JANE Montecarlo R1 User manual

OWNER’S MANUAL
IMPORTANT!
Failure to follow the warnings on the labels and in the instruction
manual can result in the death or serious injury of your child
IM 1687.01
JANE USA
15720 John J. Delaney Dr., Suite 300 / Charlotte, NC 28277 USA
PO Box 49565 - www.jane-usa.com / 1-866-890-3071

MONTECARLO R1
2
TABLE OF CONTENTS
Knowing your new Montecarlo R1 car seat
Warnings
Registration and Recall information
Vehicle Seat Belts
- Vehicle seat belt Incompatible
Part List
Pre-adjustment
1- Checking the height of the shoulder belt
Installing your Montecarlo R1 in the Vehicle
2- Installation with LATCH Anchors and the 3-point seat belt
3- Installation with the 3-point seat belt
4- Reclining the seat
5- Adjusting the width of the sides of the backrest and headrest
6- Adjusting armrest
Maintenance
Warranty
3_
4_
10_
10_
12_
13_
14_
21_
22_

3
english
KNOWING YOUR NEW MONTECARLO R1
Your new Montecarlo R1 car seat from JANÉ is designed to protect children aged from about one and a half years weighing not less than 30 lbs (13.6 Kg.) to
approximately 12 years of age weighing not more than 100 lbs (45 Kg.)
If your child needs a booster seat, we do recommend choose one with backrest. Booster cushions can offer sufficient lateral support in the lap area, but not in
the head and torso areas. The use of a booster seat with backrest, complies with the latest findings in child safety engineering. The head and body of the child
are protected laterally, which is not only safer in the event of an accident, but also ergonomically more comfortable when your child falls asleep in the seat.
If you restraint your Montecarlo R1 into the car with LATCH, the seat is more stable, you wouldn’t have to tie it when it is not occupied and your child is better
protected in the event of side-impact accidents.
For more information on the use and fitting of the Montecarlo R1, consult our website: http://www.jane-usa.com
To enhance the child’s safety, the Montecarlo R1 car seat is provided with:
• A system for fitting this Car Seat to LACTH in your car;
• A headrest with 5 different height positions to keep the child protected
while he/she grows;
• Higher sides, which provide greater protection against side impact;
• Impact-absorbing material on the sides and center of the headrest;
• Reinforced headrest to protect against twisting.
To improve its adaptability and your child’s comfort, the Montecarlo R1 car
seat includes the following features:
• Backrest and headrest whose widths can be adjusted independently of
one another;
• Reclining seat with two different positions;
• Height-adjustments armrest;
• Ventilation system in the moldings;
• Extra padding.

MONTECARLO R1
4
WARNINGS
Use only with children who weigh between
30 and 100 lbs (13,6 and 45 kg) and whose
height is 4’9” (1,5 meters) or less and who
are capable of sitting upright alone
Failure to follow these warnings can result
in the death or serious injury of your child.
According to accident statistics, children are
safer when properly restrained in the rear
seating positions than in the front seating
positions.
Based on crash statistics, the National High-
way Traffic Safety Administration (NHTSA)
recommends that parents select the rear
seat as the safest location for a properly
positioned booster seat.
Use this car seat only on the vehicle seats
that face forward. Do not use on seats that
face the sides or rear of the vehicle.
Follow all instructions on this child restraint

5
english
and in the written instructions located under
the booster.
Register your child restraint with the
manufacturer.
Secure this child restraint with a vehicle
belt.
Use only the vehicle’s lap and shoulder belt
system when restraining the child in this
booster seat.

MONTECARLO R1
6
DO NOT use this booster seat with two-
point vehicle belts (lap belt only or shoul-
der belt only). Your child could be seriously
injured in the event of a crash
Use this booster seat forward-facing
only.
This booster seat must not be used in the
home, in boats, or in other non-certified
applications.
DO NOT use any parts of this booster seat
with other seat cushions or backrest.
The primary protection for occupants of a
vehicle in a collision is the structure of the
vehicle itself; a booster seat will not pro-
tect a child when the vehicle is seriously
impacted. However, correctly installed, a
booster seat will substantially improve the
chances for survival in most crashes. Make
sure that all users fully understand the

7
english
correct ways to use this booster seat in a
vehicle.
Check vehicle instructions for more infor-
mation about air bag/child restraint use.
For vehicles with an air bag, but without
a back seat, refer to your vehicle owner’s
manual.
Make sure the shoulder belt height is
correct for your child’s size.
The shoulder belt must always be adjusted
snugly across the child’s chest.
Never take your child out of the child
restraint or try to tend to your child’s
needs while the vehicle is moving. Never
leave child unattended.
Do not use this car seat with damaged or
missing parts.
Do not substitute parts or try to modify
this car seat in any way.

MONTECARLO R1
8
Do not use this car seat after it has been in
a crash. You must get a new car seat.
This car seat should be securely belted
in the vehicle even when not in use. In a
crash or sudden stop, an unsecured car seat
could injure other occupants.
Do not use this car seat if the midpoint of
your child’s head is above the top of this
car seat’s headrest.
Jané USA LLC does not recommend or war-
rant the use of any car seat accessories ex-
cept those recommended by Jané USA LLC.
Never allow any child to play with this car
seat; it is not a toy.
Do not remove any of the warning labels or
other labels on this car seat.
This car seat is Not Certified for Use in Air-
craft.

9
english
Make sure that none of the belts are
twisted. Ensure that the child understands
that he/she must not play with the belts or
buckles under any circumstances.
This car seat may not be used without its
upholstery, or its original upholstery re-
placed, as the upholstery is an integral part
of the safety system.
Ensure that any bags inside the car or other
objects capable of causing harm in the
event of an accident, are properly secured
or protected.
Placing your child in a hot car seat may re-
sult in burns. To avoid it take the following
precautions:
1. Park in the shade or where sun does not
directly hit the car seat.
2. Cover the car seat with a sheet or blanket
when not in use.
3. Check for hot seat and car buckles before
placing child in this car seat.

MONTECARLO R1
10
REGISTRATION AND RECALL INFORMATION VEHICLE SEAT BELTS
Child restraints could be recalled for safety reasons. You must register this
restraint to be reached in a recall. Send your name, address, email address
if available and the restraint’s model number and manufacturing date to:
- Jane USA LLC,
15720 John J. Delaney Drive, Suite 300, Charlotte,
North Carolina 28277
- Or call 1.866.890.3071
- Or register online at
http://www.jane-usa.com/product-registration.
For recall information, call the U.S. Government’s Vehicle Safety Hotline at
1-888-327-4236 (TTY: 1-800-424-9153), or go to http://www.NHTSA.gov.
ONLY A LAP / SHOULDER BELT
SYSTEM CAN BE USED WITH THIS
BOOSTER SEAT, if the seat location
meets all other requirements of
these instructions and those in your
Vehicle owner’s manual.
Pay careful attention to these sys-
tems; some of the seat belts that
are NOT safe to use look very much
like seat belts that are safe to use.

11
english
- NEVER use a lap-only belt.
WARNING! The following types of vehicle seat belts are NOT compatible with this booster seat:
-NEVER use a motorized, automatic vehicle seat belt.
NEVER use Vehicle belts that are attached to the door in any way or
that move long a track to automatically surround the passenger when
the door is closed.
- NEVER use a vehicle seat belts with the top
or bottom anchor points on the vehicle door.

MONTECARLO R1
12
1. Booster seat
2. Backrest
3. Headrest
4. Armrest
5. Armrest adjustment button
6. Backrest width adjustment handle
7. Headrest width adjustment handle
8. Headrest height adjustment button
9. Shoulder belt guide
10. Abdominal belt guide
11. LATCH anchors
12. LATCH anchor release button
13. LATCH length release button
14. Ventilation channels
15. Instructions compartment
16. LATCH end caps
16
5
4
6
14
7
8
3
9
2
1
15
10 13 12
11
PART LIST

13
english
Pre-adjustments
WARNING. Adjust the height to suit the child as he/she grows.
WARNING. For maximum protection, the shoulder belt should be routed so
that it is slightly above the shoulder of the child. As the child grows, this
position will have to be adjusted.
1a
1b
To ensure maximum safety for the child, the shoulder belt should pass
slightly above the shoulder. This position will need to be adjusted as the
child grows.
1a Place the child in the seat, make sure he is positioned correctly. The
belt should go slightly above the child’s shoulder.
1b To adjust the height, pull the button found behind the headrest (8)
and slide the headrest in the required direction. When it is at the correct
height, release the button and move the headrest to the nearest locking
position, it should click into place.
1 Checking the height of the shoulder belt

MONTECARLO R1
14
Installing your Montecarlo R1 in the Vehicle
2 Installation with LATCH anchors and the 3-point seat belt
If you are going to install your MONTECARLO R1 with the rigid anchors,
follow the steps below carefully:
2b
2a 2c
2a First remove the end caps, to do this, pull the anchor button. Keep
the end caps in case you use the MONTECARLO R1 without LATCH in
the future.
2b Pull the anchor out pressing the red buttons on the sides (13).
2c Make sure that both anchors are open, the red signal should be
displayed on the anchor button (12).
LATCH

15
english
2e
2d
Place your MONTECARLO R1 on the vehicle seat in accordance with the
advice and warnings contained in the “WARNINGS” chapter.
Before installing the safety seat find the LATCH anchors on the vehicle
seat. Once you have found them, position the MONTECARLO R1 so
that the rigid anchors (11) are pointing towards the LATCH anchors
of the vehicle.
2d Press the rigid anchors towards the vehicle seat until they both
lock, check that the green signal is displayed on the two LATCH re-
lease buttons (12).
2e Keep pressing firmly until the booster seat touches the backrest of
the vehicle seat. Make sure that it is securely held by pulling the seat.
2f
2f Place the child in the MONTECARLO R1 and make sure that he/she
is sitting well back, pass the seat belt over him and fasten it.

MONTECARLO R1
16
WARNING. Ensure that the car seat is firmly in place by pulling it.
To get the child out of the seat, simply unfasten the seat belt. When you
want to remove the MONTECARLO R1 safety seat from the vehicle, pull the
buttons on the LATCH anchors (12) while removing the booster seat.
WARNING. When it is not in use, do NOT leave the MONTECARLO R1 car seat
loose inside the vehicle. Secure it with the safety belt or store it in the trunk.
When putting the child back in the car seat, check that none of the safety
belts are twisted or in the wrong place.
2g 2h
2g Insert the shoulder belt into the red clip on the headrest (9).
2h Pass the abdominal belt under both armrests of the booster seat, the
area where the belt should go is marked in red again (10). Finally, tighten
the seat belt.

17
english
Place your MONTECARLO R1 on the vehicle seat in accordance with
the advice and warnings contained in the “WARNINGS” chapter.
To protect the upholstery of your vehicle, put the caps on the ISOfix
terminal. Place the child in the MONTECARLO R1 and make sure that
he is sitting well back, pass the seat belt over him and fasten it.
3a 3b 3c
3 Installing with the 3-point seat belt
3a Place the child in the MONTECARLO R1 and make sure that he/she
is sitting well back, pass the seat belt over him and fasten it.
3b Insert the shoulder belt into the red clip on the headrest (9).
3c Pass the abdominal belt under both armrests of the booster seat,
the area where the belt should go is marked in red again (10). Finally,
tighten the seat belt.
To get the child out of the seat, simply unfasten the seat belt.
WARNING. When it is not in use, do NOT leave the MONTECARLO R1 car seat loose inside
the vehicle. Secure it with the safety belt or store it in the trunk. When putting the child
back in the car seat, check that none of the safety belts are twisted or in the wrong place.

MONTECARLO R1
18
To offer the child greater comfort the safety seat can be reclined. Maximum
safety is achieved when the seat is not reclined.
WARNING. Do not recline the seat while the child is using it. To recline or
straighten your MONTECARLO R1 safety seat, you should adjust the length
of the seat belt. Do this when the vehicle has stopped.
4a To recline the seat raise the front part of the booster seat and slide it
to the required position. It has two positions.
5a To adjust the sides of the backrest and headrest turn the handles found
on the side of the seat (6 and 7). Turn the handles clockwise to open the
sides and anticlockwise to close them.
4 Reclining the seat 5 Adjusting the width of the sides of the backrest and headrest
4a 5a

19
english
6a To adjust the armrest (4), press in the middle (5) and turn it to the
required position. It has three positions.
6 Adjusting the armrest
6a
MAINTENANCE
Do not expose the upholstery to sunlight for prolonged periods of time,
when the safety seat is not in use cover it up or store it in the boot.
Clean the plastic parts with soap and warm water, and then dry all the
parts thoroughly.
The upholstery can be taken off for washing.
Follow the instructions below:
- Headrest. Release the 2 press studs from the sides, unfasten the strap
on the back and pull the upholstery forwards, then release the two press
studs from the top part.
- Backrest. Unfasten the three straps on the back and the press studs on
both sides and then pull the upholstery forwards.
- Booster seat. Unfasten the press studs on the back, release the elastic
and the two press studs on the front part and then pull the upholstery
from the front.
To replace the upholstery, follow same steps in reverse.

MONTECARLO R1
20
Jane USA LLC, warrants this product to the original retail purchaser as
follows:
This product is warranted against defective materials or workmanship for
one year from the date of original purchase. An original sales receipt is
required for all warranty claims. In case of any covered defect, Jane USA
LLC will, at its option, provide replacement parts or replace this product.
Jane USA LLC reserves the right to substitute if the part or model has been
discontinued.
How to Make a Claim under this Limited Warranty:
To make a claim under this warranty, please contact us at info@jane-
usa.com, write to Jane USA LLC, 15720 John J. Delaney Drive, Suite 300,
Charlotte, North Carolina 28277 or call 1.866.890.3071 Monday- Friday from
9 am to 5 pm East time. Proof of purchase is required and shipping charges
are the responsibility of the consumer.
Warranty Limitations:
This warranty does not include damages which arise from misuse or abuse of
this product, failure to follow the instructions on installation, maintenance
and use, any alteration, involvement in an accident, or normal wear and
tear.
LIMITED WARRANTY
Limitation of Damages:
This limited warranty and the remedies described here are exclusive and in
lieu of all others, oral or written, express or implied. In no event shall Jane
USA LLC or the dealer selling this product be liable to you for any damages,
including incidental or consequential damages, arising out of the use or
inability to use this product.
Limitation of Implied Warranties and Other Warranty Terms; State Law
Rights:
Any implied warranties, including implied warranties of merchantability and
fitness for a particular purpose, shall be limited to the duration and terms of
this express written limited warranty. Some states do not allow limitations
as to how long an implied warranty lasts or the exclusion or limitation of
incidental or consequential damages, so the above limitations may not apply
to you. This warranty gives you specific legal rights, and you may also have
other rights, which vary from State to State. Neither Jane USA LLC, nor the
dealer selling this product, has authorized any person to create for it any
other warranty, obligation, or liability in connection with this product.
