iDataLink maestro Rr User manual

NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
Pressing the printer icon or “quick printing” this document will print
all of the guides in this compilation.
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
Print only the pages for your vehicle using the advanced
options in the Print menu.
Install your Maestro RR according to the guide for your vehicle.
HOW TO USE THIS INSTALL GUIDE
1
2
3
SELECT VEHICLE
PRINT PAGES NEEDED

20182023
JEEP WRANGLER JL
WITH 5" RADIO
INSTALL GUIDE
RETAINS STEERING WHEEL CONTROLS AND MORE!
+
OR
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
PRODUCTS REQUIRED
iDatalink Maestro RR or RR2 Radio Replacement Interface
iDatalink Maestro HRR-CH3 Installation Harness
PROGRAMMED FIRMWARE: CH3-RR-AS
HEAD UNIT
ADAPTER READY

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 2
JEEP WRANGLER JL WITH 5" RADIO 20182023
HEAD UNIT ADAPTER:
ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1
ACC-SP1
(Chime speaker)
Configuring the RR2’s Programmable
Outputs
Maestro RR2 Programmable
Outputs Guide
Installation, product information, vehicle
specific videos. VIDEO HELP
Last flash information, steering control
configuration, vehicle information. VERIFY FLASH
Software to program module. WEBLINK
WELCOME
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the install guide.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
NEED HELP?
1 866 427-2999
[email protected]
ADDITIONAL INFORMATION AND
ACCESSORIES

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 3
JEEP WRANGLER JL WITH 5" RADIO 20182023
NOTE: Factory backup camera is NOT retained.
STEP 1
Remove the factory radio
If using head unit adapter (sold separately), connect HRR-
CH3 harness to adapter and skip to step 2.
• Unbox the aftermarket radio and locate its main harness.
• Cut and remove the black 20 pin connector from the HRR-
CH3 T-harness and connect the wires, shown in the wiring
diagram, from aftermarket radio main harness to the HRR-
CH3 T-harness and match the wire functions.
Note: only connect purple/white wire to radio reverse input
or module damage will occur.
STEP 2
• Determine if the vehicle has a factory amplifier. Look for
badges on the radio, door panels and dash that indicate the
presence of an amplifier (ex: Alpine).
If the vehicle DOES NOT have a factory amplifier:
• Plug the female BLACK connector to the male BLACK
connector of your HRR-CH3 T-harness.
• Plug the female WHITE connector to the male WHITE
connector of your HRR-CH3 T-harness.
If the vehicle DOES have a factory amplifier:
• Plug the female BLACK connector to the male WHITE
connector of your HRR-CH3 T-harness.
• Plug the female WHITE connector to the male BLACK
connector of your HRR-CH3 T-harness.
• Connect the factory radio harness to the HRR-CH3
T-harness.
STEP 3
• Connect the black 2-pin connector from the extension
cable to the CH3 main harness. Route the white ends to the
CAN junction block in vehicle (see diagram for location).
Unplug any one of the 2-pin white connectors in it. Insert
the male white end from the Maestro harness into the
junction block and plug the factory 2-pin connector back
into the Maestro female white 2-pin.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Connect either the blue/yellow wire (Kenwood/JVC) or the
3.5mm to the steering control input of the radio.
STEP 5
• Connect all the harnesses to the Maestro RR module then
test your installation.
• If the vehicle is equipped with OEM parking assist and no
factory amplifier:
Plug the ACC-SP1 into the Maestro RR.
Note - 2023 Wrangler JL
• Telematics module (right side of the steering column) is
not retained and must be unplugged at this time.
Remove the steering shroud and unplug this module.
Failure to do so will result in SOS and 911 assist lights
being on in the vehicle
4
INSTALLATION INSTRUCTIONS P1 /1

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 4
JEEP WRANGLER JL WITH 5" RADIO 20182023
N.C.
4
POWER ANT.POWER ANT.
N.C.
N.C.
N.C.
AMP TURNONAMP TURNON
BACKUP CAMBACKUP CAM
CARGO CAMCARGO CAM
MICMIC
N.C.
N.C.
3
18
20
4
4
2
4
4
16
52
18
10
3
10
2
2
2
4
3
4
WIRING DIAGRAM
WITH AMP
WITHOUT AMP
STEP 2
BLUE/WHITE - AMP. TURN ON (+)
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
MAIN
HARNESS
HHR-CH3 T-HARNESS
STEP 4
WIRES FROM
VEHICLE
CONNECT TO
AFTERMARKET RADIO
STEP 5
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
STEP 1
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
PURPLE - RR SPEAKER (+)
NOT REQUIRED
MAESTRO RR MODULE
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) *
PINK - VEHICLE SPEED
LTGREEN - E-BRAKE (-)
IF NOT USING A MAESTRO HEAD UNIT ADAPTER:
CUT AND DISCARD CONNECTOR
OR
HEAD UNIT ADAPTER
SOLD SEPARATELY
IF WIRES ARE PRESENT ON
ADAPTER: SEE RADIO
REFERENCE CHART
WHITE
BLACK
WHITE
WHITE
RED
BLACK
* ONLY CONNECT TO RADIO REVERSE INPUT
OR MODULE DAMAGE WILL OCCUR
WHITE
BLACK
SEE RADIO WIRE
REFERENCE CHART
FOR RADIO WIRE
COLORS
FACTORY RADIO
HARNESS
SPEAKER*
UNPLUG
STEP 3
BLACK
CAN JUNCTION BLOCK (GREEN)
UNPLUG ANY OF THE 2-PIN CONNECTORS IN THE CAN
JUNCTION BLOCK.
INSERT THE MALE WHITE CONNECTOR FROM EXTENSION
HARNESS INTO THE JUNCTION BLOCK.
CONNECT THE FACTORY 2 PIN CONNECTOR INTO THE
EXTENSION HARNESS FEMALE WHITE 2-PIN CONNECTOR.
AUDIO
CABLE
DATA
CABLE
STEERING WHEEL
CONTROL CABLE
OR
*REQUIRED ACCESSORY
In vehicles without OEM amplifier,
with OEM parking sensors
LOCATION: BEHIND GLOVE BOX

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 5
JEEP WRANGLER JL WITH 5" RADIO 20182023
RADIO WIRE REFERENCE CHART
CH3 T-harness
Wire Description Polarity Wire Color on Maestro
T-Harness
Wire Color on Alpine
cable
Wire Color on Kenwood/
JVC cable
Wire Color on Pioneer
cable
Wire Color on Sony
cable
Illumination (+) Orange N/A Orange/White Orange/White Orange
Reverse Light* (+) Purple/White Orange/White Purple/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink N/A
Power Antenna (+) Blue Blue Blue Blue/White Blue or Blue/White
ACC-HU-ALP1
Wire Description
Polarity Wire Color on Adapter Alpine Radio
VSS (vehicle speed sensor) (DATA) Green/White Green/White
ACC-HU-KEN1
Wire Description
Polarity Wire Color on Adapter Kenwood Radio
CAM (+) Green/Red Refer to camera/radio
manual
CAM (-) Green/White Refer to camera/radio
manual
Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow
ACC-HU-KEN2
Wire Description
Polarity Wire Color on Adapter Kenwood Radio
E-Brake (-) LtGreen LtGreen
Reverse Light* (+) Purple/White Purple/White
Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow
Head unit adapter wiring (optional accessory, sold separately)
* Reverse light wire: Only connect to radio or module damage will occur.
Other brands, refer to aftermarker radio guide.

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 6
JEEP WRANGLER JL WITH 5" RADIO 20182023
MODULE DIAGNOSTICS
LED 1 LED 2
LED 1
PROGRAMMING BUTTON
LED 1
Module/Firmware
status
LED 2 (RR2)
Bluetooth activity
LED STATUS DIAGNOSTIC
• or •RED or GREEN
flashing
LED flashes 1 or more times, either red or green, when a steering wheel
button is pressed : normal operation.
•1 RED flash Module has no firmware.
Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE.
•1 GREEN flash After radio boots up : Normal operation.
•3 GREEN flashes Bluetooth is activated.
Turns off after one minute: Normal operation.
• • OFF Normal operation (inactive).

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 7
JEEP WRANGLER JL WITH 5" RADIO 20182023
TROUBLESHOOTING TABLE
PROBLEM SOLUTION
On a phone call, you cannot hear the call, but the caller can
hear you.
Make sure that the 4-pin green and white connectors in the harness are plugged in
correctly as stated in step 2.
Steering wheel controls do not work but LED on the Maestro
does blink when steering wheel buttons are pressed.
Ensure the blue 4-pin steering wheel control cable is connected between the Maestro and
the radio. The radio will use either the 3.5mm jack OR the blue/yellow wire, not both.
Connect the 3.5mm jack from the Maestro blue 4-pin cable to the radio’s 3.5mm port
(labeled steering, remote, or wheel). If no such port exists, wire the blue/yellow to blue/
yellow (Kenwood/JVC) or to the radio’s Key 1 wire (brands not listed/other) and secure the
3.5mm jack. It will not be used.
Verify the buttons are set up in the flash. If any button is set to “none” for “press once”,
it will do nothing. “Hold” column can be left as none and the “press once” function will
operate with one press and when holding the button.
Refer to radio’s owner’s manual to verify if the radio has this function:
• JVC/Kenwood : Steering Wheel Control (ON/OFF): choose ON
• Nakamichi : if model is listed, ensure PAC mode is on. If “other”, learn the buttons in
the radio steering wheel menu.
• Sony : Steering Wheel Control (Custom/Preset): choose Preset. If phone buttons do
not operate properly, flash the module as Pioneer – 2009 and newer with BT. Then select
“custom” instead of “preset” and learn the buttons in the radio menu.
• Other brands – radio should have a steering wheel menu to learn the buttons. You may
have to select type A/B/C/1/2/3 and try learning again if buttons are not saving. Refer to
radio manufacturer’s tech support for further advice if not learning properly.
The light on the Maestro is flashing RED ONCE. There is no firmware on the module; flash the RR module.
The radio does not turn ON at all. Make sure the 2-pin connectors in the harness are connected as stated in step 2.
If work was done under the driver’s dash, like replacing the speaker, ensure the CAN
connector on the back of the driver’s speaker is plugged back in.
If you have a multimeter, turn the key on and check for DC voltage at the maestro’s heavy
gauge 3-pin plug (red, yellow, and black wires). The Maestro must be plugged in to get an
accurate measurement. If there is 12 volts on the red and yellow, the Maestro is working
correctly and sending power out to turn on the radio. If no voltage on either, check the
inline fuse and then the vehicle’s fuse for the radio circuit.
The radio stays ON. Make sure the 2-pin connectors in the harness are connected as stated in step 2.
MAESTRO RR RESET PROCEDURE:
Turn the key to the OFF position, then disconnect all connectors from the module.
Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds).
Release the programming button. Wait, the LED will turn solid GREEN for 2 seconds to show the reset was successful.
TECHNICAL ASSISTANCE
Phone: [phone]
Email: maestr[email protected]
IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest firmware from the manufacturer. Please visit the radio
manufacturer’s website and look for any updates pertaining to your radio.

20192023
RAM 1500 CLASSIC
WITH 3" OR 5" RADIO
INSTALL GUIDE
RETAINS STEERING WHEEL CONTROLS AND MORE!
+
OR
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
PRODUCTS REQUIRED
iDatalink Maestro RR or RR2 Radio Replacement Interface
iDatalink Maestro HRR-CH3 Installation Harness
PROGRAMMED FIRMWARE: CH3-RR-AS
HEAD UNIT
ADAPTER READY

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 2
RAM 1500 CLASSIC WITH 3" OR 5" RADIO 20192023
HEAD UNIT ADAPTER:
ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1
ACC-SP1
(Chime speaker)
Configuring the RR2’s Programmable
Outputs
Maestro RR2 Programmable
Outputs Guide
Installation, product information, vehicle
specific videos. VIDEO HELP
Last flash information, steering control
configuration, vehicle information. VERIFY FLASH
Software to program module. WEBLINK
WELCOME
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the install guide.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
NEED HELP?
1 866 427-2999
[email protected]
ADDITIONAL INFORMATION AND
ACCESSORIES

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 3
RAM 1500 CLASSIC WITH 3" OR 5" RADIO 20192023
NOTE:
This firmware is only intended for the 3” or 5” radio trim
and cannot retain the OEM settings menus. To retain
the OEM settings menus, you must use an iDatalink
compatible radio.
Factory backup camera is NOT retained.
STEP 1
Remove the factory radio
If using head unit adapter (sold separately), connect HRR-
CH3 harness to adapter and skip to step 2.
• Unbox the aftermarket radio and locate its main harness.
• Cut and remove the black 20 pin connector from the HRR-
CH3 T-harness and connect the wires, shown in the wiring
diagram, from aftermarket radio main harness to the HRR-
CH3 T-harness and match the wire functions.
Note: only connect purple/white wire to radio reverse input
or module damage will occur.
STEP 2
• Determine if the vehicle has a factory amplifier. Look for
badges on the radio, door panels and dash that indicate the
presence of an amplifier (ex: Alpine).
If the vehicle DOES NOT have a factory amplifier:
• Plug the female BLACK connector to the male BLACK
connector of your HRR-CH3 T-harness.
• Plug the female WHITE connector to the male WHITE
connector of your HRR-CH3 T-harness.
If the vehicle DOES have a factory amplifier:
• Plug the female BLACK connector to the male WHITE
connector of your HRR-CH3 T-harness.
• Plug the female WHITE connector to the male BLACK
connector of your HRR-CH3 T-harness.
• Connect the factory radio harness to the HRR-CH3
T-harness.
STEP 3
• Connect the black 2-pin connector from the extension
cable to the CH3 main harness. Route the white ends to the
CAN junction block in vehicle (see diagram for location).
Unplug any one of the 2-pin white connectors in it. Insert
the male white end from the Maestro harness into the
junction block and plug the factory 2-pin connector back
into the Maestro female white 2-pin.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Connect either the blue/yellow wire (Kenwood/JVC) or the
3.5mm to the steering control input of the radio.
STEP 5
• Connect all the harnesses to the Maestro RR module then
test your installation.
• If the vehicle is equipped with OEM parking assist and no
factory amplifier:
Plug the ACC-SP1 into the Maestro RR.
5
INSTALLATION INSTRUCTIONS P1 /1

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 4
RAM 1500 CLASSIC WITH 3" OR 5" RADIO 20192023
N.C.
5
POWER ANT.POWER ANT.
N.C.
N.C.
N.C.
AMP TURNONAMP TURNON
BACKUP CAMBACKUP CAM
CARGO CAMCARGO CAM
MICMIC
N.C.
N.C.
3
18
20
4
4
2
4
4
16
52
18
10
3
10
2
2
2
4
3
4
WIRING DIAGRAM
WITH AMP
WITHOUT AMP
STEP 2
BLUE/WHITE - AMP. TURN ON (+)
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
MAIN
HARNESS
HHR-CH3 T-HARNESS
STEP 4
WIRES FROM
VEHICLE
CONNECT TO
AFTERMARKET RADIO
STEP 5
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
STEP 1
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
PURPLE - RR SPEAKER (+)
NOT REQUIRED
MAESTRO RR MODULE
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) *
PINK - VEHICLE SPEED
LTGREEN - E-BRAKE (-)
IF NOT USING A MAESTRO HEAD UNIT ADAPTER:
CUT AND DISCARD CONNECTOR
OR
HEAD UNIT ADAPTER
SOLD SEPARATELY
IF WIRES ARE PRESENT ON
ADAPTER: SEE RADIO
REFERENCE CHART
WHITE
BLACK
WHITE
WHITE
RED
BLACK
* ONLY CONNECT TO RADIO REVERSE INPUT
OR MODULE DAMAGE WILL OCCUR
WHITE
BLACK
SEE RADIO WIRE
REFERENCE CHART
FOR RADIO WIRE
COLORS
FACTORY RADIO
HARNESS
SPEAKER*
UNPLUG
STEP 3
BLACK
CAN JUNCTION BLOCK (GREEN)
UNPLUG ANY OF THE 2-PIN CONNECTORS IN THE CAN
JUNCTION BLOCK.
INSERT THE MALE WHITE CONNECTOR FROM EXTENSION
HARNESS INTO THE JUNCTION BLOCK.
CONNECT THE FACTORY 2 PIN CONNECTOR INTO THE
EXTENSION HARNESS FEMALE WHITE 2-PIN CONNECTOR.
LOCATION: DRIVER SIDE DASH
AUDIO
CABLE
DATA
CABLE
STEERING WHEEL
CONTROL CABLE
OR
*REQUIRED ACCESSORY
In vehicles without OEM amplifier,
with OEM parking sensors

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 5
RAM 1500 CLASSIC WITH 3" OR 5" RADIO 20192023
RADIO WIRE REFERENCE CHART
CH3 T-harness
Wire Description Polarity Wire Color on Maestro
T-Harness
Wire Color on Alpine
cable
Wire Color on Kenwood/
JVC cable
Wire Color on Pioneer
cable
Wire Color on Sony
cable
Illumination (+) Orange N/A Orange/White Orange/White Orange
Reverse Light* (+) Purple/White Orange/White Purple/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink N/A
Power Antenna (+) Blue Blue Blue Blue/White Blue or Blue/White
ACC-HU-ALP1
Wire Description
Polarity Wire Color on Adapter Alpine Radio
VSS (vehicle speed sensor) (DATA) Green/White Green/White
ACC-HU-KEN1
Wire Description
Polarity Wire Color on Adapter Kenwood Radio
CAM (+) Green/Red Refer to camera/radio
manual
CAM (-) Green/White Refer to camera/radio
manual
Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow
ACC-HU-KEN2
Wire Description
Polarity Wire Color on Adapter Kenwood Radio
E-Brake (-) LtGreen LtGreen
Reverse Light* (+) Purple/White Purple/White
Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow
Head unit adapter wiring (optional accessory, sold separately)
* Reverse light wire: Only connect to radio or module damage will occur.
Other brands, refer to aftermarker radio guide.

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 6
RAM 1500 CLASSIC WITH 3" OR 5" RADIO 20192023
MODULE DIAGNOSTICS
LED 1 LED 2
LED 1
PROGRAMMING BUTTON
LED 1
Module/Firmware
status
LED 2 (RR2)
Bluetooth activity
LED STATUS DIAGNOSTIC
• or •RED or GREEN
flashing
LED flashes 1 or more times, either red or green, when a steering wheel
button is pressed : normal operation.
•1 RED flash Module has no firmware.
Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE.
•1 GREEN flash After radio boots up : Normal operation.
•3 GREEN flashes Bluetooth is activated.
Turns off after one minute: Normal operation.
• • OFF Normal operation (inactive).

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 7
RAM 1500 CLASSIC WITH 3" OR 5" RADIO 20192023
TROUBLESHOOTING TABLE
PROBLEM SOLUTION
On a phone call, you cannot hear the call, but the caller can
hear you.
Make sure that the 4-pin green and white connectors in the harness are plugged in
correctly as stated in step 2.
Steering wheel controls do not work but LED on the Maestro
does blink when steering wheel buttons are pressed.
Ensure the blue 4-pin steering wheel control cable is connected between the Maestro and
the radio. The radio will use either the 3.5mm jack OR the blue/yellow wire, not both.
Connect the 3.5mm jack from the Maestro blue 4-pin cable to the radio’s 3.5mm port
(labeled steering, remote, or wheel). If no such port exists, wire the blue/yellow to blue/
yellow (Kenwood/JVC) or to the radio’s Key 1 wire (brands not listed/other) and secure the
3.5mm jack. It will not be used.
Verify the buttons are set up in the flash. If any button is set to “none” for “press once”,
it will do nothing. “Hold” column can be left as none and the “press once” function will
operate with one press and when holding the button.
Refer to radio’s owner’s manual to verify if the radio has this function:
• JVC/Kenwood : Steering Wheel Control (ON/OFF): choose ON
• Nakamichi : if model is listed, ensure PAC mode is on. If “other”, learn the buttons in
the radio steering wheel menu.
• Sony : Steering Wheel Control (Custom/Preset): choose Preset. If phone buttons do
not operate properly, flash the module as Pioneer – 2009 and newer with BT. Then select
“custom” instead of “preset” and learn the buttons in the radio menu.
• Other brands – radio should have a steering wheel menu to learn the buttons. You may
have to select type A/B/C/1/2/3 and try learning again if buttons are not saving. Refer to
radio manufacturer’s tech support for further advice if not learning properly.
Illumination or foot brake output does not function. Ensure the white 2 pin CAN junction connectors in step 4 are plugged into the 2-row
green CAN junction connector, not the 1-row one
The light on the Maestro is flashing RED ONCE. There is no firmware on the module; flash the RR module.
The radio does not turn ON at all. Make sure the 2-pin connectors in the harness are connected as stated in step 2.
If you have a multimeter, turn the key on and check for DC voltage at the maestro’s heavy
gauge 3-pin plug (red, yellow, and black wires). The Maestro must be plugged in to get an
accurate measurement. If there is 12 volts on the red and yellow, the Maestro is working
correctly and sending power out to turn on the radio. If no voltage on either, check the
inline fuse and then the vehicle’s fuse for the radio circuit.
The radio stays ON. Make sure the 2-pin connectors in the harness are connected as stated in step 2.
MAESTRO RR RESET PROCEDURE:
Turn the key to the OFF position, then disconnect all connectors from the module.
Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds).
Release the programming button. Wait, the LED will turn solid GREEN for 2 seconds to show the reset was successful.
TECHNICAL ASSISTANCE
Phone: [phone]
Email: maestr[email protected]
IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest firmware from the manufacturer. Please visit the radio
manufacturer’s website and look for any updates pertaining to your radio.

20132017
RAM 1500
WITH 3" OR 5" RADIO
INSTALL GUIDE
RETAINS STEERING WHEEL CONTROLS AND MORE!
+
OR
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
PRODUCTS REQUIRED
iDatalink Maestro RR or RR2 Radio Replacement Interface
iDatalink Maestro HRR-CH3 Installation Harness
PROGRAMMED FIRMWARE: CH3-RR-AS
HEAD UNIT
ADAPTER READY

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 2
RAM 1500 WITH 3" OR 5" RADIO 20132017
HEAD UNIT ADAPTER:
ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1
ACC-SP1
(Chime speaker)
Configuring the RR2’s Programmable
Outputs
Maestro RR2 Programmable
Outputs Guide
Installation, product information, vehicle
specific videos. VIDEO HELP
Last flash information, steering control
configuration, vehicle information. VERIFY FLASH
Software to program module. WEBLINK
WELCOME
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the install guide.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
NEED HELP?
1 866 427-2999
[email protected]
ADDITIONAL INFORMATION AND
ACCESSORIES

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 3
RAM 1500 WITH 3" OR 5" RADIO 20132017
NOTE:
This firmware is only intended for the 3” or 5” radio trim
and cannot retain the OEM settings menus. To retain
the OEM settings menus, you must use an iDatalink
compatible radio.
STEP 1
Remove the factory radio
If using head unit adapter (sold separately), connect HRR-
CH3 harness to adapter and skip to step 2.
• Unbox the aftermarket radio and locate its main harness.
• Cut and remove the black 20 pin connector from the HRR-
CH3 T-harness and connect the wires, shown in the wiring
diagram, from aftermarket radio main harness to the HRR-
CH3 T-harness and match the wire functions.
Note: only connect purple/white wire to radio reverse input
or module damage will occur.
STEP 2
• Determine if the vehicle has a factory amplifier. Look for
badges on the radio, door panels and dash that indicate the
presence of an amplifier (ex: Alpine).
If the vehicle DOES NOT have a factory amplifier:
• Plug the female BLACK connector to the male BLACK
connector of your HRR-CH3 T-harness.
• Plug the female WHITE connector to the male WHITE
connector of your HRR-CH3 T-harness.
If the vehicle DOES have a factory amplifier:
• Plug the female BLACK connector to the male WHITE
connector of your HRR-CH3 T-harness.
• Plug the female WHITE connector to the male BLACK
connector of your HRR-CH3 T-harness.
• Connect the factory radio harness to the HRR-CH3
T-harness.
STEP 3
• Plug the harnesses into the aftermarket radio.
• Connect the backup cam cable into the aftermarket radio
(if equipped).
• Connect either the blue/yellow wire (Kenwood/JVC) or the
3.5mm to the steering control input of the radio.
STEP 4
• Connect all the harnesses to the Maestro RR module then
test your installation.
• If the vehicle is equipped with OEM parking assist and no
factory amplifier:
Plug the ACC-SP1 into the Maestro RR.
1
INSTALLATION INSTRUCTIONS P1 /1

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 4
RAM 1500 WITH 3" OR 5" RADIO 20132017
1
POWER ANT.POWER ANT.
N.C.
N.C.
N.C.
AMP TURNONAMP TURNON
BACKUP CAMBACKUP CAM
MICMIC
CARGO CAMCARGO CAM N.C.
3
18
20
18
10
3
2
4
4
2
4
4
16
52
10
2
2
2
2
2
4
4
3
WIRING DIAGRAM
WITH AMP
WITHOUT AMP
STEP 2
BLUE/WHITE - AMP. TURN ON (+)
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
MAIN
HARNESS
HHR-CH3 T-HARNESS
STEP 3
WIRES FROM
VEHICLE
CONNECT TO
AFTERMARKET RADIO
STEP 4
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
STEP 1
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
PURPLE - RR SPEAKER (+)
NOT REQUIRED
MAESTRO RR MODULE
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) *
PINK - VEHICLE SPEED
LTGREEN - E-BRAKE (-)
IF NOT USING A MAESTRO HEAD UNIT ADAPTER:
CUT AND DISCARD CONNECTOR
OR
HEAD UNIT ADAPTER
SOLD SEPARATELY
IF WIRES ARE PRESENT ON
ADAPTER: SEE RADIO
REFERENCE CHART
WHITE
BLACK
WHITE
WHITE
BLACK
RED
BLACK
* ONLY CONNECT TO RADIO REVERSE INPUT
OR MODULE DAMAGE WILL OCCUR
WHITE
BLACK
SEE RADIO WIRE
REFERENCE CHART
FOR RADIO WIRE
COLORS
FACTORY RADIO
HARNESS
SPEAKER*
STEERING WHEEL
CONTROL CABLE
OR
AUDIO
CABLE
DATA
CABLE
IF EQUIPPED
*REQUIRED ACCESSORY
In vehicles without OEM amplifier,
with OEM parking sensors

CH3-RR-AS-(HRR-CH3)-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2023 5
RAM 1500 WITH 3" OR 5" RADIO 20132017
RADIO WIRE REFERENCE CHART
CH3 T-harness
Wire Description Polarity Wire Color on Maestro
T-Harness
Wire Color on Alpine
cable
Wire Color on Kenwood/
JVC cable
Wire Color on Pioneer
cable
Wire Color on Sony
cable
Illumination (+) Orange N/A Orange/White Orange/White Orange
Reverse Light* (+) Purple/White Orange/White Purple/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink N/A
Power Antenna (+) Blue Blue Blue Blue/White Blue or Blue/White
ACC-HU-ALP1
Wire Description
Polarity Wire Color on Adapter Alpine Radio
VSS (vehicle speed sensor) (DATA) Green/White Green/White
ACC-HU-KEN1
Wire Description
Polarity Wire Color on Adapter Kenwood Radio
CAM (+) Green/Red Refer to camera/radio
manual
CAM (-) Green/White Refer to camera/radio
manual
Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow
ACC-HU-KEN2
Wire Description
Polarity Wire Color on Adapter Kenwood Radio
E-Brake (-) LtGreen LtGreen
Reverse Light* (+) Purple/White Purple/White
Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow
Head unit adapter wiring (optional accessory, sold separately)
* Reverse light wire: Only connect to radio or module damage will occur.
Other brands, refer to aftermarker radio guide.
