Festo MPA Series User manual

Electronic
description of
MPA−...
MPA electronic
module
Types:
− VMPA1−FB−...
− VMPA2−FB−...
− VMPA1−FB−...D2...
− VMPA2−FB−...D2...
MPA pressure
sensor
Type:
− VMPA−FB−PS−...
Proportional
pressure regulator
VPPM/MPA
Type:
− VPPM−6TA−...
Valve terminal MPA−...
Description
562 113
en 0804NH
[732 589]

Contents and general safety instructions
I
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Original de. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Edition en 0804NH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Designation P.BE−MPA−ELECTRONIC−EN. . . . . . . . . . . . . . . .
Orderno. 562 113. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
E(Festo AG & Co. KG, D73726 Esslingen, Federal Republic of Germany, 2008)
Internet: http://www.festo.com
E−mail: [e-mail]
The reproduction of this document and disclosure to third
parties and the utilisation or communication of its contents
without explicit authorisation is prohibited. Offenders will
be held liable for compensation of damages. All rights re
served, in particular the right to carry out patent, utility
model or ornamental design registration.

Contents and general safety instructions
II Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
CAGE CLAMP® is a registered trade mark of WAGO Kontakttechnik GmbH,
32385 Minden, Germany
TORX® is a registered trade mark of CAMCAR TEXTRON INC.,
Rockford, Ill., USA
HARAX® is a registered trade mark of HARTING Deutschland GmbH,
32381 Minden, Germany
SPEEDCON® is a registered trade mark of PHOENIX CONTACT
GmbH & Co. KG, 32825 Blomberg, Germany

Contents and general safety instructions
III
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Contents
Intended use V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Target group VI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service VI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important user instructions VII. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Notes on the use of this manual IX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Structure of a CPX terminal X. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnosis via the Fieldbus or a network XI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. MPA pneumatic modules 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Function of the MPA pneumatic modules 1−3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.1 Display and connecting elements 1−6. . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Installation 1−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Installing 1−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Parameterising 1−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4.1 Parameters of the MPA pneumatic modules 1−17. . . . . . . . . . . . . . . . . .
1.4.2 Further parameters for electronic module type VMPA...−D2−.. 1−19. . . .
1.5 Diagnosis 1−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5.1 Composition of the LED display on MPA1 1−23. . . . . . . . . . . . . . . . . . . .
1.5.2 Composition of the LED display on MPA2 1−24. . . . . . . . . . . . . . . . . . . .
1.5.3 LED messages for MPA electronic modules
with standard diagnosis 1−26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5.4 LED messages for MPA electronic modules with diagnosis D2 1−28. . . .
1.5.5 Fault treatment and parameterising 1−29. . . . . . . . . . . . . . . . . . . . . . . . .
2. MPA pressure sensor 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 MPA pressure sensor (pressure sensor plate) VMPA−FB−PS−... 2−3. . . . . . . . . . .
2.1.1 Function 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.2 Assembly 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.3 Instructions on commissioning 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.4 Parameterising the MPA pressure sensor 2−5. . . . . . . . . . . . . . . . . . . .
2.1.5 Parameterisation example 2−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.6 Diagnostic 2−15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents and general safety instructions
IV Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
3. Proportional pressure regulator 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Proportional pressure regulator VPPM−6TA−... 3−3. . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 Function 3−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 Assembly 3−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.3 Instructions on commissioning 3−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.4 Parameterising the proportional pressure regulator 3−6. . . . . . . . . . .
3.1.5 Parameterisation example 3−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.6 Diagnostic 3−17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A. Technical appendix A−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1 Technical specifications of the MPA electronic modules A−3. . . . . . . . . . . . . . . .
A.2 Technical data MPA pressure sensor / pressure sensor plate A−6. . . . . . . . . . . .
A.3 Technical data Proportional pressure regulator VPPM/MPA A−7. . . . . . . . . . . . .
B. Index B−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents and general safety instructions
V
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Intended use
The MPA modules described in this manual have been de
signed exclusively for use in conjunction with CPX terminals
from Festo. The pneumatic interfaces and I/O modules are
only to be used as follows:
Asspecified in industrial applications.
 Without any modifications by the user. Only the conver
sions or modifications described in the documentation
supplied with product are permitted.
Inperfect technical condition.
If conventional accessory components such as sensors and
actuators are connected, the specified limits for pressures,
temperatures, electrical data, torques, etc. must not be
exceeded.
Please observe the standards specified in the relevant
chapters and comply with technical regulations, as well as
with national and local regulations.
Warning
·In order to provide the electric power supply, use only
PELV circuits as per IEC/DIN EN 60204−1 (Protective
Extra−Low Voltage, PELV).
Take into account also the general requirements for
PELV circuits as per IEC/DIN EN 60204−1.
·Use only power packs which guarantee reliable electri
cal isolation of the operating voltage as per
IEC/DIN EN 60204−1.
Protection against electric shock (protection against
direct and indirect contact) is ensured in accordance
with IEC/DIN EN 60204−1 (electrical equipment of machines,
general requirements) by using PELV circuits.

Contents and general safety instructions
VI Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Target group
This manual is intended exclusively for technicians trained in
control and automation technology, who have experience in
installing, commissioning, programming and diagnosing pro
grammable logic controllers (PLC) and Fieldbus systems.
Service
Please consult your local Festo Service if you have any
technical problems.

Contents and general safety instructions
VII
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Important user instructions
Danger categories
This description contains notes on potential dangers which
may occur if the product is used incorrectly. These notes are
marked with a signal word (Warning, Caution etc) printed on a
shaded background and additionally with a pictogram. A dis
tinction is made between the following danger warnings:
Warning
... means that failure to observe this note may result in
serious personal injury or material damage.
Caution
... means that failure to observe this note may result in
personal injury or material damage.
Note
... means that failure to observe this note may result in
material damage.
The following pictogram marks passages in the text which
describe activities with electrostatically sensitive compo
nents:
Electrostatic sensitive devices: inappropriate handling can
result in damage to components.

Contents and general safety instructions
VIII Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Identification of specific information
The following pictograms mark passages in the text which
contain specific information.
Pictograms
Information:
Recommendations, tips and references to other sources
of information.
Accessories:
Information on necessary or useful accessories for the
Festo product.
Environment:
Information on the environmentally−friendly use of
Festo products.
Text markings
·Bullet points indicate activities which may be carried out
in any sequence.
1. Figures denote activities which must be carried out in the
numerical order specified.
 Arrowheads indicate general lists.

Contents and general safety instructions
IX
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Notes on the use of this manual
This manual contains general basic information on the
method of operation, on fitting, installing and commissioning
MPA pneumatic and electronic modules.
Information on MPA pneumatics is provided in the MPA pneu
matics descriptions.
An overview of the CPX pneumatic interfaces can be found in
the manual for the CPX I/O modules".
General basic information on the method of operation, on
fitting, installing and commissioning CPX terminals can be
found in the CPX system manual.
Special information on commissioning, parameterising and
diagnosing a CPX terminal with the bus node you are using
can be found in the appropriate manual for the bus node.
Information on further CPX modules can be found in the man
ual for the relevant module.
An overview of the structure of the CPX terminal user docu
mentation is contained in the CPX system description.
Conventions
The special parameters of the modules are described in the
individual chapters. These appear in English on the Handheld
type CPX−MMI−1.
[........] The data and parameters which appear in English on the
Handheld are shown in square brackets in this manual,
e.g. [Debounce time]. This is followed in the text by the
translation, e.g.:
Eingangsentprellzeit [Debounce time].

Contents and general safety instructions
XFesto P.BE−MPA−ELECTRONIC−EN en 0804NH
Structure of a CPX terminal
CPX terminals consist of electric function modules, individual
modules and components. The diagram below shows an
example.
12 3 4
5
6
7
8
1Fieldbus node
2I/O modules
3Pneumatic interface
4Pneumatic modules
(example MPA)
5Interlinking block with additional power
supply
6Manifold sub−base without supply
7Interlinking block with system supply
8End plate
Fig.0/1: Example of CPX terminal

Contents and general safety instructions
XI
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Diagnosis via the Fieldbus or a network
Depending on the parameterisation, CPX pneumatic inter
faces and CPX I/O modules signal specific faults via the Field
bus or your network.
These can be evaluated via the:
 Status bits (system status)
 I/O diagnostic interface (system diagnosis)
 Module diagnosis
 Fault numbers
Further information on diagnosis can be found in the CPX
system manual or in the manual for the bus node.

Contents and general safety instructions
XII Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
The following product−specific terms and abbreviations are
used in this manual:
Term/abbreviation Meaning
Bus node Establishes the connection to the Fieldbus or network. Transmits control
signals to the connected modules and monitors their ability to function.
CPX module Common term for the various modules which can be incorporated in a
CPX terminal.
Diagnosis D2 Additional diagnostic functions of MPA input modules (see section 1.5)
DIL switches Dual−in−line switches consist of several switch elements with which set
tings can be made.
I Digital input
Interlinkingblock Lower part of the housing of a CPX module or block for linking the module
electrically with the CPX terminal. There are different variants, with and
without power supplies and made of plastic or metal.
I/O diagnostic interface The I/O diagnostic interface is a bus−independent diagnostic interface at
I/O level, permitting access to internal data of the CPX terminal.
I/Os Digital inputs and outputs
MPA electronic module Electronic module which provides the electronic functionality including
the diagnostic functions for the valve solenoid coils of the MPA pneu
matics.
MPA pneumatic module Pneumatic module which provides digital outputs for the valves fitted
(valve solenoid coils).
O Digital output
PLC/IPC Programmable logic controller/industrial PC
Pneumatic interface The pneumatic interface is the interface between the modular electrical
periphery and the pneumatics.
Tab.0/1: Product−specific terms

MPA pneumatic modules
1−1Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Chapter 1
Types VMPA1−FB−EMG−8
VMPA1−FB−EMS−8
VMPA2−FB−EMG−4
VMPA2−FB−EMS−4
VMPA1−FB−EMG−D2−8
VMPA1−FB−EMS−D2−8
VMPA2−FB−EMG−D2−4
VMPA2−FB−EMG−D2−4

1. MPA pneumatic modules
1−2 Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Contents
1. MPA pneumatic modules 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Function of the MPA pneumatic modules 1−3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.1 Display and connecting elements 1−6. . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Installation 1−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Installing 1−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Parameterising 1−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4.1 Parameters of the MPA pneumatic modules 1−17. . . . . . . . . . . . . . . . . .
1.4.2 Further parameters for electronic module type VMPA...−D2−.. 1−19. . . .
1.5 Diagnosis 1−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5.1 Composition of the LED display on MPA1 1−23. . . . . . . . . . . . . . . . . . . .
1.5.2 Composition of the LED display on MPA2 1−24. . . . . . . . . . . . . . . . . . . .
1.5.3 LED messages for MPA electronic modules
with standard diagnosis 1−26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5.4 LED messages for MPA electronic modules
with diagnosis D2 1−28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5.5 Fault treatment and parameterising 1−29. . . . . . . . . . . . . . . . . . . . . . . . .

1. MPA pneumatic modules
1−3
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
1.1 Function of the MPA pneumatic modules
In the CPX terminal the MPA pneumatic modules provide
digital outputs for controlling the valves and thus enable
pneumatic actuators to be controlled.
From a technical point of view, the individual pneumatic
modules each represent a separate electric module with
digital outputs.
Without intermediate electrical supply (see section 1.3)
maximum 8 MPA pneumatic modules are permitted per
CPX terminal. Up to 64 valve solenoid coils (exclusively
MPA1) or 32 valve solenoid coils (exclusively MPA2) are
therefore possible.
With intermediate electrical supply (see section 1.3) maxi
mum 16 MPA pneumatic modules are permitted per CPX
terminal. Up to 128 valve solenoid coils (exclusively MPA1)
or 64 valve solenoid coils (exclusively MPA2) are therefore
possible.
1Valve plates or
blanking plates
2Electronic module
3Manifold sub−base
1
2
3
Fig.1/1: Components of an MPA pneumatic module (example MPA1)

1. MPA pneumatic modules
1−4 Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
Type Description of the MPA pneumatic module
MPA1
 VMPA1−FB−EM...
 VMPA1−FB−AP−4−1
 VMPA1−M1H−...
 VMPA1−RP
MPA1 pneumatic module: Output module with MPA
pneumatics, consisting of:
 Electronic module with 8 outputs
Variants and description see Tab.1/2
 Sub−base for 4 valve plates
 Valve plates (or corresponding pneumatic compo
nents) or
 Cover plates for reserve locations.
MPA2
 VMPA2−FB−EM...
 VMPA2−FB−AP−2−1
 VMPA2−M1H−...
 VMPA2−RP
MPA2 pneumatic module: Output module with MPA
pneumatics, consisting of:
 Electronic module with 4 outputs
Variants and description see Tab.1/2
 Sub−base for 2 valve plates,
 Valve plates (or corresponding pneumatic compo
nents) or
 Cover plates for reserve locations.
Outputs correspond to valve solenoid coils
Tab.1/1: Overview of MPA pneumatic modules

1. MPA pneumatic modules
1−5
Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
The electrical function of an MPA pneumatic module is deter
mined by the electronic module used. The following table
provides an overview of the MPA electronic modules:
Type Description of the electronic module
VMPA1−FB−EMG−8 8 outputs
with electrical isolation
VMPA1−FB−EMG−D2−8 8 outputs
with electrical isolation
with diagnostic functions D2
VMPA1... VMPA1−FB−EMS−8 8 outputs
without electrical isolation
VMPA1−FB−EMS−D2−8 8 outputs
without electrical isolation
with diagnostic functions D2
VMPA2−FB−EMG−4 4 outputs
with electrical isolation
VMPA2−FB−EMG−D2−4 4 outputs
with electrical isolation
with diagnostic functions D2
VMPA2... VMPA2−FB−EMS−4 4 outputs
without electrical isolation
VMPA2−FB−EMS−D2−4 4 outputs
without electrical isolation
with diagnostic functions D2
Outputs correspond to valve solenoid coils
Tab.1/2: Overview of the MPA electronic modules

1. MPA pneumatic modules
1−6 Festo P.BE−MPA−ELECTRONIC−EN en 0804NH
1.1.1 Display and connecting elements
The MPA pneumatic modules possess the following display
and connecting elements:
1LEDs:
see sections
1.5.1 and 1.5.2
2Connecting plug to
further MPA pneu
matic modules
3Manual override
4Label supports with
inscription field
5Connecting plug to
the CPX pneumatic
interface or to further
MPA pneumatic
modules
12
3
4
51357
0246
Fig.1/2: Display and connecting elements (example: MPA1)
Use sign supports type VMPA1−ST−1−4 for identification of the
MPA pneumatic modules.
