HunterDouglas Luminette PowerGlide 2.0 Assembly instructions

Placing The Brackets
Measure in 5" from the end of the headrail.■
NOTE: For proper operation, the SofTrakTM headrail must be mounted level. Use a level to check
that the installation brackets are level and aligned. Shim the brackets if necessary.
Checking The Gear Alignment
Prior to attaching the modular motor assembly to
the drive assembly, the gear in the drive assembly
must be aligned (as shown on the following page).
Use a screwdriver to turn and align the gear.
■
5" Space Evenly
Space Evenly
Headrail End Marks
Window Opening
5"
Drive Assembly
Luminette®PowerGlide®2.0
Quick Installation Tips

Checking The Gear Alignment (continued)
Align the tilt gear to the arrows on the bottom of the drive assembly.
■
Attaching The Motor Assembly
Align the pins on the motor assembly with the holes in the drive assembly and press■
the motor up until it clicks in place.
If snapping in seems difficult, try moving the carriers slightly by hand, away from
➤
the fully stacked position.
Tilt
Gear Not
Aligned
Tilt
Gear
Aligned
Drive Assembly
Motor

Releasing The Motor
Method 1: Insert the screwdriver into the slot on the drive assembly. Twist about a■
1/4turn to release the spring-latch, and pull down gently on the motor assembly to
separate.
Method 2: This method
■
works best when a
sheer is installed on the
headrail. Unhook the end
treatment and the first
vane prior to detaching
motor assembly.
Insert an allen wrench
■
into the side slot on
the drive assembly to
release the spring-latch,
then pull down gently on
the motor assembly to
separate.

135103571 6/08
© 2008 Hunter Douglas Inc.
® Registered trademark of Hunter Douglas Inc. ™ Trademark of Hunter Douglas Inc.
Patented in the U.S. and foreign countries. Other U.S. and foreign patents pending.
Operation Tip
Remote Control Operation
Use the Channel 1 (left) selector switch■
on the remote control for both tilt and
traverse functions.
Quickly
■Press and Release the UP▲or
DOWN▼button to traverse the sheer(s).
The sheer(s) must be fully traversed
before rotating vanes.
Press and Hold
■the UP▲or DOWN▼
button to rotate the vanes.
IMPORTANT: For more information on the
Platinum remote and programming tips,
refer to the Platinum Technology Remote
Control Guide.
Platinum™Technology
Remote Control
UP and
DOWN
Buttons
Indicator
Light
Channel
Selector
Switch
