corob D600 extra User manual

207119 - ENGLISH V3.0 - R1 (04/2014)
COROB™ D600 - D700 - D800TX
Automatic dispenser
User’s Manual

- 2 -
COROB™ D600 - D700 - D800TX
User’s manual
Automatic dispenser
COROB™ D600 - D700 - D800TX
Version 3.0 - R1 (04/2014)
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
© COPYRIGHT 2014, COROB S.p.A.
All rights reserved in all countries
If you require additional copies of this manual or further technical information about it, please write to:
COROB S.p.A.
Via Agricoltura 103 • 41038 San Felice s/P • Modena • Italy
Phone: [phone] • Fax: [phone]
Web site: www.corob.com
Email: [email protected]
INTELLECTUAL PROPERTY RIGHTS AND DISCLAIMER
No part of this manual may be translated into any other languages and/or adapted and/or reproduced in any form, or by any means, electronic
or mechanical, including but not limited to photocopying and recording, without prior written permission of COROB S.p.A..
COROB™ is a registered trademark and/or commercial trademark used on an exclusive basis by COROB S.p.A. and its afliated companies
(hereinafter “COROB”).
A failure of a trademark to appear hereunder does not mean that COROB does not use the trademark in question nor does it constitute a waiver
by COROB of any related intellectual property rights.
Valuable proprietary technical information contained in the present manual are referring to proprietary know-how, designs, drawings and/or
applications used on an exclusive basis by COROB frequently covered by Patents and/or Patent Applications and thus protected by International
and National Intellectual Property Laws.
Unless otherwise indicated, all references to other companies other than COROB and its afliated companies, their names, data and addresses
used in the screens and/or examples are purely coincidental and serve as a reference only to clarify the use of the COROB™ products.
COROB has carefully reviewed the wording and imagines contained in the present manual, nevertheless COROB reserves the right to modify and/
or update the information herein to correct editorial errors and/or inaccuracy of the information herein without notice or commitment on its part.
The present manual contains all information necessary for the foreseeable and normal use of the COROB™ products by the nal user.
The manual does not contain guidelines and/or information for product repair. For safety reasons, only trained and authorized technical personnel
should perform such interventions. Failure to do so may result in personal injury or damage to the product.
For the purpose mentioned above, COROB has appointed authorized technical personnel.
Authorized technical personnel shall mean technicians who have attended a technical training course held by COROB and/or its afliated
companies.
Unauthorized interventions could void the warranty coverage of your COROB™ product pursuant to the sales contract or to the General Sales
Conditions of COROB. COROB can be held responsible only within the limits of the warranty coverage provided by the General Sales Conditions.
COROB does not intend to limit or exclude its liability against any statutory provisions under any applicable law. Therefore the reference to above
warranty limitations or exclusions may not apply.
The nal user can ask COROB or visit the web site www.corob.com for contact details about the nearest authorized technical service.

- 3 - COROB™ D600 - D700 - D800TX
QUICK GUIDE
At the beginning of the working day
• Check that the nozzle center is clean.
• (With humidier system for solvent-based colorants or without humidier system) Check that the sponge is
clean and saturated; if it is necessary to saturate, use only appropriate liquid (the choice of the liquid depends
on the nature of the colorants, and must be done directly by the manufacturer of the products used).
• (With humidier system for water-based colorants) Check that the water in the bottle is not below the
minimum level.
• Carry out system Initialization and Purge.
Things to remember
• Never let the machine OFF.
• In the canisters, stirring of each colorant takes place automatically (stirring times can however be customized).
• Be careful not to ll the canisters with too much colorant. In case of overlling, act as indicated in the user’s
manual.
• The colorant to be poured inside the canisters must be stirred manually. Do not use automatic shakers.
• Close the canisters with their lids right after lling operations.
• Remember to update accordingly the canisters lling levels via the management software.
• (With humidier system for solvent-based colorants or without humidier system) The sponge must be
saturated at least twice a week (the frequency of intervention is indicative, since it depends on the nature of
colorants and the environment conditions).
• (With humidier system for water-based colorants) Top up the water bottle as soon as the minimum level is
reached. Do not exceed the maximum level.
At the end of the working day
• Rell the canisters.
• Update the canister lling levels in the management software.
• Shut down the computer. Do not shut off the machine.
It is recommended to carefully read the user’s manual.
COROB™ AUTOMATIC DISPENSER

- 4 -
COROB™ D600 - D700 - D800TX

- 5 - COROB™ D600 - D700 - D800TX
CONTENTS
1 GENERAL INFORMATION...........................................................................................................7
1.1 Purpose and use of this manual........................................................................................... 7
1.1.1 Conventionally used graphics...................................................................................7
1.2 Denitions........................................................................................................................ 7
2 FEATURES ................................................................................................................................. 9
2.1 Description of the machine .................................................................................................9
2.2 Description of units ......................................................................................................... 10
2.3 Standard and optional congurations ................................................................................. 12
2.4 Usable cans.................................................................................................................... 12
2.5 Intended use .................................................................................................................. 13
2.6 Identifying information..................................................................................................... 13
3 SAFETY ................................................................................................................................... 15
3.1 Safety warnings and unauthorized use ............................................................................... 15
3.2 Warnings on the use of colorants....................................................................................... 16
3.3 Residual risks ................................................................................................................. 17
3.4 Position of labels ............................................................................................................. 18
3.5 Safety devices ................................................................................................................ 19
3.6 Requirements of the installation site ................................................................................. 20
4 SHIPPING AND HANDLING...................................................................................................... 21
4.1 General warnings ............................................................................................................ 21
4.2 Unpacking and placement ................................................................................................ 21
4.2.1 Adjusting the support feet..................................................................................... 24
4.2.2 Standard material supplied.................................................................................... 25
4.3 Installation..................................................................................................................... 25
4.4 Storage ......................................................................................................................... 25
4.5 Disposal and recycling ..................................................................................................... 26
5 START-UP ............................................................................................................................... 27
5.1 General warnings ............................................................................................................ 27
5.2 Control devices and connections........................................................................................ 28
5.3 Electrical connection and start-up...................................................................................... 29
5.4 Initialization ................................................................................................................... 29
5.5 Emergency stop .............................................................................................................. 30
5.6 Shut-down ..................................................................................................................... 30
6 USING THE DISPENSER........................................................................................................... 31
6.1 General warnings ............................................................................................................ 31
6.2 At the beginning of the working day................................................................................... 31
6.3 Running the machine ....................................................................................................... 31
6.3.1 Loading the can - Semiautomatic shelf.................................................................... 32
6.3.2 Loading the can - Automatic shelf .......................................................................... 33
6.3.3 Loading the can - Panel roll conveyor...................................................................... 33
6.3.4 Use of the can centering device ............................................................................. 34
6.3.5 Use of the Bung Hole Locator................................................................................. 34
6.3.6 Punching the can ................................................................................................. 35
6.3.7 Dispensing .......................................................................................................... 36
6.4 Automatic processes........................................................................................................ 36
6.5 Relling the canisters....................................................................................................... 37
6.6 Troubleshooting .............................................................................................................. 39
7 ORDINARY MAINTENANCE ...................................................................................................... 41
7.1 General warnings ............................................................................................................ 41
7.2 Maintenance table ........................................................................................................... 41
7.3 Products to be used......................................................................................................... 41
7.4 External cleaning ............................................................................................................ 42

- 6 -
COROB™ D600 - D700 - D800TX
7.5 Cleaning the nozzle center................................................................................................ 42
7.6 Cleaning and moistening the humidier cap sponge ............................................................ 43
7.7 Checking and replacing the puncher .................................................................................. 45
7.8 Relling the humidier system bottle ................................................................................. 46
8 TECHNICAL SPECIFICATIONS .................................................................................................47
8.1 Technical data................................................................................................................. 47
8.2 Dimensions .................................................................................................................... 48
8.3 Declaration of conformity ................................................................................................. 50
8.4 Warranty........................................................................................................................ 50

GENERAL INFORMATION
- 7 - COROB™ D600 - D700 - D800TX
1 GENERAL INFORMATION
1.1 Purpose and use of this manual
Read this manual carefully before using the machine.
This manual, inserted in the product packing, contains instructions on the use and routine maintenance needed
to uphold the machine’s performance over time. The manual contains all information needed to correctly use the
machine and avoid any accident.
The manual is to be considered an integral part of the machine, and must be stored until it is fully dismantled.
The manual contains all information available at the time of preparation regarding the machine and any
accessories; for accessories, the manual includes any variations or changes that involve different operating
procedures.
Should it be lost or partially ruined, so that its contents can no longer be read in full, you must request a new
manual from the manufacturer.
If the images contained in this manual show the machine without the guards and/or employees
without personal protective equipment, it is only for the purpose to make clearer the discussion of
the issues.
Some of the illustrations in this manual were taken from prototypes; some details may differ on
machines in standard production.
1.1.1 Conventionally used graphics
Boldface type is used to highlight notes or information of particular importance to a topic.
DANGER
Indicates a risk of personal injury.
WARNING
Indicates a risk of damage to the machine that could interfere with its operation.
Indicates a risk of damage to the machine that could interfere with its operation.
Indicates situations and/or operations that involve the management software installed on the computer.
Indicates situations and/or operations that involve the management software installed on the computer.
1.2 Denitions
OPERATOR
A person familiar with the methods to produce paints or similar products, trained and authorized to operate and
use the machine by its controls and to load and unload production materials with all safety devices installed
and enabled. He or she must work only in safety conditions and is allowed to carry out routine maintenance
operations.
MAINTENANCE TECHNICIAN/INSTALLATION TECHNICIAN
Specialist prepared and trained in a technical eld (mechanical and electrical) and assigned by the manufacturer
to work on the machine to perform machine installation, adjustments, repair breakdowns or carry out
maintenance.

FEATURES
- 8 -
COROB™ D600 - D700 - D800TX

FEATURES
- 9 - COROB™ D600 - D700 - D800TX
2 FEATURES
2.1 Description of the machine
The COROB™ D600 - D700 - D800TX automatic dispensers are devices to automatically dispense uid
colorant products into containers (metal or plastic canisters, cans or bins) of the size indicated in this manual,
pre-lled with base, to produce nished products such as paints, dyes, enamels, and inks of the desired hue,
chosen by means of the machine management software.
The dispenser consists of:
1. Dispensing area and can handling system.
2. Control panel.
3. Upper covers.
4. Canister lling area.
5. Computer support surface.
The dispenser is fully managed by a normal personal computer that can be provided upon request, since it is
not supplied as standard together with the machine. The manufacturer can also supply a wide range of software
applications to manage all of the machine’s functions.
3
4
1
2
5
1
2
3
4
5
1
2
3
4
5

FEATURES
- 10 -
COROB™ D600 - D700 - D800TX
2.2 Description of units
Canisters
The machine canisters can be of different capacities and are suitable for containing
the product to be dispensed. Covers in the upper part of the machine provide
access for lling the canisters. Each canister has its own lid.
MAX
Nozzle Center
The ends of the dispensing pipes coming from the canisters converge and are xed
to the nozzle center, from which the tinting product to ll the can is dispensed.
Shelf
The can shelf allows for the correct positioning of the can under the dispensing
nozzles.
The Automatic shelf is managed by the computer that controls its
movement and checks that the can placed on it is actually the one selected
for dispensing. A photocell checks for the presence of the can and that the
shelf is correctly positioned.
The Semiautomatic shelf is commanded by the operator with the activation
buttons (two-handed control); the shelf stops when the can is detected by
the photocell.
Tipping panel roll conveyor system
An optional system made up of tipping panel roll conveyors is available to facilitate
the loading of cans; the conveyors are xed to the front panels of the machine
and allow heavy cans to be eased as far as the shelf.

FEATURES
- 11 - COROB™ D600 - D700 - D800TX
Can centering device
On the machine accessorized with punching system, a centering device is mounted
on the shelf. The can centering device is custom-made based on the size of the
cans to be handled and is useful for aligning them with the nozzle center, so that
the can lid is punched in the middle and dispensing takes place precisely into the
hole created. The can centering device is also available as an optional accessory
to the standard machine, useful for positioning pre-punched cans right under the
dispensing center.
Bung Hole Locator (B.H.L.)
This is a system that emits laser beams that allow the positioning of pre-punched
cans, so that the hole is in line with the center of the dispensing nozzles.
Nozzle Humidier Cap
Colorants tend to dry out; this tendency may be more or less strong depending
on the type of colorant and the environment conditions (temperature, relative
humidity, etc.). To prevent colorants from drying out in the nozzle center, the
machine is equipped with a humidier cap which requires constant maintenance.
The Lift-up Autocap is an automatic humidier cap which ensures that the
nozzles are hermetically sealed. It is managed by the software, which opens
it automatically before dispensing and closes it immediately afterwards.
Manually-operated automatic puncher
The puncher is a device that perforates the can lid. Punching is carried out by
the operator by pushing contemporaneously the semiautomatic shelf activation
buttons (two-handed control); thanks to the upward movement, the shelf pushes
the can resting on it against the puncher, and with a downward movement brings
it to the correct position for dispensing.
No-Dry-Nozzle Humidier System
The humidier system for water-based colorants guarantees the nozzles are
humidied not only with Autocap closed but also during dispensing. The air,
humidied by the water contained in the bottle, is transferred to the nozzles
area. Based on the humidity level detected, the system activates or shuts off
whenever needed.
The humidier system for solvent-based colorants humidies the nozzles when
Autocap is closed. The solvent, contained in a small tank inside the Autocap,
keeps the nozzles area constantly saturated.
The two systems can be used individually or together according to the tinting
system used on the machine.

FEATURES
- 12 -
COROB™ D600 - D700 - D800TX
2.3 Standard and optional congurations
D600 TE D600 TI D700 D800TX
Canister capacity
3 Quarts - 4 Quarts - 6 Quarts - 4 Gallons (3 - 4 - 6 - 15 liters)
9.5 Quarts - 5.3 Gallons (9 - 20 liters)
(only on large additional canister modules)
Number of circuits maximum 24 maximum 32
Circuit with Standard pump standard
Nozzle center ow diameter*
1.10” (28 mm) (16)
1.54” (39 mm) (17-20)
1.77” (45 mm) (21-24)
1.10” (28 mm) (16)
1.54” (39 mm) (17-20)
1.77” (45 mm) (21-32)
Punching diameter 1.85” (47 mm) (20)
2.17” (55 mm) (21-24)
47 mm (20)
55 mm (21-32)
Additional canister modules maximum 2 maximum 4
Lift-up Autocap standard
Semiautomatic shelf standard optional standard
Automatic shelf optional standard \ optional
Manually-operated automatic
puncher optional (with semiautomatic shelf) optional optional (with semiautomatic shelf)
Panel roll conveyors standard optional
Laser Bung Hole Locator
(B.H.L.) optional
No-Dry-Nozzle Humidier
System optional
Circuit with LAB pump optional
Circuit with HF pump** optional
* Hole diameter for pre-punched cans = ow diameter + 0.59” (15 mm). The diameter may also vary based on the partition of water/solvent
circuits of the machine. ** One HF circuit replaces two standard circuits.
2.4 Usable cans
D600 TE D600 TI D700 D800TX
Standard With
puncher Standard With puncher Standard With puncher Standard With puncher
MAX
19.9”
(505 mm)
17.7”
(450 mm)
15.9”
(405 mm)
13.6”
(345 mm)
19.3”
(490 mm)
16.9”
(430 mm)
17.7”
(450 mm)
15.4”
(390 mm)
MIN
*
2.8”
(70 mm)
5.1”
(130 mm)
2.4”
(61.5 mm)
5.1”
(130 mm)
2.8”
(70 mm)
5.1”
(130 mm)
2.8”
(70 mm)
6.1”
(155 mm)
MAX 14.2”
(360 mm) 13.4”
(340 mm)
12.6”
(320 mm)
14.2”
(360 mm)
14.2”
(360 mm)
9.3”
(235 mm)
MIN
2.3”
(60 mm)
3.9”
(100 mm)
2.3”
(60 mm)
3.9”
(100 mm)
2.3”
(60 mm)
3.9”
(100 mm)
3.9”
(100 mm)
* Due to the high ll level of 1-Pint and 1-Quart cans (0.5 and 1-liter cans), COROB advises not to perforate them.

FEATURES
- 13 - COROB™ D600 - D700 - D800TX
2.5 Intended use
The machine is intended for professional use to dispense colorants in small, medium and large point of sales or
professional paint stores.
The machine must be used only with cans within the limits set forth in chapter 2.4 (Usable cans), with the
colorants specied in the table of chapter 8.1 (Technical data) and according to the procedures described in this
manual.
Any use of the machine other than that stated, which cannot be implied or deduced from this manual, is to be
considered improper and unintended therefore it voids any manufacturer’s liability arising from non-compliance
with these requirements.
2.6 Identifying information
The machine has an identication plate (chapter 3.4) indicating:
1. Manufacturer’s name.
2. CE and WEEE marking.
3. Machine model.
4. Year of manufacture.
5. Serial number.
6. Electrical specications.
Do not remove or tamper with the identication plate in any way.

SAFETY
- 14 -
COROB™ D600 - D700 - D800TX

SAFETY
- 15 - COROB™ D600 - D700 - D800TX
3 SAFETY
3.1 Safety warnings and unauthorized use
COMPULSORY
• Read the user’s manual carefully before carrying out any operation on the machine.
• The machine must be used only for its intended purpose.
• Pay close attention to the signs on the machine.
• When prescribed, wear personal protective equipment.
• Only qualied and appropriately trained personnel (MAINTENANCE TECHNICIAN) are authorized to access the
machine parts protected by panels for extraordinary maintenance and repair interventions.
• Any routine maintenance intervention performed by the operator must be carried out with the machine off
and the power supply cable disconnected from the mains socket outlet.
• The machine must be used by a single operator. Unauthorized people who could reach or touch machine
parts during operation must not be admitted in the nearby area.
• The machine must be used by an operator who has attained the age of majority and is in suitable psychophysical
conditions dened by an occupational physician.
• The substances that may be used on the machine -- such as colorants, paints, solvents, lubricants and
cleansers -- may be hazardous to your health; handle, store and dispose of these substances in keeping with
current regulations and the instructions provided with the product.
PROHIBITED
• The machine must not be used with cans exceeding the limits set forth in chapter 2.4 (Usable cans) and with
colorants other than those specied in the technical data table.
• THE MACHINE MUST NOT BE USED IN AREAS AT RISK FOR EXPLOSION.
• The machine must not be employed for food use.
• The OPERATOR must not carry out operations reserved to the MAINTENANCE TECHNICIAN or the
INSTALLATION TECHNICIAN. The manufacturer CANNOT BE HELD RESPONSIBLE for damages deriving from
the non-observance of this prohibition.
• It is strictly forbidden to use the machine without protections or with any safety devices present on the
machine disabled, broken down, or removed. The panels must be kept closed at all times.
• Do not stare the light source of the Laser Bung Hole Locator (Class II laser product).
• If the machine catches re, never use water. Use only dry powder or carbon dioxide re extinguishers, and
strictly follow the instructions and warnings indicated by the manufacturer and listed on the extinguisher.
ELECTRICAL DANGER
• ALWAYS PLUG THE MACHINE INTO A SOCKET THAT ENSURES PROPER GROUNDING. The line must
be protected from overloads, short-circuits and direct contacts according to current accident prevention
regulations. Incorrect grounding may lead to the risk of electrical shock.
• The machine must not be powered by a power source having specications other than those listed on the
identication plate.
• In the event of a sudden power outage, when power returns the machine will automatically be switched on
to allow the automatic processes to prevent products from drying out.
• To prevent any risk of electrical shock or injuries, use the machine indoors only. It is prohibited to use the
machine outdoors where it could be subjected to rain or high humidity.
• Always unplug the power supply cable from the socket outlet before carrying out any maintenance operations.
• The machine is isolated from the power supply line when the power cable is disconnected; it must therefore
be installed near an easily accessible mains socket outlet.
• Do not use extension cords to power the machine.

SAFETY
- 16 -
COROB™ D600 - D700 - D800TX
• Do not use multisockets to connect other equipment to the same socket that powers the machine. Make
sure that the power supply of the equipment connected to the machine via serial port, like the computer, is
equipotential (which has a single access point to earth) because potential differences cause interferences
and/or damage to the serial ports.
• Periodically check the condition of the power supply cable; if it is damaged, replace it with a new cable
supplied by the manufacturer.
3.2 Warnings on the use of colorants
DANGER
The machine is suitable for use with tinting products in general. Scrupulously follow the instructions for use
given on the colorant package and carefully read the MATERIAL SAFETY DATA SHEETS (MSDS) that the
dealer or manufacturer of the product is required to provide.
Observe all of the safety instructions provided. When compulsory, wear the specied personal protective
equipment.
Below are some of the most common warnings and safety precautions provided by colorant manufacturers.
1. Harmful if swallowed.
2. Avoid eye and skin contact. In case of eye and skin contact, rinse with plenty of water.
3. Keep out of the reach of children.
4. When compulsory, wear the specied personal protective equipment.
5. In case of accidental product leaks or spills, thoroughly ventilate the area and proceed as indicated in this
manual and in the instructions provided with the product itself.
6. Do not dispose of colorant in the sewage system. Follow local regulations when disposing of waste.

SAFETY
- 17 - COROB™ D600 - D700 - D800TX
3.3 Residual risks
Risk Preventive measure P.P.E.
Re. in
the
manual
Risk of electrocution - Risk of electrical
shock if you power the machine from
a socket not equipped with ground
connection.
Power the machine through a grounded
socket outlet. \ch. 5
Risk of electrocution - Risk of electrical
shock if you access machine parts
protected by panels without rst cutting
off electrical power.
The operator is not authorized to access the
machine parts protected by panels.
For the maintenance technician: before
performing any maintenance intervention,
shut off the machine and disconnect the
power supply cable from the mains socket
outlet.
\
Dorsal/lumbar injuries - Handling
heavy loads when moving the machine
and loading cans on the shelf may cause
injuries.
Do not exceed the weight limits stated by
the current regulations in force (kg 20 for
women, kg 25 for men).
If necessary, use appropriate lifting
equipment.
ch. 4 - 6
Risk of falling objects / crushing -
When positioning a can on the shelf, there
is a risk it may fall onto the operator.
Position the can so that the whole base rests
on the shelf surface. ch. 6
Risk of crushing / entanglement - The
automatic movement of the humidier
cap and of the shelf may cause injuries.
The machine must be used by a single
operator.
Keep hands away from the dispensing area
at all times while the machine is operating.
ch. 6
Risk of crushing / entanglement
- During colorant relling operations,
the stirrer inside the canister may
automatically start rotating.
Before performing any intervention, press
the emergency button. ch. 6.5
Risk of cuts - During the punching
operations or maintenance operations on
the punching device, the contact with the
puncher blade may cause injuries.
The machine must be used by a single
operator.
Keep hands away from the dispensing area
at all times while the machine is operating.
Use the special tool to remove the puncher.
ch. 6 - 7
Risk of slipping / falling - Misuse of the
shelf may cause injuries. Do not climb onto the shelf and/or sit on it. ch. 6.3
Risk of explosion - Fumes generated
by the colorants used may cause an
explosion.
Do not use the machine in areas at risk for
explosion. \
Risk of exposure to laser beam - The
Bung Hole Locator (B.H.L.) uses red laser
light sources which can be potentially
dangerous for the eyes.
Avoid staring at the light source. ch. 6
Risk of poisoning and sensitization -
Fumes generated by the colorants used
may cause poisoning and/or sensitization
during canister relling operations,
machine cleaning and disposal.
Read the warnings reported in the Material
Safety Data Sheets of the colorants used.
The MSDS must be provided by the colorant
manufacturer.
Keep the room suitably ventilated.
Personal
Protective
Equipment
as
specied
in MSDS.
ch. 3.2 - 4
- 6 - 7

SAFETY
- 18 -
COROB™ D600 - D700 - D800TX
3.4 Position of labels
1. Identication plate (chapter 2.4)
2. Label “General warnings”
3. Label “Risk of crushing”
4. Label “Risk of cuts”
5. Label “Laser danger”
6. Label “Serial ports”
Do not remove or make illegible the safety or instruction labels. Replace any label which has become
illegible or is missing, by requesting it to the manufacturer.
MODEL
YEAR
S/N
726109116X
726106285X
LASERRADIATION
CLASSIILASERPRODUCT
DONOTSTAREINTO BEAM
1mWmax
630-650nm
EN60825-1:2003
7261010772
6
MODEL
YEAR
S/ N
1
2
726106285X
3
726109116X
4
5
LASER RADIATION
CLASS II LASER PRODUCT
DO NOT STARE INTO BEAM
1mWmax
630-650 nm
EN 60825-1:2003
7261010772

SAFETY
- 19 - COROB™ D600 - D700 - D800TX
3.5 Safety devices
D600 TE D600 TI D700 D800TX
1. Emergency button.    
2. Shelf upper safety plate
(with automatic shelf).   
3. Shelf lower safety plate.   
4. Safety button to enable shelf operation
(with semiautomatic shelf).    
DANGER
In the event of a breakdown of the safety devices, it is forbidden to use components not provided by the
manufacturer. In case of need, contact only the service organization authorized by the manufacturer.
3
2
1
1
2
3
1
4
3

SAFETY
- 20 -
COROB™ D600 - D700 - D800TX
3.6 Requirements of the installation site
Environment requirements for the site where the machine is to be used:
• Clean and dust-free.
• With level and stable oor.
• Fitted with a grounded power supply socket.
• Equipped with sufcient lighting to ensure good visibility from every point of the machine (light value not
lower than 500 Lux).
• Ventilated to prevent the concentration of harmful fumes.
• Temperature between 10 °C (50 °F) and 40 °C (104 °F) and relative humidity between 5% and 85%, without
condensation.
WARNING
The environment working conditions are strictly related to the type of colorants used (ask for information from
the paint manufacturer). The requirements indicated above are valid for the machine only.
Do not place the machine near heat sources or in direct sunlight. Also humidity sources should be avoided. The
machine must be used indoors only.
Environment conditions outside the values indicated (chapter 8.1) may cause serious damage to the machine,
especially the electronic equipment.
DANGER
When using colorants containing volatile solvents the room in which the machine is installed must be
spacious, with good ventilation (air exchange) and no type of parts must be leant against or stocked close to
the machine.
