Hearth & Home CK-30 Operating instructions

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/221
Installation/Owner’s Manual
Installation and Appliance Setup
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
- DO NOT store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any other
appliance.
- What to do if you smell gas
• DO NOT try to light any appliance.
• DO NOT touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re
department.
- Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury, or death.
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed for the protection
of children and other at-risk individuals.
!
DANGER
Models:
CK-30
ADP-CK30
The CK-30 Cabinet Kit must be used with
the ADP-CK30 adapter kit, INFIT-30-BK
front along with one of the following inserts:
EXCURSION-II
RUBY30IN
RUBY30IL
SUPREME-I30-IFT
SUPREME-I30-BIR
SUPRM-I30LP-IFT
NOTICE: SAVE THESE INSTRUCTIONS
This appliance may be installed as an OEM installation
in manufactured home (USA only) or mobile home and
must be installed in accordance with the manufacturer’s
instructions and the manufactured home construction
and safety standard, Title 24 CFR, Part 3280 or Standard
for Instllation in Mobile Homes, CAN/CSA Z240MH, in
Canada.
This appliance is only for use with the type(s) of gas
indicated on the rating plate.
The surface of the appliance is hot when it is in use.
Young children should be watched carefully when they
are in the same room when the appliance is in use, and
they should be taught to avoid the hot surface. Keep
any objects that can burn well away from the appliance,
and observe the recommended clearances that follow.
WARNING
!

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/222
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
1 Product Specic and Important Safety Information
A. Kit Contents CK-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
B. Kit Contents ADP-CK30 ...........................4
C. Replacement Parts CK-30 and ADP-CK30 ............5
2 Getting Started
A. Design and Installation Considerations ............... 6
B. Tools and Supplies Needed ........................6
C. Inspect Appliance and Components..................6
3 Framing and Clearances
A. Appliance Dimension Diagram ......................7
B. Clearances to Combustibles ....................... 8
C. Hearth Extension/Floor Protection ...................8
4 Termination Location and Vent Information
A. Vent Termination and Minimum Clearances...........10
B. Approved Pipe ................................. 11
C. Use of Elbows .................................12
D. Measuring Standards ............................12
E. Venting Guidelines for Horizontal Runs ..............13
F. Vent Diagrams .................................13
5 Vent Clearances and Framing
A. Pipe Clearances to Combustibles ..................21
B. Wall Penetration Framing/Firestops .................21
C. Ceiling Firestop/Floor Penetration Framing ...........22
D. Install Attic Insulation Shield.......................22
6 Appliance Preparation
A. Assemble Cabinet ..............................23
B. Securing and Leveling Appliance ...................27
7 Venting and Chimneys
A. Assemble Vent Sections. . . . . . . . . . . . . . . . . . . . . . . . . . 28
B. Assemble Slip Sections ..........................29
C. Secure the Vent Sections .........................30
D. Disassemble Vent Sections ....................... 30
E. Vertical Termination Requirements..................32
8 Electrical Information
A. General Information .............................34
B. Wiring Requirements ............................34
9 Gas Information
A. Gas Information ................................35
10 Reference Materials
A. Vent Components Diagrams ......................36
B. Vent Components List ...........................38
C. Contact Information .............................40
 = Contains updated information.
Table of Contents

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/223
11 Product Specic and Important Safety Information
B. Kit Contents CK-30
Item DESCRIPTION QTY
1FASTENER PACK 37 (#8X1/2” SCREWS) 1
2CASE BACK ASSEMBLY 1
3CASE TOP 1
4CASE RH SIDE 1
5CASE LH SIDE 1
6BASE TOP/BOTTOM 2
7BASE BACK 1
8BASE SIDE 2

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/224
Item DESCRIPTION QTY
1FASTENER PACK 7 (#8X3/4” SCREWS) 1
2GASKET, ADAPTER 1
3TRIM RING ASSEMBLY 1
4ADAPTER SHIELD 1
52” JUMPER WIRE 1
6JUMPER WIRE 1
7ROCKER SWITCH 1
8WIRE 1
9ADAPTER ASSEMBLY 1
10 ADAPTER WELDMENT 1
C. Kit Contents ADP-CK30
4
910

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/225
D. Replacement Parts CK-30 and ADP-CK30
ITEM DESCRIPTION COMMENTS PART NUMBER
1TOP CABINET ASSEMBLY SRV4126-008
2BOTTOM CABINET ASSEMBLY SRV4126-009
3GASKET, ADAPTER SRV4126-120
4TRIM RING ASSEMBLY SRV4126-005
5ADAPTER SHIELD SRV4126-121
62” JUMPER WIRE 2012-206
7JUMPER WIRE SRV2187-198
8WIRE W/1/4 STR TERM M/F SRV30007499
9ROCKER SWITCH SRV32D0232
10 ASSEMBLY, STARTING COLLAR SRV2189-002
11 ADAPTER GASKET 460-0610
NS POWDER COAT TOUCH UP PAINT 71479
4
9
1
10
11

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/226
22 Getting Started
A. Design and Installation Considerations
This appliance may only terminate vertically, horizontal
termination is not allowed. Hearth & Home Technologies
direct vent gas appliances are designed to operate with all
combustion air siphoned from outside of the building and
all exhaust gases expelled to the outside. No additional
outside air source is required.
Installation MUST comply with local, regional, state and
national codes and regulations. Consult insurance carrier,
local building inspector, re o󰀩cials or authorities having
jurisdiction over restrictions, installation inspection and
permits.
Before installing, determine the following:
• Where the appliance is to be installed.
• The vent system conguration to be used.
• Gas supply piping requirements.
• Electrical wiring requirements.
• Whether optional accessories—devices such as a fan or
remote control—are desired.
C. Inspect Appliance and Components
• Carefully remove the appliance and components from the
packaging.
• The vent system components and optional accessories
may be shipped in separate packages.
• If packaged separately, the log set must be installed.
• Report to your dealer any parts damaged in shipment,
particularly the condition of the glass.
•Read all of the instructions before starting the
installation. Follow these instructions carefully during
the installation to ensure maximum safety and benet.
WARNING! Risk of Fire or Explosion! Damaged parts
could impair safe operation. DO NOT install damaged,
incomplete or substitute components. Keep appliance dry.
B. Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Tape measure Framing material
Pliers Hammer
Phillips screwdriver Manometer
Gloves Framing square
Voltmeter Electric drill and bits (1/4 in.)
Plumb line Safety glasses
Level Reciprocating saw
Flat blade screwdriver
Non-corrosive leak check solution
1/2 - 3/4 in. length, #6 or #8 Self-drilling screws
Caulking material (300ºF minimum continuous exposure
rating)
One 1/4 in. female connection (for optional fan).
WARNING! Risk of Fire, Explosion or Electric Shock! DO
NOT use this appliance if any part has been under water.
Call a qualied service technician to inspect the appliance
and to replace any part of the control system and/or gas
control which has been under water.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. For
assistance or additional information, consult a qualied service
technician, service agency or your dealer.
Hearth & Home Technologies disclaims any responsibility for,
and the warranty will be voided by, the following actions:
• Installation and use of any damaged appliance or vent system
component.
• Modication of the appliance or vent system.
• Installation other than as instructed by Hearth & Home
Technologies.
• Improper positioning of the gas logs or the glass door.
• Installation and/or use of any component part not approved
by Hearth & Home Technologies.
Any such action may cause a re hazard.
Installation and service of this appliance should be
performed by qualied personnel. Hearth & Home
Technologies suggests NFI certied or factory trained
professionals, or technicians supervised by an NFI
certied professional (www.ncertied.org).
Installation and service of this appliance should be performed by
qualied personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certied professionals.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/227
33 Framing and Clearances
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only.
Figure 3.1 - Appliance Dimensions
NOTE: Actual vent collar
location may change slightly
based on cabinet install.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/228
B. Clearances to Combustibles
When selecting a location for the appliance it is important to
consider the required clearances to walls (see Figure 3.2).
WARNING! Risk of Fire or Burns! Provide adequate
clearance around air openings and for service access. Due
to high temperatures, the appliance should be located out of
trac and away from furniture and draperies.
NOTICE: Illustrations reect typical installations and are FOR
DESIGN PURPOSES ONLY. Illustrations/diagrams are not
drawn to scale. Actual installation may vary due to individual
design preference.
NOTICE: Some carpet materials may be sensitive to radiant
heat from the appliance causing discoloration or odor.
Figure 3.2 - Appliance Locations
Model A B *B C *C D E
(MAX.) F G
H
Top of
pipe
Side of
pipe
CK-30
Inches 5-1/2 5 8 3 5 75 36 44 40 3 1
Millimeters 140 127 203 76 127 1905 914 1118 1016 76 25
C. Hearth Extension/Floor Protection
CAUTION! Risk of Fire or Injury! Install appliance on
a stable, level, platform or oor strong enough to support
appliance without tipping.
A non-combustible hearth pad is not required. However,
the floor beneath the appliance must be stable, level, and
strong enough to support the appliance without a tipping
hazard. It is permissible to place the appliance on carpet.
Combustible flooring may be located in front of the appliance.
See Figure 3.4 for vinyl flooring recommendations.
Alcove Installation
Note: Dimensions are minimums as shown and may not be typical for all applications. An alcove installation is
shown above on left.
*To remove the fan from the back of the appliance clearance to the wall should be increased to *B and *C to allow
back panel of the cabinet to be removed. The fan may be removed from front of appliance. See Insert Installation
Manual.
G
D
H
A
B or *B
E (Max)
A
F
C or *C
C or *C

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/229
Vinyl Flooring
Vinyl Flooring is sensitive to heat. A 12 inch minimum
depth hearth extension is recommended when using vinyl
ooring up to the applicance. See Figure 3.4.
NOTICE: Clearances that do not meet the minimum
guidelines could result in damage or buckling to the vinyl
ooring and is done at the installer’s risk.
Hearth and Home Technologies does not recommend
adhesive based vinyl ooring due to thermal expansion.
Floating-style ooring can be used, but will reach
temperatures up to 110°F in a room with ambient
temperature of 70°F. Consult ooring specications to
ensure compatibility.
Figure 3.4 - Vinyl Flooring Requirements
Vinyl Flooring
Appliance width min 12 in. min
Corner Installation - Measurement
from center of ue to wall
Figure 3.3
20-3/4 in
527 mm
3 in
76 mm

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2210
A. Vent Termination Minimum Clearances
Roof Pitch H (Min.) Ft.
Flat to 6/12...........................................................1.0*
Over 6/12 to 7/12.................................................1.25*
Over 7/12 to 8/12.................................................1.5*
Over 8/12 to 9/12.................................................2.0*
Over 9/12 to 10/12...............................................2.5*
Over 10/12 to 11/12 .............................................3.25
Over 11/12 to 12/12 .............................................4.0
Over 12/12 to 14/12.............................................5.0
Over 14/12 to 16/12.............................................6.0
Over 16/12 to 18/12.............................................7.0
Over 18/12 to 20/12.............................................7.5
Over 20/12 to 21/12.............................................8.0
Figure 4.1- Minimum Height From Roof To Lowest Discharge Opening
HORIZONTAL
OVERHANG
VERTICAL
WALL
GAS DIRECT VENT
TERMINATION CAP
12
X
ROOF PITCH
IS X/ 12
LOWEST
DISCHARGE
OPENING
2 FT.
MIN.
20 INCHES MIN.
H (MIN.) - MINIMUM HEIGHT FROM ROOF
TO LOWEST DISCHARGE OPENING
44 Termination Location and Vent Information
Fire Risk.
Maintain vent clearance to combustibles as
specied.
• DO NOT pack air space with insulation or other
materials.
Failure to keep insulation or other materials away
from vent pipe may cause overheating and re.
Figure 4.2 - Staggered Termination Caps
Gas, Wood or Fuel Oil
Termination Cap
B
Gas
Termination
Cap **
A *
*If using decorative cap cover(s), this distance may need to be
increased. Refer to the installation instructions supplied with the
decorative cap cover.
**
A B
6 in. (minimum) up to 20 in.
152 mm/508 mm
18 in. minimum
457 mm
20 in. and over 0 in. minimum
In a staggered installation with both gas and wood or fuel oil
terminations, the wood or fuel oil termination cap must be
higher than the gas termination cap.
WARNING
!

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2211
B. Approved Pipe
This appliance is approved for use with Hearth & Home
Technologies SLP, Simpson Duravent and ICC venting
systems. Refer to Section 11.A for vent component
information and dimensions.
DO NOT mix pipe, ttings or joining methods from di󰀨erent
manufacturers.
The pipe is tested to be run inside an enclosed wall. There
is no requirement for inspection openings at each joint
within the wall.
WARNING! Risk of Fire or Asphyxiation. This appliance
requires a separate vent. DO NOT vent to a pipe serving a
separate solid fuel burning appliance.
DO NOT USE FIELD-FABRICATED VENTING
COMPONENTS.
This product is approved to be vented vertically through the
roof. You may vent through a Class A or masonry chimney if
an approved adapter is used. This product is not approved
for use with a horizontal termination.
This appliance is a direct vent heater. All combustion air must
come directly from the outside of the building. The vent pipe
for this unit consists of an inner and an outer pipe. The inner
pipe carries the appliance exhaust out of the system, and
the outer pipe brings fresh combustion air into the appliance.
• A round support box/wall thimble or heat shield is required
when the venting passes through a combustible wall.
• A support box or ceiling restop is required when the
venting passes through a ceiling.
• Roof ashing and a storm collar are required when venting
passes through the roof.
• Follow instructions provided with the venting for installation
of these items.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2212
C. Use of Elbows
Diagonal runs have both vertical and horizontal vent aspects
when calculating the e󰀨ects. Use the rise for the vertical
aspect and the run for the horizontal aspect. See Figure 4.4.
Two 45º elbows may be used in place of one 90º elbow. On
45º runs, one foot of diagonal is equal to 8-1/2 in. (216 mm)
horizontal run and 8-1/2 in. (216 mm) vertical run. A length
of straight pipe is allowed between two 45º elbows. See
Figure 4.4.
Figure 4.5 shows the vertical and horizontal o󰀨sets for SLP
elbows.
Figure 4.4
HORIZONTAL
VERTICAL
RUN
RISE
EFFECTIVE
LENGTH
Y
X
X
X
Vent Type X
Inches Millimeters
SLP 11-1/4 286
Vent
Type
X Y
Inches Millimeters Inches Millimeters
SLP 5 127 11-3/4 298
SLP
Pipe
E󰀨ective Length Rise/Run
Inches Millimeters Inches Millimeters
SLP4 4 102 2-3/4 70
SLP6 6 152 4-1/4 108
SLP12 12 305 8-1/2 216
SLP24 24 610 17 432
SLP36 36 914 25-1/2 648
SLP48 48 1219 34 864
SLP6A 3 to 6 76 to 152 2-1/8-4-1/4 54-108
SLP12A 3 to 12 76 to 305 2-1/8-8-1/2 54-216
Figure 4.5 - Vertical and Horizontal O󰀨set for SLP Elbows
D. Measuring Standards
Vertical and horizontal measurements listed in the vent
diagrams were made using the following standards:
• Pipe measurements are shown using the e󰀨ective length of
pipe. See Figure 11.1 for SLP for information on e󰀨ective
length of pipe components.
• Vertical terminations are measured to bottom of
termination cap.
• Horizontal pipe installed level with 1/4 inch rise per foot.
Y
X
X
X

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2213
F. Vent Diagrams
General Rules:
• SUBTRACT 3 ft. from the total H measurement for each
90º elbow installed horizontally.
• SUBTRACT 1 ft. from the total H measurement for each
45º elbow installed horizontally.
• A maximum of three 90º elbows (or six 45º elbows) may
be used in any vent conguration. Some elbows may be
installed horizontally. See specic vent diagrams.
• When penetrating a combustible wall, a wall shield restop
must be installed.
• When penetrating a combustible ceiling, a ceiling restop
must be installed.
E. Venting Guidelines for Horizontal Runs
Max Horizontal Run 2 ft. (50 mm) when vertical
rise is 10 ft (3m)
Min Vertical Before
Elbow
Min of 4 ft vertical (102 mm)
must be used prior to any
horizontal run.
Horizontal Run requires a non-combustible support
every 5 ft (1.5 m), i.e., plumbing tape
A vent run o󰀨 the top of the appliance must have a
minimum vertical of 4 feet.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2214
Figure 4.6
V1
V1= 40 ft. Max. (12.2 m)
V1= 10 ft. Min. (3.0 m)
Note: As vertical pipe increases, vertical restrictors will need
to be adjusted. See Insert installation manual for adjustment
instructions.
Top Vent - Vertical Termination - (continued)
No Elbow

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2215
Top Vent - Vertical Termination - (continued)
Two Elbows
Figure 4.7
H1
V1
V2
2 Elbows to Max. Horizontal
V1Minimum V1+ V2 Maximum V1+ V2 Minimum H1Maximum
4 ft. 1.2 m 24 ft. 7.3 m 10 ft. 3.1 m 2 ft. 610 mm
10 ft. 3.1 m 15 ft. 4.6 m 10 ft. 3.1 m 2 ft. 610 mm
20 ft. 6.1 m 24 ft. 7.5 m 20 ft. 6.1 m 2 ft. 610 mm
28 ft. 8.5 m 34 ft. 9.1 m 28 ft. 8.5 m 3 ft. 914 mm
Note: As vertical pipe increases, vertical restrictors will need
to be adjusted. See Insert installation manual for adjustment
instructions.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2216
Figure 4.8
Top Vent - Vertical Termination - (continued)
Three Elbows
INSTALLED
HORIZONTALLY
H1
H2V1
V2
3 Elbows to Max. Horizontal
V1Minimum V1+ V2 Maximum V1+ V2 Minimum H1+ H2Maximum
8 ft. 2.4 m 34 ft. 9.1 m 28 ft. 8.5 m 1 ft. 310 mm
Note: As vertical pipe increases, vertical restrictors will need
to be adjusted. See Insert installation manual for adjustment
instructions.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2217
TERMINATION CAP
(Includ. in Link-Stove Kit)
EXISTING METAL
CHIMNEY SYSTEM
TOP ADAPTOR
(Includ. in Link-Stove Kit)
DIRECT VENT PIPE
(Length as required)
FLASHING
(Includ. in Link-Stove Kit)
4 in. (102mm) FLEX PIPE
(Includ. in Link-Stove Kit)
RETRO CONNECTOR
(Includ. in Link-Stove Kit)
Class A Metal Chimney
Prior to installing the gas stove, ensure that the existing
chimney is functionally sound and clean.
• Have the chimney and adjacent structure inspected
and cleaned by qualied professionals. Hearth & Home
Technologies recommends that NFI or CSIA certied
professionals, or technicians under the direction of
certied professionals, conduct a minimum of a NFPA
211 Level 2 inspection of the chimney.
• Replace component parts of the chimney and replace
as specied by the professionals.
• See Section 11 for venting components.
High Wind Termination Cap
(Part SLP-TVHW)
Sheet Metal Screws
Drill Four 1/8 in.
(3mm) Diamater
Holes
Figure 4.11
Figure 4.12
5. Pull the flex pipe down through the ceiling support box,
until it protrudes approximately 3 in. (76mm). Connect
the flex pipe to the retro connector, and attach with sheet
metal screws.
6. Push the flex pipe back up into the ceiling support box,
center the retro connector, and attach it to the support
box with sheet metal screws.
7. The connection between the appliance and the retro
connector may be completed with sections of direct vent
pipe.
Top Adapter
(Included in Link-Stove Kit)
Sheet Metal Screws
4” Flex Pipe
(Included in Link-Stove Kit)
Figure 4.10
Figure 4.9
1. Remove existing chimney cap.
2. Measure the distance from the top of the chimney to the
bottom of the ceiling support box, add 3 in. (76mm) to
this measurement, and cut a section of 4 in. (101mm)
flex pipe to that length (the flex should be fully extended).
3. Connect the end of the flex pipe section to the underside
of the top adapter, using four sheet metal screws. See
Figure 4.10.
4. Pass the flex pipe down through the center of the
chimney system, and center the top adapter on the top
of the chimney pipe. Drill four 1/8 in. (3mm) diameter
holes through the top adapter, and into the chimney
top. Ensure that you are drilling into the metal on the
chimney. Twist lock the high wind termination cap onto
the top adapter. See Figure 4.11 and Figure 4.12.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2218
Existing Masonry Chimney
Prior to installing the gas stove, ensure that the existing chimney is functionally sound and clean.
• Have the chimney and adjacent structure inspected and cleaned by qualied professionals. Hearth & Home Technologies
recommends that NFI or CSIA certied professionals, or technicians under the direction of certied professionals, conduct
a minimum of a NFPA 211 Level 2 inspection of the chimney.
• Replace component parts of the chimney and replace as specied by the professionals.
• See Section 10 for venting components.
Type C - Up & Out Installation
Figure 4.13
TERMINATION CAP
(Included in LINK-STOVE Kit)
FLASHING
(Included in Masonry
Chimney Conversion Kit &
LINK-STOVE Kit)
4 in. (102mm) FLEX LINER
(Included in LINK-STOVE Kit)
TOP ADAPTOR
(Included in Masonry Chimney
Conversion Kit & LINK-STOVE Kit)
RETRO CONNECTOR
(Included in Masonry Chimney
Conversion Kit & LINK-STOVE Kit)
90° ELBOW
DIRECT VENT PIPE
(Length as required)
2 ft. maximum
horizontal run

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2219
10 in. x 10 in. (254mm x 254mm)
framed opening in wall
Studwall
Masonry
Chimney
Retro Connector
(Included in Masonry Chimney
Conversion Kit)
(4) Masonry Bolts
(Not Included)
Wall Thimble Cover
(Included in Masonry
Chimney Conversion Kit)
Cut and bend flashing as needed
to fit
Sealant adhesive
1. Before cutting any holes, assemble the desired sections
of direct vent pipe to determine the center of the masonry
penetration.
2. Once the center point of the penetration has been
determined, cut a 6 in. (152mm) diameter hole in the
masonry. If the hole is too large, the retro connector
might not mount properly; if the hole is too small, the
appliance might starve for intake air. If there is a frame
wall in front of the masonry wall, cut and frame a 10 in.
(254mm) square opening in the wall (centered around
the 6 in. (152mm) masonry opening). If there is sheet
rock only (no studs) in front of the masonry the 10 in.
(254mm) opening is still needed, but does not need to be
framed. If the hole is framed a wall thimble is required.
This allows the retro connector to mount directly on
the masonry and provide the correct clearances to
combustibles. See Figure 4.14.
Figure 4.15
4. To determine the length of flex needed, measure from
3 in. (76mm) above the top of the flashing down to the
level of the opening. Add the distance from the center
of the chimney out through the wall. Cut a piece of 4
in. (102mm) flex to this length (extended to its nominal
length). Be sure to leave 2-3 in. (51-76mm) of flex above
the existing chimney to allow for connection to the
termination kit.
5. Connect the flex liner to the top adapter using three
sheet metal screws. See Figure 4.10.
6. Feed the flex liner through the flashing into the chimney.
Carefully feed the flex liner down the chimney to the
bottom and out the opening in the masonry wall, forming
an angle to line up the flex liner with the vent opening on
the appliance.
WARNING! Risk of Fire, Explosion or Asphyxiation!
Improper support may allow vent to sag and separate. Use
vent run supports and connect vent sections per installation
instructions. DO NOT allow vent to sag below connection
point to appliance.
7. If additional lengths of flex liner are needed to span the
chimney height, use a flex coupler to connect the pieces
of flex liner together. Connect the flex to the coupler by
using four sheet metal screws for each side. See Figure
4.16.
Figure 4.14
3. Secure the flashing to the top of the masonry chimney
using a bead of non-hardening sealant-adhesive. If the
flashing is larger than the top of the chimney, cut and fold
flashing as needed to fit chimney. See Figure 4.15.

Hearth & Home Technologies • CK-30 Cabinet Kit Installation Manual • 4126-900 Rev A • 07/2220
High Wind Termination Cap
(Part SLP-TVHW)
Top Adaptor
(Included in Link-Stove Kit)
(3) Sheet Metal
Screws
Flashing
(Included in Link-Stove Kit)
Figure 4.17
9. Attach the flex to the retro connector. Use three sheet
metal screws to attach the flex liner to the connector.
Mount the retro connector to the masonry wall using
masonry bolts. See Figure 4.18. Redrill larger holes
on connector as needed. Be careful to ensure that the
connector is centered in the opening and the mounting
holes line up with the masonry wall.
6 in. (152mm) diameter
opening in masonry wall
(3) Masonry Bolts
(Not included) Retro Connector
(Included in Masonry Chimney
Conversion Kit)
(4) Masonry Bolts
(Not included)
Retro Connector
(Included in Masonry
Chimney Conversion Kit)
Wall Thimble Cover
(Included in Masonry Chimney Conversion Kit)
Figure 4.16
8. Secure the top adapter to the flashing. Use three sheet
metal screws through the side of the top adapter into the
flange on the flashing See Figure 4.17. Twist lock the
high wind termination cap on to the top adapter.
Flex Liner
(3 in. Part 3DFA-35)
(4 in. Part 4DFA-35)
Flex Coupler
(3 in. Part 3DFA-FC)
(4 in. Part 4DFA-FC)
Sheet Metal Screws
Figure 4.19
Figure 4.18
10. Slide wall thimble cover over retro connector and secure
with masonry bolts. See Figure 4.19. If you have a
framed wall in front of the masonry, use wood screws
to mount wall thimble cover to framed wall, over retro
connector and 10 in. (254mm) square framed opening
See Figure 4.14. If needed, add a section of direct vent
pipe to the retro connector in order to extend through
the opening in the wall thimble cover.
11. The connection between the appliance and the retro
connector may be completed with sections of direct
vent pipe.
