Ironwood GLACIER CDCU User manual

CDCU
CDCU29
CDCU39
CORNER UNIT
0920
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a carpeted
surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].
BY

PARTS DIAGRAM
AB
C
F
D
Left Side - CDCU
Left Side - CDCU29
Left Side - CDCU39
01011041
01013141
01011141
1 ea.
1 ea.
1 ea.
E
Top 01011001 1 ea.
Right Side - CDCU
Right Side - CDCU29
Right Side - CDCU39
01011041
01013141
01011141
1 ea.
1 ea.
1 ea.
Left Side - CDCU
Left Side - CDCU29
Left Side - CDCU39
01011077
01013177
01011177
1 ea.
1 ea.
1 ea.
Modesty Panel - CDCU
Modesty Panel - CDCU29
Modesty Panel - CDCU39
01011077
01013177
01011177
1 ea.
1 ea.
1 ea.
Right Side - CDCU
Right Side - CDCU29
Right Side - CDCU39
01011053
01013153
01011153
1 ea.
1 ea.
1 ea.

H4 Rafix Bolt 909923 19 ea.
H3 Leveler 300870 6 ea.
H1 Rafix Flush Cam 909913 13 ea. H2 Leveler Insert 274650 6 ea.
H10 Connector
Screw 901350 4 ea.
H8 Grommet 286580 4 ea.
H7 1" Panhead Screw 901227 6 ea.
H9 Connector Sleeve 950200 4 ea.
H6 Corner Bracket 411170 2 ea.
HARDWARE
Hardware for Connecting to Other Glacier Circulation Units
H5 Rafix Cam 909910 6 ea.
H6

Place the Left Back (E), Modesty Panel (D), and Right Back (F) on a clean, carpeted surface with
the pre-drilled holes facing up. Insert five Rafix Flush Cams (H1) into the Left Back, three cams
into Modesty Panel, and five cams into Right Back with the arrows of the cams facing out where
indicated.
#1
H1
ASSEMBLE DISASSEMBLE
Using the Rafix System:
Insert the Rafix Cams into the
appropriate holes. The flat edge of
the cam should be facing the edge
of the panel.
Slide Rafix Cams of the panel to be
attached onto the corresponding posts.
Using a #3 Phillips screwdriver, turn the
rotating portion of the Rafix Cam a 1/2
turn clockwise to secure. IMPORTANT!
Do not exceed 1/2 turn when tightening
cams. Turn 1/2 turn counterclockwise
to disassemble and remove panel.
When screwing post
into hole, Do Not
over tighten. Screw
post down until
bottom face of post
flange just touches
board surface.
Flat
edges
must be
aligned

#2
#3
Screw seven Rafix Bolts
(H4) into the Top (C)
where indicated.
#4
Insert the Leveler Inserts
(H2) into the holes in the
bottom edge of the
Modesty Panel (D). Using
a plastic mallet, tap until
flush with the surface.
Screw the Levelers (H3)
into the Leveler Inserts.
Adjust Levelers when the
assembled unit is in place.
Slightly elevate the Top (C)
by placing some packing
material underneath it. Insert
six Rafix Cams (H5) into the
Top with the arrows of the
cams facing out.
H4
H5
H6
H5
H5

Screw six Rafix Bolts
(H4) into the Left Side
(A) and Right Side (B)
where indicated.
#5
Insert the Leveler Inserts (H2) into the holes in the bottom edges of the Left Side (A) and
Right Sight (B). Using a plastic mallet, tap until flush with the surface. Screw the Levelers
(H3) into the Leveler Inserts. Adjust Levelers when the assembled unit is in place.
#6
Position the Right Back (F)
onto the bolts of the Top (C)
and turn the cams (H1)
clockwise to secure.
#7
H4

Position the Modesty
Panel (D) onto the bolts of
the Top (C) and turn the
cams (H1) clockwise to
secure.
#8
Position the Left Back (E)
onto the Top (C) and turn
the cams (H1) clockwise
to secure.
#9
Connect the Left and Right
Back (E & F) to the
Modesty Panel (D) with
the Corner Brackets (H6)
using 1" Panhead Screws
(H7) in the pre-drilled
holes.
#10

Position the Right Side (B)
onto the bolts of the Top (C)
as shown. Turn the indicated
cams (H1) clockwise to
secure the Right Side in
place.
#11
Position the Left Side (A)
onto the bolts of the Top as
shown. Turn the cams of
the Top (C) and the Left
Back (E) clockwise to
secure the Left Side in
place.
With the assistance of
another person, turn the
unit upright.
#12
#13
H8
Insert Grommets into the Left Side (A), Right
Side (B), and Top (C).
Your Glacier Circulation Corner Unit is now fully
assembled and ready for use.

CONNECTING TO OTHER CIRCULATION DESK UNITS:
Remove Grommets from
the panels to be connected.
Using a 13/64" bit, drill through
the four pilot holes on the inside
of each side panel.
Align the side panels of the units
to be connected. Tap four
Connector Sleeves (H9) through
the holes in one side panel and
into the holes of the unit to be
connected. From the other side,
secure the units together using
four Connector Screws (H10).
H9 H10
