TRIXIGCordlessscrewdriver3.6V
TECHNICAL SPECIFICATIONS
Model: TRIXIG
Type: P2201
Voltage: 3.6 Vdc
Batterytype: 1.5 Ah/5.4Wh Lithium-Ion
Chargingtime: <300 Min
Max.hardtorque: approx. 5 Nm
Maxnoloadspeed: 200/min
Bitholder: 6.35 mm (1/4”)
Vibration(accordingtoEN62841-1,EN62841-2-2):
Screwdriving without impact: ah=0.34 m/s2, K=1.5 m/s2.
Noise(accordingtoEN62841-1):
Noise pressure level LpA = 59 dB (A), KpA = 3 dB (A)
Noise power level LwA = 70 dB (A), KwA = 3 dB (A)
INDOORUSEONLY.
Recommendedchargingratings:
5.0V d.c. / 1.0-3.0A (type C), charging temperature 0-50℃
Productfeatures
The numbering of the product features shown refers to the illustration no. 1 on the
graphic page.
1. Screwdriver main body
2. Screwdriver bit holder
3. ON/OFF switch
4. USB-C charging socket
5. Magnetic bit holder
6. LED work light
7. Rotation direction switch
8. LED power status indicator
NOTE!
USB-C cable and USB charger are not included.
AREAS OF USE
The electric screwdriver is suitable for the insertion and removal of screws.
The tool is to be used only for its prescribed purpose. Any other use is deemed to be a
case of misuse.

5
GENERAL SAFETY INSTRUCTIONS
Generalsafetyinstructionsforpowertools
WARNING!Readallsafetywarnings,instructions,illustrationsandspecications
providedwiththispowertool. Failure to follow all instructions listed below may result
in electric shock, re and/or serious injury.
Saveallwarningsandinstructionsforfuturereference
The term "power tool" in the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
Workareasafety
a. Keepworkareacleanandwelllit. Cluttered and dark areas invite accidents.
b. Donotoperatepowertoolsinexplosiveatmospheres,suchasinthepresenceof
ammableliquids,gassesordust.Power tools create sparks which may ignite the
dust of fumes.
c. Keepchildrenandbystandersawaywhileoperatingapowertool.Distractions can
cause you to lose control.
Electricalsafety
a. Powertoolplugsmustmatchtheoutlet.Nevermodifythepluginanyway.Do
notuseanyadapterplugswithearthed(grounded)powertools.Unmodied plugs
and matching outlets will reduce risk of electric shock.
b. Avoidbodycontactwithearthedorgroundedsurfacessuchaspipes,radiators,
rangesandrefrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c. Donotexposepowertoolstorainorwetconditions. Water entering a power tool
will increase the risk of electric shock.
d. Donotabusethecord.Neverusethecordforcarrying,pullingorunplugging
thepowertool.Keepthecordawayfromheat,oil,sharpedgesormovingparts.
Damaged or entangled cords increase the risk of electric shock.
e. Whenoperatingapowertooloutdoors,useanextensioncordsuitablefor
outdooruse. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. Ifoperatingapowertoolinadamplocationisunavoidable,usearesidualcurrent
device(RCD)protectedsupply.Use of an RCD reduces the risk of electric shock.
Personalsafety
a. Stayalert,watchwhatyouaredoingandusecommonsensewhenoperatinga
powertool.Donotuseapowertoolwhileyouaretiredorundertheinuenceof
drugs,alcoholormedication.A moment of inattention while operating power tools
may result in serious personal injury.
b. Usepersonalprotectiveequipment.Alwaysweareyeprotection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.

6
c. Preventunintentionalstarting:Ensurethattheswitchisintheo-positionbefore
connectingtopowersourceand/orbatterypack,pickinguporcarryingthetool.
Carrying power tools with your nger on the switch or plugging in power tools that
have the switch on invites accidents.
d. Removeanyadjustingkeyorwrenchbeforeturningthepowertoolon. A wrench
or a key left attached to a rotating part of the power tool may result in personal injury.
e. Donotoverreach.Keepproperfootingandbalanceatalltimes. This enables better
control of the power tool in unexpected situations.
f. Dressproperly.Donotwearlooseclothingorjewellery.Keepyourhair,clothing
andglovesawayfrommovingparts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g. Ifdevicesareprovidedfortheconnectionofdustextractionandcollection
facilities,ensuretheseareconnectedandproperlyused. Use of these devices can
reduce dust related hazards.
h. Donotletfamiliaritygainedfromfrequentuseoftoolsallowyoutobecome
complacentandignoretoolsafetyprinciples. A careless action can cause severe
injury within a fraction of a second.
Powertooluseandcare
a. Donotforcethepowertool.Usethecorrectpowertoolforyourapplication.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b. Donotusethepowertooliftheswitchdoesnotturnitonando. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnecttheplugfromthepowersourceand/orthebatterypackbefore
makinganyadjustments,changingaccessories,orstoringpowertools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Storeidlepowertoolsoutofthereachofchildrenanddonotallowpersons
unfamiliarwiththepowertoolortheseinstructionstooperatethepowertool.
Power tools are dangerous in the hands of untrained users.
e. Maintainpowertools.Checkformisalignmentorbindingofmovingparts,
breakageofpartsandanyotherconditionthatmayaectthepowertool's
operation.Ifdamaged,havethepowertoolrepairedbeforeuse.Many accidents
are caused by poorly maintained power tools.
f. Keepcuttingtoolssharpandclean.Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g. Usethepowertool,accessoriesandtoolbitsetc.,inaccordancewiththese
instructionsandinthemannerintendedfortheparticulartypeofpowertool,
takingintoaccounttheworkingconditionsandtheworktobeperformed.
Use of the power tool for operations dierent from those intended could result in a
hazardous situation.
h. Keephandlesandgraspingsurfacesdry,cleanandfreefromoilandgrease.
Slippery handles and grasping surfaces do not allow for safe handling and control of
the tool in unexpected situations.
Batterytooluseandcare
a. Rechargeonlywiththechargerspeciedbythemanufacturer. A charger that is
suitable for one type of battery pack may create a risk of re when used with another
battery pack.

7
b. Usepowertoolsonlywithspecicallydesignatedbatterypacks. Use of any other
battery packs may create a risk of injury and re.
c. Whenbatterypackisnotinuse,keepitawayfromothermetalobjects,like
paperclips,coins,keys,nails,screwsorothersmallmetalobjectsthatcanmake
aconnectionfromoneterminaltoanother.Shorting the battery terminals together
may cause burns or a re.
d. Underabusiveconditions,liquidmaybeejectedfromthebattery;avoid
contact.Ifcontactaccidentallyoccurs,ushwithwater.Ifliquidcontactseyes,
additionallyseekmedicalhelp. Liquid ejected from the battery may cause irritation
or burns.
e. Donotuseabatterypackortoolthatisdamagedormodied. Damaged or
modied batteries may exhibit unpredictable behaviour, resulting in re, explosion or
risk of injury.
f. Donotexposeabatterypackortooltoreorexcessivetemperatures.Exposure to
re or a temperature above 130 °C may cause an explosion.
g. Followallcharginginstructionsanddonotchargethebatterypackortool
outsidethetemperaturerangespeciedintheinstructions. Charging improperly
or at temperatures outside the specied range may damage the battery and increase
the risk of re.
Service
a. Haveyourpowertoolservicedbyaqualiedrepairpersonusingonlyidentical
replacementsparts.
This will ensure that the safety of the power tool is maintained.
b. Neverservicedamagedbatterypacks. Service of battery packs should only be
performed by the manufacturer or authorised service providers.
MACHINE-SPECIFICSAFETYINSTRUCTION
Safetywarningsfordrillsandscrewdrivers
Holdthepowertoolbytheinsulatedgrippingsurfaceswhenperformingan
operationwherethefastenermaycontacthiddenwiring. Fasteners contacting a
"live" wire may make exposed metal parts of the power tool conductive and could give
the operator an electric shock
Useappropriatedetectorstodetermineifutilitylinesarehiddenintheworkarea
orcallyourlocalutilitycompanyforassistance. Contact with electric lines can lead to
re and electric shock. Damaging a gas line can lead to explosion. Penetrating a water
line causes property damage or may cause an electric shock.
Switchothepowertoolimmediatelywhenthetoolbecomesblockedorstuck. Be
prepared for high reaction torque that can cause kickback. The tool becomes blocked
when:
• the power tool is subjected to overload
• or it becomes wedged in the workpiece.

8
Holdthemachinewitharmgrip.High reaction torque can briey occur while driving
in and loosening screws.
Securetheworkpiece. A workpiece clamped with clamping devices or in a vice is held
more secure than by hand.
Keepyourworkplaceclean.Blends of materials are particularly dangerous. Dust from
light alloys can burn or explode.
Alwayswaituntilthemachinehascometoacompletestopbeforeplacingitdown.
The tool insert can jam and lead to loss of control over the power tool.
Avoidunintentionalswitchingon.Ensure the trigger is in the o position before
inserting battery pack. Carrying the power tool with your nger on the trigger or
inserting the battery pack into power tools that have the switch on invites accidents.
SafetyWarningsforbatterychargers
Forindooruseonly.
Keepthebatterychargerawayfromrainormoisture. Penetration of water in the
battery charger increases the risk of an electric shock.
Donotchargeotherbatteries. The battery charger is suitable only for charging the
batteries that were supplied with your power tool. Otherwise there is danger of re and
explosion.
Keepthebatterychargerclean. Contamination can lead to danger of an electric shock.
Beforeeachuse,checkthebatterycharger,cableandplug.Ifdamageisdetected,
donotusethebatterycharger.Neveropenthebatterychargeryourself.Have
repairsperformedonlybyaqualiedtechnician. Damaged battery chargers, cables
and plugs increase the risk of an electric shock.
Donotoperatethebatterychargeroneasilyinammablesurfaces(e.g.,paper,
textiles,etc.)orsurroundings. The heating of the battery charger during the charging
process can pose a re hazard.
Childrenshouldbesupervisedtoensurethattheydonotplaywiththebattery
charger.
VIBRATIONANDNOISEINFORMATION
Vibrationandnoiselevel
The vibration and noise emission level stated in this instruction manual has been
measured in accordance with a standardised test in EN 62841. It may be used to compare

9
one tool with another and as a preliminary assessment of exposure to vibration and
noise when using the tool for the applications mentioned in this manual. However, using
the tool for dierent applications, or with dierent or poorly maintained accessories, may
signicantly increase the exposure level.
An estimation of the level of exposure to vibration and noise should also take into
account the times when the tool is switched o or when it is running but not being
used, as this may signicantly reduce the exposure level over the total working period.
Protect yourself against the eects of vibration and noise by maintaining the tool and its
accessories, keeping your hands warm and organising your work.
Otherrisks
Evenwhenthepowertoolisusedasprescribed,itisnotpossibletoeliminateall
otherriskfactors.Thefollowinghazardsmayariseinconnectionwiththepower
tool’sconstructionanddesign:
Damage to lungs if an eective dust mask is not worn.
Damage to hearing if eective hearing protection is not worn.
Damages to health resulting from vibrations if the power tool is being used over
longer period of time or not properly handled and maintained.
WARNING! This power tool produces an electromagnetic eld during operation. Under
some circumstances, this eld may interfere with active or passive medical implants. To
reduce the risk of serious or fatal injury, we recommend persons with medical implants
to consult their physician and the medical implant manufacturer before operating this
machine.
ASSEMBLY
Before any work on the machine (e.g. maintenance, tool change, etc.) as well as during
transport and storage, set rotational direction switch to the centre position. Unintentional
actuation of the trigger can lead to injuries.

10
Chargingthescrewdriver
First read the safety instructions and then follow the charging instructions.
Connect the USB-C cable end to the USB-C port (Pic. 2) (A) in the screwdriver. Then
connect the other USB cable end to a USB-charger or USB-outlet that can provide
sucient power to charge the screwdriver. Make sure that there are no knots or sharp
bends in the cable.
When the screwdriver is connected to the electricity supply with a USB-C cable, three
diodes on the screwdriver (Pic. 2) (B) light up to indicate the charging status:
- Pulsating light - charging in progress
- Steady light - charging completed
After the screwdriver’s battery is fully charged and the screwdriver remains
connected to power supply, the diodes will stay lit. Under normal conditions of use the
screwdriver can be recharged several hundred times.
ATTENTION! The recharging process generates heat in the battery. It is not advisable to
recharge the battery in temperatures below freezing. The battery will gradually lose its
charge over a period of time, even if the tool is not used.
NOTE!
The battery that is supplied with the screwdriver has been charged for test purposes only
and must be fully recharged before rst time use.
The lithium-ion battery is protected against deep discharging by the "Electronic Cell
Protection (ECP)". When the battery is empty, the machine is switched o by means of a
protective circuit: The inserted tool no longer rotates.
WARNING Do not continue to press the On/O switch after the machine has
been automatically switched o. The battery can be damaged.
WARNING! Recharge the battery on a non-ammable surface. Do not
recharge the battery for more than eight hours.
INSTRUCTIONS FOR USE
Operation
This basic cordless screwdriver will accept various types and length of screwdriver bits
that have a hexagonal shank that is 6.35mm (1/4") across the ats.
Insertingthescrewdriverbits(Pic.3)
Select the correct screwdriver bit for the screws being used. Insert the screwdriver bit into
the screwdriver drive, ensuring that it is pushed rmly home.
Note: It is advisable to always drill a pilot hole when driving screws with this product.
SwitchingONandOFF
For screwdriving, squeeze the ON/OFF switch (3). Releasing the ON/OFF switch will stop
the screwdriver. For screw removal and changing the rotation direction, push the rotation
direction switch (7).
