANDING
BADGE
ARM YOKE
SCREWS
SEAT PLATE
FRONT SCREWS
MOUNTING
PLATE
FRONT SHELL
SCREWS
Page 7 of 7
1070628001 Rev A
