corob EVOFLX-LW User manual

EVOFLX-LW
User manual
V1.0 - RB (2019)

User Manual
Automatic dispenser
EVOFLX-LW
Version 1.0 RB (02/2019)
ORIGINAL INSTRUCTIONS
© COPYRIGHT 2019, COROB Oy
All rights reserved in all countries
If you require additional copies of this manual or further technical information about it, please write to:
COROB Oy
Päivöläntie 5 • FIN-28400 Ulvila • FINLAND
Phone: [phone] • E-mail: [e-mail]
Web site: www.corob.com
INTELLECTUAL PROPERTY RIGHTS AND DISCLAIMER
No part of this manual may be translated into any other languages and/or adapted and/or reproduced in any form, or by
any means, electronic or mechanical, including but not limited to photocopying and recording, without prior written
permission of COROB Oy.
COROB™ is a registered trademark and/or commercial trademark used on an exclusive basis by COROB Oy and its
affiliated companies (hereinafter “COROB”).
A failure of a trademark to appear hereunder does not mean that COROB does not use the trademark in question nor
does it constitute a waiver by COROB of any related intellectual property rights.
Valuable proprietary technical information contained in the present manual are referring to proprietary know-how,
designs, drawings and/or applications used on an exclusive basis by COROB frequently covered by Patents and/or Patent
Applications and thus protected by International and National Intellectual Property Laws.
Unless otherwise indicated, all references to other companies other than COROB and its affiliated companies, their
names, data and addresses used in the screens and/or examples are purely coincidental and serve as a reference only to
clarify the use of the COROB™ products.
COROB has carefully reviewed the wording and imagines contained in the present manual, nevertheless COROB reserves
the right to modify and/or update the information herein to correct editorial errors and/or inaccuracy of the information
herein without notice or commitment on its part.
The present manual contains all information necessary for the foreseeable and normal use of the COROB™ products by
the final user.
The manual does not contain guidelines and/or information for product repair. For safety reasons, only trained and
authorized technical personnel should perform such interventions. Failure to do so may result in personal injury or
damage to the product.
For the purpose mentioned above, COROB has appointed authorized technical personnel.
Authorized technical personnel shall mean technicians who have attended a technical training course held by COROB
and/or its affiliated companies.
Unauthorized interventions could void the warranty coverage of your COROB™ product pursuant to the sales contract or
to the General Sales Conditions of COROB. COROB can be held responsible only within the limits of the warranty
coverage provided by the General Sales Conditions.
COROB does not intend to limit or exclude its liability against any statutory provisions under any applicable law.
Therefore the reference to above warranty limitations or exclusions may not apply.
The final user can ask COROB or visit the web site www.corob.com for contact details about the nearest authorized
technical service.

- 1 - COROB EVOFLX-LW
TABLE OF CONTENTS
1 QUICK GUIDE .................................................................................................................................................................3
2 GENERAL INFORMATION ..............................................................................................................................................4
2.1 Purpose and use of this manual..........................................................................................................................................................4
2.2 Definitions ..................................................................................................................................................................................................4
3 FEATURES.......................................................................................................................................................................5
3.1 Description of the machine..................................................................................................................................................................5
3.2 Description of units .................................................................................................................................................................................6
3.3 Usable cans ...........................................................................................................................................................................................8
3.4 Intended use and reasonably foreseeable misuse.......................................................................................................................9
3.5 Identifying information..........................................................................................................................................................................9
4 SAFETY .........................................................................................................................................................................10
4.1 Safety warnings and unauthorized use ....................................................................................................................................... 10
4.2 Warnings on the use of colorants .................................................................................................................................................. 11
4.3 Residual risks .......................................................................................................................................................................................... 12
4.4 Position of labels ................................................................................................................................................................................... 13
4.5 Safety devices ....................................................................................................................................................................................... 14
4.6 Emergency stop..................................................................................................................................................................................... 14
4.7 Requirements of the installation site ............................................................................................................................................. 15
5 SHIPPING AND HANDLING..........................................................................................................................................16
5.1 General warnings ................................................................................................................................................................................. 16
5.2 Unpacking and placement ............................................................................................................................................................ 16
5.3 Standard material supplied ............................................................................................................................................................... 17
5.4 Preparing the shelf for use ............................................................................................................................................................... 18
5.5 Storage...................................................................................................................................................................................................... 18
5.6 Disposal and recycling......................................................................................................................................................................... 18
6 START-UP .....................................................................................................................................................................19
6.1 General warnings ................................................................................................................................................................................. 19
6.2 Management computer...................................................................................................................................................................... 19
6.3 Control devices and connections.................................................................................................................................................... 19
6.4 Buttons and lamps ............................................................................................................................................................................... 20
6.5 OFF-line button and WHITE lamp.................................................................................................................................................... 21
6.6 Electrical connection and start-up ............................................................................................................................................. 21
6.7 Shut-down .......................................................................................................................................................................................... 21
7 USING THE DISPENSER................................................................................................................................................22
7.1 General warnings ................................................................................................................................................................................ 22
7.2 At the beginning of the working day............................................................................................................................................. 22
7.3 Running the machine .......................................................................................................................................................................... 22
7.3.1 Loading the can - manual shelf ........................................................................................................................................ 22
7.3.2 Loading the can - Semiautomatic shelf ...................................................................................................................... 23
7.3.3 Loading the can - Automatic shelf ............................................................................................................................. 24
7.3.4 Loading the can - Roll conveyor....................................................................................................................................... 24
7.3.5 Use of can centering device and Bung Hole Locater................................................................................................ 24
7.3.6 Punching the can with semiautomatic puncher ..................................................................................................... 25
7.3.7 Dispensing ............................................................................................................................................................................... 25
7.4 Automatic processes............................................................................................................................................................................ 25
7.5 Refilling the canisters........................................................................................................................................................................... 26
7.6 Troubleshooting .................................................................................................................................................................................. 29
8 ORDINARY MAINTENANCE .........................................................................................................................................30
8.1 General warnings ................................................................................................................................................................................. 30
8.2 Maintenance table ........................................................................................................................................................................... 30
8.3 Products to be used.............................................................................................................................................................................. 30
8.4 External cleaning ................................................................................................................................................................................. 31
8.5 Cleaning the nozzle center (humidifier cap) .............................................................................................................................. 31
8.6 Cleaning the nozzle center (INV) ..................................................................................................................................................... 32
8.7 Cleaning and moistening the sponge (humidifier cap) .................................................................................................. 32
8.8 Checking and replacing the puncher ...................................................................................................................................... 35
8.9 Refilling the humidifier bottle ......................................................................................................................................................... 36

COROB EVOFLX-LW - 2 -
9 TECHNICAL SPECIFICATIONS......................................................................................................................................37
9.1 Technical information ......................................................................................................................................................................... 37
9.2 Dimensions and weight...................................................................................................................................................................... 38
9.3 Declaration of conformity .................................................................................................................................................................. 38
9.4 Warranty ................................................................................................................................................................................................... 39
APPENDIX: EC DECLARATION ........................................................................................................................................40

- 3 - COROB EVOFLX-LW
1QUICKGUIDE
At the beginning of the working day
•Check that the nozzle center is clean.
•(With humidifier for solvent-based colorants or without humidifier) Check that the sponge is clean and
saturated; if it is necessary to saturate, use only appropriate liquid (the choice of the liquid depends on the nature of
the colorants, and must be done directly by the manufacturer of the products used).
•(With humidifier for water-based colorants) Check that the water in the bottle is not below the minimum level.
•Carry out system Purge (not necessary if the dispenser is equipped with Integrated Nozzle Valve System, INV).
Th i n g s to re m e m be r
•Never let the machine in the OFF position.
•In the canisters, stirring of each colorant takes place automatically (stirring times can however be customized).
•Be careful not to fill the canisters with too much colorant. In case of overfilling, act as indicated in the user’s manual.
•The colorant to be poured inside the canisters must be stirred manually. Do not use automatic shakers.
•Close the canisters with their lids right after filling operations.
•Remember to update accordingly the canisters filling levels via the management software.
•(With humidifier for solvent-based colorants or without humidifier) The sponge must be saturated at least twice
a week (the frequency of intervention is indicative, since it depends on the nature of colorants and the environment
conditions).
•(With humidifier for water-based colorants) Top up the water bottle as soon as the minimum level is reached. Do
not exceed the maximum level.
At the end of the working day
•Refill the canisters.
•Update the canister filling levels in the management software.
•Shut down the computer. Do not shut off the machine.
It is recommended to carefully read the user’s manual.

COROB EVOFLX-LW - 4-
2 GENERAL INFORMATION
2.1 Purpose and use of this manual
Read this manual carefully before using the machine.
This manual,inserted in the product packaging,contains instructions on the use and routine maintenance needed to
uphold the machine’s performance over time.The manual contains all information needed to correctly use the machine
and avoid any accident.
The manual is to be considered an integral part of the machine, and must be stored until it is fully dismantled.
The manual contains all information available at the time of preparation regarding the machine and any accessories; for
accessories, the manual includes any variations or changes that involve different operating procedures.
Should it be lost or partially ruined,so that its contents can no longer be read in full,you must request a new manual from
the manufacturer.
Some of the illustrations in this manual were taken from prototypes; some details may differ on machines in standard
production.
Conventially used graphics
Boldface type is used to highlight notes or information of particular importance to a topic.
2.2 Definitions
DANGER
Indicates a risk of personal injury
WARNING
Indicates a risk of damage to the machine that could interfere with its operation.
dd
Indicates important instructions referring to precautionary rules and/or measures to adopt.
Indicates situations and/or operations that involve the management software installed on the computer.
Indicates that to carry out the intervention described,the use of the specified tools is required.
OPERATOR
A person familiar with the methods to mix paints or similar products, trained and authorized to operate and use the
machine by its controls and to load and unload production materials with all safety devices installed and enabled.
He or she must work only in safety conditions and is allowed to carry out routine maintenance operations.
MAINTENANCE TECHNICIAN / INSTALLATION TECHNICIAN
Specialist prepared and trained in a technical field (mechanical and electrical) and assigned by the manufacturer
to work on the machine to perform machine installation, adjustments, repair breakdowns or carry out mainteance.

- 5 - COROB EVOFLX-LW
3FEATURES
3.1 Description of the machine
The automatic dispenser is a device to automatically dispense fluid colorant products into containers (metal or plastic
canisters,cans or bins) of the size indicated in this manual,pre-filled with base,to produce finished products such as
paints,dyes,enamels,and inks of the desired hue, chosen by means of the machine management software.
The dispenser consists of:
1. Dispensing area and can handling system.
2. Control panel.
3. Upper covers.
4. Canister filling area.
The dispenser is fully managed by a normal personal computer that can be provided upon request, since it is not
supplied as standard together with the machine. The manufacturer can also supply a wide range of software
applications to manage all of the machine’s functions.
dd Some of the pictures in this manual were taken from prototypes; some details may differ in machines in
standard production.
4
3
1
2

COROB EVOFLX-LW - 6 -
3.2 Description of units
Canisters
The machine canisters can be of different capacities and are suitable for
containing the product to be dispensed.
Covers in the upper part of the machine provide access for filling the canisters.
Each canister has its own lid.
Nozzle center
The ends of the dispensing pipes coming from the canisters converge and are
fixed to the nozzle center, from which the tinting product to fill the can is
dispensed.
Integrated Nozzle Valve System (INV)
The INV system integrates the dispensing nozzle and the valve of each circuit
in a single cartridge.
The cartridges are mounted onto the specially designed dispensing head.
Valve opening (dispensing) and closing (recirculation) are operated by
compressed air, through a compressor positioned inside the machine.
Thanks to the air tightening characteristics of this system, the INV prevents
colorant from drying.
Shelf
The can shelf allows for the correct positioning of the can under the dispensing nozzle.
Manual shelf - The shelf is fixed to the machine and can be raised or lowered by the operator. The shelf is provided with a
locking handle that must be pulled to release the shelf and allow it to be moved to the desired height.
Semiautomatic shelf - The shelf is commanded by the operator with the activation buttons (two-handed control); the
shelf stops when the can is detected by the photocell.
Automatic shelf - The shelf is managed by the computer that controls its movement and checks that the can placed on it
is actually the one selected for dispensing. A photocell checks for the presence of the can and that the shelf is correctly
positioned.
Roll conveyor
The foldable roll conveyor is mounted frontally on the canister module and facilitates the loading of heavy cans on the
shelf. It also features a step that makes canister refilling operations easier for the operator.
Can centering device
It is useful for placing the cans under the nozzle center, so that the can lid is punched in the middle and dispensing takes
place precisely into the hole created.

- 7 - COROB EVOFLX-LW
It is supplied on the machine accessorized with punching system, and is custom-made based on the size of the cans to
be handled.
The can centering device is also available as an optional accessory to the standard machine, useful for positioning pre-
punched cans right under the dispensing center.
Bung Hole Locator (B.H.L.)
This is a system that emits laser beams that allow the positioning of pre-
punched cans,so that the hole is in line with the center of the dispensing
nozzles.
Nozzle Humidifier Cap
To prevent colorants from drying out in the nozzle center,the machine is equipped with a humidifier cap.
Puncher
The puncher is a device that perforates the can lid.
With semiautomatic puncher,punching is carried out by the operator by
pushing contemporaneously the semiautomatic shelf activation buttons
(two-handed control).
The shelf upward movement pushes the can resting on it against the puncher,
and with a downward movement brings it to the correct position for
dispensing.
No-Dry-Nozzle Humidifier
The humidifier for water-based colorants guarantees the nozzles are
constantly humidified. The air, humidified by the water contained in the
bottle, is transferred to the nozzles area. Based on the humidity level detected,
the system activates or shuts off whenever needed.
The humidifier for solvent-based colorants humidifies the nozzles when the
cap is closed. The solvent, contained in a small tank inside the cap, keeps the
nozzles area constantly saturated.
The two systems can be present individually or together according to the
tinting system used on the machine.
The rotating cap opens thanks to
the push applied to the opening
bar while the can is being
positioned. The cap closes when
the can is removed.When the cap
is open, the system confirms the
can presence to begin dispensing.
The automatic rotating cap is an
automatic cap managed by the
software, which opens it
automatically before dispensing
and closes it immediately
afterwards.
The automatic sliding cap is an
automatic cap which ensures that
the nozzles are hermetically sealed.
It is managed by the software,
which opens it automatically
before dispensing and closes it
immediately afterwards.

COROB EVOFLX-LW - 8 -
3.3 Usable cans 
Shelf Cap
Nozzle system
Manual
500 mm [19.7”]
70 mm [2.8”]
70 mm [2.8”]
70 mm [2.8”]
380 mm[14.96”]
380 mm[14.96”]
500 mm [19.7”]
380 mm[14.96”]
240 mm [9.45”]
70 mm [2.8”]
Semiautomatic
500 mm [19.7”] 70 mm [2.8”]
380 mm[14.96”]
70 mm [2.8”]
460 mm[17.7”] with
punch
130mm [5.1”]
with punch 110 mm [4.3”]
500 mm [19.7”]
380 mm[14.96”]
240 mm [9.45”]
70 mm [2.8”]
54 mm [2.1”]
380 mm[14.96”]
240 mm[9.45”]

- 9 - COROB EVOFLX-LW
3.4 Intended use and reasonably foreseeable misuse
The machine is intended for professional use to dispense colorants in small, medium and large point of sales or
professional paint stores.
The machine must be used only with cans within the limits set forth in chapter 3.3 (Usable cans), with the colorants
specified in the table of chapter 9.1 (Technical information) and according to the procedures described in this manual.
Any use of the machine other than that stated, which cannot be implied or deduced from this manual, is to be
considered improper and unintended therefore it voids any manufacturer’s liability arising from non‐compliance with
these requirements.
3.5 Identifying information
The machine has an identification plate (chapter 4.4 ) indicating:
• Manufacturer’s name and address
•Marking
• Machine model
• Month and year of manufacture
• Serial number (S/N)
• Electrical specifications
dd
Do not remove or tamper with the identification plate in any way.

COROB EVOFLX-LW -10 -
4SAFETY
4.1 Safety warnings and unauthorized use
•Read the user’s manual carefully before carrying out any operation on the machine.
•The machine must be used only for its intended purpose.
•Pay close attention to the signs on the machine.
•When prescribed, wear personal protective equipment.
•Only qualified and appropriately trained personnel (MAINTENANCE TECHNICIAN) are authorized to access the
machine parts protected by panels for extraordinary maintenance and repair interventions.
•Any routine maintenance intervention performed by the operator must be carried out with the machine off and the
power supply cable disconnected from the mains socket outlet.
•The machine must be used by a single operator. Unauthorized people who could reach or touch machine parts
during operation must not be admitted in the nearby area.
•The machine must be used by an operator who has attained the age of majority and is in suitable
psychophysical conditions defined by an occupational physician.
•The substances that may be used on the machine ‐‐ such as colorants, paints, solvents, lubricants and
cleansers -- may be hazardous to your health; handle, store and dispose of these substances in keeping with
current regulations and the instructions provided with the product.
•The machine must not be used with cans exceeding the limits set forth in chapter 3.3 (Usable cans) and with
colorants other than those specified in the technical data table.
•THE MACHINE MUST NOT BE USED IN AREAS AT RISK FOR EXPLOSION.
•Avoid naked flames or material that may create sparks and cause a fire.
•The machine must not be employed for food use.
•The OPERATOR must not carry out operations reserved to the MAINTENANCE TECHNICIAN or the INSTALLATION
TECHNICIAN. The manufacturer CANNOT BE HELD RESPONSIBLE for damages deriving from the non-observance of
this prohibition.
•It is strictly forbidden to use the machine without protections or with any safety devices present on the machine
disabled, broken down, or removed. The panels must be kept closed at all times.
•Do not stare the light source of the Laser Bung Hole Locator (Class II laser product).
•If the machine catches fire, never use water. Use only dry powder or carbon dioxide fire extinguishers,and
strictly follow the instructions and warnings indicated by the manufacturer and listed on the extinguisher.
•ALWAYS PLUG THE MACHINE INTO A SOCKET THAT ENSURES PROPER GROUNDING. The line must be protected
from overloads, short-circuits and direct contacts according to current accident prevention regulations. Incorrect
grounding may lead to the risk of electrical shock.
•The machine must not be powered by a power source having specifications other than those listed on the
identification plate.
• In the event of a sudden power outage,when power returns the machine will automatically be switched on to allow
the automatic processes to prevent products from drying out.
•To prevent any risk of electrical shock or injuries, use the machine indoors only. It is prohibited to use the machine
outdoors where it could be subjected to rain or high humidity.
•Always unplug the power supply cable from the socket outlet before carrying out any maintenance operations.
•The machine is isolated from the power supply line when the power cable is disconnected; it must therefore be
installed near an easily accessible mains socket outlet.
•Do not use extension cords to power the machine.
dd
COMPULSORY
PROHIBITED
ELECTRICAL DANGER

- 11 - COROB EVOFLX-LW
•Do not use multisockets to connect other equipment to the same socket that powers the machine. Make sure that the
power supply of the equipment connected to the machine via serial port, like the computer, is equipotential (which
has a single access point to earth) because potential differences cause interferences and/or damage to the serial
ports.
• Periodically check the condition of the power supply cable; if it is damaged, replace it with a new cable supplied by
the manufacturer.
4.2 Warnings on the use of colorants
Below are some of the most common warnings and safety precautions provided by colorant manufacturers.
1. Harmful if swallowed.
2. Avoid eye and skin contact. In case of eye and skin contact, rinse with plenty of water.
3. Keep out of the reach of children.
4. When compulsory, wear the specified personal protective equipment.
5. In case of accidental product leaks or spills, thoroughly ventilate the area and proceed as indicated in this manual
and in the instructions provided with the product itself.
6. Do not dispose of colorant in the sewage system. Follow local regulations when disposing of waste.
DANGER
The machine is suitable for use with tinting products in general. Scrupulously follow the instructions for use given
on the colorant package and carefully read the MATERIAL SAFETY DATA SHEETS (MSDS) that the dealer or
manufacturer of the product is required to provide.
Observe all of the safety instructions provided.When compulsory, wear the specified personal protective
equipment.

COROB EVOFLX-LW -12 -
4.3 Residual risks
Risk Preventive measure P. P. E : Ch. in this
manual
Risk of electrocution - Risk of
electrical shock if you power the
machine from a socket not
equipped with ground connection.
Power the machine through a grounded
socket outlet.
/ch.6
Risk of electrocution - Risk of
electrical shock if you access
machine parts protected by panels
without first cutting off electrical
power.
The operator is not authorized to access
the machine parts protected by panels.
For the maintenance technician: before
performing any maintenance
intervention, shut off the machine and
disconnect the power supply cable from
the mains socket outlet.
/
Dorsal/lumbar injuries - Handling
heavy loads when moving the
machine and loading cans on the
shelf may cause injuries.
Do not exceed the weight limits stated by
the current regulations in force.
If necessary, use appropriate lifting
equipment.
ch. 5-7
Risk of falling objects / crushing ‐
When positioning a can on the shelf,
there is a risk it may fall onto the
operator.
Position the can so that the whole base
rests on the shelf surface.ch. 7
Risk of crushing / entanglement ‐
The automatic movement of the
humidifier cap and of the shelf may
cause injuries.
The machine must be used by a single
operator.
Keep hands away from the dispensing
area at all times while the machine is
operating.
ch. 7
Risk of crushing / entanglement -
During colorant refilling operations,
the stirrer inside the canister may
automatically start rotating.
Before performing any intervention,
press the off-line button. ch. 7.5
Risk of cuts - During the punching
operations or maintenance
operations on the punching device,
the contact with the puncher blade
may cause injuries.
The machine must be used by a single
operator.
Keep hands away from the dispensing
area at all times while the machine is
operating.
Use the special tool to remove the
puncher.
ch. 7-8
Risk of slipping / falling - Misuse of
the shelf may cause injuries.
Do not climb onto the shelf and /or sit on
it.
Do not use the shelf as ladder.
ch. 7
Risk of explosion - Fumes
generated by the colorants used
may cause an explosion.
Do not use the machine in areas at risk for
explosion.
Avoid naked flames or material that may
create sparks and cause a fire.
/
Risk of exposure to laser beam ‐
The Bung Hole Locator (B.H.L.) uses
red laser light sources which can be
potentially dangerous for the eyes.
Avoid staring at the light source./ch.7
Risk of poisoning and
sensitization -
Fumes generated by the colorants
used may cause poisoning and/or
sensitization during canister refilling
operations, machine cleaning and
disposal.
Read the warnings reported in the
Material Safety Data Sheets of the
colorants used. The MSDS must be
provided by the colorant manufacturer.
Keep the room suitably ventilated.
Personal
Protective
Equipment
as
specified
in MSDS.
ch. 4.2-5-
7-8

- 13 - COROB EVOFLX-LW
4.4 Position of labels
1. Type shield (chapter 3.5)
2. Label “General warnings”
3. Label “Electrical danger”
4. Label “Risk of crushing”
5. Label “Risk of cuts”
6. Label “Laser danger”
7. Label “Canister filling levels”
8. Label “Serial number”
dd Do not remove or make illegible the safety or instruction labels. Replace any label has become illegible or is
missing, by requesting it to the manufacturer.
8
7
5
6
4
1
2
3

COROB EVOFLX-LW -14 -
4.5 Safety devices
The machine is equipped with the following safety devices: 
4.6 Emergency stop
In case of a breakdown or dangerous conditions, press the emergency stop button (chapter 4.6). Pressing this button
causes all machine dangerous movements to be stopped, by cutting off power supply to all power circuits. The red lamp
on the control panel turns on (chapter 6.4).
with shelf:
man semiauto auto
1. Emergency button -33
2. Shelf lower safety plate -33
3. Buttons to enable and move the shelf -3-
4. Shelf upper safety plate --
3
DANGER
In the event of a breakdown of the safety devices,it is forbidden to use components not provided by the
manufacturer. In case of need, contact only the service organization authorized by the manufacturer.
DANGER
The emergency button does not completely cut off power to the entire machine.The power supply unit box inside
the machine still remains powered.
To completely remove power from the machine it is necessary to shut it off and unplug the power supply cable
from the wall socket outlet

- 15 - COROB EVOFLX-LW
After eliminating the cause of the malfunction or solved the dangerous condition, reset the button by pulling it.
4.7 Requirements of the installation site
Environment requirements for the site where the machine is to be used:
•Clean and dust-free.
•With level and stable floor.
•Fitted with a grounded power supply socket.
•Equipped with sufficient lighting to ensure good visibility from every point of the machine (light value not lower
than 500 Lux).
•Ventilated to prevent the concentration of harmful fumes.
•Temperature between 10 °C (50 °F) and 40 °C (104 °F) and relative humidity between 5% and 85%, without
condensation.
dd The emergency button does not turn the computer off,since it requires special shut‐down procedures (the
auxiliary sockets remain powered).
WARNING
The use of the emergency stop button is to be considered as an emergency action exclusively, and not as a
standard stop mode, in order to prevent machine deterioration.
WARNING
The environment working conditions are strictly related to the type of colorants used (ask for information from the
paint manufacturer). The requirements indicated above are valid for the machine only.
Do not place the machine near heat sources or in direct sunlight. Also humidity sources should be avoided. The
machine must be used indoors only.
Environment conditions outside the values indicated (chapter 9.1) may cause serious damage to the machine,
especially the electronic equipment.
DANGER
When using colorants containing volatile solvents the room in which the machine is installed must be
spacious, with good ventilation (air exchange) and no type of parts must be leant against or stocked close to the
machine.
Avoid naked flames or material that may create sparks and cause a fire.

COROB EVOFLX-LW - 16 -
5 SHIPPING AND HANDLING
5.1 General warnings
Personnel in charge of these operations must wear the following personal
protective equipment.
5.2 Unpacking and placement
Store the packing material for future use, or dispose of it according to current regulations. In any case, we recommend
that you keep it for the entire duration of the machine warranty.
Make sure the packing has not
suffered any damage or tampering during shipping; if so, contact
the authorized technical service or your dealer.
1. Cut the straps.
2. Remove cardboard box.
3. Remove the machine wrapping. Take out any accessories and/or material supplied with the machine.
4. Remove the brackets that fix the machine to the pallet..
5. Grasp the machine on the sides (this must be done by at least two people) slide it slowly along the platforms to the
ground.
6. Lower the feet to support and level the machine properly, and make sure that the wheels are not resting.
To repack the machine, follow the unpacking instructions in reverse order. We recommend reusing the original packing
any time the machine must be moved or shipped.
DANGER
To avoid personal injuries and property damage, use the utmost care and caution when handling the machine, and
carefully follow the instructions given in this chapter.
WARNING
The packing must be handled only by qualified personnel using appropriate handling equipment. Do not stack
items on the packing.
dd
If the machine is installed near a wall, keep it at least 10 cm (4”) away to prevent the cables from being crushed.
6 mm
To remove the fixing brackets
10 mm
DANGER
The following procedure must be carried out by at least 2 people.
DANGER
Should the machine appear damaged during shipping, do not attempt to start it and contact the authorized
technical service or dealer.

- 17 - COROB EVOFLX-LW
5.3 Standard material supplied
After unpacking the machine, make sure the following items are present:
1. Power supply cable.
2. Computer power cables.
3. USB cable.
4. Equipment software tools standard CD.
5. User’s manual and product documentation.
6. Spare parts.
With puncher only:
7. T-w ren ch.
8. Tool for punch removal.
9. Manual plugger.
Depending on the options specified on the purchase order, you may also find:
•Management software.
•Any accessories to be installed on the machine.
Make sure that all of the above items are included in the packing; if not, contact the manufacturer.

COROB EVOFLX-LW - 18 -
5.4 Preparing the shelf for use
5.5 Storage
If stored, the machine must be kept in a safe and protected environment, with a suitable temperature and humidity
degree and protected from dust.
5.6 Disposal and recycling
This equipment must not be disposed of with unsorted municipal waste. Carry out a separate
collection.
Pursuant to the WEEE Directive, collection, treatment, recovery and environmentally sound
disposal of Waste Electrical and Electronic Equipment (WEEE) shall be carried out in
compliancewith the national measures of each EU-Member State implementing the Directive.
Differentiate the parts making up the machine based on the various materials they are made
of (plastic, iron, etc.).
For the colorants remaining in the canisters, for the machine components most soiled with
colorant and if any products have been used on the machine that require special disposal
procedures, follow local regulations when disposing of waste.
