Hyco Accona AN2000T User manual

Accona
Panel Heater
Models
AN1500, AN1500T, AN2000 & AN2000T
Instruction Manual
Version 1.0 October 2012

HYCO ACCONA PANEL HEATER
MODELS AN1500, AN1500T, AN2000 & AN2000T
1
CONTENTS
1. Introduction
2. Safety
3. Wall Mounting
4. Electrical installation
5. Operating guide (non-timer models AN1500 and AN2000)
6. Operating guide (7-day timer models AN1500T and AN2000T)
6.1 How to set the date and time on your heater
6.2 Setting the target temperatures
6.3 Selecting a Pre-loaded schedule
6.4 Programming your own customised schedule
7. Advanced features (7-day timer models AN1500T and AN2000T)
7.1 Copy and paste programming
7.2 Activating the child lock
7.3 Centigrade/Fahrenheit display
7.4 Delayed start and delayed shut down mode
8. Cleaning and maintenance
9. Specifications
10. Guarantee and service policy

2
1. INTRODUCTION
Thank you for purchasing a Hyco Accona panel heater.The Accona panel heater
range is available in two power outputs and with 7 day LCD timer and non-timer
options.
The available models are as follows:
AN1500 (1.5kW non-timer)
AN1500T (1.5kW with 7 day LCD timer)
AN2000 (2.0kW non-timer)
AN2000T (2.0kW with 7 day LCD timer)
2. IMPORTANT SAFETY POINTS
ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A
QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE
LATEST EDITION OF THE IEE WIRING REGULATIONS.
ALWAYS SWITCH OFF THE MAINS BEFORE COMMENCING
INSTALLATION.
ONLY CONNECT THE HEATER TO A SINGLE PHASE SUPPLY
WITH A MAINS VOLTAGE AS SPECIFIED ON THE RATING LABEL.
THE SUPPLY CORD CANNOT BE REPLACED BY THE USER.
IF THE CORD IS DAMAGED THE APPLIANCE SHOULD BE
RETURNED TO THE MANUFACTURER OR AN AUTHORISED
SERVICE AGENT FOR REPLACEMENT.
THE HEATER MUST NOT BE LOCATED IMMEDIATELY BELOW
OR ABOVE AN ELECTRICAL SOCKET-OUTLET.
DO NOT CARRY THE APPLIANCE BY THE POWER CORD.
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM
8 YEARS AND ABOVE AND PERSONS WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK
OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE IN A SAFE WAY AND UNDERSTAND
THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY WITH
THE APPLIANCE.

2. IMPORTANT SAFETY POINTS (Continued)
CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY
UNLESS CONTINUOUSLY SUPERVISED.
CHILDREN AGED FROM 3 YEARS AND LESS THAN 8 YEARS
SHALL ONLY SWITCH ON/OFF THE APPLIANCE PROVIDED
THAT IT HAS BEEN PLACED OR INSTALLED IN ITS INTENDED
NORMAL OPERATING POSITION AND THEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE IN A SAFE WAY AND UNDERSTAND
THE HAZARDS INVOLVED.
CHILDREN AGED FROM 3 YEARS AND LESS THAN 8 YEARS
SHALL NOT PLUG IN, REGULATE AND CLEAN THE APPLIANCE
OR PERFORM USER MAINTENANCE.
CLEANING AND MAINTENANCE SHALL NOT BE
UNDERTAKEN BY CHILDREN.
DO NOT LET THE POWER CORD HANG OVER THE
APPLIANCE.
CAUTION – SOME PARTS OF THIS PRODUCT CAN BECOME
VERY HOT AND CAUSE BURNS. PARTICULAR ATTENTION HAS
TO BE GIVEN WHERE CHILDREN AND VULNERABLE PEOPLE
ARE PRESENT.
ONLY USE THE MOUNTING BRACKET SUPPLIED AND DO
NOT MODIFY THE BRACKET.
DO NOT COVER THE UNIT AS OVERHEATING WILL RESULT.
FIXED HEATERS LIKELY TO USED IN BATHROOMS ARE TO BE
INSTALLED SO THAT SWITCHES AND OTHER CONTROLS
CANNOT BE TOUCHED BY A PERSON IN THE BATH OR
SHOWER.
3

3.WALL MOUNTING
Step 1:
Choose a suitable location for the mounting of the heater ensuring that the
surface will be strong enough to hold the weight of the product.The heater must
not be mounted closer than 150mm to any horizontal or vertical surface, as
detailed in figure 1.
Step 2:
Hold the bracket up against the mounting surface, ensuring it is horizontal, and
mark the outer holes through the bracket onto the surface of the mounting wall.
Drill and fit wall plugs and then fix the bracket to the mounting surface.
Step 3:
Offer up the heater to the bracket and attach as per figure 2. Fasten the clips and
verify heater is securely fixed to wall.
4
6 inches
150 mm
6 inches
150 mm
6 inches
150 mm
figure 1
figure 2
6 inches
150 mm
1
a
2
b

4. ELECTRICAL INSTALLATION
• The installation, electrical connection and first operation of this appliance
should be carried out by a qualified electrician.
• If the heater is to be connected to the fixed wiring of the property then
installation must include a double pole isolating switch with a break contact
distance of at least 3mm.
• Make the connections as:
Green/Yellow earth wire to terminal marked or “E”
Brown live wire to the terminal marked “L”
Blue neutral wire to the terminal marked “N”
5. OPERATING GUIDE (non-timer models AN1500 and AN2000)
• Turn the power switch to the on (—) position
• Turn the thermostat dial clockwise until the power light illuminates.
This indicates the element is now on.
• Adjust the thermostat to the desired temperature.
5
4 5 63
1
2
1. Control Unit 4. Temperature Control Knob
2. Air Outlet 5. Power Indicator
3. Air Inlet 6. Switch (ON: — & OFF: O)

6
6. OPERATING GUIDE (7-day timer models AN1500T and AN2000T)
6.1 HOW TO SET THE DATE AND TIME ON YOUR HEATER
The below example illustrates how to set the clock to Thursday 3.03PM.
Step 1:
Press the clock icon once, this will cause
the day of the week to start flashing.
Step 2:
Use the up/down icons to cycle through
the days. In this example the up button
has been pressed three times selecting
Thursday.
Step 3:
Press the clock icon again and this will
store the day as well as highlight the next
field which is the hour of the day.
17
1. Control Unit 10. Standby Button
2. Air Outlet 11. Date and Time Setting Button
3. Air Inlet 12. Copy and Paste Button
4. Red "Peak" Temperature Indicator 13. Down Select Button
5. Yellow Element "On" Indicator 14. Up Select Button
6. Green "Off Peak" Temperature Indicator 15. Timer On/Off Button
7. Temperature Setting Button 16. On/Off Indicator
8. Program Select Button 17. LCD Display
9. User Program Setting Button
32
1
6
16
4 8 15 147 10
11 12 9 13
5

6.1 HOW TO SET THE DATE AND TIME ON YOUR HEATER (continued)
Step 4:
Use the up/down icons to cycle through
the hours, in this example we will press the
up button three times in order to display
15:00.
Step 5:
Press the clock icon to save the hour
setting and move on to the minutes setting.
Step 6:
Use the up/down icon to cycle through
the minutes, in this example we will press
the up button three times in order to
select 15:03.
Step 7:
Press the clock icon to finalise the
time.
7

6.2 SETTING THE TARGET TEMPERATURES
The thermostat settings can only be set whilst the unit is turned on (not standby).
Unlike many panel heaters the Accona Timer range utilises two temperature
ranges.The first is the temperature the heater will maintain during the ‘Peak’
setting, and the second is the ‘Off peak’ setting.
Peak :When you are want a ‘comfortable’ temperature whilst occupying the
room in which the heaters is located.This can be as high as 30°C.
Off Peak :The Off Peak (typically night) temperature setting ensures the room
will not fall below a user chosen temperature .This can be as low as 5°C (frost
protection) and must be a few degrees cooler that the Peak temperature setting.
Step 1:
Press the °C icon to enter the ‘Peak’
temperature setting mode, when selected
correctly it will be indicated by the flashing
symbol.
Step 2:
To alter the target temperature, press
the up/down icon the desired number of
times. In this example the up icon has been
pressed three times to increase the set
point from 22°C to 25°C.
Step 3:
Press the °C icon to store the ‘Peak’
temperature and also move onto the ‘Off
peak’ setting.‘Off peak’ is indicated by the
symbol which will flash when selected.
Step 4:
As with step 2 it is possible to alter the
target temperature for the ‘Off peak’ mode
by simply pressing the up/down symbol the
desired number of times. In this example
the down icon has been pressed three
times to change the target temperature
from 17°C to 14°C.
Step 5:
To store the ‘Off peak’ setting simply press
the °C icon once.The display will now
return to the current room temperature
display.
8

9
6.3 SELECTING A PRE-LOADED SCHEDULE
The heater is supplied with number of pre-loaded operating schedules already
stored in memory. It will be quicker to choose one of these defaults if it
corresponds sufficiently closely to your requirements, but you can create your
own schedule if you wish (see ‘programming your own customised schedule’).
The pre-loaded schedules are identified by a two letter code (eg “P3” or “CF”)
and are as follows:
Table of Pre-loaded Operating Schedules
NOTE:
1. The numbers 0,8,16 and 24 represent time on a 24-hour clock and equate to midnight,
8:00am, 4:00pm and midnight respectively.
2. The symbol means the heater operates in OFF PEAK MODE during the given time.
3. The symbol means the heater operates in PEAK MODE during the given time.
4. CF means FROST PROTECTION MODE; the unit will heat only to avoid frost and protect
itself when the room temperature is very low. The temperature cannot be
adjusted in this program.
5. CE means OFF PEAK MODE all the time.
6. CC means PEAK MODE all the time. This is the factory default setting.
7. UP means USER PROGRAM; the user can set the program according to his/her specific
needs. The UP program factory default is PEAK MODE all day, every day.
WEEKDAY SATURDAY SUNDAY
P1
UP
P2
P3
P4
P5
P6
P7
P8
P9
CF
CE
CC

10
6.3 SELECTING A PRE-LOADED SCHEDULE (continued)
The pre-loaded schedules that are available are defined in the previous table.
If you wish to have the unit operate in non-timer style you should select
pre-set ‘CC ’to swith the heater on/off press the button.
Study the available pre-sets to decide which setting is best suited to the
requirements.
Step 1:
Press the Picon to enter the schedule
selection mode.This will cause the current
selected pre-set to flash. Upon first
operation the default pre-set is ‘CC’.
Step 2:
Press the up/down icon until the desired
schedule is displayed.We have selected P2
as our schedule.
Step 3:
Once the desired schedule is selected,
press the Picon to store and run this
setting.The display will now show the
selected schedule.
6.4 PROGRAMMINGYOUR OWN CUSTOMISED SCHEDULE
Along with a number of pre-sets schedules (see table in previous section) there
is also one schedule that can be used to create your own custom timer settings.
This schedule is represented by the initials ‘UP’ (user programmed).
Step 1:
First select the ‘UP’ mode from the pre-set
program (see ‘selecting a pre-set’ section
6.3).
Enter the ‘UP’ editing mode by selecting the
icon.The screen will display the current
day of the week flashing. In the example the
day in question is Monday (Mon).

11
6.4 PROGRAMMINGYOUR OWN CUSTOMISED SCHEDULE (cont.)
Step 2:
Next select the day to programme. Simply
press the timer icon until the required
day is displayed. In this example we have
selected Wednesday (Wed) which required
two presses of the timer icon.
Step 3:
Now the day is selected a value for every segment of a full day must be assigned
(there are 24 in total).The program will only be saved when this is complete. Use
the up/down icon to allocate the mode for each segment. Up = ‘peak’ setting and
down = ‘off peak’. In the below example the down button has been pressed eight
times followed by the up button eight times and finally the down button eight
times.This will mean the heater operates in ‘off peak’ temp from 00.00 to 08.00
and then ‘peak’ setting from 08.00 until 16.00 and then finally ‘offpeak’ from16.00
until 00.00.
To confirm and save this setting, press the icon. Next repeat the whole process
for each of the remaining six days of the week.
7.ADVANCED FEATURES (7-day timer models AN1500T and AN2000T)
7.1 COPY AND PASTE PROGRAMMING
To make creating a ‘UP’ (custom schedule) slightly easier, you may wish to copy
and paste a full day’s program onto another day. For instance, you have set
Monday’s program and you wish to replicate this for the remaining week days.This
can be achieved by copying and pasting Monday’s settings on to the remaining days,
this will negate the need to program each segment for each day separately. Follow
the below process to achieve this.
Step 1:
To enter the ‘UP’ program from the default
pre-sets (see timer functions section.
Enter the ‘UP’ editing mode by pressing
the icon.This will bring up the screen as
shown.

12
7.1 COPY AND PASTE PROGRAMMING (continued)
Step 2:
To copy the Monday (Mon) programme,
press the icon.This will copy the
programme and the screen will confirm this
with the word ‘Copy’ displayed alongside
the word ‘Prog’.
Note: to copy from a different day, select the required day using the clock icon
before pressing the icon.
Step 3:
Press the timer icon the desired number of
times to cycle to the day to programme to.
In this example we have pressed the timer
icon twice in order to display Wednesday
(Wed).
Step 4:
Press the icon to complete the paste of
the custom setting onto the desired day.
In order to paste to more days you will
need to exit the current screen using
icon, and then returning to Step 1 of
this section to repeat for other days.
7.2 ACTIVATING THE CHILD-LOCK
The timer unit can be locked on your heater in order to prevent settings being
altered.
Step 1:
Press the Picon once.
Step 2:
Push and hold the timer and programme icons for
2-3 seconds.
Step 3:
When the timer is successfully locked a ‘key’ icon will be
displayed to confirm this.
Step 4:
To unlock the timer simply repeat the steps for locking.

13
7.3 CENTIGRADE / FAHRENHEIT DISPLAY
It is possible to switch the temperature setting between Fahrenheit (F) and
Celsius (C). Simply hold down the temp icon (°C) for approximately 3 seconds.
Both modes are illustrated below.
7.4 DELAYED START AND DELAYED SHUT DOWN MODE
It is possible to turn the unit on automatically a number of hours in the future. For
example, to automatically start in 10hrs time this can be achieved as follows:
Step 1:
The heater must first be in standby mode.
Press the alarm clock icon and a symbol of
a clock will be displayed.
Step 2:
Use the up/down icon to enter the number
of hours to wait before the heater starts.
In this example we have chosen ten hours
which is achieved by pressing the up button
ten times.
Step 3:
Press the alarm icon again to exit timer mode and save the
selection.The heater will now start up automatically in ten hours
time.
It is possible to programme the heater to switch off in specified number of hours
in the future.
Step 1:
The heater must be On (not in standby)
to utilise this feature. Press the alarm
clock icon and a symbol of a clock will be
displayed.

14
7.4 DELAYED START AND DELAYED SHUT DOWN MODE (continued)
Step 2:
Use the up/down icon to enter the amount
of hours to wait before the heater goes
into ‘sleep’ mode. In this example we have
gone for ten hours which is achieved by
pressing the up button ten times.
Step 3:
Press the alarm icon again to exit timer mode and save the
selection.The heater will now automatically go into ‘sleep’ mode in
ten hours time.
8. CLEANING AND MAINTENANCE
• Replacing the battery is will required from time to time, the LCD will display
the remaining charge of the battery.
• Before cleaning, ensure the heater is disconnected from the mains supply and
has completely cooled.
• Wipe the exterior surfaces with soft dry cloth.
• Never use chemicals or abrasive cleaners.
9. SPECIFICATIONS
Model AN1500 AN1500T AN2000 AN2000T
Supply 230V
~50Hz
230V
~50Hz
230V
~50Hz
230V
~50Hz
IP Rating X0 X0 X0 X0
Dimensions
H x W x D
700 x 440 x
98 mm
700 x 400 x
98 mm
855 x 440 x
98 mm
855 x 440 x
98 mm
Power
(Watts) 1500W 1500W 2000W 2000W

INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT
IN ACCORDANCE WITH THE EUROPEAN DIRECTIVE 2002/96/E
At the end of its working life this equipment must not be disposed
of as household waste. It must be taken to a local authority waste
collection centre or to a dealer providing this service. Disposing
of electrical and electronic equipment separately enables its
components to be recovered and recycled to obtain significant
savings in energy and resources. In order to underline the duty to
dispose of this equipment separately, the product is marked with a
crossed out dustbin.
10. GUARANTEE AND SERVICE POLICY
This product is guaranteed against faulty materials and manufacture for a period
of one year from the date of purchase. Hyco will in its sole discretion replace,
repair or refund any faulty unit. Incorrect installation and frost damage are
excluded. Consequential costs such as labour charges or damage to fittings and
surroundings are expressly excluded.
