HIK VISION Pyronix Enforcer V10 Service manual

Wireless Alarm System
Extended User Guide
Alarm Panel
Time 10:09 c

2
Enforcer V!0 User Guide
Contents
Introduction 5
ProControl+ 7
Setting Devices 8
The Wireless Panel Keypad and Additional Keypads 8
Proximity Tag Readers 8
Internal 8
External 9
Wireless Keyfobs 9
Locking the Keyfob 9
Quick Setting 10
The Wireless Arming Station 10
Setting and Unsetting 10
Activating the Outputs 10
Using Predictive Text 10
Predictive Text 11
Setting the System 11
Using a PIN Code or Proximity Tag 11
Using the Wireless Keyfob 12
Unsetting the System 12
Using a PIN Code or Proximity Tag 12
Using the Wireless Keyfob 13
Unsetting after an Alarm 13
Using a PIN Code or Proximity Tag 13
Using the Wireless Keyfob 13
Using Proximity Tag Readers 14
Setting and Unsetting 14
Entry Control 14
External Proximity Reader Instructions 15
Anti-Code & Engineer Restore Facilities 15

3
Enforcer V10 User Guide
Anti-Code 15
Engineer Reset 16
Fault Indications & Unable to Set 16
Fault Indications 16
Control Panel 16
Unable to Set 16
Control Panel Indication 16
Keyfob Indication 16
Advanced Functions 17
Chime 17
Omitting Inputs 17
Keypad Hold Up 17
Master Manager Mode Overview 18
Entering Master Manager Mode 19
Exiting Master Manager Mode 20
Master Manager Mode Options 20
Set Time and Date 20
Operate User Outputs 21
Omit Inputs 21
Edit Users 21
Button Actions 22
Flexi-set 22
Adding a New User 22
Deleting a User 24
Change User 24
Change Master Manager Code 24
Review Logs 24
Set Up App Data 25
Wi-Fi Setup 26
SMS/Voice Phonebook 27
Walk Test 27

4
Enforcer V!0 User Guide
Siren Test 28
Dial Out Menu 28
Allow Engineer Menu 28
Block UDL Set 29
System Sounds Demo 29
ProControl+ Smart Device Application 30
Getting Started 30
Downloading the App 30
Registering to the ProControl+ Service 30
Adding a Control Panel to ProControl+ 31
Basic Controls 32
Connecting to the Panel 32
Intruder Alarm Homescreen 33
Advanced Controls 34
History 34
Setting/Unsetting Logs 35
Acknowledging a Voice Call 35
Certication 36
Installation Information 37
Engineer Information 37
Input Table 38
Users 40
Standard Users 40
Guard, Duress and Dial Back Users 43

5
Enforcer V10 User Guide
Introduction
Two-Way Wireless Security Protects Your Family and Property Without
Compromise.
This wireless alarm system has been designed with your security in mind; with quick and
easy installation and minimal maintenance, this system protects your home or property with
a multitude of unique features.
Taking full advantage of the innovative two-way wireless technology, the wireless devices
on this system are constantly communicating with each other, using High Security Wireless
Encryption Protocol.
Compared to a conventional one-way wireless system where devices can be ‘asleep’ for up
to ve minutes at a time, therefore compromising your security, this wireless alarm system
ensures your safety at your home or oce at any time.
This wireless alarm system has been engineered to be secure, reliable and easy to use. It
includes the following features:
Battery Monitoring/Saving
Advanced technology preserves the battery life of each wireless device. However, the system
informs you when a battery needs replacing up to a month in advance before the device
stops working. This key feature gives you enough time to change the battery in the specic
device. Conventional wireless alarm systems may not give you a low battery warning signal,
meaning that devices could stop working, leaving your environment unprotected.
User Friendly Keyfobs
The fully two way wireless keyfob allows you to see the status of the control unit via three
colour LEDs:
System set: When the system is set a red LED will illuminate
System unset: When the system is unset a green LED will illuminate
System fault: When the system is in fault condition an amber LED will illuminate.
It is possible to allocate dierent functions to each keyfob such as setting/unsetting dierent
areas, activating outputs, requesting system status, and activating panic alarms. Up to 32
wireless keyfobs can be added to the wireless alarm system. Each wireless keyfob has its own
user ID which can be reported to the ARC and stored into the event log of the control panel
individually. The keyfob also allows you to set/unset every area individually, giving you total
control of your system.
User Automation Outputs
User automation outputs gives you the option to operate up to 20 devices such as gates,
lights, sprinklers, etc. via your keypad or remotely via your keyfob, extending the use of your
security system

6
Enforcer V!0 User Guide
Push and Voice Notications
Receive instant push notications from the control panel to ProControl+ enabling you
to react quicker to alarms. Combine the installation with Full HD Wi-Fi cameras for video
verication as soon as the notication is received for peace of mind and higher security of
your property.
ProControl+ also delivers voice notications alongside the push notications simultaneously
to make sure you never miss an incident, whether this be your alarm unsetting, perimeter
breached or panic alarm you will be the rst to know.
SMS Text Notications
Receive notications via SMS text messages of any incidents within your home in real
time. This can be programmed to send a notication in dierent situations: System is set or
unset: Notication that your child has returned home from school safely. Alarm activation:
Notication that the alarm has been triggered, allowing you to monitor your home from
anywhere in the world.
This wireless alarm system has 4 areas in which may be set up in the following way:
Area A: Full set of the house
Area B: Downstairs unset. Upstairs set.
Area C: Garage set. Rest of house unset.
Your engineer will be able to design the system according to your needs.

7
Enforcer V10 User Guide
ProControl+
Connect to your home from anywhere
AES-256
Encryption
Set and unset your system
View your system status in real time, including: alarm, CO and
smoke detectors
Customise and receive push notifications from your system
Have instant access to your events and history log
Control appliances such as lights, garage doors, gates and
blinds
All using an encrypted, highly secure system, for extra peace
of mind that your family and home is safe and secure
https://apple.co/2N4DF51https://play.google.com/store/apps/
details?id=com.mcu.Pyronix&hl=en

8
Enforcer V!0 User Guide
Setting Devices
The Wireless Panel Keypad and Additional Keypads
Additional wired keypads may also be connected
to the wireless control panel, please ask your
engineer for more information.
a= Exits the Master Manager menu and
selects Area A when setting.
b= Moves backwards in the Master Manager
menu and selects Area B when setting.
c= Enables chime, displays additional
information in the event log, and selects Area C
when setting.
d= Moves forward in the log, scrolls between options, enters
the Master Manager menu and selects Area D when setting.
fp= Not used.
[]= Directional buttons and enables/disables functions.
f= Enters menus and accepts programming preferences.
h= Cancels items, resets the panel and moves to next item in a menu item.
Proximity Tag Readers
Tag readers can be used for setting/unsetting, entry control or access control. Ask your
engineer for more details.
Internal
Proximity area (please present your tag here)
:Alert LED
;Alarm LED
<Tamper LED
=Fault LED
>Unset LED

9
Enforcer V10 User Guide
External
To set/unset the system using the External Tag Reader, present a
pre-programmed tag to the centre of the reader.
The reader will display the system status:
Green LED means the system is unset.
Red LED means the system is set.
Present the tag again within 10 seconds and the system will set
or unset.
The system will then set depending on the type of exit mode programmed (nal door, timed
or push to set).
Wireless Keyfobs
The wireless keyfob has four buttons that may be programmed for specic purposes, these
options are programmed in the ‘EDIT USERS?’section.
Locking the Keyfob
All four buttons on the keyfob may be locked so that any accidental presses will not aect
your wireless alarm system. For example, this protects the buttons from being pressed
accidentally if a keyfob is in someone’s pocket.
OR OR
5 seconds 5 seconds
The buttons can be customised to operate as desired. The table below gives the defaults of
how each button is programmed.
LOCK When pressed, the Area A will start to set.
UNLOCK When pressed, the wireless alarm system will unset any area that is
already set.
I BUTTON When pressed, the Area B will start to set.
II BUTTON
When pressed, if the GREEN LED is shown then the wireless alarm
system will be unset. If the RED LED is shown then the wireless alarm
system will be set.

10
Enforcer V!0 User Guide
Quick Setting
If one of the buttons is programmed as ‘Set Area’, the wireless alarm system can be set by
pressing the programmed button on the keyfob. The keypad will then start to count down
the exit time, wait for a ‘nal door’ to be opened and closed or wait for a Push to Set (PTS)
button to be pressed (depending what exit mode is programmed as by the engineer).
Once the alarm panel is in this‘setting’stage, it is possible to‘quick set’the system by pressing
the same button again; this will reduce the time to set to‘immediate setting’. The alarm panel
will revert to the normal display with the time showing, but a beep will be heard conrming
the system has set.
The Wireless Arming Station
Up to four wireless arming stations can be programmed on to the wireless alarm system.
Setting and Unsetting
If you are using a proximity tag to set or unset the
wireless alarm system, press any key rst (except
d), to ‘wake’ the wireless arming system before
presenting a tag.
Alternatively, if a user code is being used, then
enter the code. The wireless arming station will
automatically‘wake’once the rst button is pressed.
After a tag or code has been activated, choose the
area to set by pressing the a, b, cor d.
The key will illuminate indicating that area has been
chosen to be set. Once conrmed, press the t
key.
To unset, simply enter the user code.
OP 1 OP 2 OP 3OP 4
OP 1 OP 2 OP 3OP 4
“BEEP”
OP 1 OP 2 OP 3OP 4
Activating the Outputs
Press the dkey and enter the Master Manager
code.
The keys 123 and 4will illuminate.
The OP1–4 LEDs will illuminate once the 1-4
numeric keys have been pressed. Once illuminated,
it signies that the output has triggered. Press the
key again to deactivate the output.
OP 1 OP 2 OP 3OP 4
Using Predictive Text

11
Enforcer V10 User Guide
Predictive Text
The wireless alarm system incorporates predictive text, so the system will predict which
word is being spelt.
For example, if you want to type ‘Daniel’, press 3once and the name ‘David’ will appear.
Using the [and ]keys move the cursor under the ‘v’and press 6twice to change it
to a ‘n’. The text will now change to ‘Daniel.’ Press fto accept.
If the word that you require does not appear in the list, just continue typing the word letter
by letter.
In addition, the a b c d keys are used as follows:
a= make the character into a capital
b= move cursor left
c= delete the character above the cursor
d= moves cursor right
Setting the System
Using a PIN Code or Proximity Tag
Enter a valid PIN code or present a valid tag to the
symbol as shown.
Enter Your Code
[******]
Enter the area you wish to set and press f.
‘Please wait setting wireless’will be displayed.
Set Areas?[A ]
There are three dierent setting methods your
installer will instruct you through:
Final Door: Leave the building and make sure the
exit door is closed properly.
Timed: Make sure you leave the building before the
timer shown on the keypad expires.
Push to set: Press the push to set button installed by
your engineer to set the system.
Please leave via
Exit Route

12
Enforcer V!0 User Guide
Using the Wireless Keyfob
To set via a keyfob. Pressand hold for more than 2
seconds.
The keyfob LED will start to ash green indicating that the
system is starting to set.
‘Please wait setting wireless’will be displayed on the keypad
and the programmed area will begin to set.
To ‘quick set’, press and hold thekey again for four
seconds.
Once set, the keyfob LED will illuminate RED indicating that
the system is now set.
<2 seconds
Unsetting the System
Using a PIN Code or Proximity Tag
Enter the building, the ‘entry time’ will start. ENTRY TIME [30]
Enter a valid PIN code or present a valid tag to the
symbol as shown.
Enter Your Code
[******]
The area that the code is assigned to will be unset. Alarm Panel
Time 10:09 c
Please note: If ‘exi-set’ is disabled then the system will automatically unset that level set once a valid user
code or tag is presented.

13
Enforcer V10 User Guide
Using the Wireless Keyfob
To unset via a keyfob. Press .
The keyfob LED will ash green indicating that the system
has unset.
Please note: Unsetting with a keyfob will only be allowed if your
engineer has enabled this.
<2 seconds
Unsetting after an Alarm
Using a PIN Code or Proximity Tag
Enter a valid PIN code or present a valid tag to the
symbol as shown.
Enter Your Code
[******]
The alarm symbol will ash indicating there has
been an alarm activation and the keypad will
display which input has activated.
Alarm Silenced
Lounge
Press hto reset the system. Alarm Panel
Time 10:09 c
Using the Wireless Keyfob
To unset via a keyfob. Press .
The keyfob LED will start to ash green indicating that the
system has unset.
Resetting the system after an alarm can only be done at
the keypad.
Please note: Unsetting with a keyfob will only be allowed if your
engineer has enabled this.
<2 seconds

14
Enforcer V!0 User Guide
Using Proximity Tag Readers
Setting and Unsetting
If you have a tag reader installed, then it will be possible to set and unset the wireless alarm
system using a tag (the same tags can also be used on the readers on the main control panel
and keypads).
There are two types of readers that can be used with the wireless alarm system - the internal
tag reader and the external tag reader (used both indoors and outdoors).
Tags for the readers need to be programmed through the ‘Edit Users’ function in the Master
Manager Menu. The internal and external readers can be both assigned to individual areas,
this will need to be set up by your engineer.
Unset Set Unset Set
Entry Control
The readers may be used for entry control, which means they can operate automatic locks
for example as well as setting and unsetting the system. This can be set up by your engineer.
Unlocked Locked Unlocked Locked

15
Enforcer V10 User Guide
External Proximity Reader Instructions
Arming
Present a valid tag to the reader, the green LED will illuminate on the external reader, remove
the tag, the door will unlock, then present the same tag within 10 seconds and the system
will arm and the door will lock.
Disarming
Present a valid tag to the reader and then remove it, the status will be shown (the alarm
symbol will illuminate indicating the system is armed on the internal reader and the red LED
on the external reader), present the same tag within 10 seconds again and the system will
be disarmed, and the door will unlock.
Access Control/Entry Control
The readers can be used also for opening doors only without the ability to arm and disarm.
Please contact your installer for more information on this feature.
Anti-Code & Engineer Restore Facilities
Your engineer may have set up the system so that either an ‘Anti-Code’ or ‘Engineer Restore’
is required in order to fully reset the wireless alarm system
Please note: Your code will still silence the alarm, but it will not reset the system.
Anti-Code
After alarm activation has occurred, enter a valid
PIN code, present a valid tag, or press  on the
keyfob to silence the alarm.
The keypad will display as shown to the right.
Take note of the number, on the screen and call
your Alarm Receiving Centre (ARC).
Press h.
Alarm Silenced
Restore G12298
When the time is displayed, enter the number given
to you by the ARC.‘Engineer Restore Performed’will
be displayed.
Press h.
Engineer Reset
Performed

16
Enforcer V!0 User Guide
Engineer Reset
When the time is displayed, enter the Engineer
Code.
‘Engineer Reset Performed’ will be displayed.
Press a.
Restore
Required
Fault Indications & Unable to Set
Fault Indications
Control Panel
Any faults that occur on the system will be easily
recognised by the ashing ALERT LED.
Alarm Panel
Time 10:09 c
To see what the fault is, enter a valid PIN code, or
present a valid tag, or press on the keyfob.
Depending on how the system has been set up by
your engineer, it may be possible to set the system
with a fault, to do this press f.
Control Panel
Battery Fault
Please note: Any fault may aect the overall performance of your alarm control panel and therefore your
engineer should be contacted for further assistance if any fault is active.
Unable to Set
Control Panel Indication
If‘unable to set’is displayed, it indicates that an input
is open and the area where the input is should be
checked for open windows, pets, movement etc.
If the problem cannot be solved contact your
engineer, or omit the input.
Unable To Set
Input 01
Keyfob Indication
If the panel is unable to set for any reason, the keyfob status LED ashes amber indicating a
fault is on the system.

17
Enforcer V10 User Guide
Advanced Functions
Chime
The chime can be used for any input on the system.
This can be set up by your engineer.
To enable the chime on the keypad, when the time
is displayed, press c.
‘c’ will be displayed on the right side of the keypad
display. Press cagain to clear the chime feature.
Alarm Panel
Time 10:09 c
Omitting Inputs
On occasion, a detector may need to be isolated if
a room is occupied.
Enter your User Code.
Press f.
Select the inputs that need to be omitted’
Press a.
After 10 seconds the exit time continues.
Omit Day Al [01]
Please note: Inputs have to be programmed as omittable by your engineer for this feature to operate.
Keypad Hold Up
A ‘hold up’ alarm will be generated when 1and
7are pressed and held down for 2 seconds (this
time period can be altered by your engineer).
Alarm Silenced
2 Key HU
Please note: The keyfob can also be programmed to provoke a hold up alarm. All hold up alarms including
duress codes must be enabled by the engineer.

18
Enforcer V!0 User Guide
Master Manager Mode Overview
The Master Manager Menu has the following functions:
Please note: The options visible will depend on which modem is installed in the panel.
Set Date and Time
Programs the date and time.
Operate User Outputs
Activates/deactivates user automation outputs that are used to remotely activate devices,
such as electronic gates & lights.
Omit Inputs
Omits inputs programmed as ‘Day Alarm’ only.
Edit Users
Adds/Edits/Deletes User PIN codes, tags and keyfobs.
Review Logs
Displays all event log information.
SMS Phonebook
If SMS texting is enabled, there can be up to 10 mobile numbers programmed to send SMS
alarms. Please discuss this feature with your installer if required.
Please note: Third party SIM cards only.
Voice Phonebook
Edits the telephone numbers that the panel is programmed to send voice messages to.
Set Up App Data
If the ProControl+ App has been enabled, this function will control the settings.
Wi-Fi Setup
Adds or changes a Wi-Fi connection with your router.
Walk Test
Tests each input.

19
Enforcer V10 User Guide
Siren Test
Tests all external sounders (wired or wireless).
Dial Out Menu
Calls the UDL software.
Allow Engineer Menu
Enables or disables engineer access.
Block UDL Set
Blocks remote setting from the PC software.
Block UDL
Blocks uploading/downloading from the PC software.
System Sounds Demo
Demonstrates all the sounds of the alarm system.
Exit Manager Mode
Exits Master Manager mode.
Please note: The Master Manager code allows access to all the options above. A User Code has access to the
‘User Menu’ which includes the functions: ‘Operate User Outputs’, ‘Change Code’, ‘Review Logs’, ‘Walk Test’,
‘Siren Test’. ‘Allow Engineer Menu’, and ‘Exit User Menu’.
Entering Master Manager Mode
Press d.
Enter the Master Manager code or present the
Master Manager tag.
Press bor ato scroll through the dierent
functions.
Enter Your Code
[ ]

20
Enforcer V!0 User Guide
Exiting Master Manager Mode
Press bor hkeys to scroll through until ‘EXIT
MANAGER MODE?’ is displayed.
Press f.
Or, when a main menu item is displayed (capital
letters) press a.
EXIT MANAGER
MODE?
Master Manager Mode Options
Set Time and Date
Press bor hto scroll to ‘SET DATE & TIME?’.
Press f.
SET DATE & TIME?
Enter the year.
Press f.
Year (00-99)[18]
Enter the month.
Press f.
Month (01-12)
[09]
Enter the day.
Press f.
Day (01-30) [04]
Enter the hours.
Press f.
Hours (00-23)
[18]
Enter the minutes.
Press f.
Minutes (00-59)
[00]
Select whether DST is to be activated.
Press f.
DST Adjust?
Yes [1]
