iDataLink BLADE-AL-HK4-EN User manual

NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
reviewtheInstallation Guide carefullybefore beginning any work.
!
The brand names and logos found in this guide are property of their respective owners. Automotive Data Solutions Inc. © 2017
U.S. PATENT NO. 8,856,780
Automotive Data Solutions Inc.
INSTALL GUIDE
BLADE-AL(DL)-HK4-EN
AVAILABLE FOR: ADS-BLADE AL
HK4
PLEASE VISIT WWW.IDATALINK.COM FOR COMPLETE PRODUCT DETAILS
Rev. Date: May 26, 2017
Doc. No.: ##39751##
20170526

U.S. Patent No. 8,856,780
INSTALL TYPE SELECTION
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS SECURE TAKEOVER PRIORITY UNLOCK DOOR LOCK DOOR UNLOCK ARM OEM ALARM DISARM OEM ALARM TRUNK/HATCH RELEASE POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) DOOR STATUS OUTPUT TRUNK STATUS OUTPUT RAP SHUTDOWN CTRL E-BRAKE OUTPUT A/M ALARM CTRL FROM OEM REMOTES HOOD STATUS*
HYUNDAI
Azera STD key AT 06-11 01 • • • • • • • • • • • • •
Elantra Coupe STD key AT 13-14 08 • • • • • • • • • • • • •
Elantra Sedan STD key AT 11-13 08 • • • • • • • • • • • • •
Elantra Sedan STD key AT 14-16 14 • • • • • • • • • • • • •
Entourage STD key AT 07-10 02 • • • • • • • • • • • • • •
Genesis Coupe STD key AT 13-16 12 • • • • • • • • • • • • •
Sonata STD key AT 11-14 07 • • • • • • • • • • • • •
Tucson STD key AT 10-15 09 • • • • • • • • • • • •
Veracruz STD key AT 07-12 03 • • • • • • • • • •
KIA
Amanti STD key AT 07-09 04 • • • • • • • • • • •
Borrego STD key AT 08-11 05 • • • • • • • • • •
Optima STD key AT 11-13 11 • • • • • • • • • • • • •
Optima STD key AT 14-15 15 • • • • • • • • • • • • •
Sedona STD key AT 06-12 02 • • • • • • • • • • • • •
Sedona STD key AT 14 02 • • • • • • • • • • • • •
Sorento 4 cyl STD key AT 11-13 06 • • • • • • • • •
Sorento 6 cyl STD key AT 11-13 06 • • • • • • • • •
Sorento STD key AT 14-15 13 • • • • • • • • • • • •
Sportage STD key AT 11-16 10 • • • • • • • • • • •
*Available only if vehicle is equipped with factory hood switch.
Page 2 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
HYUNDAI
Azera
STD key
AT
06-11
CanH MF31 ~ 18 pin 02 Blue/Black (DATA) Driver kick panel ~
CanL MF31 ~ 18 pin 11 Green/Black (DATA) Driver kick panel ~
Data* EM01 Blue 39 pin 09 White (DATA) Top left connector, passenger kick panel ~
Ignition ~ ~ ~ ~ ~ (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 3 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 1 - WIRING DIAGRAM
445566778899 112233
101014141515161617171818 111112121313
10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25 26
27 28 29 30 31 32 33 34 35 36 37 38 39
1234567 8 9
9
11
2
CANH
CANL
BROWN/RED - CANHBROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
BLACK (NC)
BLACK (NC)
PINK (NC)
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
DATA
VEHICLE IGNITION (+)
WHITE/BLACK - ECM CONNECTOR SIDEWHITE/BLACK - ECM CONNECTOR SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
PASSENGER KICK PANEL
DRIVER KICK PANEL
EM01 - BLUE
MF31
ORANGE/BLACK (NC)
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 4 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
HYUNDAI
Entourage
STD key
AT
07-10
CanH BCM-IM Gray 72 pin 16 Black (DATA) BCM driver side dash ~
CanL BCM-IM Gray 72 pin 15 Yellow (DATA) BCM driver side dash ~
Data* EM22 White 32 pin 08 Red (DATA) Left side, base of center console, inside harness ~
Ignition ~ ~ ~ ~ ~ (+) Ignition switch ~
KIA
Sedona
STD key
AT
06-12
CanH BCM-IM Gray 72 pin 16 Black (DATA) BCM driver side dash ~
CanL BCM-IM Gray 72 pin 15 Yellow (DATA) BCM driver side dash ~
Data* EM22 White 32 pin 08 Red or Green (DATA) Left side, base of center console, inside harness ~
Ignition ~ ~ ~ ~ ~ (+) Ignition switch ~
Sedona
STD key
AT
14
CanH BCM-IM Gray 72 pin 16 Black (DATA) BCM driver side dash ~
CanL BCM-IM Gray 72 pin 15 Yellow (DATA) BCM driver side dash ~
Data* EM22 White 32 pin 08 Red or Green (DATA) Left side, base of center console, inside harness ~
Ignition ~ ~ ~ ~ ~ (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 5 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 2 - WIRING DIAGRAM
12 13 21 22
23 24 31 32
10 111 2
14 15 16 17 18 19 20
25 26 27 28 29 30
3456789
8
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
16
15
PINK (NC)
REMOTE STARTER
EM22 - WHITE
CENTER CONSOLE HARNESS
BROWN/RED - CANHBROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
BLACK (NC)
BLACK (NC)
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
GREEN/RED - ECM CONNECTOR SIDE
GREEN/RED - ECM CONNECTOR SIDE
GRAY/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - IMMOBILIZER VEHICLE SIDE
DATA
WHITE/BLACK - ECM CONNECTOR SIDEWHITE/BLACK - ECM CONNECTOR SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
VEHICLE IGNITION (+)
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
CANH
CANL
BCM
DRIVER SIDE DASH
BCM-IM - GRAY
Page 6 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 3 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
HYUNDAI
Veracruz
STD key
AT
07-12
CanH MF61 Yellow 18 pin 03 Orange or Red/Black (DATA) Driver kick panel ~
CanL MF61 Yellow 18 pin 01 Blue (DATA) Driver kick panel ~
Data* MC11 Yellow 20 pin 13 Gray (DATA) Passenger kick panel ~
Ignition ~ ~ ~ ~ ~ (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 7 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 3 - WIRING DIAGRAM
44 55 66 77 88 9911 22 33
1010 1414 1515 1616 1717 18181111 1212 1313
1 3
10
11 12 13 14 15 16 17 18 19 20
123456789
13
BLACK (NC)BLACK (NC)
PINK (NC)
REMOTE STARTER
CANH
CANL
BROWN/RED - CANHBROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
DATA
WHITE/BLACK - ECM CONNECTOR SIDEWHITE/BLACK - ECM CONNECTOR SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
MF61 - YELLOW
PASSENGER
KICK PANEL
MC11 - YELLOW
VEHICLE IGNITION (+)
DRIVER KICK PANEL
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 8 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 4 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
KIA
Amanti
STD key
AT
07-09
CanH MFR52 ~ 20 pin 01 Brown (DATA) Passenger kick panel ~
CanL MFR52 ~ 20 pin 02 White (DATA) Passenger kick panel ~
Data* MC12 ~ 39 pin 32 Red/Black (DATA) Center console ~
Ignition ~ ~ ~ ~ ~ (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 9 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 4 - WIRING DIAGRAM
3 4 5 61 2
17 18 19 20
7 8
15 16
11 12 13 14
9
10
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25 26
27 28 29 30 31 32 33 34 35 36 37 38 39
32
21
CENTER CONSOLE
MC12
MFR52
CANH
CANL
DATA
BLACK (NC)BLACK (NC)
PINK (NC)
REMOTE STARTER
BROWN/RED - CANHBROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
VEHICLE IGNITION (+)
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
PASSENGER KICK PANEL
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 10 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 5 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
KIA
Borrego
STD key
AT
08-11
CanH MF31 White 39 pin 27 Blue (DATA) Driver kick panel ~
CanL MF31 White 39 pin 28 Red (DATA) Driver kick panel ~
Data* EM31 White 10 pin 04 Black/Orange (DATA) Center console, above gas pedal ~
Ignition ~ ~ ~ ~ ~ (+) ~ ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 11 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 5 - WIRING DIAGRAM
10
1 2 3 4
56789
4
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25 26
27 28 29 30 31 32 33 34 35 36 37 38 39
2827
DATA
CENTER CONSOLE DRIVER SIDE
MF31 - WHITE
EM31 - WHITE
DRIVER KICK PANEL
CANH
CANL
VEHICLE IGNITION (+)
BLACK (NC)BLACK (NC)
PINK (NC)
REMOTE STARTER
BROWN/RED - CANHBROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 12 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
KIA
Sorento
4 cyl
STD key
AT
11-13
Immobilizer Data* MC21 Green 18 pin 18 Blue or Blue/Orange (+) Junction connector in passenger kick panel ~
CanH BCM-MM White 16 pin 05 Blue (DATA) IPM back side, driver side dash ~
CanL BCM-MM White 16 pin 06 Red (DATA) IPM back side, driver side dash ~
Brake CHG39 White 04 pin 01 Yellow (+) Brake switch above brake pedal ~
Ignition M15 Black 06 pin 04 Orange (+) Ignition switch ~
Parking Light BCM-ML White 26 pin 21 LtBlue (-) IPM back side, driver side dash ~
Hood Pin I/P-F Red 20 pin 16 Red/Black (-) IPM front side, driver side dash ~
Sorento
6 cyl
STD key
AT
11-13
Immobilizer Data* MC21 Green 18 pin 18 Red (+) Junction connector in passenger kick panel ~
CanH BCM-MM White 16 pin 05 Blue (DATA) IPM back side, driver side dash ~
CanL BCM-MM White 16 pin 06 Red (DATA) IPM back side, driver side dash ~
Brake CLG39 White 04 pin 01 Green/Black (+) Brake switch above brake pedal ~
Ignition M15 Black 06 pin 04 Orange (+) Ignition switch ~
Parking Light BCM-ML White 26 pin 21 LtBlue (-) IPM back side, driver side dash ~
Hood Pin I/P-F Red 20 pin 16 Red/Black (-) IPM front side, driver side dash ~
TYPE 6 - WIRE CROSS REFERENCE CHART
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 13 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 6 - WIRING DIAGRAM
123
4567891011
1213
141516
1718192021222324
2526
12345678
910111213141516
6 5
21
12345678910
11 12 13 14 15 16 17 18 19 20
16
12
34
1
445566778899 112233
101014141515161617171818 111112121313
18
BCM-MM - WHITE
CANH
CANL
BCM-ML - WHITE
PARKING LIGHT (-)
HOOD STATUS (-) INPUTHOOD STATUS (-) INPUT
PARKING LIGHT (-) OUTPUT
PARKING LIGHT (-) OUTPUT
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
BRAKE STATUS (+) INPUT
BRAKE STATUS (+) INPUT
VEHICLE IGNITION (+)
I/P-F - RED
HOOD STATUS (-)
IPM - FRONT VIEW
DRIVER SIDE DASH - YELLOW
IPM - REAR VIEW
DRIVER SIDE DASH - YELLOW
BRAKE SWITCH LOCATED
ABOVE BRAKE PEDAL
CLG39 - WHITE
BRAKE (+)
DATA
PASSENGER
KICK PANEL
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
BLUE/RED (NC)BLUE/RED (NC)
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
BROWN/RED - CANH
BROWN/RED - CANH
- IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
BLACK (NC)
BLACK (NC)
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
MC21 - GREEN
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 14 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 7 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
HYUNDAI
Sonata
STD key
AT
11-13
CanH I/P-F White 24 pin 12 White/Orange (DATA) I/P junction box, back side, driver side dash ~
CanL I/P-F White 24 pin 11 Yellow/Orange (DATA) I/P junction box, back side, driver side dash ~
Data* EM11 White 43 pin 10 White or Blue (DATA) Driver kick panel ~
Ignition M03 White 06 pin 04 Pink (+) Ignition switch ~
Sonata
STD key
AT
14
CanH I/P-F White 24 pin 12 White/Orange (DATA) I/P junction box, back side, driver side dash ~
CanL I/P-F White 24 pin 11 Yellow/Orange (DATA) I/P junction box, back side, driver side dash ~
Data* EM11 White 43 pin 10 Blue/Black (DATA) Driver kick panel ~
Ignition M03 White 06 pin 04 Pink (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 15 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 7 - WIRING DIAGRAM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
11
12
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
401
2
3
4
5
6
7
8
9
41
42
43
10
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
BLUE/RED (NC)BLUE/RED (NC)
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
BROWN/RED - CANH
BROWN/RED - CANH
- IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
BLACK (NC)
BLACK (NC)
IP/F - WHITE
CANH
CANL
IGNITION (+) OUTPUTIGNITION (+) OUTPUT
I/P JUNCTION BOX - YELLOW
DRIVER SIDE DASH
REAR VIEW
VEHICLE IGNITION (+)
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
DATA
EM11 - WHITE
KICK PANEL - DRIVER SIDE
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 16 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 8 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
HYUNDAI
Elantra Coupe
STD key
AT
13-14
CanH I/P-G White 24 pin 13 Brown (DATA) I/P junction box, back side, driver side dash ~
CanL I/P-G White 24 pin 01 White (DATA) I/P junction box, back side, driver side dash ~
Data* EM11 White 55 pin 10 Blue or Blue/Black (DATA) Driver kick panel ~
Ignition M03 White 06 pin 04 Pink (+) Ignition switch ~
Elantra Sedan
STD key
AT
11-13
CanH I/P-G White 24 pin 13 White/Orange (DATA) I/P junction box, back side, driver side dash ~
CanL I/P-G White 24 pin 01 Yellow/Orange (DATA) I/P junction box, back side, driver side dash ~
Data* EM11 White 55 pin 10 Blue or Blue/Orange (DATA) Driver kick panel ~
Ignition M03 White 06 pin 04 Pink (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 17 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 8 - WIRING DIAGRAM
10 11
12131415
16
17 18 19 20 21 22 23 24 25 26
27282930
31
32 33 34 35 36 37 38 39 40 41
42 43
44 45 46 47
48 49 50 51
52 53 54 55
12 3 4567 8 9 10
101112
131415161718192021222324
123456789
13
1
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
BLUE/RED (NC)BLUE/RED (NC)
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
BROWN/RED - CANH
BROWN/RED - CANH
- IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GREEN/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/RED - ECM CONNECTOR SIDE
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
BLACK (NC)
BLACK (NC)
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
DATA
EM11 - WHITE
CANL
CANH
I/P-G - WHITE
DRIVER KICK PANEL
I/P JUNCTION BOX - YELLOW - REAR VIEW
VEHICLE IGNITION (+)
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 18 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 9 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
HYUNDAI
Tucson
STD key
AT
10-15
CanH I/P-H White 18 pin 08 Blue (DATA) I/P junction box, back side, driver side dash ~
CanL I/P-H White 18 pin 01 Red (DATA) I/P junction box, back side, driver side dash ~
Data* MC41 Blue 15 pin 08 Blue (DATA) Driver kick panel ~
Ignition M18 White 06 pin 04 Pink (+) Ignition switch ~
*(USA) Data Immobilizer wire is only present if vehicle is equipped with an immobilizer.
Page 19 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##

U.S. Patent No. 8,856,780
TYPE 9 - WIRING DIAGRAM
3
4
5
6
1
2
17
187
8
15
16
11
12
13
14
9
10
10 11 12 13 14 15
1 2 3 4 5 6 7 8
9
8
8
1
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
BLUE/RED (NC)BLUE/RED (NC)
WHITE/BLACK - ECM CONNECTOR SIDE
WHITE/BLACK - ECM CONNECTOR SIDE
BROWN/RED - CANH
BROWN/RED - CANH
- IMMOBILIZER VEHICLE SIDE
WHITE/RED - IMMOBILIZER VEHICLE SIDE
WHITE (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
BLACK (NC)
BLACK (NC)
CANH
CANL
IGNITION (+) OUTPUTIGNITION (+) OUTPUT
DATA
MC41 - BLUE
DRIVER KICK PANEL
I/P-H - WHITE
I/P JUNCTION BOX - WHITE
REAR VIEW
GREEN/RED - ECM CONNECTOR SIDEGREEN/RED - ECM CONNECTOR SIDE
GRAY/RED - IMMOBILIZER VEHICLE SIDE
GRAY/RED - IMMOBILIZER VEHICLE SIDE
VEHICLE IGNITION (+)
STANDARD (IGNITION, ACCESSORY, START, 12V)
REMOTE STARTER CONNECTIONS TO VEHICLE
ARE REQUIRED
(U.S. VEHICLES)
CONNECT ONLY IF
VEHICLE IS EQUIPPED
WITH IMMOBILIZER
Page 20 of 35 BLADE-AL(DL)-HK4-EN 20170526
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2017
DOORLOCK INTERFACE
Hyundai/Kia
Doc. No.: ##39751##
