Heat & Glo LOGS-6000G User manual

STEP 2.
Place the metal grate on top of the burner.
Position the legs of the grate into the forward set
of indentations in the burner top. Make sure that
grate is all the way forward. See Figure 2.
STEP 1.
CAUTION: Logs are fragile! Carefully remove
the logs, grate and supporting cardboard from
the inside of the fireplace See Figure 1.
If the gas logs have been factory installed they
should not need to be positioned. If the logs have
been packaged separately, refer to the following
instructions.
Figure 2
Figure 4 Top View
1
1
2
2
3
3
4
4
5
5
STEP 3.
Log #1 (SRV2103-107):
Place the log on the burner so the cutout in the
loggoesaroundthehumpintheburner.Theouter
legs of the log should self center on the sides of
the burner. Pull the log forward. The ramp shape
in the bottom of the log sits fully against the ramp
shape molded into the burner. The right side of
the log will touch the smaller hump. There will
be a 1/4 inch or so gap around the hump. See
Figures 3 and 4.
1
1
Figure 1
1
1
Figure 3 Front View
Log Set Assembly: LOGS-6000G
Models: 6000G, 6000GBV, 6000GCF LOG PLACEMENT
INSTRUCTIONS
Heat & Glo • 6000G • 2103-910 Rev. C • 8/06
HUMP SMALLER
HUMP
INDENTATIONS

Figure 12 Top View
Figure 6 Top View
STEP 5. Log #3 (SRV2103-110): Place log #3 on top of the burner surface in front of the hump. The bottom of
the log has a square groove cut through it. The groove sits over the second grate tine from the left. Slide it back against the
hump.
STEP 4. Log #2 (SRV2103-108): Place log #2 on top of the left side of log #1. The bottom of this log has a slot in
it that goes over the tab molded into the top of log #1. The left end sits behind the simulated ember cluster on the burner top.
STEP 6. Log #4 (SRV2103-109): Place log #4 on top of the right side of log #1. The bottom of this log has a
slot in it that goes over the tab molded into the top of log #1. The other end of the log rests on the grate, against the second
tine from the right.
STEP 7. Log #5 (SRV2103-111): Place log #5 in front of log #3 the notch in the bottom of this log rests over
the center tine on the grate. The log shouldn’t cover any ports.
Figure 8 Top View
Figure 10 Top View
2
2
3
3
4
4
5
5
3
3
5
5
4
4
Figure 5 Front View
Figure 7 Front View
Figure 9 Front View
Figure 11 Front View
2
2
