corob Flex 900 User manual

PRELIMINARY VERSION (05/2014)207153 - ENGLISH
COROB™ FLEX 900
Automatic Dispenser
User’s Manual

COROB™ FLEX 900
User’s Manual
Automatic Dispenser
COROB™ FLEX 900
Preliminary version (05/2014)
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
© COPYRIGHT 2014, COROB S.p.A.
All rights reserved in all countries
If you require additional copies of this manual or further technical information about it, please write to:
COROB S.p.A.
Via Agricoltura 103 • 41038 San Felice s/P • Modena • Italy
Phone: [phone] • Fax: [phone]
Web site: www.corob.com
Email: [email protected]
INTELLECTUAL PROPERTY RIGHTS AND DISCLAIMER
No part of this manual may be translated into any other languages and/or adapted and/or reproduced in any form, or by any means, electronic
or mechanical, including but not limited to photocopying and recording, without prior written permission of COROB S.p.A..
COROB™ is a registered trademark and/or commercial trademark used on an exclusive basis by COROB S.p.A. and its afliated companies
(hereinafter “COROB”).
A failure of a trademark to appear hereunder does not mean that COROB does not use the trademark in question nor does it constitute a waiver
by COROB of any related intellectual property rights.
Valuable proprietary technical information contained in the present manual are referring to proprietary know-how, designs, drawings and/or
applications used on an exclusive basis by COROB frequently covered by Patents and/or Patent Applications and thus protected by International
and National Intellectual Property Laws.
Unless otherwise indicated, all references to other companies other than COROB and its afliated companies, their names, data and addresses
used in the screens and/or examples are purely coincidental and serve as a reference only to clarify the use of the COROB™ products.
COROB has carefully reviewed the wording and imagines contained in the present manual, nevertheless COROB reserves the right to modify
and/or update the information herein to correct editorial errors and/or inaccuracy of the information herein without notice or commitment on
its part.
The present manual contains all information necessary for the foreseeable and normal use of the COROB™ products by the nal user
.
The manual does not contain guidelines and/or information for product repair. For safety reasons, only trained and authorized technical
personnel should perform such interventions. Failure to do so may result in personal injury or damage to the product.
For the purpose mentioned above, COROB has appointed authorized technical personnel.
Authorized technical personnel shall mean technicians who have attended a technical training course held by COROB and/or its afliated
companies.
Unauthorized interventions could void the warranty coverage of your COROB™ product pursuant to the sales contract or to the General Sales
Conditions of COROB. COROB can be held responsible only within the limits of the warranty coverage provided by the General Sales Conditions.
COROB does not intend to limit or exclude its liability against any statutory provisions under any applicable law. Therefore the reference to
above warranty limitations or exclusions may not apply.
The nal user can ask COROB or visit the web site www.corob.com for contact details about the nearest authorized technical service.
PRODUCT DISPOSAL AND RECYCLING
This equipment must not be disposed of with unsorted municipal waste. Carry
out a separate collection.
Pursuant to the WEEE Directive, collection, treatment, recovery and environmentally
sound disposal of Waste Electrical and Electronic Equipment (WEEE) shall be carried out
in compliance with the national measures of each EU-Member State implementing the
Directive.
For more information about proper disposal and recycling of your COROB™ product,
please contact the company at the address info[email protected].
For the colorants remaining in the canisters, for the machine components most soiled
with colorant and if any products have been used on the machine that require special
disposal procedures, follow local regulations when disposing of waste.

COROB™ FLEX 900
COROB™ AUTOMATIC DISPENSER
QUICK GUIDE
At the beginning of the working day
• Check that the nozzle center is clean.
• Check that the sponge is clean and saturated; if it is necessary to saturate, use only appropriate liquid (the
choice of the liquid depends on the nature of the colorants, and must be done directly by the manufacturer
of the products used).
• Carry out system Initialization and Purge.
Things to remember
• Never let the machine OFF.
• In the canisters, stirring of each colorant takes place automatically (stirring times can however be
customized).
• Be careful not to ll the canisters with too much colorant. In case of overlling, act as indicated in the user’s
manual.
• The colorant to be poured inside the canisters must be stirred manually. Do not use automatic shakers.
• Close the canisters with their lids right after lling operations.
• Remember to update accordingly the canisters lling levels via the management software.
• The sponge must be saturated at least twice a week (the frequency of intervention is indicative, since it
depends on the nature of colorants and the environment conditions).
At the end of the working day
• Rell the canisters.
• Update the canister lling levels in the management software.
• Shut down the computer. Do not shut off the machine.
It is recommended to carefully read the user’s manual.

COROB™ FLEX 900

- 1
COROB™ FLEX 900
CONTENTS
1 GENERAL INFORMATION.........................................................................................................3
1.1 Purpose and use of this manual......................................................................................... 3
1.1.1 Conventionally used graphics.................................................................................3
1.2 Identifying information.....................................................................................................3
1.3 Intended and improper use ..............................................................................................4
1.4 Denitions ...................................................................................................................4
2 SAFETY ...................................................................................................................................5
2.1 General warnings ............................................................................................................ 5
2.2 Warnings on the use of colorants....................................................................................... 6
2.3 Residual risks ................................................................................................................. 7
2.4 Position of labels ............................................................................................................. 8
3 FEATURES ...............................................................................................................................9
3.1 Description of the machine ...............................................................................................9
3.2 Description of units ....................................................................................................... 10
3.3 Standard and optional congurations ............................................................................... 12
3.4 Usable cans.................................................................................................................. 12
4 SHIPPING, HANDLING AND UNPACKING............................................................................... 13
4.1 General warnings .......................................................................................................... 13
4.2 Environment conditions of the installation site .................................................................. 13
4.3 Unpacking and placement .............................................................................................. 14
4.3.1 Adjusting the support feet................................................................................... 16
4.3.2 Standard material supplied.................................................................................. 17
4.4 Installation................................................................................................................... 17
4.5 Packing and handling..................................................................................................... 17
5 START-UP .............................................................................................................................19
5.1 General warnings .......................................................................................................... 19
5.2 Control devices and connections...................................................................................... 20
5.3 Electrical connection and start-up.................................................................................... 21
5.4 Machine conditions ........................................................................................................ 22
5.5 Initialization ................................................................................................................. 22
5.6 Use of the off-line button ............................................................................................... 22
5.7 Shut-down ................................................................................................................... 23
6 USING THE DISPENSER.........................................................................................................25
6.1 General warnings .......................................................................................................... 25
6.2 At the beginning of the working day................................................................................. 25
6.3 Running the machine .................................................................................................... 25
6.3.1 Adjusting the can shelf height.............................................................................. 26
6.3.2 Loading the can ................................................................................................. 26
6.3.3 Use of the can centering device ........................................................................... 27
6.3.4 Use of the Bung Hole Locator............................................................................... 27
6.3.5 Dispensing ........................................................................................................ 28
6.4 Automatic timed processes ............................................................................................. 28
6.5 Relling the canisters..................................................................................................... 29
6.6 Troubleshooting ............................................................................................................ 31
7 ORDINARY MAINTENANCE ....................................................................................................33
7.1 General warnings .......................................................................................................... 33
7.2 Maintenance table ......................................................................................................... 33
7.3 Products to be used....................................................................................................... 33
7.4 External cleaning .......................................................................................................... 34
7.5 Cleaning the nozzle center.............................................................................................. 34
CONTENTS

2 -
COROB™ FLEX 900
7.6 Cleaning and moistening the humidier cap sponge ........................................................... 36
8 TECHNICAL SPECIFICATIONS ...............................................................................................39
8.1 Technical data............................................................................................................... 39
8.2 Dimensions .................................................................................................................. 40
8.3 Declaration of conformity ............................................................................................... 40
8.4 Reference standards ...................................................................................................... 41
8.5 Warranty...................................................................................................................... 41
CONTENTS

GENERAL INFORMATION - 3
COROB™ FLEX 900
1 GENERAL INFORMATION
1.1 Purpose and use of this manual
This manual, inserted in the product packing, contains instructions on the use and routine maintenance needed
to uphold the machine’s performance over time.
Read this manual carefully before using the machine.
The manual is to be considered an integral part of the machine, and must be stored until it is fully dismantled.
The manual contains all information available at the time of preparation regarding the machine and any
accessories; for accessories, the manual includes any variations or changes that involve different operating
procedures.
Should it be lost or partially ruined, so that its contents can no longer be read in full, you must request a new
manual from the manufacturer.
Some of the illustrations in this manual were taken from prototypes; some details may differ on
machines in standard production.
1.1.1 Conventionally used graphics
Boldface type is used to highlight notes or information of particular importance to a topic.
DANGER
Indicates a risk of personal injury.
WARNING
Indicates a risk of damage to the machine that could interfere with its operation.
Indicates important instructions referring to precautionary rules and/or measures to adopt.
Indicates situations and/or operations that involve the management software installed on the computer.
Indicates that to carry out the intervention described, the use of the specied tools is required.
1.2 Identifying information
The machine has an identication plate (chapter 2.4), indicating:
1. Manufacturer’s name.
2. CE and WEEE marking.
3. Machine model.
4. Year of manufacture.
5. Serial number.
6. Electrical specications.
Do not remove or tamper with the identication plate in any way.

4 - GENERAL INFORMATION
COROB™ FLEX 900
1.3 Intended and improper use
The machine must be used only within the limitations set forth by the technical specications and according to
the procedures described in this manual.
Any use other than that stated, which cannot be implied or deduced from this manual, is to be considered
prohibited.
1.4 Denitions
OPERATOR
A person familiar with the methods to produce paints or similar products, assigned to
operate and use the machine by its controls and to load and unload production materials
with all safety devices enabled. He or she must work only in safety conditions and is
allowed to carry out routine maintenance operations.
MAINTENANCE
TECHNICIAN
Specialist prepared and trained in a technical eld (mechanical and electrical) and
assigned to work on the machine to perform adjustments, repair breakdowns or carry
out maintenance.

SAFETY - 5
COROB™ FLEX 900
2 SAFETY
2.1 General warnings
COMPULSORY
• Read the user’s manual carefully before carrying out any operation on the machine.
• The machine must be used only for its intended purpose.
• Pay close attention to the signs on the machine.
• The substances that may be used on the machine -- such as colorants, paints, solvents, lubricants and
cleansers -- may be hazardous to your health; handle, store and dispose of these substances in keeping
with current regulations and the instructions provided with the product.
• Only qualied and appropriately trained personnel (MAINTENANCE TECHNICIANS) are authorized to access
the machine parts protected by panels for maintenance and repair interventions.
• During routine maintenance operations, scrupulously follow the safety instructions given in the corresponding
chapters before accessing the dangerous area.
PROHIBITED
• The OPERATOR must not carry out operations reserved to the MAINTENANCE TECHNICIAN. The manufacturer
CANNOT BE HELD RESPONSIBLE for damages deriving from the non-observance of this prohibition.
• It is strictly forbidden to bypass or disable the protections and any safety devices present on the machine.
• The panels must be kept closed at all times.
• THE MACHINE IS NOT EXPLOSION-PROOF AND MUST NOT BE USED IN AREAS AT RISK FOR
EXPLOSION.
• Do not stare the light source of the Laser Bung Hole Locator (Class II laser product).
• If the machine catches re, never use water. Use only dry powder or carbon dioxide re extinguishers, and
strictly follow the instructions and warnings indicated by the manufacturer and listed on the extinguisher.
ELECTRICAL DANGER
• In the event of a sudden power outage, when power returns the machine will automatically be switched on
to allow the automatic processes to prevent products from drying out.
• The machine must not be powered by a power source having specications other than those listed on the
identication plate.
• Incorrect grounding may lead to the risk of electrical shock; always plug the machine into a socket that
ensures proper grounding. The line must be protected from overloads, short-circuits and direct contacts
according to current accident prevention regulations.
• To prevent any risk of electric shock or injuries, the machine must be used indoors only.
• Always unplug the power supply cable from the socket outlet before carrying out any maintenance operations.
• The machine is isolated from the power supply line when the power cable is disconnected; it must therefore
be installed near an easily accessible mains socket outlet.
• Do not use extension cords to power the machine.
• Do not use multisockets to connect other equipment to the same socket that powers the machine.
• Periodically check the condition of the power supply cable; if it is damaged, replace it with a new cable
supplied by the manufacturer.

6 - SAFETY
COROB™ FLEX 900
2.2 Warnings on the use of colorants
DANGER
The machine is suitable for use with tinting products in general. Scrupulously follow the instructions for use
given on the colorant package and carefully read the SAFETY DATA SHEET that the dealer or manufacturer
of the product is required to provide. Observe all of the safety instructions provided. When compulsory, use
personal protection equipment for eyes and hands.
Below are some of the most common warnings and safety precautions provided by colorant manufacturers.
1. Harmful if swallowed.
2. Avoid eye and skin contact. In case of eye and skin contact, rinse with plenty of water.
3. Keep out of the reach of children.
4. When compulsory, wear protecting equipment for eyes and hands.
5. In case of accidental product leaks or spills, thoroughly ventilate the area and proceed as indicated in this
manual and in the instructions provided with the product itself.
6. Do not dispose of colorant in the sewage system. Follow local regulations when disposing of waste.

SAFETY - 7
COROB™ FLEX 900
2.3 Residual risks
Risk Preventive measure Re. in the
manual
Risk of crushing during the cans
loading and unloading operations.
Wear appropriate personal protective equipment
(shoes and gloves). chapter 6
Risk of electrocution if you
perform any operation without
rst cutting off electrical power.
The operator is not authorized to access the machine
parts protected by panels.
Before removing the panels, unplug the power supply
cable from the mains socket outlet.
chapter 2.1
Risk of electrocution caused by
high leakage current. Power the machine through a grounded socket outlet. chapter 5.3
Dorsal/lumbar injuries caused by
handling of heavy loads.
Do not exceed the weight limits stated by the
current regulations in force (kg 20 for women, kg
30 for men).
chapter 6
Contact or inhalation of colorants
during the canister relling
operations. Keep the room suitably ventilated.
Wear appropriate personal protective equipment
(safety goggles, gloves and mask).
chapter 2.2
chapter 6.5
Contact or inhalation of colorants
during the cleaning operations of
the nozzle center and moistening
of the humidier cap sponge.
chapter 2.2
chapter 7
Exposure to laser beam.
The Bung Hole Locator (B.H.L.) uses red laser light
sources which can be potentially dangerous for the eyes.
AVOID STARING AT THE LIGHT SOURCE.
chapter 6
Fire due to the use of colorants
containing volatile solvents.
Do not use naked ames, electrical tools or other
types of devices that could cause sparks or re
hazards close to the machine.
The room in which the machine is installed must be
spacious, with good ventilation (air exchange) and no
type of parts must be leant against or stocked close to
the machine.
chapter 4.2
Canister top up must be carried out opening one canister
at the time.
If during this operation, some colorant should spill out of
the canister, immediately disconnect the machine from
the mains before cleaning.
chapter 6.5

8 - SAFETY
COROB™ FLEX 900
2.4 Position of labels
MODEL
YEAR
S/N
COMMESSA
CODICEMACCHINA
7261011370
LASERRADIATION
CLASSIILASERPRODUCT
DONOTSTAREINTOBEAM
1mWmax
630-650nm
EN60825-1:2003
7261010772
1
2
LASER RADIATION
CLASS II LASER PRODUCT
DO NOT STARE INTO BEAM
1mWmax
630-650 nm
EN 60825-1:2003
7261010772
3
4
7261011370
MODEL
YEAR
S/N
XXXXXXXX
XXXXX
XXXXX
COROB S.p.A.
Via Agricoltura 103
S. Felice s/P (MO) ITALY
Figure 1
1. Identication plate (chapter 1.2)
2. Label “General warnings”
3. Label “Laser danger” (only with Laser BHL)
4. Label “Electrical danger”
Do not remove or make illegible the safety or instruction labels. Replace any label which has become
illegible or is missing, by requesting it to the manufacturer.

FEATURES - 9
COROB™ FLEX 900
3 FEATURES
3.1 Description of the machine
The COROB™ FLEX 900 automatic dispenser is a device to automatically dispense uid colorant products into
containers (metal or plastic canisters, cans or bins) of the size indicated in this manual, pre-lled with base, to
produce nished products such as paints, dyes, enamels, and inks of the desired hue, chosen by means of the
machine management software.
1
3
2
4
5
Figure 2
The dispenser consists of:
1. Dispensing area and can handling system.
2. Off-line button.
3. Upper covers.
4. Canister lling area.
5. Computer support surface.
The dispenser is fully managed by a normal personal computer that can be provided upon request, since it is
not supplied as standard together with the machine. The manufacturer can also supply a wide range of software
applications to manage all of the machine’s functions.

10 - FEATURES
COROB™ FLEX 900
3.2 Description of units
Canisters
The machine canisters are suitable for containing the product to be dispensed.
Covers in the upper part of the machine provide access for lling the canisters.
Nozzle Center
The ends of the dispensing pipes coming from the canisters converge and
are xed to the nozzle center, from which the tinting product to ll the can is
dispensed.
Shelf
The can shelf allows for the correct positioning of the can under the dispensing
nozzles.
The Lift manual shelf is xed to the machine and can be raised or lowered
by the operator. The shelf is provided with a locking handle that must be
pulled to release the shelf and allow it to be moved to the desired height.
Can centering device
The can centering device is useful for positioning pre-punched cans right under
the dispensing center and is custom-made based on the size of the cans to be
handled.
Bung Hole Locator (B.H.L.)
This is a system that emits laser beams that allow the positioning of pre-punched
cans, so that the hole is in line with the center of the dispensing nozzles.

FEATURES - 11
COROB™ FLEX 900
Nozzle Humidier Cap
Colorants tend to dry out; this tendency may be more or less strong depending on the type of colorant and
the environment conditions (temperature, relative humidity, etc.). To prevent colorants from drying out in the
nozzle center, the machine is equipped with a humidier cap which requires constant maintenance.
The Sliding cap is a simple cap, which opens thanks to the push applied
to the opening bar while the can is being positioned. The cap closes when
the can is removed. The system checks that the cap is properly opened
and conrms the can presence to begin dispensing.
The Sliding Autocap is an automatically activated cap, whose movement
is managed by the application program, which opens it automatically
before dispensing and closes it automatically immediately afterwards. A
photocell prevents dispensing from taking place when no can is resting
on the shelf.

12 - FEATURES
COROB™ FLEX 900
3.3 Standard and optional congurations
Canister capacity 2.3 liters
Number of circuits maximum 16
Circuit ow rate 0.2 l/min
Nozzle center ow diameter* 31 mm
Lift manual shelf standard
Sliding cap standard
Sliding Autocap optional
Laser Bung Hole Locator (B.H.L.) optional
Side computer support arm optional
* Hole diameter for pre-punched cans = ow diameter + 15 mm.
3.4 Usable cans
Humidier cap > sliding cap sliding autocap
Panels > sheet metal ABS sheet metal ABS
MAX
505 mm 490 mm 490 mm 475 mm
MIN
75 mm 60 mm 35 mm 20 mm
MAX
230 mm 340 mm

SHIPPING, HANDLING AND UNPACKING - 13
COROB™ FLEX 900
4 SHIPPING, HANDLING AND UNPACKING
4.1 General warnings
DANGER
To avoid personal injuries and property damage, use the utmost care and caution when handling the machine,
and carefully follow the instructions given in this chapter.
The packing must be handled only by skilled personnel using appropriate handling equipment.
4.2 Environment conditions of the installation site
Environment requirements for the site where the machine is to be used:
• Clean and dust-free.
• With level and stable oor.
• Fitted with a grounded power supply socket.
• Equipped with sufcient lighting to ensure good visibility from every point of the machine.
• Ventilated to prevent the concentration of harmful fumes.
• Temperature between 10 °C (50 °F) and 40 °C (104 °F) and relative humidity between 5% and 85%,
without condensation.
WARNING
The environment working conditions are strictly related to the type of colorants used (ask for information
from the paint manufacturer). The requirements indicated above are valid for the machine only.
Do not place the machine near heat sources or in direct sunlight. Also humidity sources should be avoided.
The machine must be used indoors only.
Environment conditions outside the values indicated (chapter 8.1) may cause serious damage to the machine,
especially the electronic equipment.
DANGER
When using colorants containing volatile solvents the room in which the machine is installed must be
spacious, with good ventilation (air exchange) and no type of parts must be leant against or stocked close
to the machine.
If the machine is installed near a wall, keep it at least 10 cm away to allow the upper covers to be
opened and prevent the cables from being crushed.

14 - SHIPPING, HANDLING AND UNPACKING
COROB™ FLEX 900
4.3 Unpacking and placement
1 x 10 mm
2 x 13 mm To remove the xing brackets
PH2 To x the packing cover
DANGER
The following procedure must be carried out by at least 2 people.
Store the packing material for future use, or dispose of it according to current regulations. In any case, we
recommend that you keep it for the entire duration of the machine warranty.
Make sure the packing has not suffered any damage or tampering during shipping; if so, contact the
authorized technical service or your dealer.
1. Remove cover A.
2. Remove cardboard box.
3. Remove machine wrapping.
1 32
B
A
Figure 3
DANGER
Should the machine appear damaged during shipping, do not attempt to start it and contact the authorized
technical service or dealer.
4. Slightly loosen the two screws that x the front bracket to the base of the pallet.
5. Lower the feet (chapter 4.3.1) until the wheels are no longer resting on the pallet surface.
6. Remove all screws and nuts that x the rear bracket to the machine and to the pallet.
7. Operating from the front side, with one person at each corner, tilt the machine frontally until the rear
bracket is free and can be removed by a third person.
8. Now remove the front bracket.

SHIPPING, HANDLING AND UNPACKING - 15
COROB™ FLEX 900
9. Raise the feet (chapter 4.3.1) until the wheels touch the pallet surface.
46
107 8
C
b
aa
3x
BA
Figure 4
10. Fix cover Afrontally to the pallet and place the two sliding plates Bpreviously removed from inside the
packing. Grasp then the machine on the sides, then slide it slowly to the ground along the cover.
11. Lower the feet (chapter 4.3.1) to support and level the machine properly, and make sure that the wheels
are not resting.

16 - SHIPPING, HANDLING AND UNPACKING
COROB™ FLEX 900
4.3.1 Adjusting the support feet
PH2 To open machine panels
1 x 17 mm To adjust machine feet
1 2
Figure 5
123
a b a
Figure 6
