Digilock ADA User Key Owner's manual

User Manual / Care Instructions
PRODUCT #:
DL01KUSR104
ITEM:
Accessory - ADA User Key (Blue)
from Digilock
Digilock
SOURCE FOR PURCHASE:
SpaEquip, Inc.
211 Wappo Ave., Calistoga, CA 94515
p: 707.737.1100
f: 707.737.1150
www.spaequip.com
LIST PRICE (USD):
18
FEATURES:
Digilock ADA User Key (Blue). Digilock meets the US Access Board's requirements for ADA compliance with the use of
the ADA User Key. Users with disabilities are issued an ADA User Key that will allow access to any available locker
without tight grasping, tight pinching or twisting of the wrist to operate. Local regulations may vary and should be
consulted prior to installation. Typically 1%-5% of lockers should be ADA compliant.
SPECIFICATIONS:
Dimensions: N/A
Electrical: Battery Power
Suggested Outlet: N/A
Plumbing: None
Notes: See Specs for DLSTS6190134
Warranty: 2 Year Limited Warranty
Certifications: N/A
Country of Origin: United States
Installed By: Client's Contractor
Product Code: DL01KUSR104
www.spaequip.net
p: 707.737.1100
Page 1 of 3

This step will add additional manager bypass keys to one lock and
does not erase any previously registered manager bypass keys.
1) Go to one lock.
2) Press: c K 5 5 K
The LED will flash.
3) Touch the programming key (red) to the key slot for one full
second.
The LED is solid.
4) Touch each manager bypass key (black) to the key slot, one at a
time.
A single blink of the led and a single beep after touching each
manager bypass key is an indicator that the manager bypass key
to be registered has been properly touched to the lock.
5) Touch the programming key (red) to the key slot for one full
second.
A double tone signifies successful Addition of manager keys.
If you need to add these manager keys to additional locks:
1) Follow instructions “ To initialize new locks: (step 2).”
2) Follow instructions “To initialize new locks: (step 3).”
To Add Additional Manager Bypass Keys :
Quick
Operating & Programming
Digilock Shared Usage Locks
Standard & High Security
NOTE: New locks will operate only with c K until initialized.
Step one will initialize one lock and register the manager bypass keys
to one lock.
** If you have more than one lock you will complete steps one and two
on one lock and step three on the remaining locks in your facility.
1) Touch the programming key (red) to the key slot for one full
second.
The LED will turn on.
2) Touch each manager bypass key (black) to the key slot, one at a
time.
A single blink of the led and a single beep after touching each
manager bypass key is an indicator that the manager bypass key
to be registered has been properly touched to the lock.
3) Touch the programming key (red) to the key slot for one full
second.
A double tone signifies successful initialization of your lock .
To initialize new locks: (Step 1)
Step two will copy the registration of the manager bypass keys to the
programming key.
This step is to initialize or program more than one lock.
1) Go to the lock you initialized in step 1.
2) Press: c K 6 6 K
3) Touch the programming key (red) to the key slot for one full
second.
A double tone signifies that the registered manager bypass
keys were successfully copied to the programming key.
To initialize new locks: (Step 2)
Step three will paste the information that was copied to the program-
ming key in step two to all locks at your facility.
(This step is only required if you have more than one lock).
1) Go to any lock that requires programming.
2) Touch the programming key (red) to the key slot.
A double tone signifies that the lock was successfully initial-
ized and the manager bypass keys were successfully registered
to the lock.
3) Repeat this procedure to all locks in your facility.
It is recommended to test the registration of the manager bypass keys
to the lock(s). To do this operate the lock(s) with the manager bypass
key(s) by following the operating instructions “To Operate with Man-
ager Bypass Key.”
To initialize new locks: (Step 3)
Digilock Accessory Guide
Programming Key (Solid Red)
• Registers Manager Override Keys to locks.
• Provides external power in case of battery failure.
• Each lock accepts only (1) programming key.
Manager Bypass Key (Solid Black)
• Provides management access to locks.
• Provides external power in case of battery failure.
• Each lock accepts up to (25) manager bypass keys.
ADA User Key (Solid Blue)
• ADA compliant user key.
• Allows user to lock and unlock any available lock.
Product Code: DL01KUSR104
www.spaequip.net
p: 707.737.1100
Page 2 of 3

For a lost programming key:
Contact your Digilock Product Representative to order a re-
placement programming key.
For a lost manager bypass key(s):
1) collect all remaining manager keys or order additional keys
from your Digilock Product Representative .
2) At one lock press c K 5 5 K
The LED will flash.
3) Touch the programming key (red) to the key slot for one full
second.
The LED is solid.
4) Touch the programming key (red) to the key slot for one full
second.
The LED will turn off and all registered manager keys will
be erased on the one lock.
5) Follow instructions “To add additional manager bypass
keys.” If you have more than one lock, continue with steps 6
and 7.
6) Follow instructions “ To initialize new locks: (step 2).”
7) Follow instructions “To initialize new locks: (step 3).”
For lost or stolen keys:
1) No Audible feedback when c button is pressed:
A) the batteries have failed- replace batteries located in
the rear unit.
B) poor connection on door- remove lock from door and
reinstall.
C) The lock is in “sleep state.” Try again after one minute.
2) Lock does not unlock:
A) listen for additional audible feedback for an indicator as to
what is going on.
B) Try operating with manager bypass key or programming key
C) Contact your Digilock Product Representative or Digilock
customer support.
3) Lock emits 2 sets of three beeps during operation:
A) low battery indicator- replace batteries located in the rear
unit.
4) lock emits 10 rapid beeps during operation:
A) binding indicator- the lock is binding with the strike plate.
Press firmly on the door while operating. If binding is a fre-
quent occurrence, the strike plate and/or door hinges need to
be aligned with the lock.
Troubleshooting
To lock:
1) Find an available lock.
2) press: c ` ` ` ` K
(any four-digit code)
To unlock:
1) At same lock.
2) press: c ` ` ` ` K
(same code used to lock)
To lock:
1) Find an available lock.
2) touch the ADA user key (blue) to key slot.
To unlock:
1) At same lock.
2) Touch the ADA user key (blue) to key slot.
To operate with a user code:
To operate with an ADA user key:
To lock or unlock:
1) touch a registered manager bypass key (black) to key
slot .
To lock or unlock:
1) Press: c K
2) Insert programming key (red) to key slot.
To operate with the manager bypass keys:
To operate with the programming key:
5341 Old Redwood Highway, Suite 200,
Petaluma, CA 94954
Phone: [phone]  [phone]
Fax: [phone]  [phone]
For Additional Product and/or
Product Information:
Visit: www.digilock.com
E-mail: [email protected]
Contact: Digilock or your Digilock Product Representative
If you have the high security platform, this product line is capable
of audit trail with use of a software programming kit. For addi-
tional information regarding this feature contact your Digilock
product representative.
Additional Product Features
