Häfele AdjustableTableSystem 630.44 Series User manual

AdjustableTableSystem™
Electric Sit to Stand System 630.44 series
Item No.: 630.44 Series
Mounting Instructions
Step 1:
Attach feet to side bases using 2 pcs. each
M10 x 12 pan head screws
Step 2:
Mount the J-Channels with the M6 x 12 cylinder head screws
Step 3:
Mount the top plate with the M6 x 12 countersink screws
Step 4:
Plug electrical components together:
• Plug cords from side bases into control box using portals #1 and #2
• Plug switch into control box
• Plug power cord into control box, and then into power supply (outlet)
Inital Operation – Important:
Press and hold down arrow button for a few seconds to allow left and right side bases to synchronize.
They will generally adjust slightly.

3901 Cheyenne Drive
P.O. Box 4000
Archdale, NC 27263
1-800-423-3531
www.hafele.com
Step 5:
Attach Control Box and Control Switch at desired location – Control Box is generally
mounted between the two J-Channels.
Step 6:
Attach Tabletop to assembled frame.
Note: Not included are screws for attaching Control Box, Control Switch, or screws for
attaching Tabletop to frame.

3
FEET
M10X12
pan head screws
M6X12
countersink screws
M6X12
cylinder head screws
J-CHANNEL
CONTROL SWITCH
CONTROL BOX
SIDE BASE
TOP SUPPORT
