Cornwell Tools CSE-VS300 User manual

CSE-VS300/CSE-VS600 1 Rev. 1/29/02
• Operating Manual
• Warning Information
• Parts List
CSE-VS300
3 Ton
Vehicle Stand
CSE-VS600
6 Ton
Vehicle Stand
THIS OPERATING
MANUAL CONTAINS
IMPORTANT SAFETY
INFORMATION.
READ CAREFULLY
AND UNDERSTAND
ALL INFORMATION
BEFORE OPERATING
THIS TOOL.
SAVE THIS MANUAL
FOR FUTURE USE.
DO NOT OVERLOAD STAND. OVERLOADING CAN CAUSE DAMAGE TO, OR
FAILURE OF, THE STAND.
PLACE LOAD IN THE CENTER OF THE SADDLE ONLY.
USE STANDS IN PAIRS, ON HARD, LEVEL SURFACES CAPABLE OF SUSTAINING
THE LOAD.
LOAD AND STANDS SHALL BE STABLE. USE ON OTHER THAN HARD, LEVEL
SURFACES MAY RESULT IN POSSIBLE LOSS OF LOAD.
INSPECT EACH STAND TO BE SURE IT IS IN GOOD CONDITION BEFORE USE.
NO ALTERATIONS TO THE STAND SHALL BE MADE.
USE SUPPORT POINTS SPECIFIED BY VEHICLE MANUFACTURER.
DO NOT CRAWL UNDER VEHICLE WHEN PLACING/REMOVING STANDS.
ENSURE BOTH STANDS ARE SET AT SAME HEIGHT AND HOLDING DOGS ARE
FULLY ENGAGED.
READ, STUDY & UNDERSTAND THE OPERATING MANUAL PACKED WITH THIS
STAND BEFORE USING STAND. FAILURE TO HEED THESE WARNINGS MAY
RESULT IN LOSS OF LOAD, DAMAGE TO STAND, AND/OR FAILURE RESULTING
IN PROPERTY DAMAGE, PERSONAL OR FATAL INJURY.
Meets or exceeds ASME PALD-1997
standards for performance & safety.

CSE-VS300/CSE-VS600 2 Rev. 1/29/02
OWNER/USER RESPONSIBILITY
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this vehicle stand. Personnel involved in the
use and operation of equipment shall be careful,
competent, trained, and qualified in the safe operation of
the equipment and its proper use when servicing motor
vehicles and their components. Warning information
should be emphasized and understood. If the operator is
not fluent in English, the manufacturer’s instructions and
warnings shall be read to and discussed with the operator
in the operator’s native language by the purchaser/owner,
making sure that the operator comprehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturer’s instructions and pertinent
warning information. Owner and/or user is responsible
for keeping all warning labels and instruction manuals
legible and intact. Replacement labels and literature are
available from the manufacturer.
INSPECTION
Visual inspection should be made before each use of the
vehicle stand. Any stand which appears to be damaged in
any way, is found to be badly worn, or operates
abnormally must be removed from service. If the stand is
accidentally subjected to an abnormal load or shock it
must be inspected by a manufacturer’s authorized repair
facility immediately. It is recommended that an annual
inspection of the stand be made by a manufacturer’s
authorized repair facility and that any defective parts,
decals, or warning labels be replaced with manufacturer’s
specified parts. All repairs must be made by a factory
authorized service center. A list of authorized repair
facilities is available from the manufacturer.
MAINTENANCE INSTRUCTIONS
Oil all release handle moving parts and be sure they
continue to work properly.
ASSEMBLY INSTRUCTIONS
Remove both stands and ratcheting posts from box. Insert
posts into stands.Bend in tab on side of collar using a
punch and hammer. Lift release lever and lift ratcheting
bar to desired height. Check to make sure the dog
engages each tooth properly on the ratcheting post.
OPERATING INSTRUCTIONS
Begin by setting parking brake on vehicle and blocking
all wheels. Make sure vehicle is raised to desired height
and is stable. Extend the post to height close to the
support member. Check the load locking and release
handle to insure that the dog portion has engaged a
tooth on the post.Make sure both jack stands are at an
equal height and will support the load equally when the
lifting device is removed.Place jack stands carefully under
support points specified by vehicle manufacturer. Do not
crawl under vehicle when placing or removing stands!
SLOWLY lower the load onto the jack stands and check to
insure the load is located on the center portion of the
post saddle. Check the load for stability. If the load is NOT
located on the center of the post saddle, or if the load is
not stable, re-lift the load and reposition the jack stands
to insure proper loading before continuing with work or
repairs. NOTE: When using jack stands for body shop
work such as straightening of frame and/or body of
vehicle, use caster wheel type jack stand dollies to
prevent load from being pulled off jack stands. When
removing stands, carefully raise vehicle enough to clear
the stands, making sure the vehicle remains stable.
Remove stands, being careful not to crawl under vehicle
while doing so. Carefully lower vehicle to floor.
Capacity . . . . . . . . . . . . . . . . . . . . . . . . .3 Ton
Low Height . . . . . . . . . . . . . . . . . . . . . . . .12"
Raised Height . . . . . . . . . . . . . . . . . . .17-1/4"
Base . . . . . . . . . . . . . . . . . . . . . . . .7-1/2" x 8"
Shipping Weight . . . . . . . . . . . . . . . . .21 Lbs.
CSE-VS300 SPECIFICATIONS
Capacity . . . . . . . . . . . . . . . . . . . . . . . . .6 Ton
Low Height . . . . . . . . . . . . . . . . . . . .16-9/16"
Raised Height . . . . . . . . . . . . . . . . . . . . . .26"
Base . . . . . . . . . . . . . . . . . . . . . . .9-3/4" x 11"
Shipping Weight . . . . . . . . . . . . . .38-1/2 Lbs.
CSE-VS600 SPECIFICATIONS

CSE-VS300/CSE-VS600 3 Rev. 1/29/02
PARTS BREAKDOWN - CSE-VS300/CSE-VS600
Post
Saddle
Tab
Base
Load Locking
and Release
Handle
Note: Parts are not available due to safety precautions.

CSE-VS300/CSE-VS600 4 Rev. 1/29/02
WARRANTY COVERAGE
Cornwell Quality Tools Company (“Cornwell”) warrants against defects in material and workmanship on this product for a period of
TWO (2) YEARS from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at
its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials.
This warranty does not cover any damage to this product that results from accident, abuse, misuse, natural or personal disaster, or
any unauthorized disassembly, repair, or modification. Repairs, disassembly and modification are only authorized to be made by
Cornwell or a warranty service center approved by Cornwell.
WARRANTY SERVICE
To obtain warranty service, contact your Cornwell dealer.
EXCLUSIONS AND LIMITATIONS
THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND
CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. CORNWELL SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING, TO THE EXTENT PERMITTED BY APPLICABLE LAW, ANY WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. IF CORNWELL CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES UNDER THIS LIMITED WARRANTY,
ALL SUCH IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
IN NO EVENT SHALL CORNWELL BE LIABLE TO THE PURCHASER OR TO THE USER OF A CORNWELL PRODUCT FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT, OR
ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, WITHOUT LIMITATION, EXPENSES, LOST REVENUES, LOST SAVINGS, LOST
PROFITS, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE PURCHASE, USE OR INABILITY TO USE THE
CORNWELL PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitation on the
duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary by state.
Cornwell Quality Tools Company
667 Seville Road • Wadsworth, OH 44281-1094
