HIK VISION DS-K3B802BX Series User manual

DS-K3B802BX Series Swing Barrier
User Manual

Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K3B802BX Series Swing Barrier User Manual
i

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-K3B802BX Series Swing Barrier User Manual
ii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K3B802BX Series Swing Barrier User Manual
iii

under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
DS-K3B802BX Series Swing Barrier User Manual
iv

Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●The equipment must be connected to an earthed mains socket-outlet.
●Shock hazard! Disconnect all power sources before maintenance.
●Do not touch the bare metal contacts of the inlets aer the circuit breaker is turned o.
Electricity sll exists.
● indicates hazardous live and the external wiring connected to the terminals requires
installaon by an instructed person.
●Keep body parts away from fan blades. Disconnect the power source during servicing.
●Keep body parts away from motors. Disconnect the power source during servicing.
●To prevent possible hearing damage, do not listen at high volume levels for long periods.
●All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
If the top caps should be open and the device should be powered on for maintenance, make
sure:
1. Power o the fan to prevent the operator from geng injured accidentally.
2. Do not touch bare high-voltage components.
3. Make sure the switch’s wiring sequence is correct aer maintenance.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●When the product is installed on wall or ceiling, the device shall be rmly xed.
●If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
DS-K3B802BX Series Swing Barrier User Manual
v

●Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think baeries might have
been swallowed or placed inside any part of the body, seek immediate medical aenon.
●If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauons:
●The equipment shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the equipment.
●Ensure correct wiring of the terminals for connecon to an AC mains supply.
●The equipment has been designed, when required, modied for connecon to an IT power
distribuon system.
●+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
+ idenes the negave terminal(s) of equipment which is used with, or generates direct
current.
●No naked ame sources, such as lighted candles, should be placed on the equipment.
●This equipment is suitable for mounng on concrete or other non-combusble surface only.
●Install the equipment according to the instrucons in this manual.
●To prevent injury, this equipment must be securely aached to the oor/wall in accordance with
the installaon instrucons.
●Stainless steel may be corroded in some circumstances. You need to clean and care the device by
using the stainless steel cleaner. It is suggested to clean the device every month.
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
DS-K3B802BX Series Swing Barrier User Manual
vi

●Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
●Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
●Do not stay in the lane when the device is reboong.
●RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
●SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
●The instrucons shall require connecon of the equipment protecve earthing conductor to the
installaon protecve earthing conductor.
DS-K3B802BX Series Swing Barrier User Manual
vii

Available Models
Product Name Model Descripon
Swing Barrier DS-K3B802BX-L Le Pedestal
DS-K3B802BX-M Middle Pedestal
DS-K3B802BX-R Right Pedestal
DS-K3B802BX Series Swing Barrier User Manual
viii

Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Introducon ........................................................................................................................... 1
1.2 Main Features ........................................................................................................................ 1
Chapter 2 System Wiring ............................................................................................................ 3
Chapter 3 Installaon ................................................................................................................. 5
3.1 Disassemble before Installaon ............................................................................................. 5
3.2 Install Pedestals ..................................................................................................................... 9
Chapter 4 General Wiring ......................................................................................................... 10
4.1 Components Introducon .................................................................................................... 10
4.2 Wiring Electric Supply .......................................................................................................... 13
4.3 Wire Interconnecng Cable ................................................................................................. 15
4.4 Wire Network Switch ........................................................................................................... 15
4.5 Terminal Descripon ............................................................................................................ 16
4.5.1 Main Lane Control Board Terminal Descripon .......................................................... 17
4.5.2 Sub Lane Control Board Terminal Descripon ............................................................ 17
4.5.3 Access Control Board Terminal Descripon ................................................................ 18
4.5.4 Main Extended Interface Board Terminal Descripon ................................................ 20
4.5.5 Sub Extended Interface Board Terminal Descripon .................................................. 22
4.5.6 Card Reader Board Terminal Descripon .................................................................... 23
4.5.7 Lane Status Indicator Board ........................................................................................ 23
4.5.8 Wiring Diagram ........................................................................................................... 25
4.5.9 RS-485 Wiring ............................................................................................................. 26
4.5.10 Face Recognion Module Wiring .............................................................................. 27
Chapter 5 Device Sengs ......................................................................................................... 29
5.1 Set Study Mode .................................................................................................................... 29
5.2 Pair Keyfob ........................................................................................................................... 31
DS-K3B802BX Series Swing Barrier User Manual
ix

5.3 Inialize Device .................................................................................................................... 33
Chapter 6 Acvaon ................................................................................................................. 34
6.1 Acvate via SADP ................................................................................................................. 34
6.2 Acvate Device via Client Soware ...................................................................................... 35
6.3 Acvate via Web Browser .................................................................................................... 36
Chapter 7 Operaon via Web Browser ...................................................................................... 37
7.1 Login .................................................................................................................................... 37
7.2 Web Wizard .......................................................................................................................... 37
7.2.1 Time Sengs ............................................................................................................... 37
7.2.2 Administrator Sengs ................................................................................................ 38
7.3 Overview .............................................................................................................................. 38
7.4 Person Management ............................................................................................................ 39
7.5 Search Event ........................................................................................................................ 41
7.6 Conguraon ....................................................................................................................... 43
7.6.1 View Device Informaon ............................................................................................. 43
7.6.2 Set Time ...................................................................................................................... 43
7.6.3 Set DST ........................................................................................................................ 44
7.6.4 Change Administrator's Password ............................................................................... 44
7.6.5 Online Users ................................................................................................................ 44
7.6.6 View Device Arming/Disarming Informaon .............................................................. 45
7.6.7 Network Sengs ......................................................................................................... 45
7.6.8 Set Audio Parameters .................................................................................................. 47
7.6.9 Event Linkage .............................................................................................................. 47
7.6.10 Access Control Sengs ............................................................................................. 48
7.6.11 Turnsle .................................................................................................................... 53
7.6.12 Card Sengs ............................................................................................................. 57
7.6.13 Set Privacy Parameters .............................................................................................. 58
7.6.14 Set Smart Parameters ............................................................................................... 58
DS-K3B802BX Series Swing Barrier User Manual
x

7.6.15 Prompt Schedule ....................................................................................................... 59
7.6.16 Upgrade and Maintenance ....................................................................................... 61
7.6.17 Device Debugging ..................................................................................................... 62
7.6.18 Component Status .................................................................................................... 63
7.6.19 Log Query .................................................................................................................. 64
7.6.20 Cercate Management ........................................................................................... 64
Chapter 8 Client Soware Conguraon ................................................................................... 66
8.1 Conguraon Flow of Client Soware ................................................................................. 66
8.2 Device Management ............................................................................................................ 66
8.2.1 Add Device .................................................................................................................. 67
8.2.2 Reset Device Password ................................................................................................ 69
8.2.3 Manage Added Devices .............................................................................................. 70
8.3 Group Management ............................................................................................................. 71
8.3.1 Add Group ................................................................................................................... 71
8.3.2 Import Resources to Group ......................................................................................... 72
8.4 Person Management ............................................................................................................ 72
8.4.1 Add Organizaon ........................................................................................................ 72
8.4.2 Congure Basic Informaon ....................................................................................... 73
8.4.3 Issue a Card by Local Mode ......................................................................................... 73
8.4.4 Upload a Face Photo from Local PC ............................................................................ 75
8.4.5 Take a Photo via Client ................................................................................................ 76
8.4.6 Collect Face via Access Control Device ....................................................................... 77
8.4.7 Collect Fingerprint via Client ....................................................................................... 78
8.4.8 Collect Fingerprint via Access Control Device ............................................................. 79
8.4.9 Congure Access Control Informaon ........................................................................ 80
8.4.10 Customize Person Informaon .................................................................................. 81
8.4.11 Congure Resident Informaon ................................................................................ 82
8.4.12 Congure Addional Informaon ............................................................................. 82
DS-K3B802BX Series Swing Barrier User Manual
xi

8.4.13 Import and Export Person Idenfy Informaon ........................................................ 83
8.4.14 Import Person Informaon ....................................................................................... 83
8.4.15 Import Person Pictures ............................................................................................. 84
8.4.16 Export Person Informaon ........................................................................................ 84
8.4.17 Export Person Pictures .............................................................................................. 85
8.4.18 Get Person Informaon from Access Control Device ................................................ 85
8.4.19 Move Persons to Another Organizaon .................................................................... 86
8.4.20 Issue Cards to Persons in Batch ................................................................................. 86
8.4.21 Report Card Loss ....................................................................................................... 87
8.4.22 Set Card Issuing Parameters ...................................................................................... 87
8.5 Congure Schedule and Template ....................................................................................... 88
8.5.1 Add Holiday ................................................................................................................. 88
8.5.2 Add Template .............................................................................................................. 89
8.6 Set Access Group to Assign Access Authorizaon to Persons .............................................. 90
8.7 Congure Advanced Funcons ............................................................................................ 93
8.7.1 Congure Device Parameters ...................................................................................... 93
8.7.2 Congure Remaining Open/Closed ............................................................................. 99
8.7.3 Congure Mul-Factor Authencaon ..................................................................... 100
8.7.4 Congure Custom Wiegand Rule .............................................................................. 103
8.7.5 Congure Card Reader Authencaon Mode and Schedule .................................... 104
8.7.6 Congure First Person In ........................................................................................... 106
8.7.7 Congure An-Passback ........................................................................................... 107
8.7.8 Congure Device Parameters .................................................................................... 108
8.8 Congure Linkage Acons for Access Control .................................................................... 109
8.8.1 Congure Client Acons for Access Event ................................................................. 109
8.8.2 Congure Device Acons for Access Event ............................................................... 110
8.8.3 Congure Device Acons for Card Swiping ............................................................... 111
8.9 Door Control ...................................................................................................................... 112
DS-K3B802BX Series Swing Barrier User Manual
xii

8.9.1 Control Door Status ................................................................................................... 113
8.9.2 Check Real-Time Access Records .............................................................................. 114
Appendix A. Tips for Scanning Fingerprint ............................................................................... 116
Appendix B. DIP Switch ........................................................................................................... 118
B.1 DIP Switch Descripon ....................................................................................................... 118
B.2 DIP Switch Corresponded Funcons .................................................................................. 118
Appendix C. Error Code Descripon ........................................................................................ 119
Appendix D. Communicaon Matrix and Device Command .................................................... 121
DS-K3B802BX Series Swing Barrier User Manual
xiii

Chapter 1 Overview
1.1 Introducon
The swing barrier with two barriers and 24 pair of IR lights is designed to detect unauthorized
entrance or exit. By adopng the swing barrier integrated with the access control system, person
should authencate to pass through the lane via swiping IC or ID card, scanning QR code, etc. It is
widely used in aracons, stadiums, construcon sites, residences, etc.
1.2 Main Features
●32-bit high-speed processor
●TCP/IP network communicaon
The communicaon data is specially encrypted to relieve the concern of privacy leak.
●Permissions validaon and an-tailgang
●Remaining open/closed mode selectable
DS-K3B802BX Series Swing Barrier User Manual
1

●Bidireconal (Entering/Exing) lane
The barrier opening and closing speed can be congured according to the visitor ow.
●The barrier will be locked or stop working when people are nipped
●An-forced-accessing
The barrier will be locked automacally without open-barrier signal.
●Self-detecon, Self-diagnoscs, and automac alarm
●Audible and visual alarm will be triggered when detecng intrusion, tailgang, reverse passing,
and climbing over barrier
●IP conict detecon
●Remote control and management
●Online/oine operaon
●LED indicates the entrance/exit and light bar indicates passing status
●Barrier remains open when powered down
●Fire alarm passing
When the re alarm is triggered, the barrier will be open automacally for emergency
evacuaon
●Valid passing duraon sengs
System will cancel the passing permission if a person does not pass through the lane within the
valid passing duraon
●Opens/Closes barrier according to the schedule template
DS-K3B802BX Series Swing Barrier User Manual
2

Chapter 2 System Wiring
The preparaon before installaon and wiring.
Steps
1. Draw a central line on the installaon surface of the le or right pedestal.
2. Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is L+190 mm. L represents the lane width.
3. Slong on the installaon surface and dig installaon holes according to the hole posion
diagram.
Figure 2-1 Hole Posion Diagram
4. Bury cables. Each lane buries 1 low voltage cable and 1 high voltage cable. For details, see the
system wiring diagram above.
DS-K3B802BX Series Swing Barrier User Manual
3

Note
●High voltage: AC power input
●Low voltage: interconnecng cables
●The supplied interconnecng cables are 5.5 m in length.
●The suggested inner diameter of the low voltage conduit is larger than 30 mm.
●If you want to bury both of the AC power cord and the low voltage cable at the entrance, the
two cables should be in separated conduits to avoid interference.
●If more peripherals are required to connect, you should increase the conduit diameter or bury
another conduit for the external cables.
●The external AC power cord should be double-insulated.
●The network cable must be CAT5e or the network cable has beer performance. And the
suggested network cable length should be less than 100 m.
DS-K3B802BX Series Swing Barrier User Manual
4

Chapter 3 Installaon
3.1 Disassemble before Installaon
Before installaon, you should disassemble the pedestal and remove some screws.
Before You Start
●Keep the disassembled components and screws.
●You should prepare the following tools to disassemble the pedestal: 1. Pedestal Key (supplied); 2.
Allen Wrench (2.5 mm); 3. Allen Wrench (3 mm); 4. Allen Wrench (4 mm).
Steps
1. Use the pedestal key to open the front and back components.
Figure 3-1 Lock Posion
DS-K3B802BX Series Swing Barrier User Manual
5

2. Use the Allen wretch (4 mm) to loosen the 2 screws (M5 × 25) at the top of the device and
remove the components carefully.
Figure 3-2 Front/Back Component Screw
3. Use the Allen wretch (4 mm) to loosen the 2 screws (M5 × 12) at the front or back of the
pedestal base and remove the side base cover slowly.
DS-K3B802BX Series Swing Barrier User Manual
6
