FabiaTech Fanless Series User manual

FabiaTech Corporation
IPC Solution
Website: http://www.fabiatech.com
Email: [e-mail]
Small Cube System
Fanless Series
FX5639/FX5639L
User’ Manual
MAR 2019
Version: 2.0
Part Number: FX5639

Copyright
Copyright © 2017 FabiaTech Corporation, The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, and magnetic… or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system or setting up the relevant
devices, and software that are not explained in this manual, please contact our
service engineer for service, or send email to sup[email protected].
Returning Your Board for Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
Description of you peripheral attachments
Description of your software (operating system, version, application
software, etc.) and BIOS configuration
Description of the symptoms (Extract wording any message)
For updated BIOS, drivers, manuals, or product information, please visit us at
www.fabiatech.com
ii

Table of Contents
FX5639/FX5639L User’ Manual..........................................................................................i
Chapter 1 Introducing the FX5639 System ............................................................................... 1
Overview..................................................................................................................................1
Series Comparison Table.......................................................................................................2
Layout.......................................................................................................................................3
Specifications..........................................................................................................................5
Packing List..............................................................................................................................6
Chapter 2 Hardware Installation ............................................................................................... 9
Before Installation...................................................................................................................9
To install Hardware- remove the bottom cover...........................................10
LED Indicators (On the Front Panel)...............................................................17
I/O Peripheral Connectors ..............................................................................17
Connecting the DC Power and Power Button ............................................21
Internal Connector and Jumper Setting.......................................................22
Chapter 3 BIOS Setup............................................................................................................... 25
Overview................................................................................................................................25
BIOS Functions ...................................................................................................26
Keyboard Convention.....................................................................................27
Main Setup ............................................................................................................................28
Advanced Setup..................................................................................................................29
ACPI settings......................................................................................................30
IT8786 Super IO Configuration.........................................................................32
Hardware Monitor Configuration...................................................................36
Serial Port Console Redirection ......................................................................37
CPU Configuration............................................................................................43
Thermal Configuration Parameters................................................................46
SATA Configuration...........................................................................................47
Network Stack Configuration..........................................................................48
CSM Configuration...........................................................................................49
USB Configuration.............................................................................................51
Security Configuration .....................................................................................54
iii

Realtek PCIe GBE Family Controller (MAC)..................................................55
Chipset...................................................................................................................................56
North Bridge.......................................................................................................57
South Bridge.......................................................................................................60
Security...................................................................................................................................64
Boot ........................................................................................................................................66
Save & Exit.............................................................................................................................68
Chapter 4 Software Installation ............................................................................................... 71
System Driver.........................................................................................................................71
WIN 7/8.1/10 -32/-64 Driver..............................................................................71
VGA Driver.............................................................................................................................72
WIN 7/8.1/10 -32/-64 Driver..............................................................................72
Audio Driver...........................................................................................................................72
WIN 7/8.1/10 X86/X64 Driver............................................................................72
LAN Driver (RTL 8111F)..........................................................................................................73
WIN 7 Driver X86/X64 Driver.............................................................................73
USB 3.0 Driver.........................................................................................................................73
WIN7 X86/X64 Driver .........................................................................................73
TXE Driver................................................................................................................................74
WIN7/8.1/10 X86/X64 Driver.............................................................................74
EFI BIOS Flash Utility...............................................................................................................75
Watchdog Timer...................................................................................................................76
Watchdog Timer Setting..................................................................................77
Watchdog Timer Enabled ...............................................................................78
Watchdog Timer Trigger ..................................................................................78
Watchdog Timer Disabled...............................................................................78
Digital I/O (GPIO) programming........................................................................................79
Chapter 5 Technical Reference .............................................................................................. 81
Technical Reference............................................................................................................81
Physical and Environmental............................................................................81
Serial Ports..........................................................................................................82
Parallel Ports.......................................................................................................86
Appendix................................................................................................................................... 89
iv

v
Dimension..............................................................................................................................89

FabIATech Corporation
Chapter1IntroducingtheFX5639System
Overview
The FX5639 is an embedded system with Intel® Celeron® Braswell low-power CPU
module inside. This user’s manual provides information on the physical features,
installation, and BIOS setup of the FX5639.
Built to unleash the total potential of the Intel® Celeron® N3160 Quad-Core
Processor, Able to support 1.6 GHz CPU, this system supports two 10/100/1000M
Base –TX LAN ports, one PCIe Mini Card connector for Wireless/GPRS modules, four
USB 2.0 and three USB 3.0 ports, Audio, GPIO, and two So-DIMM socket supports up
to 8GB DDR3 RAM, free expansion PCI or PCIE slot, DP, HDMI and VGA ports.
Each FX5639 has six serial ports and parallel port for I/O communications. Four RS-
232 ports and two RS232/RS422/RS485 port are available; the two RS232 and two
RS232/ RS422/ RS485 with DB9 on the rear I/O and other two RS232 and parallel
ports need use the system board to rear panel bracket option cable.
The FX5639 is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,
gaming and infotainment, measurement technology, lotteries, banking and Thin
Client and small Embedded Control.
1

FabIATech Corporation
2
SeriesComparisonTable
Model FX5639 FX5639L
System Processor Intel ® Celeron ® N3160
(Braswell)
Clock Speed 1.6GHZ
Cache 2M/L2
Burst Frequency 2.24 GHZ
Graphics Display VGA/HDMI/DP
Memory
204 Pin-DIMM*2 DDR3L-1333 4GB / 8GB (Max.)
One CFAST SocketStorage One 2.5’ SATA HDD Connector
USB 2.0 / 3.0 Four / Three
Audio Ear-Phone/Line-In And MIC-In
RJ45 LAN port
(10/100/1000 Mbps) Two Realtek RTL8111F
Two RS232 and Two RS232/RS422/RS485Multi I/O Internal Two RS232 and One Parallel
GPIO Two- In/Two-Out
PCIe Mini Card Socket One
SIM Card Socket One
Watchdog Timer Yes
Half size mini PCIE Module
Adapter kits
(OPI)
AK1006
PN:0606010028G
Wall Mounting Kit
(OPI) FX5636K1
P/N:0606010027G
One PCI & PCIE
Riser Card Kit (OPI) - FB4745
P/N: 0120010004R
One/Two PCI Bus
Riser Card Kit (OPI) FB4705
P/N:0153000001G FB4730 P/N: 0153010001G
One/Two PCIE Bus
Riser Card Kit (OPI) FB4744
P/N: 0120010003R -
Operating Temperature - 20~+ 55℃(4~131℉)
Storage Temperature - 30~+70℃(-22~158℉)
Dimensions (Unit: mm) 190(W) x 240(D) X 82(H) 190(W) x 240(D) X 105(H)
Note: OPI (Option Item)

FabIATech Corporation
3
Layout
¾a. FX5639
2
CFAST
OUT
+10
12~24V
1
IN
-01
D I/O 2 3
ANTENNA RESET LAN2
DISPLAY3DISPLAY2 EAR-PHONE LAN1
USB
POWER BUTTON CFASTDIGITAL I/O MIC LINE IN HDD
DC IN
ANTENNA ANTENNA
COM1COM3 USB
DC12~24V
-+
1
19V
42
3 1
10101 1 2
COM4VGA LAN2 SLOT COM2 LAN1

FabIATech Corporation
¾b. FX5639L
1
2
3
CFAST
IN 2
-01
D I/O
OUT
+10
12~24V
LAN1
HDDLINE IN
MIC
DISPLAY3DISPLAY2
CFAST
EAR-PHONE
USB
RESET LAN2
DIGITAL I/O
ANTENNA
POWER BUTTON
1
4
3
DC12~24V
1
-
19V
+
10101
2
12
SLOTVGA COM4 COM2 LAN1 LAN2
COM1DC IN
ANTENNA COM3 ANTENNA
USB
4

FabIATech Corporation
Specifications
Processor Board –
Intel ® Celeron ® Braswell N3160 Quad-Core Soc 1.6GHZ (Burst- 2.24GHz)
Low Power Processor with 4GB DDR3L-RAM.
I/O Outlets –
Two 10/100/1000 base-TX Ethernet LAN ports
Three USB 3.0 (front side) and four USB 2.0 (rear side) ports
Two RS-232 and Two RS-232/RS422/RS485 port with DB9
One HDMI, one DP Port and one VGA display connector with DB15
Three audio connectors for Earphone, Line-In and Microphone-in
Two-In and two-out GPIO with terminal block
One PCIE Mini card socket modules, especially for WLAN/GPRS module
One free PCI or PCIe slot for add-on PCI/PCIe card
One DC-In jack connector/terminal block with power push button switches
LED Indicator –
One power LED, One HD/CFAST access LED, and two LAN-Link LED
Storage Bay-
CFAST Compact Flash socket for CFAST Compact Flash modules
One 2.5" SATA hard disk space
Power requirement –
+12 ~ +24V DC, 2.82A maximum (1.22A typical) with 19V input voltage
Dimensions -
FX5639 - 190mm (W) x 240mm (D) x 82mm (H)
FX5639L - 190mm (W) x 240mm (D) x 105mm (H)
5

FabIATech Corporation
PackingList
Upon receiving the package, verify the following things. Should any of the
mentioned happens, contact us for immediate service.
•Unpack and inspect the FX5639 package for possible damage that may
occur during the delivery process.
•Verify the accessories in the package according to the packing list and see
if there is anything missing or incorrect package is included.
•If the cable(s) you use to install the FX5639 is not supplied from us, please
make sure the specification of the cable(s) is compatible with the FX5639
system.
Note: after you install the FX5639, it is recommended that you keep the diskette or
CD that contains drivers and document files, and keep the document
copies, or unused cables in the carton for future use.
The following lists the accessories that may be included in your FX5639 package.
Some accessories are option items that are only shipped upon order.
•One FX5639x embedded system.
•One AC to DC power adapter and 1 AC power cord.
•One 3-pin and one 6-pin apartable terminal block.
•One pack for HDD/riser card/mini card installation fixed screws (2/2/2).
•Four rubber stands with 4 fixed screws.
•One compact disc includes software utility and manual.
Option Items for All FX5639x:
•AK1006- Half size mini PCIe module adapter kits. (PN: 0606010028G)
•FX5636K1- Wall mounting Kit (P/N:0606010027G)
•One Serial and parallel port interface cable with bracket. (PN:7001000014G)
•Two serial ports interface cable with bracket.(PN:7001000093G)
6

FabIATech Corporation
Option Items for FX5639:
•FB4705- 1 Slot (32bit) PCI riser card. (PN: 0153000001G)
•FB4744- 1 Slot PCIE riser card. (PN: 0120010003R)
Option Items for FX5639L:
•FB4730- 2 Slot (32bit) PCI riser card. (PN: 0153010001G)
•FB4745- 1 Slot 32bit PCI + 1 slot PCIE riser card. (PN: 0120010004R)
7

FabIATech Corporation
8

FabIATech Corporation
Chapter2HardwareInstallation
This chapter introduces the system connectors & jumper settings, and guides you to
apply them for field application.
BeforeInstallation
Before you install the system, make sure you follow the following descriptions.
1. Before removing the cover, shut down the operation System and disconnect
power switch to off and unplug AC-to DC Adapter cable.
2. Install or unplug any connector, CFAST, Mini-Card , and hard disk be sure that
the power is disconnected or power switch to off from the system. If not, this
may damage the system.
3. The ESD (Electricity Static Discharge) may be created from human body that
touches the board. It may do damage to the board circuit.
9

FabIATech Corporation
To install Hardware- remove the bottom cover
If you are installing following hardware items, you can remove the bottom cover.
They include SATA 2.5" HDD inside, mini PCIE WLAN or GPRS module, PCI or PCIE
Riser card kit, PCI or PCIE expansion card and DDR3L-RAM module to the FX5639.
(Please see the spots circled.)
a. Installing CFAST Compact Flash
Use a cross-head screwdriver to remove screws that secure the front cover.
Note: The CFAST Compact Flash socket supports CFAST Compact Flash Modules.
b. Unscrew Bottom cover
Use a cross-head screwdriver to remove 10 screws that secure the bottom cover.
10

FabIATech Corporation
c. Installing Memory
If you may extend additional memory to system, see as following figure. The So-
DIMM socket supports 2GB to 4GB (Max. 8GB) of DDR3L RAM modules. Installing
memory module to DIMM1 socket, when only one memory module. We
recommend that installing dual channel (DIMM1 & DIMM2) RAM module made
by the same part number and manufacturer.
DIMM2 DIMM1
d. Installing Hard Disk
Faster Screws up the Hard disk device to HDD metal frame before plug to the SATA
connector then insert to SATA slot and screws up metal frame to system. See
following figure.
Note: Use caution when handling the hard disk to prevent damage to SATA
connector as you inserted hard disk. Be careful with the orientation when
installing connectors.
11

FabIATech Corporation
e. Installing PCIe Mini Card Module
FX5639x supports PCIe mini card socket; you may extend additional PCIe mini card
module and SIM card to system. Connect to the antenna cable from rear and front
side antenna holes to GPRS or Wireless LAN module and install the SIM card for
GPRS. See following figures.
e1. Installing PCIe Mini Card and SIM card
Note: 1. When installing PCIe GPRS Mini card on FX5639 system these is need the
installing the SIM Card to system board.
2. Open the cover with SIM socket then insert SIM card into the SIM card hold.
Make sure that the SIM card is properly inserted and that golden contact
area on the card is facing downwards.
e2. Installing Half Size Mini PCIe module kit (Option)
12

FabIATech Corporation
f. Installing PCI or PCIE Riser Card kit (Option) - for Expansion Card
FX5639 and FX5639L provides FB4705 kit- 1 slot PCI bus, FB4744 kit -1 slot PCIE bus,
FB4745 kit- 1 slot PCI and 1 slot PCIE bus, FB4730 kit -2 slot PCI bus, If you are
installing the riser card kit for Expansion PCIE hardware, you can remove the
bottom cover. The following figure will guide you how to install riser card kit inside
the FX5639/L., See following figures.
f1. Installing FB4705 or FB4744 kit- PCI or PCIE Riser Card
RISER CARD(OPTION)
f2.Installing FB4730, or FB4745 - 2PCI, or PCI+PCIE Riser Card
RISER CARD(OPTION)
13

FabIATech Corporation
14
g. To installing Expansion Card – PCI/PCIE Card
If you are installing Expansion PCI or PCIE hardware interface card, you can
remove the bottom side cover.The following figure will guide you how to install
PCI/PCIE interface card inside the FX5639 system and screw the L-Type Metal on
the PCI/PCIE card Bracket and expansion card holder. (Please see the spots
circled.)
g1. Installing PCI or PCIE Expansion Card- for FX5639
PCI Express half_length CARD
168mm REF(6.6inch)
g2. Installing PCI and PCIE Expansion Card- for FX5639L
168mmREF(6.6inch)
PCIExpresshalf_length CARD
PCISHORT CARD
Note: 1. The PCI Slot supports +3.3V/+5V/+12V (1A)/-12V (500mA).
2. The PCIE bus supports x1/x2 lanes via PCIE X16 slot.

FabIATech Corporation
h. Installing the FX5636K1 –Wall Mounting
Please refer to the down side figure for installing the FX5639/FX5636L with universal
fixers.
h1.FX5639
h2.FX5639L
15
