Digilock Next Mech User manual

Installation Guide
Lock Parts
Mounting
Screws
Screw type
M3×10 ✓
0 – 5 mm
✓
M3×145 – 8 mm
M3×108 – 12 mm
M3×1412 – 16 mm
M3×1816 – 20 mm
Mounting plate
Accommodates door
thickness up to 20 mm
Mortise Hole Dimensions
Spacer Requirements
Spacer required* for door
thickness less than 8 mm
Factory default combination 0-0-0-0
Removal keyManager key
Door thickness *Spacer required
R3
77 mm
31.5 mm
min. 6.35 mm
Cam in Locked Position
must overlap Strike
Plate by at least ¼"
(6.35 mm)
Mounting
Screws
Screw type
M3×10 ✓
0 – 5 mm
✓
M3×145 – 8 mm
M3×108 – 12 mm
M3×1412 – 16 mm
M3×1816 – 20 mm
Mounting plate
Accommodates door
thickness up to 20 mm
Mortise Hole Dimensions
Spacer Requirements
Spacer required* for door
thickness less than 8 mm
Factory default combination 0-0-0-0
Removal keyManager key
Door thickness *Spacer required
R3
77 mm
31.5 mm
min. 6.35 mm
Cam in Locked Position
must overlap Strike
Plate by at least ¼"
(6.35 mm)
Mounting
Screws
Screw type
M3×10 ✓
0 – 5 mm
✓
M3×145 – 8 mm
M3×108 – 12 mm
M3×1412 – 16 mm
M3×1816 – 20 mm
Mounting plate
Accommodates door
thickness up to 20 mm Mortise Hole Dimensions
Spacer Requirements
Spacer required* for door
thickness less than 8 mm
Factory default combination 0-0-0-0
Removal keyManager key
Door thickness *Spacer required
R3
77 mm
31.5 mm
min. 6.35 mm
Cam in Locked Position
must overlap Strike
Plate by at least ¼"
(6.35 mm)
Setup
Note: Removing the Programming Key in the circle mark position will remove the core. See Replace Key Set and Core instructions to reinsert the core.
Mounting
Screws
Screw type
M3×10 ✓
0 – 5 mm
✓
M3×145 – 8 mm
M3×108 – 12 mm
M3×1412 – 16 mm
M3×1816 – 20 mm
Mounting plate
Accommodates door
thickness up to 20 mm Mortise Hole Dimensions
Spacer Requirements
Spacer required* for door
thickness less than 8 mm
Factory default combination 0-0-0-0
Removal keyManager key
Door thickness *Spacer required
R3
77 mm
31.5 mm
min. 6.35 mm
Cam in Locked Position
must overlap Strike
Plate by at least ¼"
(6.35 mm)
Assign a User Combination
Once a new user combination is assigned, the previously assigned user combination will no longer operate the lock. If the current user code
is unknown, follow the Reset Combination instructions to find the current assigned code then continue to Assign a new User Combination.
1. Set the dial to show the current assigned combination.
2. Insert the Programming Key and turn the knob to the
circle mark position.
3. Set any 4-digit combination.
4. Turn the knob to the locked position and remove the
Programming Key.
5. Scramble the code.
Dial Combo
Assigned Use
Product Guide
Rear UnitFront Unit
Locked Position
Reset Pin Holes
Key Slot
Unlocked Position
Programming
Position
Comibination Dial
Cam

Mounting
Screws
Screw type
M3×10 ✓
0 – 5 mm
✓
M3×145 – 8 mm
M3×108 – 12 mm
M3×1412 – 16 mm
M3×1816 – 20 mm
Mounting plate
Accommodates door
thickness up to 20 mm Mortise Hole Dimensions
Spacer Requirements
Spacer required* for door
thickness less than 8 mm
Factory default combination 0-0-0-0
Removal keyManager key
Door thickness *Spacer required
R3
77 mm
31.5 mm
min. 6.35 mm
Cam in Locked Position
must overlap Strike
Plate by at least ¼"
(6.35 mm)
Operating Instructions
Operate with a Combination
Reset Combination
Operate with a Manager Key
To Lock:
1. Close the door.
2. Turn the knob to the locked position.
3. Scramble the combination.
To Unlock:
1. Enter the assigned 4-digit combination.
2. Turn the knob to the unlocked position.
3. Open the door.
To Unlock with Manager Key:
1. Insert the Manager Key.
2. Turn the knob to the unlocked position.
3. Open the door.
To Lock with Manager Key:
4. Close the door.
5. Turn the knob to the locked position.
6. Remove the Manager Key.
Mounting
Screws
Screw type
M3×10 ✓
0 – 5 mm
✓
M3×145 – 8 mm
M3×108 – 12 mm
M3×1412 – 16 mm
M3×1816 – 20 mm
Mounting plate
Accommodates door
thickness up to 20 mm Mortise Hole Dimensions
Spacer Requirements
Spacer required* for door
thickness less than 8 mm
Factory default combination 0-0-0-0
Removal keyManager key
Door thickness *Spacer required
R3
77 mm
31.5 mm
min. 6.35 mm
Cam in Locked Position
must overlap Strike
Plate by at least ¼"
(6.35 mm)
Note: The Manager key cannot be inserted or removed when the knob is in
the unlocked position.
Note “M” for
Manager on key
Programming Instructions
Dial Combo
Assigned Use
Product Guide
Note “M” on
Manager Key
If the door is locked, use the Manager Key to
open the door.
1. Using the Manager Key, turn the knob to
the locked position.
2. Remove the Manager Key.
Insert the Reset Tool into the four pin holes on
the rear of the unit.
Push in the Reset Tool and simultaneously turn
all dials until they stop.
The final code displayed is the current code. In
this example, the combination was 5-9-9-4.
Remove the Reset Tool and turn the knob to
the unlocked position.
Follow instructions to Assign a User Combination.
Reset Tool
1
4
2
5
3
