Häfele Nova Pro Scala User manual

PRODUCT FITTING INSTRUCTIONS
Nova Pro Scala 186mm Height
554.33.501/554.33.503/554.33.504/554.33.505/554.33.507/554.33.508/554.33.509/
554.33.510/554.33.901/554.33.903/554.33.904/554.33.905/554.33.907/554.33.908/
554.33.909/554.33.910
> Height 186 mm
> Depth 450 mm
> Width 300 -1000 mm
> Set consists of:
1. Drawer Set
2. Runners x 1 pair
3. Front fixing clips x 2, front fixing clips 186mm x 2, and fixing screw set
Before you start
> Unpack all items and check you have everything noted below - if you are missing something, please call 0800 1712908.
> Make sure that you have all additional requirements as noted below, and a clean, dry area for installing.
> Installing should be done in the stages shown.
Included in this pack
If in doubt, please contact our Technical support team on 0800 1712908
alternatively send your query by e-mail to [email protected]
FITT_Ref: 105424 Issue-2
Length
Body Ø 4.7
Thread Ø 6.0
Ø 7
8x 340.29.724 Varianta screw
length 13.5 mm
Length
Ø
Head
Ø
8x 015.31.639 Hospa
screw, Ø 3.5 x 15 mm
2x Front fixing clips
AD
Optional items
B
Tools to help with installation
Runner drilling jig
558.18.125
Drawer front marking jig
558.18.070
Order online at www.hafele.co.uk
CTouch to open set
For drawers up to 600mm
551.91.182
For drawers up to 1200mm
551.91.183
Drawer front not included, for illustration purposes only
2
1
3
2
2x Front fixing clips
for 186mm

CLICK
clic k
click
L
R
± 1.5
± 2mm
28
453
Minimum installation depth
9.5
32
288 320
0
KV
450
37
40 kg
462
Minimum installation depth
18. 5
450
KV
37
40 kg
32
288 320
0
1
1
2
2
3
3
If in doubt, please contact our Technical support team on 0800 1712908
alternatively send your query by e-mail to [email protected]
50%
CLICK
clic k
• Drill 5mm holes as shown below in carcase both sides
x 8 x 8
• Note:
Please refer to www.hafele.co.uk for internal drawer fronts
FAS
22.5
EBS
LWK
16 171
42.5
(9.5)
52* min.157
FST
40.5 32 96
32
50
Inserting the drawer
Adjustment
Fixing positions for full extension drawer slides standard installation Fixing positions for full extension drawer slides internal drawer
Standard Drawer, installation Detail
Removing thedrawer
FB Front holder
FAS Front overlay, side
FST Front overlay
KV Front edge of cabinet
LWK Inside cabinet width
Installed height of slide
52*: min. 49.5 mm
min. 58 mm (For Touch to open soft close
sets)
Bottom of carcase
Tilt adjustment
