GE Power Break II User manual

Catalog
Number
Voltage
Rating ➀
Peak Inrush
Current, mA ➁
Nominal RMS
Current, mA
SPUV480AC 480 Vac 750 20
SPUV600AC 600 Vac 600 16
➀ Rated for 50/60 Hz. Rating is 120 Vac without step-down
transformer.
➁ Peak inrush current is present for 2–6 ms after activation. This
number is provided so that fuses and supplies can be chosen
appropriately.
AVERTISSEMENT: Les modules de déclenchement à
manque de tension 480 Vac et 600 Vac doivent être
utilisés avec le transformateur abaisseur de tension qui
est fourni.
When the applied control voltage is above 80% of the UVR’s
rated value, th e breaker can be closed. When the voltage
drops to 35–60% of the rated value, the UVR will trip the
breaker.
The Undervoltage Release is installed in the accessory
compartment through the front of the circuit breaker in the
position shown in Figure 2.
Use the following procedure to install the UVR accessory into
the UVR slot in the accessory compartment of the circuit
breaker:
Open the hinged door over the accessory compartment
and Trip Unit.
To remove an existing accessory, loosen the accessory
locking screw and pull the accessory out with the Rating
Plug Removal Tool (catalog number TRTOOL).
AVERTISSEMENT: Avant d’installer toute accessoire, mettre
le disjoncteur en position OFF, le déconnecter de toute
tension d’alimentation, et décharger les ressorts
d’armement.
WARNING: 480 Vac and 600 Vac Undervoltage Release
accessories must be used with the supplied step-down
transformer.
WARNING: Before installing any accessories, turn the
breaker OFF, disconnect it from all voltage sources, and
discharge the charging springs.
—
Figure 1. Undervoltage Release.
1
—
Table 1. Catalog numbers and voltages for the Undervoltage Release.
Installation
GEH6520 I NSTRUCTIONS
Power Break® II Circuit Breaker Accessories
Undervoltage Release 480 & 600 Vac
Introduction
The Undervoltage Release (UVR) accessory, shown in Figure 1,
can be installed in 800–4000 ampere frame Power Break® II
circuit breakers. This accessory trips the circuit breaker when
the input control voltage drops to 35–60% of its rated value
and prevents an open breaker from closing until the input
control voltage is greater than 80% of the rated value.
In addition to providing a trip signal to the breaker, the UVR
accessory can be set up to interact with other Power Break II
accessories, when used with a MicroVersaTrip Plus™ or
MicroVersaTrip PM™ Trip Unit. DIP switches on the rear of
the breaker Trip Unit can configure the UVR accessory to
activate a Bell Alarm–Alarm Only accessory or a Bell Alarm
with Lockout accessory when a UVR trip occurs. The
Accessory Configuration section below describes how this
can be done. If the breaker is equipped with a Power+™ Trip
Unit, it is configured so that only protection trips will activate
a Bell Alarm–Alarm Only or Bell Alarm with Lockout.
The catalog numbers for the UVR for 480 and 600 Vac
applications are listed in Table 1. Voltage and current ratings
in Table 1 are given at the input of the transformer. The
voltage and current ratings at the input of the UVR accessory
are equal to that of the SPUV120AC accessory. Input voltage
is 120 Vac, peak inrush current is 3 A, and the nominal RMS
current is 80 mA.
Operation
Apply control voltage to the primary of the supplied step-
down transformer. The secondary of the transformer is
connected to terminals 29 and 30 of the terminal strip on the
right side of the breaker.
1.
2.

CAUTION: Over tightening the locking screw may damage
or distort the case of the accessory.
Catalog Number/
Control Voltage
Primary
Connections
Secondary
Connections
9T58K0042 / 480 V H1, H4 ➀ X1, X2
9T58K0062 / 600 V H1, H4 X1, X3
Tighten the locking screw on the front of the accessory
until it is snug (torque of 9 in-lb.)
If the breaker is equipped with a MicroVersaTrip Plus or
MicroVersaTrip PM Trip Unit, the UV R accessory can be
configured to activate installed Bell Alarm–Alarm Only or
Bell Alarm with Lockout accessories when a UVR trip
occurs, with the procedure described in the Accessory
Configuration section.
Mount the supplied step-down transformer near the
circuit breaker.
Connect the control wiring for the UVR to the primary
side of the transformer, marked as the H-numbered
terminals. Table 2 lists the correct transformer primary
taps.
WARNING: 480 Vac and 600 Vac Undervoltage Release
accessories must be used with the supplied step-down
transformer.
AVERTISSEMENT: Les modules de déclenchement
à manque de tension 480 Vac et 600 Vac doivent être
utilisés avec le transformateur abaisseur de tension qui
est
Test the UVR to ensure proper operation, according to the
procedures below.
Reconnect power to the circuit breaker and any other
accessories.
Close and lock or seal the door over the accessory
compartment and Trip Unit to prevent unauthorized
changes to Trip Unit settings and to keep contaminants
out empty accessory slots.
Accessory Configuration
This section of only applies if Bell Alarm–Alarm Only or Bell
Alarm with Lockout accessories are installed in the breaker,
along with a MicroVersaTrip Plus or MicroVersaTrip PM Trip
Unit. If the breaker is equipped with a Power+ Trip Unit, the
factory default settings, listed in Table 3, cannot be changed.
The UVR accessory can be configured to activate the
Bell Alarm–Alarm Only or Bell Alarm with Lockout accessories
if a UVR trip occurs. The configuration can be changed
by removing the Trip Unit from the breaker, setting the
DIP switches on the rear of the Trip Unit, and reinstalling the
Trip Unit. Figure 4 illustrates the Trip Unit read DIP switches
and their functions. Table 3 lists the switch functions and
the factory settings for each.
ATTENTION: Le serrage excessif de la vis de verrouillage
peut déformer le boîtier d’accessoire.
—
Figure 4. Accessory switch on the rear of the MicroVersaTrip Plus™ or MicroVersaTrip PM™ Trip Unit,
showing the factory settings (solid part indicates that the switch is pushed in on that side).
Insert the UVR accessory into the proper slot, as
illustrated in Figure 3. The UVR accessory is keyed for
the correct slot in the accessory compartment. If the
accessory cannot be fully seated in the compartment,
check that the compartment position is correct.
—
Figure 3. Inserting the Undervoltage Release into the accessory compartment.
➀ A jumper must be placed from H2 to H3.
—
Table 2. Primary and secondary connections for step - down transformers
Connect the secondary side of the transformer, marked as
the X - numbered terminals, to terminals 29 and 30 of the
terminal block on the right side of the breaker. Table 2 lists
the correct transformer secondary taps.
—
Figure 2. Accessory compartment on front of circuit breaker, with Undervoltage Release slot indicated.
3.
4.
5.
6.
7.
8.
9.
10.
11.
2

When a Shunt Trip accessory causes the breaker to
trip, the contacts of the Bell Alarm–Alarm Only also
change state. (The factory switch setting is disabled ).
When an Under voltage Release accessory causes the
breaker to trip, the contacts of the Bell Alarm–Alarm
Only also change state. (The factory switch setting is
disabled ).
When a protection trip (long-time, short-time,
instantaneous, ground-fault, or protective-relay)
occurs, the contacts of the Bell Alarm–Alarm Only also
change state.(The factory switch setting is enabled . )
When a Shunt Trip accessory causes the breaker to
trip, the contacts of the Bell Alarm with Lockout also
change state. (The factory switch setting is disabled. )
When an Under voltage Release accessory causes the
breaker to trip, the contacts of the Bell Alarm with
Lockout also change state. (The factory switch setting
is disabled. )
When a protection trip (long-time, short-time,
instantaneous, ground-fault, or protective-relay)
occurs, the contacts of the Bell Alarm with
Lockout also change state. (The factory switch
setting is enabled. )
Procedure for Changing Switch Settings
Change the accessory switch settings with the following
procedure:
Test Procedure
Use the following procedure to test the UVR for proper
operation.
Open the breaker.
Turn off the power to the UVR.
Try to manually close the breaker; the breaker should not
close.
Apply at least 80% of the rated voltage specified on the
UVR name plate to the UVR control inputs.
Try to close the breaker; it should close as normal.
If a MicroVersaTrip Plus or MicroVersaTrip PM Trip Unit is
installed, check that the Trip Unit display is active
(powered).
With the breaker closed, reduce the UVR control voltage to
35–60% of the rated voltage; the breaker should trip within
0.5 second.
If a Bell Alarm–Alarm Only or Bell Alarm with Lockout is
present, ensure that they activate (or do not activate) as
selected by the MicroVersaTrip Plus or MicroVersaTrip PM
Trip Unit DIP switches.
AVERTISSEMENT: Avant de commencer cette procédure,
mettre le disjoncteur en position OFF, le déconnecter de
toute tension d’alimentation, et désarmer les ressorts de
fermeture.
Loosen the four #8-32 screws on the breaker trim-plate
assembly and remove the trim plate.
Loosen the four #10-32 screws at the corner of
the breaker cover. Remove the cover from the breaker
face.
Pull the Trip Unit locking lever to the right, then hold the
Trip Unit near the battery cover and lift it straight out of
the breaker.
Refer to Figure 4 and Table 3 to determine the switches
to be changed.
Push in the appropriate “Enable” or “Disable” side of the
switch.
Confirm all switch settings before reinstalling the Trip
Unit in the breaker.
Pull the Trip Unit locking lever to the right. While holding
the lever, carefully align the connector on the rear of the
Trip Unit with the connector in the breaker. Press down
on the Trip Unit, while holding it near the battery cover.
When the Trip Unit is fully seated, slide the locking lever
back to the left.
Reinstall the breaker top cover and tighten the four #10-
32 screws to 32 in-lb.
Replace the trim plate and tighten the four #8-32 screws
to 20 in-lb.
Verify that the switch settings are correct by inducing
breaker trips from the UVR and Shunt Trip or Shunt Trip
with Lockout (if present) and checking the responses of
the Bell Alarm–Alarm Only and Bell Alarm with
Lockout accessories.
WARNING: Before beginning this procedure, turn the
breaker OFF, disconnect it from all voltage sources, and
discharge the closing springs.
Switch
Factory
Setting Function
1 Disabled
2 Disabled UVR trip activates Bell
Alarm–Alarm Only
3 Enabled Protection trip activates
Bell Alarm–Alarm Only
4 Disabled Shunt trip activates
Bell Alarm withLockout
Disabled UVR trip activates Bell
Alarm with Lockout
Enabled Protection trip activates
Bell Alarm with Lockout
3
—
Table 3. Accessory switch settings, including factory defaults.
Description of Switch Settings
Following are descriptions of the effects of each accessory
switch when it is enabled:
5
6
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
1.
2.
3.
4.
5.
6.
7.
8.
Shunt trip activates
Bell Alarm–Alarm Only

Trouble-Shooting
The following guide is provided for trouble-shooting and isolating common problems. It does not cover every possible situation.
Contact the Customer Support Center at 800- 843-3742 if any problem is not resolved by these procedures.
Symptom Possible Cause Corrective Action
The accessory is inserted
incorrectly.
The UVR accessory will
not insert completely in
the breaker.
The breaker closes when
the UVR is de-energized.
The UVR lockout plunger is not
engaged.
The UVR is actually energized.
The breaker will not
close when the UVR is
energized.
The UVR solenoid is not energized.
4. The breaker does not
trip when UVR control
power is removed.
5.
The breaker is not closed.
UVR control power is actually still
applied.
The UVR trip connection is poor.
The Bell Alarm–Alarm Only or Bell
Alarm with Lockout configuration
switches on the back of the
MicroVersaTrip Plus or
MicroVersaTrip PM Trip Unit are
not properly set. Note that this
feature is not available with Power
+™ Trip Units.
The Bell Alarm–Alarm Only or Bell
Alarm with Lockout accessory is
improperly installed.
Ensure that the accessory is inserted in the correct slot, as in Figure 2,
and that the label is upright. Ensure that the accessory is completely
seated and that the screw is tightened.
Remove the UVR accessory. Check that the lockout plunger protrudes
approximately 1⁄4 inch out of the accessory; if it does not, replace the
UVR. If the plunger length is correct, reinsert the UVR, ensuring good
alignment of the accessory to the pocket. Ensure that it is completely
seated, flush with the top of the pocket, then tighten the screw to 9 in-
lb.
Check that the control power to the UVR is off.
Check that UVR control power is applied at greater than 80% of the
UVR rated voltage. Check that the accessory is completely inserted;
reinsert if necessary.
Note that an otherwise unpowered Trip Unit is powered up by an
energized UVR accessory.
Ensure that steps 6, 7, and 8 in the Installation section have been
followed correctly.
Verify that the breaker is closed.
Check that the UVR control power has been removed or that its voltage
is less than 35% of the rated value.
Check that the UVR accessory is completely inserted. Check that the
Trip Unit is seated correctly. If the Trip Unit was removed to set the
switches, check that it has been correctly installed; remove and
reinstall, if necessary.
Follow the procedure to remove the Trip Unit and set the switches.
Check that the switches have been set correctly.
See the Trouble-Shooting Guide for the Bell Alarm with Lockout in
GEH6278 or the Bell Alarm–Alarm Only in GEH6275.
1SQC930035M0201, GEH6520 December 2019
4
—
ABB Inc.
305 Gregson Drive
Cary, NC 27511.
electrification.us.abb.com
—
We reserve the right to make technical
changes or modify the contents of this
document without prior notice. With
regard to purchase orders, the agreed
particulars shall prevail. ABB Inc. does not
accept any responsibility whatsoever for
potential errors or possible lack of
information in this document.
We reserve all rights in this document and
in the subject matter and illustrations
contained therein. Any reproduction or
utilization of its contents – in whole or in
parts – is forbidden without prior written
consent of ABB Inc.
Copyright© 2019 ABB
All rights reserved
—
GE is a trademark of GE. Manufactured
by ABB Inc. under license from GE.
The transformer connections are
incorrect.
The Bell Alarm–Alarm
Only or Bell Alarm with
Lockout does not trip
correctly (trips when it
shouldn’t or doesn’t
trip when it should).
3.
1.
2.
