John Lewis Bali Caddy User manual

Bali Caddy
Stock number: 816 61907
H92 W24 D33.5cm

2
Thank you for purchasing the Bali Caddy. Please read the instructions and warnings carefully before use, to
ensure safe and satisfactory operation of this product.
At John Lewis, we are committed to making great products possible.
From our in-house Design Team, to our Buyers, we work together to bring great designs to life.
Our expert Product Technologists work collaboratively with our buyers and suppliers to assure the legality,
safety and quality of the product we sell.
We are all committed to designing and developing products to the highest industry standards.
We hope you are happy with your product and welcome any feedback or comments you may have.
The John Lewis Team
Tools required
Time to assemble
1 hour
People to assemble

3

4
Your caddy
Le
LHS Leg
920x50x18mm
1
Internal dimensions
Stock number: 816 61907 Top storage box size: H4 W30 D17.5cm
Middle storage box size: H9 W30 D17.
Bottom storage box size:H14 W30 D17.5 cm
Ref Description Dimensions Qty
RHS Leg 920x50x18mm 1
Handle 204x50x25mm 1
Top Storage Box 335x204x50mm 1
Middle Storage Box 335x204x100mm 1
Bottom Storage Box 335x204x150mm 1

5
Fixtures and fittings
Fixtures and fittings
supplied (actual size)
Ref
Description
Dimension
Qty
Cam stud
M6x40mm
2
Cam
12mm
2
Wooden dowel
Ø8x30mm
2
Wooden dowel
Ø6x20mm
12
Spring washer
M6x2mm
12
Washer
M6x12mm
12
Assembly screw
M6x25mm
12
Fixtures and fittings
supplied (not actual size)
Ref
Description
Dimension
Qty
Allen Key
4mm
1

6
Product assembly
Bali Caddy
816 61907
Step 1
Parts, fittings and tools
Step 2
Parts, fittings and tools
Note: To avoid damaging your
fixings, please do not overturn
cam B.

7
Step 3
Parts
Step 4 – final assembly
Parts, fittings and tools
Note: To avoid damaging your
fixings, please do not overturn
cam B.

Care guide
Care and maintenance
Melamine furniture
The Bali range is made from board with a wood structure melamine surface.
How to care for your melamine furniture
Furniture with a melamine surface should be dusted with a dry cloth.
Spray polishes are best avoided as they contain silicones which may spoil the furniture’s surface by building up
over time.
Make sure all surfaces are protected from heat and liquids by mats and coasters. Wipe up spills immediately and
ensure that a mat or pad is placed under paper if you are writing.
Our furniture will endure most temperatures in the home but it is best to avoid placing furniture next to heat
sources such as radiators or fires. Be particularly careful with solid wood as the lack of humidity caused by
central heating can cause damage such as warping
Safety instructions
Periodically check all fixings to ensure none have come loose and re-tighten where necessary.
Please take care when handling or moving the furniture as careless handling may cause damage or injury.
Furniture can be dangerous if incorrectly installed. Assembly should be carried out by a competent person. No
liability will be accepted for damage or injury caused by incorrectly installed or assembled furniture.
Handle with care!
Retain these instructions for future reference.
John Lewis Partnership
171 Victoria Street
London SW1E 5NN
johnlewis.com
