Thank you for purchasing the Scirocco convector heater. The SC2000Y and
SC2000Y standard convectors come with a thermostat and three heat
settings; the SC2000YST also includes a timer. The Scirocco convector heater
is ideal for a wide range of fixed installation or portable heating applications
in the home and office environment. Please read and understand these
instructions before commencing installation, and leave them with the user
when installation is complete.
1. Important afety point
• The Electrical installation must be carried out by a qualified electrician in accordance
with the current edition of the I.E.E. Wiring Regulations.
• This appliance must be earthed.
• Only connect the unit to a single phase supply with a mains voltage as specified
on the rating plate.
• Do not carry the appliance by the supply cord.
• The supply cord cannot be replaced by the user. If the cord is damaged the
appliance should be returned to the manufacturer or an authorised service agent
for replacement.
• The appliance must not be located immediately below an electrical socket outlet.
• Always keep the outlet and inlet grills clean.
• Do not cover the outlet as it may cause overheating.
• Children of less than 3 years should be kept away unless continuously supervised.
• Children aged from 3 years and less than 8 years shall only switch on/off the
appliance provided that it has been placed or installed in its intended normal
operating position and they have been given supervision or instruction concerning
use of the appliance in safe way and understand the hazards involved. Children aged
from 3 years and less than 8 years shall not plug in, regulate and clean the appliance
or perform user maintenance.
• This unit should be installed at least 1.5m from baths, showers, laundries, swimming
pools etc.
Scirocco_Layout 1 03/06/2015 11:57 Page 2

3
• When the unit is first switched on or after a long period unused, a burning smell
may occur due to dust gathered on the heating element.
2. In tallation
Wall Mounting
Ensure that the surface selected for mounting the appliance is suitable for
the weight of the product.
This unit should be installed at least 1.5m from baths, showers, laundries,
swimming pools etc.
If the heater is to be wall mounted, the feet should not be attached. Use the fixings
and brackets provided. Choose the position to mount the heater carefully. See the
installation guide for minimum mounting distances.
Once the location of the heater is determined, frill 2 holes 8mm diameter x 43mm deep
at 403mm centres at a minimum distance of 400mm from the floor (allowance must be
made for any floor coverings, carpet etc. and if any skirting boards are present). The
fixing holes must be a minimum of 400mm above the top edge of the skirting board.
Attach 2 of the brackets (1 left handed and 1 right handed) to the wall using supplied
wall plugs and fixing screws. The remaining 2 brackets are fitted to the base of the unit
instead of the feet using the feet retaining screws so that the brackets project out at the
rear of the heater and space the bottom edge of the unit away from the wall. Hang the
heater on the wall mounted brackets. Remove heater. Drill holes 8mm diameter x 43mm
deep and insert wall plugs supplied.
Hang the heater on brackets, then secure bottom brackets using fixing screws supplied.
Right-handed
Bracket
Left-handed
Bracket
Back Panel
Mounting Hole
Insert Bracket
Bracket Inserted
1
2
3
1
2
3
4
5
1
24
23
22
21
20
19
18
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
19
D inc. feetW
H
H (inc. feet)
Scirocco_Layout 1 03/06/2015 11:57 Page 3

These images are to illustrate how the mounting holes and brackets are fitted
together – these views will not be visible in the actual mounting process.
The supplied fixings are for a solid wall only: brick, masonry etc.
Alternate fixings may be required for cavity and soft walling: drywall, plaster etc.
Floor standing
If the heater is to be used in a free
standing position, attach the provided
feet. Place the feet inside the grooves
of the metallic cover. Then attached
both by means of the screws supplied
with the unit. Tighten the screws to hold
the feet securely but do not overtighten.
Electrical
• This appliance must be earthed.
• The unit comes pre-wired with a 13A plug. If connection is required to the fixed
wiring of the property it should be connected following the colour coding below:
➢Brown: L
➢Blue: N
➢Green / Yellow: E
4
Right-handed
Bracket
Left-handed
Bracket
Back Panel
Mounting Hole
Insert Bracket
Bracket Inserted
1
2
3
1
2
3
4
5
1
24
23
22
21
20
19
18
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
19
D inc. feetW
H
H (inc. feet)
Right-handed
Bracket
Left-handed
Bracket
Back Panel
Mounting Hole
Insert Bracket
Bracket Inserted
1
2
3
1
2
3
4
5
1
24
23
22
21
20
19
18
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
19
D inc. feetW
H
H (inc. feet)
Scirocco_Layout 1 03/06/2015 11:57 Page 4

3. Operation
• ake sure the power switches are in the OFF position.
Plug the power cord into the closest outlet
(DO NOT use an extension cord).
• Turn the thermostat switch to maximum.
• Select the desired power setting by pressing
switches 1 (750W) or 2 (1250W) or 1 and 2 (2000W).
• When the desired temperature has been reached,
turn the thermostat (3) until it clicks. The unit will
then switch on and off by itself and maintain the
selected temperature.
SC2000YST Model – Using the timer feature
1. Set the timer by moving the disc so that the pointer on the timer is
the same as the time. For example at 1000 hours (10 o’clock) set the
disc to the number 10.
2. Position the slide switch to the central position.
3. Set the periods of time that you want the heater to work each day
by pulling the outer teeth forward. Each tooth represents 15 minutes.
4. To reset the programming, move the teeth back to the original position
before repeating step 3.
5. If the heater is required to run continuously, set the slide switch on
the timer to the position indicated by .
6. If you do not wish to use the heater function but want the timer to
continue to run, move slider switch to the position indicated by .
Slide back to the central position when you require timed operation.
5
Right-handed
Bracket
Left-handed
Bracket
Back Panel
Mounting Hole
Insert Bracket
Bracket Inserted
1
2
3
1
2
3
4
5
1
24
23
22
21
20
19
18
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
19
D inc. feetW
H
H (inc. feet)
Right-handed
Bracket
Left-handed
Bracket
Back Panel
Mounting Hole
Insert Bracket
Bracket Inserted
1
2
3
1
2
3
4
5
1
24
23
22
21
20
19
18
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
19
D inc. feetW
H
H (inc. feet)
Slide Switch
Segment
Pointer
Scirocco_Layout 1 03/06/2015 11:57 Page 5

4. Maintenance
Always isolate the appliance from the power supply before commencing
any maintenance.
Never use abrasive chemicals or materials to clean the unit.
• Clean the exterior of the unit using a soft, damp cloth.
5. Specification
Voltage 230v~50Hz
Power 2000W
Weight 3.0kg
Height (mm)* Width(mm) Depth(mm)
SC2000Y 370 580 110
SC2000YM 335 530 110
SC2000YST 370 580 110
*Dimensions excluding feet. Including feet add 55mm to height and 40mm to depth.
6
Right-handed
Bracket
Left-handed
Bracket
Back Panel
Mounting Hole
Insert Bracket
Bracket Inserted
1
2
3
1
2
3
4
5
1
24
23
22
21
20
19
18
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
19
D inc. feetW
H
H (inc. feet)
Scirocco_Layout 1 03/06/2015 11:57 Page 6
