Ironwood GLACIER LFDS User manual

0422
LIBRARY FURNITURE
LFDS
DICTIONARY STAND
LECTERN
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a carpeted
surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].
BY

PARTS DIAGRAM
AD
B
CEF
AD
B
CEF
Left Panel 32”
Left Panel 39”
01040241
01040141
1 ea.
1 ea. Right Panel 32”
Right Panel 39”
01040241
01040141
1 ea.
1 ea.
Top 01040101 1 ea.
Panhead Screw 901220 2 ea.
Adjustable Shelf 01040127 1 ea.
AD
B
CEF
AD
B
CE
F
AD
B
C
E
F
H2
Paper Stop 46931 1 ea.
H1
AD
B
C
EF
Back 32”
Back 39”
01040252
01040152
1 ea.
1 ea.
Bottom Shelf 01040111 1 ea.
Flush Rafix
Cam 909911 10 ea.
H5
Rafix Cam 909909 8 ea.
H6
Rafix Bolt 909925 18 ea.
H7

ASSEMBLE DISASSEMBLE
Using the Rafix System:
Insert the Rafix Cams into the
appropriate holes. The flat edge of
the cam should be facing the edge
of the panel.
Slide Rafix Cams of the panel to be
attached onto the corresponding posts.
Using a #3 Phillips screwdriver, turn the
rotating portion of the Rafix Cam a 1/2
turn clockwise to secure. IMPORTANT!
Do not exceed 1/2 turn when tightening
cams. Turn 1/2 turn counterclockwise
to disassemble and remove panel.
When screwing post
into hole, Do Not
over tighten. Screw
post down until
bottom face of post
flange just touches
board surface.
Flat
edges
must be
aligned

A
H5
H7
H7
#3 Screw five Rafix Bolts (H7) into the Left
Panel (A) where indicated.
Insert two flush rafix Cams (H5) into
the Left Panel (A) facing out.
#4
B
H3
H7
H5
Screw Rafix Bolts (H7) into the Right
Panel (B) where indicated.
Insert two Rafix Flush Cams (H5) into
the Right Panel (B) facing out.
#1
C
H7 H7
Attach the Paper Stop (H1) to the
upper surface of the Top Panel (C)
using 1/2” Panhead Screws (H2) in the
pre-drilled holes as shown.
Turn the Top Panel (C) over. Screw
four Rafix Bolts (H7) into the pre-
drilled holes of the Top Panel (C)
as indicated.
#2
H2

E
D
A
H6
#7
#8
Position the Bottom Shelf
(E) onto the Left Panel
(A) and turn cams to
secure.
Position the bolts of the
Right Panel (B) onto the
unit and turn cams to
secure.
B
D
E
A
H5
H6
#5
D
E
H5
H5
H6
H6
#6
A
D
H5
Insert six Rafix Flush Cams (H5) into
the Back Panel (D) and Rafix Cams
(H6) into the Bottom Shelf (E).
Position the Back Panel (D) onto
the Left Panel (A) and turn cams to
secure.

#10
F
H6
#11
H7
F
Insert four Rafix Cams (H6) into the Adjustable Shelf
(F) facing outwards and tap until fully seated in place
as shown.
IMPORTANT! The edge of the Rafix Cam must be
aligned with the shelf edge. Rafix Cams are
difficult to reposition if installed incorrectly.
Placement of the Adjustable
Shelf (F) is optional. Screw the
Rafix Bolts (H7) into pre-drilled
holes of each Side (A and B) at
a selected height.
Your Glacier
Lectern/Dictionary
Stand is now fully
assembled and
ready for use.
#9
H5
H5
Turn the assembly
upright. Position the
Top Panel (C) onto the
unit and turn the cams
to secure.
