Häfele CLEVER User manual

CLEVER
ASSEMBLY INSTRUCTIONS
0000.2299-A
Required Tools:
#2 Phillips Driver
Metric Allen Wrenches
Table Kit Includes:
2 Clever Columns 1 Cross Beam with Motors 2 Feet
2 Top Supports Control Box Hand Switch Hardware
Hardware Included

M10 x 50mm Button Head
QTY 4

M8 x 12mm Button Head
QTY 8
#  / Wood “re
QTY 20
Clever Columns
Cross Beam with Motors
Clever Feet
Clever Top Supports
Control Box
Independent Beams with Motors
Or
Hand Switch

CLEVER
ASSEMBLY INSTRUCTIONS
0000.2299-A
All eletri otors MU“T e iitialized efore oig the tale i the UP diretio.
Please follow the below instructions for proper initialization:
1. All Columns (motors) must be plugged into the Control box.
2. Plug the Up/Do Had sith i to the Control box.
3. Plug the Control box power cord into a 110 volt grounded outlet.
4. Hold the Do utto i util the olus otto out to the loest positio.
5. Please otiue to hold util a likig soud is heard ad the olus oe
slightl UP.
6. Once this is completed your system is properly initialized and can be operated
without harm to the system.

CLEVER
ASSEMBLY INSTRUCTIONS
0000.2299-A
WARNING! Slide the column into the beam. Column and Beam need to be installed perpendicular to
each other –failure to do so may result in undesired noise during use. Make sure to align the male hex (located at the
end of the column) with the female hex (located inside of the motor housing inside of the Beam). Use a 9mm wrench
to turn the hex adapter on the column to align with the hex in the motor. Failing to do so will damage the motor! (Do not
try to turn the motor!)
Step 1 - Insert Clever Column into Cross Beam and slide Top Supports over the width of the Beam. (Fig. 1)
Step2 - Attach the Top Supports to the Clever Column using the M8x12mm Button Head Screws provided.
Torque screws to 24 N m (18 ft lb). (Fig. 2)
(Fig. 1)
(Fig. 2)
Or

CLEVER
ASSEMBLY INSTRUCTIONS
0000.2299-A
Step 3:
Attach the Clever Feet using the
M10x50mm Button Head screws
provided. (Fig. 3)
Step 4:
After Step 3 is complete, flip the
assembly right side up (in the
operating position).
(Fig. 3)
Clever Feet

CLEVER
ASSEMBLY INSTRUCTIONS
0000.2299-A
Step 5:
Attach Top Supports and Cross
Beam to the table top with the #10
x 3/4" Wood Screws provided.
(Fig. 4)
Step 6:
Attach Control Box and Hand
Switch underneath the work
surface. Center the control box on
the opposite side of the user next
to the Cross Beam. Install the
Hand Switch where it will be
convenient for the end user.
(Fig. 5)
NOTE: Remember to reference the
STOP sign page at the beginning for
the proper start up procedure.
(Fig. 4)
(Fig. 5)
Hand Switch
Control Box
