Htek U Series User manual

1
Htek IP Phones UC507 U Series
User Manual
Version 2.20.10.22.4
2020.9

2
Notices Information
Copyright
Copyright © 2005 - 2021 Nanjing Hanlong Technology CO., LTD. All rights reserved.
Nanjing Hanlong Technology Co., LTD. owns all the rights to modify and copy this document at any time.
And all the illustrations and text in this document are copyright protected. Therefore, no parts of this
document may be used or reproduced, transmitted by the third parties for any purposes without the
express written permission of Nanjing Hanlong Technology CO., LTD.
When this document is made available on www.htek.com, Nanjing Hanlong Technology Co., LTD. gives
its right to download and print copies of this content only for private use as a user manual. No parts shall
have the right to alter, modify or use as commercial means without prior written permission from Nanjing
Hanlong Technology Co., LTD.
Safety Instructions
To use the Phone, please follow the instructions in this user manual.
Use the power adapter supplied with your phone. Other power adapters may damage the phone.
This phone is only for indoor use. And also avoid in high humidity, water and some other liquids.
Do not use the phone during thunderstorms.
CE
FCC
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
Cleaning
To clean the device, use an anti-static cloth. Please avoid cleaning liquids as they might damage the
surface or internal electronics of the phone.

3
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
Specific Absorption Rate (SAR) information:
This IP Phone meets the government's requirements for exposure to radio waves. The guidelines are
based on standards that were developed by independent scientific organizations through periodic
and thorough evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons regardless of age or health. FCC RF
Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one
gram of tissue. Device types: Tablet has also been tested against this SAR limit. This device was
tested for typical body-worn operations with the back of the phone kept 0mm from the body. To
maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm
separation distance between the user's body and the back of the phone. The use of belt clips,
holsters and similar accessories should not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply with FCC RF exposure
requirements, and should be avoided.

4
Table of Content
