Extreme Tools RX722501HC User manual

Models:
RX722501HC 72”W x 25”D
RX723001HC 72”W x 30”D
RX552501HC 55”W x 25”D
72 inch Steel Top Hutch
shown on RX Series Roller Cabinet
Owner’s Manual
Professional
Powder-Coated Steel Hutches
Extreme Tools, Inc.
740 Frontenac Road
Naperville, Illinois 60563
[email protected]
630.369.9303
www.ExtremeTools.com

22
13A
10
4A
(30” Deep Model Only)
1

RX722501HC Parts List
ITEM # PART NUMBER DESCRIPTION QTY.
1 Z-7225HC-01 BK 7225 Hutch Top-Back panel, BK 1
1 Z-7225HC-01 BL 7225 Hutch Top-Back panel, BL 1
1 Z-7225HC-01 GN 7225 Hutch Top-Back panel, GN 1
1 Z-7225HC-01 MB 7225 Hutch Top-Back panel, MB 1
1 Z-7225HC-01 OR 7225 Hutch Top-Back panel, OR 1
* ZRB-10 OD Rubber bumper, 10 mm OD 2
2 Z-7225HC-02 KC RX 25" Side panel, Left, Black w/ Chrome trim 1
2 Z-7225HC-02 UC RX 25" Side panel, Left, Blue w/ Chrome trim 1
2 Z-7225HC-02 GK RX 25" Side panel, Left, Green w/ Black trim 1
2 Z-7225HC-02 MK RX 25" Side panel, Left, Matte Black w/ Black trim 1
2 Z-7225HC-02 OK RX 25" Side panel, Left, Orange w/ Black trim 1
3 Z-7225HC-05 KC RX 25" Side panel, Right, Black w/ Chrome trim 1
3 Z-7225HC-05 UC RX 25" Side panel, Right, Blue w/ Chrome trim 1
3 Z-7225HC-05 GK RX 25" Side panel, Right, Green w/ Black trim 1
3 Z-7225HC-05 MK RX 25" Side panel, Right, Matte Black w/ Black trim 1
3 Z-7225HC-05 OK RX 25" Side panel, Right, Orange w/ Black trim 1
4 Z-7225HC-10 BK 7225 Hutch Top-Upper Front panel, Black 1
4 Z-7225HC-10 BL 7225 Hutch Top-Upper Front panel, Blue 1
4 Z-7225HC-10 GN RX7225 Hutch Top-Upper Front panel, Green 1
4 Z-7225HC-10 MB 7225 Hutch Top-Upper Front panel, Matte Black w/ black handle 1
4 Z-7225HC-10 OR 7225 Hutch Top-Upper Front panel, Orange 1
5 Z-RX7225HC-13 BKCR RX7225 Hutch Lower-Front Lid Assy, Black w/ Chrome handle 1
5 Z-RX7225HC-13 BLCR RX7225 Hutch Lower-Front Lid Assy, Blue w/ Chrome handle 1
5 Z-RX7225HC-13 GNBK RX7225 Hutch Lower-Front Lid Assy, Green w/ Black handle 1
5 Z-RX7225HC-13 MBBK RX7225 Hutch Lower-Front Lid Assy, Matte Black w/ Black handle 1
5 Z-RX7225HC-13 ORBK RX7225 Hutch Lower-Front Lid Assy, Orange w/ Black handle 1
6 ZST300400M6
Strut door support for a RX722501, RX723001HC & DX722101HC
hutch, M6 stud ball joint
, 40 kg. force
2
6 ZST300400M6Q
Strut door support for a RX722501, RX723001HC & DX722101HC
hutch,
M6 stud ball joint with wire pin quick disconnect, 40 kg. force
2
7 Z-7225HC-20 SPLICER POST ASSY, internal part 2
8 ZM4SCCS-10 M4 Screw, Counter sink, 10 mm long, for splicer mounting to RC 2
10 ZRG-38 RUBBER GROMMET - 38 MM ID 2
11 ZM6SCPH-12 M6 X 12MM SCREW, Pan head 20
12 Z-7225HC-19 BK RX 72" Hutch adjustable shelf, For 25" deep, Black 1
12 Z-7225HC-19 BL RX 72" Hutch adjustable shelf, For 25" deep, Blue 1
12 Z-7225HC-19 GN RX 72" Hutch adjustable shelf, For 25" deep, Green 1
12 Z-7225HC-19 MB RX 72" Hutch adjustable shelf, For 25" deep, Matte Black 1
12 Z-7225HC-19 OR RX 72" Hutch adjustable shelf, For 25" deep, Orange 1
13 Z-PS333032 POWER STRIP, 2.1A USBX2, 120VX3 1
13A ZM4SCPH-12 PAN HEAD M4 SCREWS, 12 MM LONG for power strip 4
14 Z-7225HC-22 BK Hutch-RC Connecting Bracket for sides, BK 2
14 Z-7225HC-22 BL Hutch-RC Connecting Bracket for sides, BL 2
14 Z-7225HC-22 GN Hutch-RC Connecting Bracket for sides, GN 2
14 Z-7225HC-22 MB Hutch-RC Connecting Bracket for sides, MB 2
14 Z-7225HC-22 OR Hutch-RC Connecting Bracket for sides, OR 2

ITEM # PART NUMBER DESCRIPTION QTY.
15 ZM6SCSH-35 M6 x 35 mm Socket Head Screw, for RX/DX HC door hinge 2
16 ZM8WAFT-BK M8 flat washer, Black 2
16 ZM8WAFT-BL M8 flat washer, Blue 2
16 ZM8WAFT-GN M8 flat washer, Green 2
16 ZM8WAFT-MK M8 flat washer, Matte Black 2
16 ZM8WAFT-OR M8 flat washer, Orange 2
16A ZM8SCHX-16 BK M8X16 Hex Bolts, Black 2
16A ZM8SCHX-16 BL M8X16 Hex Bolts, Blue 2
16A ZM8SCHX-16 GN M8X16 Hex Bolts, Green 2
16A ZM8SCHX-16 MB M8X16 Hex Bolts, Matte Black 2
16A ZM8SCHX-16 OR M8X16 Hex Bolts, Orange 2
17 Z-ECM13 Hole plug for RX/DX hutch pivot hole 2
18 Z-LK EX01-04 SEE KEY CODE ON LOCK (EX01-04) 1
19 ZTRRX564-CR RX72, RX55 & RX41 chest or hutch vertical side trim chrome. 2
19 ZTRRX564-BK RX72, RX55 & RX41 chest or hutch vertical side trim, Black finish. 2
20 ZDPRX1740-BK 72" RX Chest or Hutch lid handle, Black 1
20 ZDPRX1740-CR 72" RX Chest or Hutch lid handle, Chrome 1
22 ACPTRBK Adjustable Power Tool Rack, Black 1
22 ACPTRBL Adjustable Power Tool Rack, Blue 1
22 ACPTRGN Adjustable Power Tool Rack, Green 1
22 ACPTRMB Adjustable Power Tool Rack, Matte Black 1
22 ACPTROR Adjustable Power Tool Rack, Orange 1
*Z-SP-STRUT Spring Pin to Secure Gas Strut 4
*ZM4SCPH-6 PAN HEAD M4 SCREWS, 6 MM LONG for lid handle 8
*ZM4WAFT-ST BK
M4 flat washer, steel, Black, for handle & power strip (8 already
installed on door panel)
12
*ZM4NTLK ZK M4 Nylon lock nut, Zn plating 4
*NOT SHOWN ON DRAWING
RX722501HC Parts List


ITEM # PART NUMBER DESCRIPTION QTY.
1 Z-7225HC-01 BK 7225 Hutch Top-Back panel, BK 1
1 Z-7225HC-01 BL 7225 Hutch Top-Back panel, BL 1
1 Z-7225HC-01 GN 7225 Hutch Top-Back panel, GN 1
1 Z-7225HC-01 MB 7225 Hutch Top-Back panel, MB 1
1 Z-7225HC-01 OR 7225 Hutch Top-Back panel, OR 1
* ZRB-10 OD Rubber bumper installed on lid panel, 10 mm OD 2
2 Z-7230HC-02 KC RX 30" Side panel, Left, Black w/ Chrome trim 1
2 Z-7230HC-02 UC RX 30" Side panel, Left, Blue w/ Chrome trim 1
2 Z-7230HC-02 GK RX 30" Side panel, Left, Green w/ Black trim 1
2 Z-7230HC-02 MK RX 30" Side panel, Left, Matte Black w/ Black trim 1
2 Z-7230HC-02 OK RX 30" Side panel, Left, Orange w/ Black trim 1
3 Z-7230HC-05 KC RX 30" Side panel, Right, Black w/ Chrome trim 1
3 Z-7230HC-05 UC RX 30" Side panel, Right, Blue w/ Chrome trim 1
3 Z-7230HC-05 GK RX 30" Side panel, Right, Green w/ Black trim 1
3 Z-7230HC-05 MK RX 30" Side panel, Right, Matte Black w/ Black trim 1
3 Z-7230HC-05 OK RX 30" Side panel, Right, Orange w/ Black trim 1
4 Z-7225HC-10 BK 7225 Hutch Top-Upper Front panel, Black 1
4 Z-7225HC-10 BL 7225 Hutch Top-Upper Front panel, Blue 1
4 Z-7225HC-10 GN RX7225 Hutch Top-Upper Front panel, Green 1
4 Z-7225HC-10 MB 7225 Hutch Top-Upper Front panel, Matte Black w/ black handle 1
4 Z-7225HC-10 OR 7225 Hutch Top-Upper Front panel, Orange 1
4A
Z-7230HC-17 BK RX 72" Hutch spacer panel, For 30" deep, Black 1
4A
Z-7230HC-17 BL RX 72" Hutch spacer panel, For 30" deep, Blue 1
4A
Z-7230HC-17 GN RX 72" Hutch spacer panel, For 30" deep, Green 1
4A
Z-7230HC-17 MB RX 72" Hutch spacer panel, For 30" deep, Matte Black 1
4A
Z-7230HC-17 OR RX 72" Hutch spacer panel, For 30" deep, Orange 1
5 Z-RX7225HC-13 BKCR RX7225 Hutch Lower-Front Lid Assy, Black w/ Chrome handle 1
5 Z-RX7225HC-13 BLCR RX7225 Hutch Lower-Front Lid Assy, Blue w/ Chrome handle 1
5 Z-RX7225HC-13 GNBK RX7225 Hutch Lower-Front Lid Assy, Green w/ Black handle 1
5 Z-RX7225HC-13 MBBK RX7225 Hutch Lower-Front Lid Assy, Matte Black w/ Black handle 1
5 Z-RX7225HC-13 ORBK RX7225 Hutch Lower-Front Lid Assy, Orange w/ Black handle 1
6 ZST300400M6
Strut door support for a RX722501, RX723001HC & DX722101HC
hutch, M6 stud ball joint
, 40 kg. force
2
6 ZST300400M6Q
Strut door support for a RX722501, RX723001HC & DX722101HC
hutch,
M6 stud ball joint with wire pin quick disconnect, 40 kg. force
2
7 Z-7225HC-20 SPLICER POST ASSY, internal part 2
8 ZM4SCCS-10 M4 Screw, Counter sink, 10 mm long, for splicer mounting to RC 2
10 ZRG-38 RUBBER GROMMET - 38 MM ID 2
11 ZM6SCPH-12 M6 X 12MM SCREW, Pan head 30
12 Z-7230HC-19 BK RX 72" Hutch adjustable shelf, For 30" deep, Black 1
12 Z-7230HC-19 BL RX 72" Hutch adjustable shelf, For 30" deep, Blue 1
12 Z-7230HC-19 GN RX 72" Hutch adjustable shelf, For 30" deep, Green 1
12 Z-7230HC-19 MB RX 72" Hutch adjustable shelf, For 30" deep, Matte Black 1
12 Z-7230HC-19 OR RX 72" Hutch adjustable shelf, For 30" deep, Orange 1


ITEM # PART NUMBER DESCRIPTION QTY.
13 Z-PS333032 POWER STRIP, 2.1A USBX2, 120VX3 1
13A ZM4SCPH-12 PAN HEAD M4 SCREWS, 12 MM LONG for power strip 4
14 Z-7225HC-22 BK Hutch-RC Connecting Bracket for sides, BK 2
14 Z-7225HC-22 BL Hutch-RC Connecting Bracket for sides, BL 2
14 Z-7225HC-22 GN Hutch-RC Connecting Bracket for sides, GN 2
14 Z-7225HC-22 MB Hutch-RC Connecting Bracket for sides, MB 2
14 Z-7225HC-22 OR Hutch-RC Connecting Bracket for sides, OR 2
15 ZM6SCSH-35 M6 x 35 mm Socket Head Screw, for RX/DX HC door hinge 2
16 ZM8WAFT-BK M8 flat washer, Black 2
16 ZM8WAFT-BL M8 flat washer, Blue 2
16 ZM8WAFT-GN M8 flat washer, Green 2
16 ZM8WAFT-MK M8 flat washer, Matte Black 2
16 ZM8WAFT-OR M8 flat washer, Orange 2
16A ZM8SCHX-16 BK M8X16 Hex Bolts, Black 2
16A ZM8SCHX-16 BL M8X16 Hex Bolts, Blue 2
16A ZM8SCHX-16 GN M8X16 Hex Bolts, Green 2
16A ZM8SCHX-16 MB M8X16 Hex Bolts, Matte Black 2
16A ZM8SCHX-16 OR M8X16 Hex Bolts, Orange 2
17 Z-ECM13 Hole plug for RX/DX hutch pivot hole 2
18 Z-LK EX01-04 SEE KEY CODE ON LOCK (EX01-04) 1
19 ZTRRX564-CR RX72, RX55 & RX41 chest or hutch vertical side trim chrome. 2
19 ZTRRX564-BK RX72, RX55 & RX41 chest or hutch vertical side trim, Black finish. 2
20 ZDPRX1740-BK 72" RX Chest or Hutch lid handle, Black 1
20 ZDPRX1740-CR 72" RX Chest or Hutch lid handle, Chrome 1
22 ACPTRBK Adjustable Power Tool Rack, Black 1
22 ACPTRBL Adjustable Power Tool Rack, Blue 1
22 ACPTRGN Adjustable Power Tool Rack, Green 1
22 ACPTRMB Adjustable Power Tool Rack, Matte Black 1
22 ACPTROR Adjustable Power Tool Rack, Orange 1
*
SP-STRUT Spring Pin to Secure Gas Strut 4
*ZM4SCPH-6 PAN HEAD M4 SCREWS, 6 MM LONG for lid handle 8
*ZM4WAFT-ST BK
M4 flat washer, steel, Black, for handle & power strip (8 already
installed on door panel)
12
*ZM4NTLK ZK M4 Nylon lock nut, Zn plating 4
*NOT SHOWN ON DRAWING


ITEM # PART NUMBER DESCRIPTION QTY
1 Z-5525HC-01 BK 7225 Hutch Top-Back panel, BK 1
1 Z-5525HC-01 BL 7225 Hutch Top-Back panel, BL 1
1 Z-5525HC-01 GN 7225 Hutch Top-Back panel, GN 1
1 Z-5525HC-01 MB 7225 Hutch Top-Back panel, MB 1
1 Z-5525HC-01 OR 7225 Hutch Top-Back panel, OR 1
2 Z-7225HC-02 KC RX 25" Side panel, Left, Black w/ Chrome trim 1
2 Z-7225HC-02 UC RX 25" Side panel, Left, Blue w/ Chrome trim 1
2 Z-7225HC-02 GK RX 25" Side panel, Left, Green w/ Black trim 1
2 Z-7225HC-02 MK RX 25" Side panel, Left, Matte Black w/ Black trim 1
2 Z-7225HC-02 OK RX 25" Side panel, Left, Orange w/ Black trim 1
3 Z-7225HC-05 KC RX 25" Side panel, Right, Black w/ Chrome trim 1
3 Z-7225HC-05 UC RX 25" Side panel, Right, Blue w/ Chrome trim 1
3 Z-7225HC-05 GK RX 25" Side panel, Right, Green w/ Black trim 1
3 Z-7225HC-05 MK RX 25" Side panel, Right, Matte Black w/ Black trim 1
3 Z-7225HC-05 OK RX 25" Side panel, Right, Orange w/ Black trim 1
4 Z-5525HC-10 BK 7225 Hutch Top-Front panel, Black 1
4 Z-5525HC-10 BL 7225 Hutch Top-Front panel, Blue 1
4 Z-5525HC-10 GN RX7225 Hutch Top-Front panel, Green 1
4 Z-5525HC-10 MB 7225 Hutch Top-Front panel, Matte Black w/ black handle 1
4 Z-5525HC-10 OR 7225 Hutch Top-Front panel, Orange 1
5 Z-RX5525HC-13 BKCR RX7225 Hutch Lower-Front Lid Assy, Black w/ Chrome handle 1
5 Z-RX5525HC-13 BLCR RX7225 Hutch Lower-Front Lid Assy, Blue w/ Chrome handle 1
5 Z-RX5525HC-13 GNBK RX7225 Hutch Lower-Front Lid Assy, Green w/ Black handle 1
5 Z-RX5525HC-13 MBBK RX7225 Hutch Lower-Front Lid Assy, Matte Black w/ Black handle 1
5 Z-RX5525HC-13 ORBK RX7225 Hutch Lower-Front Lid Assy, Orange w/ Black handle 1
6 ZST300350M6
Strut door support for a RX722501, RX723001HC & DX722101HC
hutch, M6 stud ball joint
, 40 kg. force
2
6 ZST300350M6Q
Strut door support for a RX722501, RX723001HC & DX722101HC
hutch,
M6 stud ball joint with wire pin quick disconnect, 40 kg.
2
7 Z-7225HC-20 SPLICER POST ASSY, internal part 2
ZRB-10 OD Rubber bumper, 10 mm OD 2
12 Z-5525HC-19 BK RX 72" Hutch adjustable shelf, For 25" deep, Black 1
12 Z-5525HC-19 BL RX 72" Hutch adjustable shelf, For 25" deep, Blue 1
12 Z-5525HC-19 GN RX 72" Hutch adjustable shelf, For 25" deep, Green 1
12 Z-5525HC-19 MB RX 72" Hutch adjustable shelf, For 25" deep, Matte Black 1
12 Z-5525HC-19 OR RX 72" Hutch adjustable shelf, For 25" deep, Orange 1
ZRG-38 RUBBER GROMMET - 38 MM ID 2
11 ZM6SCPH-12 M6 X 12MM SCREW, Pan head 18
13 Z-PS333032 POWER STRIP, 2.1A USBX2, 120VX3 1


ITEM # PART NUMBER DESCRIPTION QTY
15 ZM6SCSH-35 M6 x 35 mm Socket Head Screw, for RX/DX HC door hinge 2
16 ZM8WAFT-BK M8 flat washer, Black 2
16 ZM8WAFT-BL M8 flat washer, Blue 2
16 ZM8WAFT-GN M8 flat washer, Green 2
16 ZM8WAFT-MK M8 flat washer, Matte Black 2
16 ZM8WAFT-OR M8 flat washer, Orange 2
16A ZM8SCHX-16 BK M8X16 Hex Bolts, Black 2
16A ZM8SCHX-16 BL M8X16 Hex Bolts, Blue 2
16A ZM8SCHX-16 GN M8X16 Hex Bolts, Green 2
16A ZM8SCHX-16 MB M8X16 Hex Bolts, Matte Black 2
16A ZM8SCHX-16 OR M8X16 Hex Bolts, Orange 2
14 Z-7225HC-22 BK Hutch-RC Connecting Bracket for sides, BK 2
14 Z-7225HC-22 BL Hutch-RC Connecting Bracket for sides, BL 2
14 Z-7225HC-22 GN Hutch-RC Connecting Bracket for sides, GN 2
14 Z-7225HC-22 MB Hutch-RC Connecting Bracket for sides, MB 2
14 Z-7225HC-22 OR Hutch-RC Connecting Bracket for sides, OR 2
8 ZM4SCCS-10 M4 Screw, Counter sink, 10 mm long, for splicer mounting to RC 2
17 Z-ECM13 Hole plug for RX/DX hutch pivot hole 2
18 Z-LK EX01-04 SEE KEY CODE ON LOCK (EX01-04) 1
19 ZTRRX564-CR RX72, RX55 & RX41 chest or hutch vertical side trim chrome. 2
19 ZTRRX564-BK RX72, RX55 & RX41 chest or hutch vertical side trim, Black finish. 2
20 ZDPRX1305-BK 72" RX Chest or Hutch lid handle, Black 1
20 ZDPRX1305-CR 72" RX Chest or Hutch lid handle, Chrome 1
ZM4SCPH-6 PAN HEAD M4 SCREWS, 6 MM LONG for handle 8
ZM4SCPH-12 PAN HEAD M4 SCREWS, 12 MM LONG for power strip 4
ZM4WAFT-ST BK
M4 flat washer, steel, Black, for handle & power strip (8 already
installed on door panel)
12
ZM4NTLK ZK M4 Nylon lock nut, Zn plating
4
ACPTRBK Adjustable Power Tool Rack, Black 1
ACPTRBL Adjustable Power Tool Rack, Blue 1
ACPTRGN Adjustable Power Tool Rack, Green 1
ACPTRMB Adjustable Power Tool Rack, Matte Black 1
ACPTROR Adjustable Power Tool Rack, Orange 1
*NOT SHOWN ON DRAWING

Step 0: PRIOR TO ASSEMBLY
a. BEFORE ASSEMBLING SIDE PANEL, check the tightness of
the Splicer Posts by inserting them into the side trim. The t
should be snug while still allowing the post to be inserted or
pulled out of the trim. Use the adjustment screw to tighten or
loosen the t of the post as needed.
b. Roller Cabinet Work Surface & Spacer Instructions:
i. If installing on 5/8” (15mm) black MDF work surface,
proceed to Step 1.
ii. If installing on 1” (25mm) black MDF or Stainless Steel
work surface, then SPACER at bottom of both Side Panels
MUST be removed BEFORE continuing to Step 1.
Adjustment
screw to manage
tightness of t in
trim piece
Step 1: Attach Splicer Posts to Side Panels
a. Slide Splicer Post Assembly (#9) into
bottom opening of the left-hand Side Panel
Assembly(#2).
b. Line up hole in Splicer Post with hole in
Side Panel.
c. Insert Counter Sink Screw (#8) and tighten.
Do not completely tighten until hutch is
fully assembled.
d. Repeat for other side.
Adjustment
Screw
Check t of Splicer Post
BEFORE attaching to Side
Panel. Adjust as necessary
using Adjustment Screw.
Counter Sink Screw attaches
Splicer Post to Side Panel.
Remove SPACER if installing on
1” MDF or Stainless Steel Work
Surface

Step 2: Install Side Panels on Roller Cabinet
a. Remove plastic end caps from the top of the trim located at the front
corners of the roller cabinet.
b. Slide end of splicer channel into opening where plastic end cap was
located until side panel rests on top of MDF/Stainless Steel Top.
c. Repeat process for right-hand side.
Plastic End Cap
Plastic
End
Cap

Step 3: Secure Side Panels
a. Loosely install one Hold-Down Bracket (#14) on each side
using one at washer (#16) and one M8 bolt (#15) for each
side.
If attaching the side locker or side box, do not use Hold-Down
Bracket on that side.
OPTION: To make installing the back panel easier, you may wait
until the end to install Hold-Down Bracket.
Hold-Down
Bracket
Flat
Washer
M8 Bolt
Back Raised Edge
(aka: Fence Rail)

Determine adjustable shelf height.
Pre-thread (2) screws about halfway in
on each side at desired height.
Step 4: Install Adjustable Shelf
a. Determine the desired height for the Adjustable Shelf. Pre-thread (2)
screws (#11) about halfway in on left-hand and right-hand sides.
b. Locate the (2) open slots on each side of the shelf. Line up the open
slots with the (4) threaded screws that were installed in Step 5d. Lay
down shelf so that (4) open slots t on top of the (4) screws.
c. Loosely tighten (4) screws.

Back Raised Edge
(aka: Fence Rail)
Slide Back Panel down
behind Side Panels with
bottom of Back Panel tting
between roller cabinet fence
rail and top work surface.
Back panel ange should
rest inside the Side
Panel
Step 5: Install Back Panel
a. Pull MDF board/Stainless Steel Top forward approximately 1/8” from
Back Raised Edge (aka: Fence Rail.)
b. Lift Back Panel into place behind the two side panels. (BACK PANEL is
HEAVY and requires 2 people to place!) Slide the bottom edge of the
Back Panel between the MDF/Stainless Steel Top and rear fence rail
of roller cabinet. Flange on left and right sides of back panel should be
resting against the inside back edges of both side panels.

Locate threaded inserts
and insert (2) screws
through the back
pegboard then through
shelf holes to secure
shelf to Back Panel.
Secure side panel to back panel using (6)
M6x16mm Pan Head Screws
Step 6: Secure Back Panel
c. Locate (2) threaded inserts on the back of the shelf. From the back of
the Back Panel, insert (2) screws through the back of the pegboard
and through the threaded inserts of the shelf and tighten.
d. Use (6) M6 screws (#11) on each side to fasten the back panel to side
panel assemblies.
e. Repeat on for right-hand side panel.

Attach long
side of spacer
to back panel
top section
and short
sides to top of
side panels.
Step 7: Attach Spacer Panel (for 30” Deep Model ONLY)
a. After the back panel has been installed, attach the spacer panel to
the top section of the back panel. Use (6) M6x12mm pan head screws to
secure spacer panel to top section of back panel.
Use (4) additional screws to attach the spacer to the top of both side
panels.

Step 8: Attach Gas Struts to Lid
a. Lay the lid down on packaging material so that the front of the lid is face down. Use a soft
surface or packaging material under the lid so that it does not get scratched or damaged.
b. Locate the middle hinge of the front/top lid assembly.
c. Using a Phillips screw driver, remove 3 screw holding hinge in place.
d. Disengage the other hinges that hold the front lid panel to the hood assembly by sliding the
front lid panel to the side. Remove front lid panel and lay down with the inner sti󰀨ener panel
facing up onto a soft surface to prevent scratching.
Remove Front Lid Panel
Disengage hinges
e. Install the piston side of the gas strut into ball joint which is located at the end of the
sti󰀨ener of the top lid panel. Repeat procedure for the other side.
Screw piston end of gas strut onto
installed ball socket on side of lid sti󰀨ener
f. Install M6x35mm socket head screw (ZM6SCSH-35) onto both side panels. Make sure the
screw head is ush with the inner side panel.

Step 10: Secure Lid to Body of Hutch - may require assistance of another adult
a. Position the top front panel so that it rests on top of the side and back panels and holes on lid and side
panels are aligned as shown below.
b. Use the Allen wrench (supplied with the parts) to drive the pre-threaded M6x35mm Sock Head Screw
(#15) into the round opening on the side of the lid. Repeat on the other side.
c. Insert one plastic hole plug (#17) in each of the socket head screw openings.
Top of Lid
Side of Hutch
M6x35mm Socket
Head Screw
(#15)
Drive screw into
opening on side
of lid using Allen
wrench

Step 11: Secure Gas Strut to Side of Hutch
a. Lift top/front panel so that the unattached ball joint on the gas strut is lined up
with the rivet nut hole on the side panel.
b. Hand-tighen the male stud into the rivet nut opening. Strut must be fully
engaged with the ball stud. Open and close the lid to conrm alignment. You
should feel some tension when engaging the strut.
c. Securely tighten socket in place using M12 Box wrench.
d. Repeat for the gas strut (#6) on the other side.
e. Test lid function by opening and closing several times.
e. 

Align ball joint
with rivet nut hole
on side panel.
Secure the male
end of the piston
into the opening
on the side of the
hutch. Secure
with M12 box
wrench.

Re-attach front panel
by re-engaging hinges
from front panel with
hinges on lid.
Hinges
Hutch with lid and front
panel attached.
Step 12: Re-Attach Front Panel to Lid
a. Lift front panel into place to re-attach to lid. Align the hinges on the top panel with the hinges on
the lid and slide into place. Smooth side of lid should face out - panel sti󰀨ener should be on the
inside.
b. Replace and secure the front panel to lid with 3 Phillip screws that were removed in Step 8.
c. Securely tighten the screws.
d. Open and close the lid several times to conrm that lid is secure and aligned.

Step 12: Final Details
a. If you did not install the Hold Down Bracket in Step 3, then do so now.
b. Securely tighten ALL screws and bolts!
FULLY ASSEMBLED
RX SERIES HUTCH
shown on
RX SERIES ROLLER CABINET
