FabiaTech FB2701 User manual

i
FabiaTech Corporation
IPC Solution
Website: http://www.fabiatech.com
Email: [e-mail]
ISA CPU Card
Low Power Series
FB2701 User’s Manual
JULY 2019
Version: 1.1
Part Number: FB2701

ii
Copyright
Copyright © 2017 FabiaTech Corporation. The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, magnetic etc. or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system board, or setting up the
relevant devices, and software that are not explained in this manual, please
contact our service engineer for service, or send email to [email protected].
Returning Your Board for Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
Description of you peripheral attachments
Description of you software (operating system, version, application software,
etc.) and BIOS configuration
Description of the symptoms (Extract wording any message)
For updated drivers, manuals, or product information, please visit us at
www.fabiatech.com

iii
Table of Contents
FB2701 User’s Manual ...........................................................................................................i
Chapter 1 Introducing the FB2701 CPU Card........................................................................... 1
Overview..................................................................................................................................1
Series Comparison Table.......................................................................................................2
Layout.......................................................................................................................................3
Specifications..........................................................................................................................4
Packing List..............................................................................................................................5
Chapter 2 Hardware Installation ............................................................................................... 7
Before Installation...................................................................................................................7
Hardware Features.................................................................................................................8
DIMM1: DIMM Socket for DDR3L SDRAM Modules ........................................9
CN18: CFAST Socket...........................................................................................9
CN1 & CN2: Serial ATA hard Disk Connector .................................................9
J1 & J2: USB Port & Connector Header.........................................................10
CN8, CN3, CN4 & CN5: Serial Ports 0, 1, 2, 3 Connectors...........................10
CN17 & CN16: Keyboard/Mouse Connector...............................................11
CN10: RJ45 LAN Connector............................................................................11
J4: CPU or System Fan Connector .................................................................12
JP2: Clear CMOS Data.....................................................................................12
CN7 & CN6: PCIe Mini Card or m-SATA Module & SIM Card.....................13
BUS1: PC/104 Bus Connectors.........................................................................14
BUS4: PCIeX1......................................................................................................15
CN9: External Bus Connector for Audio Function........................................16
CN14: Auxiliary Power Connector (for ATX Power Supply Only) ..............17
J3 & BZ1: Multi Function Header and On-Board Buzzer..............................18
Chapter 3 Installing VGA & LCD Display................................................................................. 19
LVDS LCD FLAT PANEL DISPLAY...........................................................................................19
VGA Display (CN13).............................................................................................................20
CN12 & CN11: LVDS Connector and Power Connector............................21
Chapter 4 BIOS Setup............................................................................................................... 23
Overview................................................................................................................................23
BIOS Functions...................................................................................................24

iv
Keyboard Convention.....................................................................................25
Main Setup ............................................................................................................................26
Advanced Setup..................................................................................................................27
ACPI settings......................................................................................................28
CPU Configuration............................................................................................30
IDE Configuration..............................................................................................32
USB Configuration.............................................................................................34
SMART Settings...................................................................................................37
IT8786 Super IO Configuration.........................................................................38
Hardware Health Configuration.....................................................................41
Wake Configuration.........................................................................................42
Realtek PCIe GBE Family Controller (MAC)..................................................43
ITE8888 Setting...................................................................................................44
ITE8888 ISA Decode Memory ..........................................................................46
Chipset...................................................................................................................................47
North Bridge.......................................................................................................48
North Bridge LVDS Config Select....................................................................50
South Bridge.......................................................................................................51
Boot ........................................................................................................................................54
CSM Parameters ...............................................................................................56
Security...................................................................................................................................58
Save & Exit .............................................................................................................................60
Chapter 5 Software Installation ............................................................................................... 63
Install AMD Catalyst ™ Drivers............................................................................................63
WIN XP/7 32/64 Driver................................................................................................63
Audio Driver...........................................................................................................................64
WIN XP/7 X86/X64 Driver ...........................................................................................64
LAN Driver (RTL 8111F)..........................................................................................................64
WIN XP/7 Driver X86/X64 Driver................................................................................64
PCI to ISA Bridge Drivers ......................................................................................................65
WINDOWS Driver ........................................................................................................65
BIOS Flash Utility.....................................................................................................................65
Watchdog Timer...................................................................................................................66

v
Watchdog Timer Setting..................................................................................67
Watchdog Timer Enabled ...............................................................................68
Watchdog Timer Trigger ..................................................................................68
Watchdog Timer Disabled...............................................................................68
Chapter 6 Technical Reference .............................................................................................. 69
Technical Reference............................................................................................................69
Physical and Environmental............................................................................69
Real-Time Clock and Non-Volatile RAM .......................................................69
CMOS RAM Map...............................................................................................71
I/O Port Address Map.......................................................................................72
Interrupt Request Lines (IRQ)...........................................................................73
Serial Ports ..........................................................................................................74
Configure Positively Decode I/O port & Memory...........................................................78
Appendix................................................................................................................................... 80
Dimension....................................................................................................................80

vi

FabiaTech Corporation
1
Chapter1IntroducingtheFB2701CPUCard
Overview
The FB2701 is an AMD® G-Serial T40E low power all–in-one ISA CPU card. This user’s
manual provides information on the physical features, installation, and BIOS setup.
Built to unleash the total potential of the AMD® G-Serial T40E Processor, the FB2701 is
an ISA CPU card capable of handling today’s demanding requirements. Able to
support 1GHz CPU, this unit supports 10/100/1000 Base –TX interface network port,
audio, 2 SATA, CFAST socket, PCIe mini card socket for Wireless, GPRS or m-SATA, 1
DIMM socket supports up to 4GB DDR3L RAM, four USB2.0 ports, and a VGA controller.
Each FB2701 has four ports for I/O communications. Three RS-232 and one RS-232
/422/485 ports are available. There is also a watchdog timer that can be configured
from software to automatically reset the system.
The CPU card perfect for POS and POI applications, network systems, panel / MMI’s,
order entry kiosks and test equipment. The unit is only 185x122 mm.

FabiaTech Corporation
2
SeriesComparisonTable
Model FB2701
Processor AMD® G-Serial T40E 1.0 GHZ
Memory
204 Pin So-DIMM*1 DDR3L-1066 2GB
4GB (Max.)
Display VGA/LVDS
S-Chipset AMD Fusion Controller HUB A55E
Multi I/O Port Three RS232 &
One RS232/RS422/RS485
USB 2.0 Port Four
SATA Port
CFAST Socket
Storage m-SATA (PCIe Mini Card Socket)
Audio* Line -Out And MIC-In
RJ45 LAN port
(100/1000Mbps) Realtek RTL8111F
PCIe Mini Card Socket One
SIM Card Socket One
Watchdog Timer Yes
BUS* PC/104, ISA & PCIe*1
Operating Temperature 0~+ 60℃(32~140℉)
Storage Temperature -20~+70℃(-4~158℉)
Dimensions (Unit: mm) 185(D) x 122(W)
* Audio Function is optional.
* The ISA bus can’t support DMA.

FabiaTech Corporation
3
Layout
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
CN18 DIMM1

FabiaTech Corporation
4
Specifications
Processor & Memory –
AMD® G-Serial T40E 1.0 GHZ (512KB L2 Cache For Per Core) Dual Core Low
Power Processor
One 204 pin So-DIMM socket support 2G to 4G DDR3L RAM module
I/O Outlets –
One 10/100/1000 base-TX Ethernet LAN port with RJ45
VGA connector with DB15 and LVDS LCD Connector
4 USB ports (2.0) and providing AC97 audio function
PS/2 compatible keyboard and mouse interface
3 RS-232 and 1 RS-232/RS422/RS485 port
Bus –
16 Bit ISA, PC104 & PCIe *1
LED Indicator –
Providing onboard hard disk access and system LED.
Storage -
CFAST Compact Flash socket for CFAST Compact Flash modules
2 SATA connectors for Hard Disk or Solid State Disk
Power requirement –
+5V DC only, 5.3A maximum (2.7A Typical) / Supports AT and ATX mode
function
Dimensions -
ISA form-factor, 185 mm x 122 mm

FabiaTech Corporation
5
PackingList
Upon receiving the package, verify the following things. Should any of the mentioned
happens, contact us for immediate service.
•Unpack and inspect the FB2701 package for possible damage that may occur
during the delivery process.
•Verify the accessories in the package according to the packing list and see if
there is anything missing or incorrect package is included.
•If the cable(s) you use to install the FB2701 is not supplied from us, please make
sure the specification of the cable(s) is compatible with the FB2701.
Note: after you install the FB2701, it is recommended that you keep the diskette or
CD that contains drivers and document files, document copies, and
unused cables in the cartoon for future use.
The following lists the accessories that may be included in your FB2701 package.
Some accessories are optional items that are only shipped upon order.
•1 FB2701all-In-One ISA CPU Card.
•1 dual serial port interface cables with bracket.
•2 dual USB adapter cable with bracket.
•1 Compact disc containing manual file in PDF format and necessary drivers
and utilities.
Optional:
•Y-type keyboard and mouse port adapter cables. (P/N: 7003000008G)
•One Serial port interface cable. (P/N: 7001000006G)
•FB4706- Audio/USB adapter board with cables. (PN: 0103020022G-21)
•AK1006- Half size mini PCIe module adapter kits. (PN: 0606010028G)
•BP04IE- Backplane 4 slots+ 1 PCIe*1 slot. (PN: 0103000019G-11)

FabiaTech Corporation
6

FabiaTech Corporation
7
Chapter2HardwareInstallation
This chapter introduces the system connectors & jumper settings, and guides you to
apply them for field application.
BeforeInstallation
Before you install the system, make sure you follow the below descriptions.
1. Before removing the CPU card from its anti-static bag, wear an anti-static strap to
prevent the generation of Electricity Static Discharge (ESD). The ESD may be
generated by man’s physical touch. It may do damage to the board circuit.
2. Install any connector, module, or add on card, be sure that the power is
disconnected from the CPU card. If not, this may damage the CPU Card
components, module, or the add-on-card.
3. When you connect the connectors and memory modules, be careful with the pin
orientations.

FabiaTech Corporation
8
HardwareFeatures
The following lists the connectors and jumpers to install the FB2701.
Item Description
CN1, CN2 SATA Connector (7-Pin)
CN8, CN3,
CN4, CN5 COM1(CN8-DB9)-RS232/422/485 port, COM2(CN5)/ COM3(CN4)/ COM4(CN3)– RS232
(JST 2*5- Pin 2.0mm)
CN6 SIM Card Socket for GPRS
CN7 PCIe Mini Card socket for Wireless, GPRS or m-SATA module
CN9 HD Audio Connector (IDC 2*6 - Pin 2.0mm )
CN10 LAN Connector (RJ45 )
CN11,CN12 LVDS LCD Connector (DF13 30- Pin) /Power Connector for LVDS LCD Backlight(JST 5- Pin)
CN13 VGA Connector (DB-15)
CN14 Mini-ATX power connector (ATX 2*5- Pin)
CN15 ATX Power Signal (JST 4- Pin 2.5mm)
CN16 PS-2 Keyboard and Mouse connector (JST 6- Pin 2.0mm)
CN17 Keyboard and Mouse connector (6- Pin mDin)
CN18 CFAST Socket
J1, J2 USB #1/#2/#3/#4 ports connector header (2*5- Pin 2.54mm)
J3 Multi Function Header – PW Button+ RS Button+ Power+ LAN LED(2*4- Pin 2.54mm)
J4 Case/CPU cooling fan header (3- Pin 2.54mm)
JP2 Clear CMOS data header (3- Pin 2.54mm)
BZ1 On board Buzzer
DIMM1 DDR3L SDRAM So-DIMM Socket (204- Pin)
BUS1 PC/104 Bus
BUS4 PCIe*1

FabiaTech Corporation
9
DIMM1: DIMM Socket for DDR3L SDRAM Modules
The 204 pin So-DIMM socket supports 2GB to 4GB of DDR3L RAM modules.
CN18 DIMM1
CN18: CFAST Socket
The CFAST Compact Flash socket CN18 (on the solder side) is support CFAST Compact
Flash.
CN18 DIMM1
CN1 & CN2: Serial ATA hard Disk Connector
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
Pin Signal
1 Ground
2 TX-DP
3 TX-DN
4 Ground
5 RX-DN
6 RX-DP
7 Ground

FabiaTech Corporation
10
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
J1 & J2: USB Port & Connector Header
The CPU card supports four USB port. Any USB device can be attached to USB ports
with plug-and-play supported, J1 and J2 are 10-pin connectors. Use the inclued USB
adapter cable and (or) FB4706 Audio board (Option) can attach up to 4 USB devices.
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
CN8, CN5, CN4 & CN3: Serial Ports 0, 1, 2, 3 Connectors
The Serial port 0 (CN8-DB9) is designed for multiple proposes. It could be RS-232, RS-422
or RS-485 by BIOS CMOS setting. Use the included serial cables for transferring 10-pin
JST to 9-pin D-sub connector. The following tables show the signal connections of these
connectors.
Pin Signal Pin Signal
1 USBV0 2 Case Ground
3 USBD0- 4 USBG1
5 USBD0+ 6 USBD1+
7 USBG0 8 USBD1-
9 Case Ground 10 USBV1
Pin RS-232 DB9 RS-422 RS-485
1 -DCD 1 TX- 485-
2 -DSR 6 - -
3 RXD 2 TX+ 485+
4 -RTS 7 - -
5 -TXD 3 RX+ -
6 -CTS 8 - -
7 -DTR 4 RX- -
8 -RI 9 - -
9 GROUND 5 - -
10 GROUND Shield - -
Mode/Serial Port0 Port1 Port2 Port3
RS-232 CN8 CN5 CN4 CN3
RS-422 CN8 - - -
RS-485 CN8 - - -
Mode Select BIOS - - -
J1 & J2
2
1
10
9
CN3/CN4/CN5
1
2
9
10
6
5
1
9
DB9- CN8

FabiaTech Corporation
11
CN17 & CN16: Keyboard/Mouse Connector
CN17 is a standard PS/2 type keyboard connector and any PS/2 type keyboard can
plug into CN17 directly without extra adapter cable. Use the keyboard + mouse
adapter cable (optional), you can connect keyboard and mouse simultaneously.
CN16 is another way to attach keyboard and mouse with optional adapter cable.
CN10: RJ45 LAN Connector
The RJ45 connector with 2 LED’s for LAN. The down side LED (orange) indicates data is
being accessed and the up side LED (green) indicates on-line status. (On indicates on-
line and off indicates off-line)
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
Pin Signal
1 Mouse Data
2 Keyboard Data
3 Ground
4 VCC
5 Mouse Clock
6 Keyboard Clock
RJ45 Signal RJ45 Signal
1 MDI0+ 5 MDI2-
2 MDI0- 6 MDI1-
3 MDI1+ 7 MDI3+
4 MDI2+ 8 MDI3-
Front View
CN16
6
1
CN17
CN10
(Front View)
8
1
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16

FabiaTech Corporation
12
J4: CPU or System Fan Connector
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
JP2: Clear CMOS Data
You can use JP2 to clear CMOS data. The CMOS stores information like system date,
time, boot up device, password, IRQ… which are set up with the BIOS. To clear the
CMOS, set JP2 to 2-3 closed and wait 3~5 sec then return to open before powers is off.
The default setting is 1, 2 closed.
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
Pin
Signal
1 Ground
2 +12V
3 Speed-In
J4
3 1
2
JP2
Clear CMOS Data
1
2
3
Normal Operation
Default
1
2
3

FabiaTech Corporation
13
CN7 & CN6: PCIe Mini Card or m-SATA Module & SIM Card
This CPU card supports PCIe mini card socket; you may extend additional PCIe mini
card module and SIM card or m-SATA module to card. Connect to the antenna cable
to GPRS or Wireless LAN module and install the SIM card for GPRS.
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
¾Installing AK1006 kit (Optional): For Half Size Mini PCIe module
Note: 1. When installing PCIe GPRS Mini card on CPU card these is need the installing the
SIM Card to SIM socket.
2. The insert SIM card into the SIM card socket. Make sure that the SIM card is properly
inserted and that golden contact area on the card is facing downwards.

FabiaTech Corporation
14
BUS1: PC/104 Bus Connectors
J1 J2 CN1 CN2 CN3 CN4 CN5
CN13
CN17
CN10
CN8
JP1
J3
U20 U22
CN11
CN12
CN14
CN15
J4 BUS1
BT1
CN6
CN7 D1
D2
CN9
JP2
CN16
PC/104 A&B Pin
Pin Signal Pin Signal Pin Signal Pin Signal
A1 -IOCHK A17 SA14 B1 Ground B17 --
A2 SD7 A18 SA13 B2 RSTDRV B18 --
A3 SD6 A19 SA12 B3 +5V B19 -Refresh
A4 SD5 A20 SA11 B4 IRQ9 B20 BUSCLK
A5 SD4 A21 SA10 B5 -- B21 IRQ7
A6 SD3 A22 SA9 B6 -- B22 IRQ6
A7 SD2 A23 SA8 B7 -- B23 IRQ5
A8 SD1 A24 SA7 B8 -ZWS B24 IRQ4
A9 SD0 A25 SA6 B9 +12V B25 IRQ3
A10 IORDY A26 SA5 B10 KEY B26 --
A11 AEN A27 SA4 B11 -SMEMW B27 TC
A12 SA19 A28 SA3 B12 -SMEMR B28 ALE
A13 SA18 A29 SA2 B13 -IOW B29 +5V
A14 SA17 A30 SA1 B14 -IOR B30 OSC
A15 SA16 A31 SA0 B15 -- B31 Ground
A16 SA15 A32 Ground B16 -- B32 Ground
PC/104 C& D Pin
Pin Signal Pin Signal Pin Signal Pin Signal
C1 GND C11 MEMW# D1 Ground D11 --
C2 SBHE C12 SD8 D2 MEMCS16# D12 --
C3 LA23 C13 SD9 D3 IOCS16# D13 --
C4 LA22 C24 SD10 D4 IRQ10 D14 --
C5 LA21 C25 SD11 D5 IRQ11 D15 --
C6 LA20 C26 SD12 D6 IRQ12 D16 --
C7 LA19 C27 SD13 D7 IRQ15 D17 VCC
C8 LA18 C28 SD14 D8 IRQ14 D18 -
C9 LA17 C29 SD15 D9 -- D19 GND
C10 MEMR# C20 KEY D10 -- D20 GND
Note: The FB2701 does not support ISA-DMA mode. The PC/104 and ISA can’t
automatically get accessed to I/O Port resource; when set ITE8888 ISA Decode is Positively
decode, if you add on the I/O card or memory card to FB2701.You can refer to Chapter 6
Technical Reference “ Configure Positively Decode I/O port & Memory ” for setting up the
I/O port address and Memory resource
BUS1 – BUS C & D
BUS1 – BUS A & B
