KI Pirouette Tables User manual

Assembly Instructions
Pirouette™Tables
Fixed Base
April 2014
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Fixed Legs & Worksurface
Support to Top Installation
1. Carefully remove contents from
shipping cartons and identify parts
and hardware supplied.
2. Place table top upside down on a
soft, protective surface. Position
the stiffener channel onto the center
of the tabletop underside, aligning
the stiffener mounting holes with
the pre-drilled holes in the table.
Secure stiffener to top using
#10 x 3/4” screws through all
stiffener mounting holes provided
(Figure 1).
3. Position each fixed table leg over
pre-drilled mounting holes in the
underside of the table as illustrated.
Secure the table legs to the top
using seven #12 x 1” screws
through each base (Figure 2).
4. Locking and non-locking casters
are provided. Locking casters are to
be installed to the front, user-side
of each leg and non-locking casters
should be installed to the rear of
each leg. Use a 19mm open end
wrench to tighten casters to the foot
of each leg (Figure 2).

1330 Bellevue Street • P.O. Box 8100 • Green Bay, WI 54308-8100 • Tel [phone] • www.ki.com
© 2014 Krueger International, Inc. All Rights Reserved • Code KI-62602/KI/PDF/0413
Pirouette™Tables - Fixed Base
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Modesty Panel & Velcro®
Wireway Managers
5. If velcro wire managers are
provided, locate pre-drilled holes
at underside of table and install
with four #10 x 3/4” screws each
(Figure 3).
6. With table upside down, position
the modesty panel onto the table
with the wire manager face-up
and the notches in the modesty
panel facing toward the table
frame as illustrated (Figure 4 &
Detail A).
7. Use the location of the weld
bumps and notches in the
modesty panel to assist in
locating the mounting holes for
the modesty panel clips at the
underside of the table. Position
the clips over the pivot rod of the
modesty panel, to the inside of
the weld bumps and align clamps
with the mounting holes in the
table top. Screw each clamp to
the underside of the table with a
#10 x 3/4” wood screw per clamp
as illustrated. Each Pirouette
modesty panel should be secured
with two clamps. Tables 72” in
length will have three clamps and
screws to assemble per modesty
panel wire manager (Figure 4 &
Detail A).
8. Carefully turn the table to the
upright position. Take care when
rotating table as modesty panel/
wire manager will rotate down
into position as table is turned
over.
9. To install power and data,
reference instruction sheet
included with electrical
components.
