CLUB SERIES
TREADMILL USER’S GUIDE
FOR MODELS:
CST3.6
CST4.6
PERFORMANCETRACKI N G
IN CLI N E
1%
2%
3%
4%
5%
6%
7%
8%
9%
10%
11%
12%
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
7
MPH
8
MPH
9
MPH
10
MPH
11
MPH
12
MPH
SELECTPROGRAM
S T A R T
PROGRAM
PRESSTOBEGIN
USER USER
SELECTUSER
(OPTIONAL)
ADJUSTPROGRAMSETTINGS
EN T E R
MOUNTAIN
CLIMB
WEIGHT
LOSS5K
SPEED
+0.5
INCLIN E
+0.5
SPEED
PRESS
TOSET
INCLINE
PRESS
TOSET
SPEED
QUI C K
ST A RT
STOP/ P AUSE
HOLD T O RESE T
CAUTION!
Consultaphysicianbeforeusingthis
equipment.Stopexercisingifyoufeel
pain,faint,dizzyorshortofbreath.
WARNING!
Attachsafetykeycliptoclothingbeforestarting.Toavoidinjury,standonthesiderails before
startingtreadmill.Readandfollowallinstructionsbefore operating.Keepchildenawayfrom
thisequipment.Removesafetykeywhennotinuseandstoreoutofreachofchildren.
DATECLOCK
PRESSTOSWITCH
CURRENTWORKOUT
AVERAGEWORKOUT
LASTWORKOUT
DISTANCE
TIMEPACE
CALORIES/ PULSE
INCLI NESPEED
WEEKLYTOTAL
MONTLYTOTAL
LIFETIMETOTAL

3
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
CONGRATULATIONS and THANK YOU for your purchase of this Freespirit treadmill!
Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Freespirit treadmill can
help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics
and innovative features you need to get stronger and healthier, faster. Because we're committed to
designing fitness equipment from the inside out, we use only the highest quality components. It's a
commitment we back with one of the strongest frame-to-motor warranty packages in the industry.
You want exercise equipment that offers the most comfort, the best reliability and the highest quality
in its class.
Freespirit Treadmils deliver.
INTRODUCTION
Important Precautions
Assembly
Before You Begin
Treadmill Operation
Conditioning Guidelines
Troubleshooting & Maintenance
Limited Warranty
CONTACT INFORMATION
4
6
13
16
27
35
38
Back Panel
TABLE OF CONTENTS

4
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
SAVE THESE INSTRUCTIONS
Read all instructions before using this treadmill. When using an electrical product, basic precautions
should always be followed, including the following: Read all instructions before using this treadmill. It is the
responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings
and precautions. If you have any questions after reading this manual, contact Customer Tech Support at the
number listed on the back panel of this manual.
Connect this exercise product to a properly grounded outlet only. See grounding
instructions.
GROUNDING INSTRUCTIONS
This product must be grounded. If a treadmill should malfunction or breakdown, grounding provides a path
of least resistance for electrical current to reduce the risk of electrical shock. This product is equipped with
a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with local codes and ordinances.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or serviceman if you are in doubt
as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
This product is for use on a nominal 110-volt circuit
and has a grounding plug that looks like the illustration
to the right. This product must be used on a dedicated
circuit. To determine if you are on a dedicated circuit,
shut off the power to that circuit and observe if any other
devices lose power. If so, move devices to a different
circuit. Note: There are usually multiple outlets on one
circuit. It is recommended that the treadmill be used
with a 20 amp circuit for optimal performance.
IMPORTANT PRECAUTIONS
WARNING
WARNING
3-Pole Grounded Outlet
GROUNDED
TREADMILL
POWER CORD

5
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
At NO time should pets or children under the age of 12 be closer to the treadmill than 10 feet.
At NO time should children under the age of 12 use the treadmill.
Children over the age of 12 should not use the treadmill without adult supervision.
To reduce the risk of burns, fire, electrical shock or injury to persons:
• Never use the treadmill before securing the safety tether clip to your clothing.
• If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness
of breath, stop exercising immediately and consult your physician before continuing.
• Do not wear clothes that might catch on any part of the treadmill.
• Always wear athletic shoes while using this equipment.
• Do not jump on the treadmill.
• Keep power cord away from heated surfaces.
• Do not insert or drop any object into any opening.
• Unplug treadmill before moving or cleaning it. To clean, wipe surfaces down with soap and slightly damp
cloth only; never use solvents. (See MAINTENANCE)
• At no time should more than one person be on treadmill while in operation.
• The treadmills should not be used by persons weighing more than 325 pounds. Failure to comply will
void the warranty.
• The treadmill is intended for in-home use only. Do not use this treadmill in any commercial, rental, school
or institutional setting. Failure to comply will void the warranty.
• Do not use treadmill in any location that is not temperature controlled, such as but not limited to garages,
porches, pool rooms, bathrooms, car ports or outdoors. Failure to comply may void the warranty.
• Use the treadmill only as described in this manual.
OTHER SAFETY TIPS FOR YOUR TREADMILL
OPERATION
To reduce the risk of damaging important components on your treadmill, it is strongly
recommended that your treadmill is plugged into a dedicated 20 amp circuit, without
the use of an additional extension cord and/or power strip. Failure to comply may void
the warranty.
IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets.
It is essential that your treadmill is used only indoors, in a climate controlled room. If your treadmill has been
exposed to colder temperatures or high moisture climates, it is strongly recommended that the treadmill is
warmed up to room temperature before first time use. Failure to do so may cause premature electronic failure.
WARNING
WARNING

6
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY
IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE!
During the assembly process of the treadmill there are several areas that special attention must be paid.
It is very important to follow the assembly instructions correctly and to make sure all parts are firmly
tightened. If the assembly instructions are not followed correctly, the treadmill could have frame parts that
are not tightened and will seem loose and may cause irritating noises. There should be no side-to-side play
in the console masts or any forward and back play in the console assembly or handlebars. If there is any
play in these areas, the treadmill has not been properly assembled. To prevent damage to the treadmill, the
assembly instructions must be reviewed and corrective actions should be taken.
UNPACKING
Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on
your floor. Take CAUTION when handling and transporting this unit. Never open box when it is on its side.
Once the banding straps have been removed, do not lift or transport this unit unless it is fully assembled
and in the upright folded position, with the lock latch secure. Unpack the unit where it will be used. Never
grab hold of any portion of the incline frame and attempt to lift or move the treadmill. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN INJURY!
Before proceeding, find your treadmill’s serial number
and model name located under the deck on the frame
crossbar and enter it in the space provided below.
ENTER YOUR SERIAL NUMBER AND
MODEL NAME IN THE BOxES BELOW:
SERIAL NUMBER:
MODEL NAME:
* Refer to the SERIAL NUMBER and MODEL NAME when calling for service.
* Also enter this serial number on your Warranty Card.
WARNING

7
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
TOOLS INCLUDED
PARTS INCLUDED
1 Safety Key
1 Console Assembly (located under treadmill deck)
1 Power Cord
4 Hardware Bags
2 Handlebar Extensions
2 End Caps
2 Console Masts
1 Heartrate Chest Strap
DISPLAY AREA
WATER BOTTLE HOLDER
GRIP PULSE HANDRAILS
ON/OFF SWITCH
CIRCUIT BREAKER
TRANSPORT WHEEL
POWER CORD
CONSOLE
HANDLEBAR EXTENTIONS
SAFETY KEY PLACEMENT
MOTOR COVER
RUNNING BELT / RUNNING DECK
SIDE RAIL
ROLLER END CAP
CONSOLE MAST
REAR ROLLER
ADJUSTMENT BOLTS
FOOT LOCK LATCH
If you have questions or if there are any missing parts, contact Customer Tech Support.
contact information is located on the back panel of this manual.
5 mm Allen Wrench
6 mm T-wrench
Screwdriver
READING RACK
PERFORMANCE TRACKING
INCLINE
1%
2%
3%
4%
5%
6%
7%
8%
9%
10%
11%
12%
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
7
MPH
8
MPH
9
MPH
10
MPH
11
MPH
12
MPH
SELECT PROGRAM
S T A R T
PROGRAM
PRESS TO BEGIN
USER USER
SELECT USER
(OPTIONAL)
ADJUST PROGRAM SETTINGS
ENTER
MOUNTAIN
CLIMB
WEIGHT
LOSS5K
SPEED
+0.5
INCLINE
+0.5
SPEED
PRESS
TO SET
INCLIN E
PRESS
TO SET
SPEED
QUICK
S T A R T
STOP/PAUSE
HOLD TO RESET
CAUTION!
Consulta physician before usingthis
equipment.Stop exercising if you feel
pain,faint,dizzyor short of breath.
WARNING!
Attachsafety key clip to clothing before starting. Toavoid injury, stand on theside rails before
startingtreadmill. Read and follow allinstructions before operating. Keep childen away from
thisequipment. Remove safety key when not in use and store out of reach of children.
DATE CLOCK
PRESS TO S W I TCH
CURRENT WORKOUT
AVERAGEWORKOUT
LAST WORKOUT
DISTANCE
TIME PAC E
CALORIES / PULSE
INCLINE SPEED
WEEKLYTOTAL
MONTLYTOTAL
LIFETIME TOTAL
(CST 4.6 SHOWN)

8
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
Disassemble box and remove the cardboard packaging that is not beneath the treadmill. Do not attempt to
lift the treadmill at this time. Remove plastic wrap from console masts.
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and partially threaded in before
completely tightening any ONE bolt. NOTE: A light application of grease may aid in the installation of hardware.
Any grease, such as lithium bike grease is recommended.
Open HARDWARE BAG 1.
Pull LEAD WIRE through RIGHT
CONSOLE MAST to drag upward.
Place RIGHT CONSOLE MAST
into upright position using 2
BOLTS (A) and 2 WASHERS (B)
and tighten. Be sure to hold the
console mast firmly, as it will
not stay in the upright
position on its own.
Repeat on the left side. Note:
There is no wire in the LEFT
CONSOLE MAST.
PRE-ASSEMBLY
ASSEMBLY STEP 1
A
B
C
D
BOLT (A)
65 mm
Qty: 4
FLAT WASHER (B)
8 mm
Qty: 4
HARDWARE BAG 1 CONTENTS :
Z01
BOLT (A)
FLAT WASHER (B)
CONSOLE CABLE
LEAD WIRE

9
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
ASSEMBLY STEP 2
NOTE: There is no hardware bag for this step.
Lift the RUNNING DECK until
lock latch on side of treadmill is
fully engaged.
Remove CONSOLE from box
and place out of the way.
Lower the treadmill RUNNING
DECK from the folded position
by stepping on LOCK LATCH on
the bottom left side of the deck.
A
B
C
1
3
2

10
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
SCREW (C)
ROLLER END CAP
MAIN FRAME
ASSEMBLY STEP 3
SCREW (C)
12 mm
Qty: 2
HARDWARE BAG 3 CONTENTS :
A Open HARDWARE BAG 3.
B Slide left ROLLER END CAP onto MAIN FRAME and attach with SCREW (C).
C. Repeat on other side.
