Hearth & Home ST36-CFP User manual

1
Hearth & Home Technologies • CFP Panel Installation Instructions • 2313-930 Rev. C • 6/18
ST36-CFP, ST48-CFP, ST60-CFP, ST72-CFP
Models: MEZZO36/48/60/72ST-B, CRAVE4836/6048/7260/8472ST-B, ECHEL36/48STIN,
MEZZO36/48/60/72ST, CRAVE4836/6048/7260/8472ST
Panel Installation Instructions
CAUTION! Risk of Cuts or Abrasions. Wear protective
gloves and safety glasses during installation.
KIT COMPONENTS
• (1) Right Front Panel
• (1) Left Front Panel
• (1) Right Back Panel
• (1) Left Back Panel
Leave this manual with party responsible for use
and operation.
Figure 2. 36 in. Panel Identication
Note: Only for use when CFT fronts are used
on both sides of the appliance.
Figure 1. 48, 60, 72 in. Panel Identication
RIGHT FRONT
LEFT FRONT
RIGHT BACK
LEFT BACK
RIGHT FRONT
LEFT FRONT
RIGHT BACK
LEFT BACK
Instructions
1. Remove door from the front side of the appliance.
Set door aside in a safe location, preferably a soft
surface such as carpet or cardboard.
Note: The front side of the appliance is where the con-
trols are located.
2. Locate the Right Front panel. See Figure 1 or 2 (de-
pending on the appliance).
3. Bend the two short tabs outward 45 degrees. See
Figure 3 & 4.
Figure 3. Bend the Tabs 45 degrees
For Appliances: 48, 60 and 72 in.
For Appliances: 36 in.
RIGHT FRONT
BEND TABS 45 DEGREES
Note: Example is 48, 60, 72 Panel

Hearth & Home Technologies • CFP Panel Installation Instructions • 2313-930 Rev. C • 6/18
2
Please contact your Hearth & Home Technologies dealer with any
questions or concerns.
For the location of your nearest Hearth & Home Technologies dealer,
please visit www.hearthnhome.com.
Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
4. Insert the panel at the top right side of the appliance.
The panel is placed over the glass clips with the bent
tabs resting behind the glass clips. See Figure 4.
5. Slide the panel to the right until it reaches the outer
wrap of the appliance. See Figure 4.
6. Locate the Left Front panel. See Figure 1 or 2 (de-
pending on the appliance).
7. Bend the two short tabs outward 45 degrees. See
Figure 3 & 4.
8. Insert the panel at the top left side of the appliance.
The panel is placed over the glass clips with the bent
tabs resting behind the glass clips. See Figure 5.
9. Slide the panel to the left until it reaches the outer
wrap of the appliance.
10. Replace door.
Figure 5. Panel over Glass Clip (BACK VIEW)
Figure 4. Slide Panel to Outer Wrap (FRONT RIGHT VIEW)
SLIDE TO OUTER WRAP
BENT TAB
GLASS CLIP
11. Follow steps 1-10 for the reverse (back) side of the
appliance using the Right and Left Back Panels.
See Figure 5.
