fantastic furniture CODA INSERT 2 DRAWER User manual

Version 1.0
CODA
INSERT 2 DRAWER
www.fantasticfurniture.com.au

Enjoy
Your purchase from
Australia’s Best Value Furniture Store
www.fantasticfurniture.com.au PAGE 2

Assembly checklist
Useful Information
www.fantasticfurniture.com.au PAGE 3
Read through the instructions carefully
before you begin.
Identify and lay out all of the components
before you begin assembly.
! Never use power tools unless specifically instructed. They can damage your components or
hardware if used incorrectly.
! If you are having any difficulties assembling your product, missing any hardware or
components please visit our website Help Centre for further assistance.
! Periodically check and re-tighten all fasteners. Check the product care label or website for
product care instructions.
! Never use any glue until you are certain that the parts belong together.
! Bulky items such as wardrobes and bunk beds should be assembled in the room they will be
used in as they may not fit through a door once assembled.
! Always use a soft surface (such as carpet or cardboard) when assembling your product to
avoid scratching or damaging the surface of the product.
! The most common mistakes made during assembly are using the wrong hardware or getting
components back to front.
Unless instructed, do not fully tighten screws
until the item is fully assembled.
Make sure you have all the required tools.
Never use power tools unless instructed.

What you need
to assemble the product
Parts list
Box 1:Left Side Panel (P1);
Right Side Panel (P2);
Rail (P3);
Back Panel (P4);
2 x Drawer Fronts (P5);
2 x Left Drawer Sides (P6);
2 x Right Drawer Sides (P7);
2 x Drawer Bases (P8);
2 x Drawer Backs (P9);
2 x Drawer Supports (P10);
www.fantasticfurniture.com.au PAGE 4
6 x Dowels
(H1)
Left
Side Panel
(P1)
Right
Side Panel
(P2)
Back Panel
(P4)
Rail
(P3)
Hardware Pack
Additional Tools Required
Flat head screwdriver;
Phillips head screwdriver;
DO NOT USE
20 x Long
Screws (L30mm)
(H2)
16 x Small
Screws
(H5)
10 x Small
Cam Nuts
(H4)
10 x Small
Cam Bolts
(H3)
2 x CL Runner
Tracks
(H6)
2 x CR Runner
Tracks
(H7)
2 x DR Runners
(H9)
2 x DL Runners
(H8)
Left
Drawer Side
(P6)
Right
Drawer Side
(P7)
Drawer Back
(P9) Drawer
Base
(P8)
Drawer Front
(P5)
x 2
Drawer
Support
(P10)
4 x Covers
(H11)
2 x Medium
Screws (L20mm)
(H10)

You will need
Step 1
You will need
Step 2
www.fantasticfurniture.com.au PAGE 5
2 x CL Runner
Tracks (H6)
8 x Small
Screws (H5) Phillips head screwdriver
2 x CR Runner
Tracks (H7)
(P2)
(P1)
(P1)
(P3)
(P4)
H1
H6
H6
H2
H2
H2 H2
H5
H5
H5
H5
H7
H7
H5
H5
H5
H5
2 x Dowels
(H1)
Phillips head
screwdriver
4 x Long
Screws (H2)
H6
CL
H5
H7
CR
H5
Insert 2 x Dowels (H1) into the holes of Left Side Panel (P1) as shown.
Attach Back Panel (P4) and Rail (P3) to Left Side Panel (P1)
with 4 x Long Screws (H2) using a Phillips head screwdriver.
Attach 2 x CL Runner Tracks (H6) to Left Side Panel (P1) with 4 x Small Screws (H5).
Attach 2 x CR Runner Tracks (H7) to Right Side Panel (P2) with 4 x Small Screws (H5).

www.fantasticfurniture.com.au PAGE 6
You will need
Step 3
You will need
Step 4
(P3)
(P2)
(P4)
H2
H2
H2
H1
H1
2 x Dowels
(H1)
Phillips head
screwdriver
4 x Long
Screws (H2)
Phillips head
screwdriver
5 x Small Cam
Bolts (H3)
(P5)
H3
H3
H3
H3
H3
Insert 2 x Dowels (H1) into the holes of Back Panel (P4) as shown.
Attach Right Side Panel (P2) to Back Panel (P4) and Rail (P3) with 4 x Long Screws (H2).
Tighten the screws with a Phillips head screwdriver.
Screw 5 x Small Cam Bolts (H3) into Drawer Front (P5) with a Phillips head screwdriver.

www.fantasticfurniture.com.au PAGE 7
This is how a cam nut works........
The head of the cam
bolt goes into the open
mouth of the cam nut.
You then turn the cam
nut so it tightens over
the bolt.
H1
1 x Dowel
(H1)
(P5)
You will need
5 x Small Cam
Nuts (H4)
Step 5
Flat head
screwdriver
Step 6
Phillips head
screwdriver
You will need
6 x Long
Screws (H2)
Step 7
(P6)
(P6)
(P6)
(P7)
(P7)
(P7)
(P8)
(P9)
H4
H2
H2
H2
H2
H4
H4
H4
H4
(P10)
H2 H2
Slide Drawer Base (P8) in through the grooves
on Drawer Sides (P6, P7).
Insert 1 x Dowel (H1) into Drawer Front (P5) as shown.
Insert 5 x Small Cam Nuts (H4) into the holes of Drawer Sides (P6, P7) and Drawer Support (P10).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Align the holes together, secure
Drawer Sides (P6, P7) and Drawer Support (P10) into place,
tighten the cam nuts using a Flat head screwdriver.
Attach Drawer Back (P9) to Drawer Sides (P6, P7)
and Drawer Support (P10) with 6 x Long Screws (H2),
make sure that the groove lines up the whole way around the drawer.
Tighten the screws using a Phillips head screwdriver.

www.fantasticfurniture.com.au PAGE 8
(P6)
(P7)
4 x Small
Screws (H5)
You will need
1 x DL Runner
(H8) 1 x DR Runner (H9)
H9
H5
DR
H5
H8 DL
H5 H5
Step 8
Phillips head
screwdriver
H5
H9
H8
H5
H5
H5
Attach 1 x DL Runner (H8) to the bottom of Left Drawer Side (P6) and
1 x DR Runner (H9) to the bottom of Right Drawer Side (P7) with 4 x Small Screws (H5).
Tighten Screws using a Phillips head screwdriver.
Repeat Step 4 to Step 8 to assemble another drawer.
Step 9
Put the insert cabinet into the bookcase,
make sure the drawer front of insert cabinet is flush with the edge of shelf.

www.fantasticfurniture.com.au PAGE 9
H10
H10
You will need
Step 10
Phillips head
screwdriver
2 x Covers
(H11)
H11
H11
Take down the drawers from the insert cabinet carefully.
Attach the cabinet to the bookcase with 2 x Medium Screws (H10) using a Phillips head screwdriver.
If you'd like to adjust the insert cabinet or remove it,
please seal the holes with the Covers (H11).
2 x Medium
Screws (H10)

www.fantasticfurniture.com.au PAGE 10
Job Complete!
In the interest of our environment please dispose of all packaging thoughtfully.
Recommended weight capacity: 5KG.
Put the drawers into the cabinet as shown.
