Hearth & Home AVFL42NTSC User manual

Log Placement Instructions
Model: AVFL42(N/P)TSC
WARNING: Turn off replace and allow to cool complete-
ly before beginning installation.
Kit Contents:
• Two(2)ceramicberdriftwoodlogs
• Four(4)logsupportpinbrackets
• Eight(8)#8bracketmountingscrews
NOTE —Donothandlelogswithyourbarehands.Always
wear gloves to prevent skin irritation from ceramic bers.
Afterhandlingthelogs,washyourhandswithsoapandwater
toremoveanytracesofbers.
NOTE:Priortoinstallingthelogset,youmustrstinstall
thepinbracketsontheburner.Theairdeectionglassand
reglassshouldonlybeinstalledafterthepinbracketsare
inplace.Theairdeectionglassshouldbeinstalledpriorto
placingandreglassontheburner.Thelogsmustthenbe
placedintheunitafterthereglassandairdeectionglass.If
theoptionallogsareaddedaftertheairdeectionglassand
reglassareinuse,movethereglassawayfromtheareas
in Figure 1andinstallthesupportbrackets,thenarrange
reglassevenlyacrossburneragain.
Figure 1 –
Log Pin Assembly
Figure 2 –
Alternative Log Placement 203060768/21Rev.A
Pin placement
Log #1 (Rear)
Pin placement
Log #2 (Front)
Option 1
Pin placement
Log #2 (Front)
Option 2
AirDeection
Glass

Log Placement Instructions
1. Mountthefourlogsupportpinbracketsusingmounting
holes and screws provided in locations indicated in
Figure 2.Notethatthefrontlogcanbemountedintwo
differentpositions.Thepinbracketscanbemovedto
accommodatethepreferredlogplacement.
2. Placethelargerearlog(#1)byaligningtheholesinthe
bottomofthe log withthetwopins at thebackofthe
burner.Figure 3.
3. Placethefrontlog(#2)byaligningtheholesinthebot-
tomofthelogwiththetwopinsatthefrontoftheburner.
Thefrontlogmaybeplacedinoneoftwopositionson
theburnerdependingonwhichtwopinsetlocationsare
used.
203060768/21Rev.A
Hearth & Home Technologies
7571215thStreetWest,Lakeville,MN55044
www.hearthnhome.com
Please contact your Hearth & Home Technologies dealer
withanyquestionsorconcerns.
ForthelocationofyournearestHearth&Home
Technologiesdealer,pleasevisit
www.hearthnhome.com.
Figure 3–
Front Log Placement
Figure 4 –
Alternative Front Log Placement
LG1180
AVFL36 logs
