Installation •Operation •Care
Silhouette®and Nantucket™
Window Shadings
SoftTouch™Motorization

CONTENTS
Getting Started:
Product View ..........................................................................................................1
Tools and Fasteners Needed ....................................................................................2
Installation:
Installation Overview ...............................................................................................3
STEP 1 — Mount the Installation Brackets...............................................................3
Inside Mount.......................................................................................................4
Outside Mount ....................................................................................................6
End Mount..........................................................................................................9
STEP 2 — Mount the Battery Wand and Connect the Power Cable, If Applicable ......10
STEP 3 — Install the Shading ...............................................................................11
STEP 4 — Connect the Power Source, If Applicable ...............................................13
Unpack the Wand and Attach to Activation Arm .......................................................15
Attach Magnetic Hold-Down Brackets (Optional)......................................................16
Operation:
Basic Operation ....................................................................................................17
Set and Go to a Favorite Position............................................................................17
Troubleshooting ....................................................................................................18
Care:
Removing the Shading...........................................................................................24
Cleaning Procedures .............................................................................................24
Warranty..................................................................................................Back Cover
© 2018 Hunter Douglas. All rights reserved. All trademarks used herein are the property of Hunter Douglas or
their respective owners.
Questions?
Call Hunter Douglas Consumer Support at 1-888-501-8364.

GETTING STARTED
1
Product View
Battery Wand
Battery Wand Clips
Installation
Brackets
Limit Stops
Magnetic
Hold-Down
Brackets
(Optional)
Weight
Clip
Weight
Clip
Bottom Rail
Balance Weight
Power Cable
Activation
Arm
Wand

2
GETTING STARTED
Thank you for purchasing Hunter Douglas Silhouette®or Nantucket™Window Shadings with
SoftTouch™Motorization. With proper installation, operation, and care, your new shadings will
provide years of beauty and performance.
Please thoroughly review this instruction booklet and the packing list before beginning the
installation.
Tools and Fasteners Needed
■Flat blade and Phillips screwdrivers ■Level (laser level is recommended)
■Measuring tape and pencil ■Pliers or heavy-duty scissors
■Power drill,
3
/ 32 " drill bit,
and
1
/ 4 " hex driver
In addition, you will need fasteners designed to work with your specific mounting surface(s).
■#6 Hex Head Screws (Provided). Two 1
1
/ 2 " screws are provided per installation bracket.
■Longer Hex Head Screws (Not Provided). If using spacer blocks, use #6 screws long
enough for a secure attachment.
■Speed Nuts and Screws (Provided). Extension brackets come with screws and speed nuts.
■Drywall Anchors (Not Provided). Use drywall anchors when mounting into drywall.
Speed Nut
and Screw
(Provided with Each
Extension Bracket)
#6 x 1
1
/ 2 "
Hex Head Screw
(Provided)
Longer #6 Hex Head Screw
for Use with Spacer Blocks
(Not Provided)
Importance of Limit Stops on Silhouette and Nantucket Window Shadings
Limit stops serve as the upper travel limit for the bottom rail, preventing it from rotating
around the fabric roll. Limit stops are located 6" from the ends of the headrail or are
centered on shadings less than 36" wide.
When a shading is made, the limit stops are adjusted according to the size of the fabric
roll. Occasionally, this adjustment changes during shipping or installation. If this happens,
problems can be fixed by readjusting the limit stops. See page 21 in the Troubleshooting
section if shading operation is difficult or if the bottom rail rotates around the fabric roll.
Shown below are the four possible positions of limit stops for large to small fabric rolls.
Large Fabric Roll Small Fabric Roll

INSTALLATION
3
Installation Overview
To install your shading, you will need to perform the following three steps:
STEP 1: Mount the Installation Brackets
STEP 2: Mount the Battery Wand and Connect the Power Cable, If Applicable
STEP 3: Install the Shading
STEP 4: Connect the Power Source, If Applicable
STEP 1 — Mount the Installation Brackets
■Your order will include the correct number of installation brackets for your shading width, as
shown in the table below.
■Shading orders may also include spacer blocks or extension brackets, if they were specified
for added clearance.
➤Extension brackets are used for end mount shadings, as well.
Mounting Types and Window Terminology
If the installation brackets are mounted correctly, the rest of the installation process follows
easily. To prepare for this important first step, review the mounting types and basic window
terminology illustrated below.
■Refer to the appropriate page below based on the mounting type chosen for your order:
➤Inside Mount — Page 4
➤Outside Mount — Page 6
➤End Mount — Page 9
Installation Bracket For Added Clearance
Shading Width Brackets
2
3
4Extension
Bracket
1
/ 2 " Spacer
Block
14" to 48"
48
1
/ 8 " to 96"
96
1
/ 8 " to 120"
Inside Mount
Shading fits within
window opening.
Collectively, the sill and
jambs are called the
“window casement.”
Molding
Head Jamb
Sill
Jamb Jamb
Outside Mount
Shading mounts outside
window opening.

INSTALLATION
4
Mount the Installation Brackets — Inside Mount
Prepare the Installation Brackets
The purpose of the back cover bracket is to provide an attachment for the optional back cover.
The top tab ensures that there is clearance for the battery wand.
■If using the optional back cover:
NOTE: If you have a battery wand, do not
remove the top tab on the back cover bracket.
➤If you have a satellite battery pack or an
18V DC power supply, remove the top tab
on the back cover bracket.
➤Snap the back cover bracket into the metal
installation bracket.
➤Place the back cover into the slots on the
top and bottom of the bracket.
■If not using the optional back cover:
➤If you have a battery wand, remove the
bottom tab from the back cover bracket.
➤Snap the back cover bracket into the metal
installation bracket. This ensures adequate
space for the battery wand.
➤If you have a satellite battery pack or an
18V DC power supply, it is not necessary
to use the back cover bracket.
Mount the Installation Brackets
■Measure and mark end bracket locations 2" in from each jamb.
➤If more than two installation brackets are required (see table on page 3), mark the
location of additional bracket(s) spaced evenly between the two end bracket locations.
Mount into wood whenever possible. Allow a minimum of 18" from the motor side
for the battery wand.
Remove top tab if using a satellite
batter
y pack or an 18V DC power supply.
Back Cover Bracket
Remove bottom tab if using a
battery wand and no back cover.
Top Tab
Bottom
Tab
Back Cover
Slots
2"
Motor
Side
2"
Space Evenly
Jamb Jamb
Space Evenly
18" Minimum for Battery Wand

INSTALLATION
5
■Mark the location of the screw holes.
➤The minimum depth required for mounting is 2"
with a battery wand and a back cover.
➤Minimum depth is 1
1
/ 4
"with a satellite battery
pack or 18V DC power supply and back cover.
➤The depth required for fully recessed mounting
will vary depending on the type of headrail and
vane size. Refer to the chart below for depth
requirements.
IMPORTANT: The front edges of the installation brackets must be level and aligned.
WARNING: Failure to properly align the brackets could result in the headrail
releasing from the brackets.
■Drill the screw holes using a
3
/ 32 " drill bit.
CAUTION: Use drywall anchors when mounting into drywall.
■Use a level to check that the mounting surface is level. If
necessary, you can shim the brackets using the top tabs that
were removed from the brackets.
■Attach the installation brackets using the screws provided.
IMPORTANT: Do not overtighten the screws. Check to
ensure the lever can be moved easily side to side. If not,
loosen the screws in one-eighth turn increments until the
lever can be moved easily.
■If using the optional back cover: Install the cover into
the back cover brackets. If necessary, trim the back cover
to the desired width.
IMPORTANT: If using a battery wand, do not install the
optional back cover until the wand is installed (see Battery
Wand on page 10).
Proceed to “STEP 2 — Mount the Battery Wand and Connect the Power Cable, If Applicable”
on page10.
Fully Recessed
Mounting Depths
Classic
Headrail
Quartette®4"
Headrail
Battery Wand & Back Cover 4
1
/ 16 " 4
9
/ 16 "
Satellite Battery Pack or DC Power
Supply & Back Cover 3
1
/ 2 " 4"
Minimum
Depth
2" Battery Wand
1
1
/ 4 " Battery Pack or
18V DC Power Supply
2"
Back
Cover

INSTALLATION
6
Mount the Installation Brackets — Outside Mount
Mount the Installation Brackets
■Center the headrail over the window opening at the desired height. Use a pencil to lightly
mark each end of the headrail.
➤Alternatively, measure the width of the headrail and use that width to mark the headrail
end points over the window opening.
■Mark 2" in from each of the headrail end marks.
➤If more than two installation brackets are required (see table on page 3), mark the
location of additional bracket(s) spaced evenly between the two end bracket locations.
Mount into wood whenever possible. Allow a minimum of 18" from the motor side
for the battery wand.
Window Opening
2"
Motor
Side
2"
Headrail End Marks
Space Evenly Space Evenly
18" Minimum for Battery Wand

INSTALLATION
7
■Center the installation brackets or extension brackets on your marks and mark where to drill
the screw holes.
➤A minimum 1
1
/ 8 " flat vertical surface isrequired for the installation brackets. Extension
brackets require 1
1
/ 4 ".
➤The tops of the installation brackets or extension brackets should be at the desired
height. The brackets should be level andaligned.
CAUTION: The rear of the brackets must be flush against a flat mounting surface. Do not
mount brackets oncurved molding.
■Drill the screw holes using a
3
/ 32 " drill bit.
CAUTION: Use drywall anchors when mounting into drywall.
■Attach the installation or extension
brackets using the screws provided.
IMPORTANT: The tops of the
installation brackets or extension
brackets must be level with their
front edges aligned.
IMPORTANT: If using a battery wand, use a
minimum of one
1
/ 2 " and one
1
/ 4 " spacer blocks per
installation bracket to provide the clearance required
for the battery wand and battery wand bracket.
1
1
/ 8 "Extension
Bracket
1
1
/ 4 "
1
/ 2 "
1
/
4
"
Spacer Blocks

INSTALLATION
8
■If using spacer blocks, attach the spacer block(s) and
installation bracket to a flat vertical mounting surface
with #6screws long enough for asecure installation.
IMPORTANT: Do not add more than 1
1
/ 2 " of
clearance using spacer blocks.
IMPORTANT: The tops of the installation brackets
must be level with the front edges aligned.
■If using extension brackets, attach an installation bracket
to the underside of each extension bracket using the
speed nuts and screws provided.
Proceed to “STEP 2 — Mount the Battery Wand and Connect the Power Cable, If Applicable”
on page10.
Screws
Speed Nuts
1
1
/
2
"
Maximum
Spacer
Blocks
Longer
Screw

INSTALLATION
9
Mount the Installation Brackets — End Mount
End mount the headrail when conventional mounting techniques will not work — for example, in
an arched window opening.
■If you ordered a back cover, attach the back cover
brackets to the installation brackets.
➤If a satellite battery pack or an 18V DC power
supply is used, first remove the top tab from the
back cover bracket.
➤Snap the back cover bracket into the metal
installation bracket.
■Mount extension brackets to each side of the opening at the desired height of the shading.
➤The mounting surface must be vertical and flat,
not part of an arched curve.
➤Minimum mounting surface width with a built-in
battery wand is 2
1
/ 8 ".
➤Minimum mounting surface width with a satellite
battery pack or DC power supply is 1
1
/ 2 ".
■Attach the installation brackets to the extension
brackets using the provided screws and speednuts.
WARNING: To end mount shadings into a surface other than a secure wall stud, use
medium to heavy-duty wall anchors (not provided) matched to the wall thickness.
Failure to mount the brackets securely may result in injury or property damage.
■If using the optional back cover: Install the cover into the
back cover brackets. If necessary, trim the back cover to the
desired width.
IMPORTANT: If using a battery wand, do not install the
optional back cover until the battery wand is installed
(see Battery Wand on page 10).
Proceed to “STEP 2 — Mount the Battery Wand and Connect the Power Cable, If Applicable”
on page10.
Back
Cover
Remove top tab if using a satellite
batter
y pack or an 18V DC power supply.
Back Cover Bracket
Remove bottom tab if using a
battery wand and no back cover.
Top Tab
Bottom Tab
Back Cover
Slots
Extension
Bracket
1
1
/ 2 "
Minimum
Depth

INSTALLATION
10
STEP 2 — Mount the Battery Wand and Connect the Power
Cable, If Applicable
For an optional satellite battery pack, 18V DC power supply, 18V DC power supply with daisy-
chain connections, C-size satellite battery wand, or large DC power supply, the power source will
be connected after the shading is installed.
Battery Wand
Install the Battery Wand Clips
■Attach the battery wand clips to the headrail.
IMPORTANT: Position the clips close to the power cable.
Mount the Battery Wand into the Battery Wand Clips
■Position the battery wand with its socket toward
the motor end of the shading.
■Push the battery wand straight up into the
battery wand clips until it snaps into place.
Check to make sure the battery wand is secure.
CAUTION: Be sure the cables do not
become pinched by the battery wand clips
during installation. Damage or overheating of
components could result.
Plug the Power Cable into the Battery Wand
NOTE: When power is connected to the motor, a green LED inside the control side end cap will
flash to indicate the shading is ready for operation.
■From the back of the shading headrail, connect
the power cable (from the motor side) into the
socket on the battery wand.
Place the socket
toward the motor end.
Batter
y
Wand
Power
Cable

INSTALLATION
11
STEP 3 — Install the Shading
Install the Optional Back Cover (If Applicable)
The optional back cover is used on inside mounts only.
■Install the back cover into the back cover brackets on the rear of the installation brackets, as
shown. If necessary, trim the back cover to the desired width.
➤On shadings with battery wand(s), the top of the back cover fits onto the top tab of the
back cover bracket.
IMPORTANT: If using a battery wand, do not install the optional back cover until
the battery wand is installed (see Battery Wand on page 10).
➤On all other shadings, the top tab has been removed and installs closer to the
installation bracket.
Mount the Headrail
■Peel back the protective covering from the top of the fabric-covered headrail. Leave the rest
of the protective covering on the front of the headrail.
■Position the shading so that the front faces you.
■Slide the headrail into the installation brackets so the edge of the headrail is between the
lever and the bracket, asshown.
■Firmly push the headrail into each
bracket until it clicks and the lever
snaps to the right side of the bracket.
IMPORTANT: Carefully pull on the
headrail at each bracket to ensure it
is installed securely.
■Completely remove the protective
covering from the fabric-covered headrail.
Headrail
Installation
Bracket
Lever
Slide the Headrail
Between the Lever
and the Bracket
Back
Cover
Back
Cover

INSTALLATION
12
If You Have an Optional Dust Cover (For Outside Mount Shadings)...
The dust cover is used to protect the top of the headrail from exposure on outside mounted
shadings.
■Cut the dust cover to desired width.
■Remove the paper backing on one side of the hook and loop
fastener dots.
■Apply the dots to the installation brackets on each end of theshading.
■Remove the remaining paper backing from the dots.
■Center the dust cover over the top of the shading, above the previously placed dots.
■Press the dust cover down onto the dots.
Remove
Paper
Backing
Overhead View
No Dust Cover
Dots
Dust Cover Installed

INSTALLATION
13
STEP 4: Connect the Power Source, If Applicable
■If you have attached the battery wand in step 2, proceed to “Unpack the Wand and Attach to
Activation Arm” on page15.
NOTE: When power is connected to the motor, a green LED inside the control side end cap will
flash to indicate the shading is ready for operation.
■Refer to the appropriate page based on your order.
➤For an optional satellite battery pack, see below.
➤For an optional 18V DC power supply, see page 14.
➤For an optional 18V DC power supply with daisy-chain connections, see page 15.
➤For an optional C-size satellite battery wand or large DC power supply, see the
instructions that came with the unit.
Satellite Battery Pack
Mount the Satellite Battery Pack
■Decide where you want to mount the satellite battery pack. A satellite battery pack may be
mounted in any orientation.
■Mark the screw holes for the wall mount bracket.
■Drill the screw holes using a
3
/ 32 " drill bit.
■Remove the backing from the double-sided tape. Press the
bracket into place.
■Attach the bracket using the screws provided.
■Position the battery wand so the power cable is easily connected to the socket.
■Snap the battery wand into the wall mount bracket.
■Install the cover with the slot aligned to the socket in the battery wand.
Wall Mount Bracket
Socket
Battery Wand Cover
Slot
Socket

INSTALLATION
14
■Plug the power cable from the shading into
the extension cable.
■Plug the other end of the extension cable
into the socket in the battery wand.
Proceed to “Unpack the Wand and Attach to Activation Arm” on page15.
18V DC Power Supply
Connect the Power Supply
■Plug the power cable from the shading
into the extension cable.
■Plug the other end of the extension cable
into the 18V DC power supply.
■Plug the 18V DC power supply into a
standard outlet.
■Secure the extension cable using wire
retainers (not supplied). If hiding the
cable behind the shading, make sure
it does not impede the operation of
theshading.
■Space the wire retainers approximately
15" apart along the extension cable, as
shown.
WARNING: Keep cords and small
parts out of the reach of children.
They can wrap cords around their
necks and STRANGLE.They can
also put small parts in their
mouths and CHOKE.
WARNING: Electric shock and/or a fire hazard may occur, if not properly installed.
Proceed to “Unpack the Wand and Attach to Activation Arm” on page15.
Battery Wand Cover
Extension
Cable
Power Cable
from Shading
Power Cable
from Shading
Extension
Cable
18V DC
Power
Supply
15"
Maximum
Wire Retainers

INSTALLATION
15
18V DC Power Supply with Daisy-Chain Connections
The daisy-chain feature allows up to three PowerView®shadings to be powered by a single 18V
DC power supply. However, each shading can operate independently. The daisy-chain feature is
only available with the 18V DC power supply option.
■Route the power cables from each shading to the connector, using an extension cable,
if necessary.
■Plug an extension cable into the connector and plug the cable into the 18V DC power supply.
Two extension cables and two connectors are used for three shadings.
■Plug the 18V DC power supply into a standard outlet.
Unpack the Wand and Attach to Activation Arm
■Attach the top of the wand (magnet side) to the
activation arm.
Proceed to “Attach Magnetic Hold-Down Brackets
(Optional)” on page16 or “Basic Operation” on
page17.
Power Cable from Shading
Power Cable from Shading
Extension
Cable
Connector 18V DC Power Supply
Magnet
Activation
Arm

INSTALLATION
16
Attach Magnetic Hold-Down Brackets (Optional)
■Lower the shading, keeping the vanes closed.
■Place the magnetic hold-down brackets onto the bottom rail just inside
the end caps, oriented as shown.
■Hold the brackets while opening and closing the vanes. (It may be
necessary to have someone assist you.) Adjust the brackets to the best
overall position.
■Mark the screw locations using one of the mounting options shown
below.
➤The screw should be placed in the middle of the channel. This will
allow for adjustment.
■Drill the screw holes using a
3
/ 32 " drill bit.
■Attach the hold-down brackets to the mounting surface
using the screws provided.
■If necessary, adjust the bracket height by loosening the
screw and sliding the bracket up or down.
Hold-Down
Bracket
Bottom
Rail
Outside Mount
Preferred Alternate
Inside Mount
Preferred Alternate
Adjust the
bracket
up or down
using the
channel.

OPERATION
17
Basic Operation
To Open the Shading
■Push the wand up and release to move the shading in
the up/open direction.
■The shading will move to the fully open position.
To Close the Shading
■Pull the wand down and release to move the shading in
the down/closed direction.
■The shading will move to the fully closed position.
To Stop the Shading
■While the shading is in motion, pull down (or push
up) the wand and release to stop shading or vane
movement anywhere along its travel.
To Operate the Vanes
NOTE: The shading must be fully lowered.
■To move the vanes to the fully open position, pull the wand down and release.
■To move the vanes to the fully closed position, push the wand up and release.
Set and Go to a Favorite Position
NOTE: The default favorite position is the vanes closed and the shading at 50% open.
Set a Favorite
■Put the shading in motion. With the shading still in motion, as it reaches the desired Favorite
position, push the wand up (or pull the wand down) and hold for approximately 4 seconds.
■The shading will beep and the shading moves slightly twice (down, up) to indicate a new
Favorite position is set.
Go to Favorite
■With the shading stationary, or moving — in a single motion, quickly push the wand up and
pull the wand down and release. The shading will move to the Favorite position.
NOTE: Quickly pulling the wand down and pushing the wand up will also work.

OPERATION
18
Troubleshooting
If your shading is not operating correctly:
■Refer to the following troubleshooting procedures for specific solutions for your shading.
For questions, please contact Hunter Douglas Consumer Support at 1-888-501-8364.
Problem The shading will not fit into the installation brackets.
Solution
If the shading has a battery wand, check that the wand is not interfering with the
installation brackets.
Check that the installation brackets are level and aligned. Adjust and/or shim (not
provided) to level, if necessary.
Be sure the heads of the mounting screws are flush against the installation
brackets.
Check that the headrail is completely inserted into the installation brackets so
that the locking lever on the installation bracket slides over the headrail. See
“STEP 3 — Install the Shading” on page11.
Problem Batteries in the battery wand need to be replaced.
Solution Replace the batteries in the battery wand.
Squeeze the cap latch to release
the cap and remove the cap
from the battery wand.
Install the batteries according to
the instructions on the battery
wand label.
Press the cap on until it latches.
NOTE: Hunter Douglas recommends AA alkaline batteries for use with our battery-
powered shadings. These will provide more than one year of operation, depending
on usage. Lithium and rechargeable batteries are not recommended.
Cap
Latch
Battery
Wand
Squeeze
